SLIDE 1

Understanding the Share of IPv6 Traffic in a Dual-Stack ISP

Enric Pujol, Philipp Richter, and Anja Feldmann PAM 2017, Sydney, Australia

SLIDE 2

IPv6 adoption metrics

User end hosts Server-side measurements

2

e.g., Google reports 20% of the hosts have IPv6

SLIDE 3

IPv6 adoption metrics

User end hosts Networks Server-side measurements Allocations (IANA) Routing (BGP) ...

3

e.g., Google reports 20% of the hosts have IPv6 e.g., 23% of the Autonomous Systems announce IPv6

SLIDE 4

IPv6 adoption metrics

Services / Content Client-side measurements

4

e.g., 13% of the Alexa top 1M Web sites have set IPv6 User end hosts Networks Server-side measurements Allocations (IANA) Routing (BGP) ... e.g., Google reports 20% of the hosts have IPv6 e.g., 23% of the Autonomous Systems announce IPv6

SLIDE 5

IPv6 adoption metrics

Services / Content Client-side measurements

5

13% of the Alexa top 1M Web sites have set IPv6 User end hosts Networks Server-side measurements Allocations (IANA) Routing (BGP) ... e.g., Google reports 20% of the hosts support IPv6 e.g., 23% of the Autonomous Systems announce IPv6 Many different “connectivity” metrics. What about traffic?

SLIDE 6

6

IPv6 traffic statistics

Vantage point % of IPv6 traffic Year 260 networks < 1 % 2013 Dual-stack ISP 11 % 2016 AMS-IX (IXP) 1-3 % 2017

SLIDE 7

7

IPv6 traffic statistics

Vantage point % of IPv6 traffic Year 260 networks < 1 % 2013 Dual-stack ISP 11 % 2016 AMS-IX (IXP) 1-3 % 2017 What is the interplay between connectivity and traffic?

A dual-stack ISP is ideal to study barriers for IPv6 traffic

SLIDE 8

(i) OS (ii) applications

Home network

Dual-stack ISP: when is IPv6 connectivity used?

8

Devices need to support IPv6 e.g., old OSes, some IoT don’t

SLIDE 9

(i) OS (ii) applications

Home network

Dual-stack ISP: when is IPv6 connectivity used?

9

(iii) CPE

IPv6 needs to be enabled at many CPEs

SLIDE 10

(iii) CPE (i) OS (ii) applications

Home network Dual-stack ISP

IPv4 traffic IPv6 traffic (iv) ISP connectivity

Dual-stack ISP: when is IPv6 connectivity used?

10

ISP has to provide IPv6 connectivity to all subscribers

SLIDE 11

(iii) CPE (i) OS (ii) applications

Home network Dual-stack ISP Service providers

IPv4 traffic IPv6 traffic (iv) ISP connectivity (v) service availability

Dual-stack ISP: when is IPv6 connectivity used?

11

Internet

IPv6 upstream and DNS RRs correctly set

SLIDE 12

(iii) CPE (i) OS (ii) applications

Home network Dual-stack ISP Service providers

IPv4 traffic IPv6 traffic (iv) ISP connectivity (v) service availability

Internet

Dual-stack ISP: when is IPv6 connectivity used?

12

First we need to understand this “chain” of connectivity

SLIDE 13

Inferring connectivity

13

User devices DNS requests (A & AAAA)

IPv6-speaking vs. IPv4-only devices

SLIDE 14

CPEs / ISP Local AAAA DNS reqs Global RADIUS (ISP)

Inferring connectivity

14

User devices DNS requests (A & AAAA)

Obtain an IPv6 prefix and make use of it

SLIDE 15

CPEs / ISP

Inferring connectivity

15

Services DNS responses (AAAA) active measurements (connectivity) User devices DNS requests (A & AAAA)

A service is a Fully-Qualified Domain Name (FQDN)

Local AAAA DNS reqs Global RADIUS (ISP)

SLIDE 16

CPEs / ISP Local AAAA DNS reqs Global RADIUS (ISP)

Inferring connectivity

16

Services DNS responses (AAAA) active measurements (connectivity) User devices DNS requests (A & AAAA) That is connectivity, what about traffic?

