Units 11 and 12 Risk Reduction Activity MetalMapper Advanced - PowerPoint PPT Presentation

Units 11 and 12 Risk Reduction Activity MetalMapper Advanced Classification Fort Ord, California PRESENTED BY: DAVID EISEN JOHN JACKSON ANDY GASCHO ALISON PASKI DEAN KEISWETTER OCTOBER 22, 2015 The Team U.S. Army Corps of Engineers David


  1. Units 11 and 12 Risk Reduction Activity MetalMapper Advanced Classification Fort Ord, California PRESENTED BY: DAVID EISEN JOHN JACKSON ANDY GASCHO ALISON PASKI DEAN KEISWETTER OCTOBER 22, 2015

  2. The Team • U.S. Army Corps of Engineers • David Eisen • John Jackson KEMRON • • Project Management • UXO Subsurface Removal Team • Gilbane • Andy Gascho • NAEVA Geophysics • Mark Howard Peter Jump • • Ryan Swaffer • Kevin Hagie • Alison Paski • Cora Blits • Ben Dameron • Acorn Science and Innovation Dean Keiswetter • • ESTCP/CB&I/Black Tusk Geophysics 2

  3. ESTCP Demonstration Results 3

  4. ESTCP Demonstration • Primary Objective: • Demonstrate whether large munitions such as 155mm and 8 ‐ inch projectiles at depths to 2 feet can be confidently classified within a challenging high metallic anomaly density background. • Secondary Objectives: • Demonstrate whether large munitions at depths to 4 feet can be confidently classified within a challenging high metallic anomaly density background. • Demonstrate if smaller munitions such as 40mm projectiles can be confidently classified within the range of high background conditions. 4

  5. ESTCP Grid Locations 5

  6. Initial ROC Curve (Primary) TOI1 TOI1 FtOrd BlackTusk PolMatch None MetalMapper Custom s1 v1 FtOrd BlackTusk PolMatch None MetalMapper Custom s1 v1 Analyst's Type Non-TOI Small TOI Medium TOI Large TOI Total 100 90 2030 83 97 54 2264 Non-TOI Percent of TOIs Correctly Classified (%) 80 70 Small TOI 60 Small TOI (diam<50mm) Difficult TOIs: 50 Medium TOI (50mm<=diam<100mm) Medium TOI 155mm legacy Large TOI (100mm<=diam) 40 30 Large TOI 1 24 25 20 10 2031 83 97 78 2289 Total 0 0 500 1000 1500 2000 Number of Non-TOIs Incorrectly Classified 6

  7. Final(ish) ROC Curve (Primary) TOI1 FtOrd BlackTusk PolMatch None MetalMapper Custom s2 v1 Analyst's Type Non-TOI Small TOI Medium TOI Large TOI Total 1802 259 133 55 2249 Non-TOI Percent of TOIs Correctly Classified (%) Small TOI Small TOI (diam<50mm) Medium TOI (50mm<=diam<100mm) Medium TOI Large TOI (100mm<=diam) Large TOI 24 24 1802 259 133 79 2273 Total 7

  8. Initial ROC Curve (Secondary) TOI1or2 TOI1or2 FtOrd BlackTusk PolMatch None MetalMapper Custom s3 v1 FtOrd BlackTusk PolMatch None MetalMapper Custom s3 v1 Analyst's Type Non-TOI Small TOI Medium TOI Large TOI Total 100 90 Non-TOI 1777 286 147 38 2248 Percent of TOIs Correctly Classified (%) 80 Difficult TOIs: 35mm legacy 70 10 93 6 2 111 60mm legacy Small TOI 20mm legacy 60 35mm legacy Small TOI (diam<50mm) 20mm legacy 50 Medium TOI 1 2 168 6 177 Medium TOI (50mm<=diam<100mm) 20mm legacy Large TOI (100mm<=diam) 40mm legacy 40 35mm legacy 40mm legacy 30 1 32 33 Large TOI 40mm legacy + 1 more ... 20 10 Total 1788 381 322 78 2569 0 0 500 1000 1500 2000 Number of Non-TOIs Incorrectly Classified 8

  9. Results and Conclusions • 2,804 unique cued locations • 35 total TOI 1 (100%) • 361 total TOI 2 (350/361 = 97%) • Achieving primary objective (large TOI to 2 ‐ feet) = EASY! • Achieving secondary objective 1 (large TOI to 4 ‐ feet) = DIFFICULT but DOABLE! • Achieving secondary objective 2 (all TOI to depth of detection)= CLOSE, but NOT POSSIBLE! • Moving forward, need to address depth –vs ‐ signal strength –vs ‐ anomaly density issues • Removal action –vs ‐ risk reduction 9

  10. Units 11 and 12 Risk Reduction Objective 10

  11. Units 11 and 12 Risk Reduction Goals • Remove large MEC items from planned burn areas to address the potential risk identified for areas to be burn ‐ ready (with additional site preparation activities) • Evaluate the ability of the advanced technology to classify items of interest in high density environment in real sites as initially indicated by ESTCP demonstration • All Quality Control and Quality Assurance seeds and 100% of the targets of interest (TOI) were correctly classified and recovered 11

