SLIDE 1
Up-coming projects Bjrn Einar Bjordal, 13 March 2018 Bane NOR - - PowerPoint PPT Presentation
Up-coming projects Bjrn Einar Bjordal, 13 March 2018 Bane NOR - - PowerPoint PPT Presentation
Up-coming projects Bjrn Einar Bjordal, 13 March 2018 Bane NOR InterCity Vestfold line Main civil and rail contracts 2018-2025 Vestfold line projects Drammen-Kobervikdalen (UDK), Nykirke-Barkker (UNB) 4 Project information and
SLIDE 2
SLIDE 3
Vestfold line
Main civil and rail contracts 2018-2025
SLIDE 4
Vestfold line projects
Drammen-Kobervikdalen (UDK), Nykirke-Barkåker (UNB)
4
SLIDE 5
Project information and contracts, UDK
- UDK 01: Rock tunnel and bridge over E18
‒ “Design and build”, negotiated procedure
- UDK 02: Cut-and-cover and soil tunnel
‒ Design and build, competitive dialog
- UDK 03: Drammen – Gulskogen stations and railroad systems
‒ Execution contract, negotiated procedure
5 Dark blue: UDK 01 Blue: UDK 02 Red: UDK 03
SLIDE 6
Contract Structure, UDK
SLIDE 7
Project Information, Nykirke-Barkåker (UNB)
7
New Holmestrand Tunnel
- Finished 2016
Exsisting Railway Cut&Cower Tunnel Crossing under E18/Kopstadveien; 950 m Skottås Tunnel,
- 2,2km Rock Tunnel
- 800m Cut&Cower Tunnel
- 2 Access tunnels
New Skoppum station
- Incl bridges across Rv 19
- 3 tracks to Plattform
- Considerable concrete amount
Gråmunk Tunnel
- 1,2 km Rock Tunnel
Barkåker
- New double track Railway
- Finished 2011
E 18
SLIDE 8
Contract structure, UNB
SLIDE 9
Tendering Schedule (tentative), Vestfold line
Qualification
- Sign. Contract
UDK UDK 01 Civil works
- Sept. 2018
- Aug. 2019
UDK 02 Civil works June 2018
- Aug. 2019
UDK 03 Civil and rail May 2019 April 2020 UNB UNB 01Civil works
- Aug. 2018
June 2019 UNB 10 Rail works Aug 2018 June 2019
SLIDE 10
Tendering process
- Prequalification ( Electronic process – Visma Tendsign)
‒ https://tendsign.com/public/register_seller.aspx
‒ Minimum criteria (fulfilment y/n) ‒ Selection criteria (evaluation) ‒ Shortlist 3-5 Tenderers
- Tender (Visma Tendsign)
‒ Invitation to Tender including specification (Norwegian) ‒ Some of the documents may/will be translated to English ‒ Contract will be based on NTK 15 (Norwegian Total Contract) ‒ Some payment/fee for submitting valid Tender ‒ Tender language: Norwegian ‒ All communication (questions/answers etc.) via Visma Tendsign
10
SLIDE 11
11
SLIDE 12
Joint Rail and Road Project Ringerike Line and E16 Highway
Bjørn Einar Bjordal, 13 March 2018
SLIDE 13
FELLESPROSJEKTET RINGERIKSBANEN OG E16
Ringerike Line and E16 Highway
SLIDE 14
FELLESPROSJEKTET RINGERIKSBANEN OG E16
Project summary – railway and highway
Ringerike Line and E16 Highway
- 40 km new double track railway from Sandvika to Hønefoss
prepared for a maximum speed of 250 km/h:
- 15 km four lane highway, prepared for max speed 110 km/h
- Construction of a new railway station at Sundvollen
- Complete rebuild of existing railway station at Hønefoss
- Highway intersections at Elstangen, Styggedalen, Ve and
possibly at Helgelandsmoen
SLIDE 15
FELLESPROSJEKTET RINGERIKSBANEN OG E16
Project summary – tunnels and bridges
Ringerike Line and E16 Highway
- 23 km double track railway tunnel with parallel escape and
service tunnel from Sandvika to Sundvollen
- 3 km double track railway tunnel at Vik
- 770 m double track railway bridge across Kroksund
- 640 m highway bridge across Kroksund
- 2 x 3 km highway tunnels at Vik
- Crossing the river and wetlands at Mælingen:
‒ Alt 1: Two railway bridges: 300 m + 900 m plus three highway bridges (1 x 300 m + 2 x 900 m) ‒ Alt 2: One railway bridge 1800 m plus two highway bridges (2 x 1800 m)
SLIDE 16
FELLESPROSJEKTET RINGERIKSBANEN OG E16
Premiliminary contract structure
Jong - Ringi railway tunnel Rustan - Høgås railway tunnel Kroksund - Kjelleberget, highway and railroad tunnels and day zones Kjelleberget - Storelva, highway and railway day zones Hghway and railway bridges across Storelva and Mælingen RT Tracks, overhead contact line, HW/LW, telecom Signal System design for railway technique (RT) Design substructure rail and road Build substructure rail and road Preparatory / Enabling works Ringerike Line and E16 Highway TK-08 (EPC) TK-01 (EPC) TK-02 (EPC) TK-04 (EPC) TK-05 (EPC) TK-06 (EPC) TK-03 (EPC) Prestemoen - Styggedalen day zones, intersections at Ve and Styggedalen, Hønefoss railway station, tracks and railway technique Styggedalen- Hønefoss Several contracts (construction only) Bane NOR TK-07 (EPC) Sundvollen railway tunnel, Sunvollen railway station, Elstangen highway interection, highway and railway bridges across Kroksund
SLIDE 17
FELLESPROSJEKTET RINGERIKSBANEN OG E16
Preliminary Key Dates
Ringerike Line and E16 Highway
Contracts for preparatory works:
- Prequalification, bidding and evaluation: 2019
- Contract Award: 2020
- Start preparatory works: 2020
Main Contracts for Railway Substructures, Highways and Railway Techniques:
- Prequalification: From 2019
- ITT: From 2020
- Contract Award: From 2020
- Construction start main contracts: 2021 and 2022
- Project completion: 2028
SLIDE 18
FELLESPROSJEKTET RINGERIKSBANEN OG E16