  12. Site Background Information • Prescribed burns within the Impact Area at Fort Ord are part of the remedy and support • Vegetation clearance to support MEC removal actions • Periodic burning to maintain natural habitat • Prescribed burns originally planned for Units 11 and 12 in 2011 • Canceled due to the discovery of large MEC items on the ground surface • Subsequent activities conducted in Units 11 and 12 • Vegetation cutting • Surface MEC removal • Digital geophysical mapping • Prescribed burns rescheduled for fall of 2015 12

  13. Risk Reduction Objective • Reduce risk to prescribed burn personnel by removing large, near ‐ surface MEC that might unintentionally detonate during prescribed burn operations • Targets of interest (TOI) • 155mm projectiles • 8 ‐ inch projectiles • Larger MEC • Removal depth requirements • Outer Zone (within 436 feet of fuel breaks) • Removal of TOI to 2 ‐ foot depth • Detonation presents a risk to burn personnel on perimeter fuel break roads • Inner Zone (greater than 436 feet from fuel breaks) • Removal of TOI to 1 ‐ foot depth • Detonation presents a risk to support aircraft flying overhead 13

  14. Assumptions • From the existing DGM data, it is possible to select a subset of anomalies that could represent 155mm and 8 ‐ inch projectiles down to two ‐ foot depths • Advanced geophysical classification utilizing the MetalMapper can evaluate these anomalies and identify those that match the signal characteristics of 155mm and 8 ‐ inch projectiles • Depths of classified items can be predicted with high confidence 14

  15. Risk Reduction Goals • MetalMapper cued anomaly data analysis to model and classify each investigated anomaly • TOI – Highly ‐ likely to be large MEC items (155mm projectiles, 8 ‐ inch projectiles) • Non ‐ TOI – highly ‐ likely to be something other than TOI • TOI – removed prior to the commencement of burn operations • Non ‐ TOI – left in place • Targets where the acquired data does not support a confident classification decision (“cannot analyze”) will be removed. 15

  16. Site Layout and Anomaly Selection Procedures 16

  17. Anomaly Selection • Approximately 550,000 anomalies in existing EM61 detection data • Naval Research Laboratory EM61 response data used to determine minimum response of a 155mm projectile at the required removal depths • Outer Zone • 2 feet below ground surface • Select anomalies with EM61 channel 3 response values of 114mV or greater • Inner Zone • 1 foot below ground surface • Select anomalies with EM61 channel 3 response values of 446mV or greater 17

  18. MetalMapper Investigation Anomalies Resp sponse se Va Value Zo Zone Anomalies lies Th Thre resh shold (m (mV) Unit 11 ‐ Outer 446 2,695 Unit 11 ‐ Inner 114 192 Unit 12 ‐ Outer 446 1,717 Unit 12 ‐ Inner 114 21 TO TOTA TAL 4,625 18

  19. MetalMapper Investigation Anomalies 19

  20. Quality Control 20

  21. Measurement Quality Objectives 21

  22. QC Seeding • Blind QC seed items buried prior to MetalMapper investigation • Large ISO • Average of 1 QC seed item each day – 35 total • Blind Seed Firewall Plan to protect the integrity of QC seed program 22

  23. Data Acquisition Procedures 23

  24. Instrument Setup and Configuration • MetalMapper advanced TEM system • Tow vehicle with platform and sled mount • Positioning with GPS and IMU • Long time range collection settings • Infield inversion settings

  25. Initial Instrument Tests and Initial Library • Performed tests described in the Units 11 and 12 MEC Risk Reduction GCMR ‐ QAPP • Setup and configuration • Sensor assembly • Software settings and configuration • Initial IVS • Background survey was performed • Seeded survey compared result to large ISO in standard library with good result • Test pit • 25ms data needed to establish UX ‐ Analyze library • Performed measurements over large ISO, 155mm and 8 inch projectiles

  26. Field Collection Procedures • Twice daily IVS survey • Initial background readings to validate location. Hourly background readings during survey. • Collect cued reading and refine location based on infield inversion result • Infield inversion performed in separate software from data logging software • Ensures the MetalMapper is positioned above the target • Provides fit location for a single source inversion result

  27. Data Processing and Classification 27

  28. Data Processing Steps • UX ‐ Analyze Advanced Software • ESTCP supported development, has been successfully demonstrated at multiple sites • Special build for 25ms MetalMapper data • Initial instrument tests and site specific library • Initial and Daily IVS • Daily Data Verification • Library Validation • Initial Classification • Final Classification 28

  29. Initial Instrument Tests/Establish Initial Library • Instrument tests evaluated to confirm correct setup, configuration and operation • Test Pit • Were provided data from ESTCP demo test pit • Processed data and evaluated early time gates • Determined for large shallow items the use later time gates • Initial IVS • IVS library established with the initial fit location and polarizabilities • Initial library from IVS and Test Pit • Representative samples of expected TOI at the site • 155mm, 8 inch, Large ISO • Contained 44 entries with measurements of test items at different depths and orientations 29