SLIDE 17

Inferring connectivity

17

Annotate network flows: <DSLID,FQDN, #bytes>

DSLID has IPv6? A request? A RR? AAAA request? AAAA RR?

We can now reason about traffic!

CPEs / ISP Local AAAA DNS reqs Global RADIUS (ISP) Services DNS responses (AAAA) active measurements (connectivity) User devices DNS requests (A & AAAA) That is connectivity, what about traffic?

SLIDE 18

From connectivity to traffic: example

18

Name server A www.google.com 172.217.25.164 AAAA www.google.com 2404:6800:4006:809::2004 172.217.25.164

?

18

Flow: <DSLXY,www.google.com,100KB>

DSLID has IPv6 A request A RR present AAAA request AAAA RR present

IPv6-speaking device uses IPv4 to connect to Google

(1) (2)

SLIDE 19

Trace Total # bytes 64.5TB # flows 356.2M

Dual-stack ISP with 12.9K subscribers, 45 h trace (winter 15/16)

First question: do all subscribers get and use IPv6?

Dataset

19

SLIDE 20

DSL subscribers

20

Question: Do all subscribers get IPv6? IPv4-only (17%) IPv6 connectivity ❌ IPv6 traffic ❌ We see AAAA

1) Operator’s policy: new contracts get IPv6 2) DNS requests are not always indicative

SLIDE 21

DSL subscribers

21

Question: Do all subscribers get IPv6? IPv4-only (17%) IPv6 connectivity ❌ IPv6 traffic ❌ We see AAAA IPv6-inactive (30%) IPv6 connectivity ✔ IPv6 traffic ❌ Almost no AAAA

CPE does not support/provide IPv6 → default conf.?

SLIDE 22

DSL subscribers

22

Question: Do all subscribers get IPv6? IPv4-only (17%) IPv6 connectivity ❌ IPv6 traffic ❌ We see AAAA IPv6-inactive (30%) IPv6 connectivity ✔ IPv6 traffic ❌ Almost no AAAA IPv6-active (53%) IPv6 connectivity ✔ IPv6 traffic ✔ IPv6 share is 21%

Let’s study their interaction with services...

SLIDE 23

Questions

23

What is the interplay between connectivity and traffic? When will we see more IPv6 traffic in these networks? IPv6 barriers: services offered on IPv6 but clients accessed on IPv4 IPv6 intent: services offered on IPv4 but clients requested IPv6

SLIDE 24

27% of the overall traffic relates to IPv6-ready services

IPv6 barriers

24

SLIDE 25

IPv6 barriers

25

yet only ~⅓ of that is carried over IPv6!

SLIDE 26

IPv6 barriers

26

Why does IPv4 dominate?

SLIDE 27

70% due to CPE configuration & ISP policy!

IPv6 barriers

27

SLIDE 28

IPv4-only speaking devices & happy-eyeballs fallbacks

IPv6 barriers

28

IPv6-active

SLIDE 29

Questions

29

What is the interplay between connectivity and traffic? When will we see more IPv6 traffic in these networks? IPv6 barriers: services offered on IPv6 but clients accessed on IPv4 IPv6 intent: services offered on IPv4 but clients requested IPv6

SLIDE 30

IPv6 intent

30

What is the breakdown by DSL-subscriber type?

SLIDE 31

IPv6 intent

31

What if these services would be made available for IPv6?

SLIDE 32

IPv6 intent

32

IPv4-only speaking devices? (*)

SLIDE 33

IPv6 intent

33

Most traffic could be exchanged over IPv6!

SLIDE 34

Questions

34

What is the interplay between connectivity and traffic? When will we see more IPv6 traffic in these networks? Happy eyeballs What-if scenarios IPv6 barriers: services offered on IPv6 but clients accessed on IPv4 IPv6 intent: services offered on IPv4 but clients requested IPv6

SLIDE 35

Happy eyeballs (RFC 6555): fallback to IPv4

www.example.com AAAA? www.example.com A? 192.0.2.1 2001:db8::1 TCP SYN, IPv6 TCP SYN+ACK, IPv4 TCP ACK, IPv4 TCP SYN, IPv4 TCP RST, IPv6

Client Name server 192.0.2.1 2001:db8::1

35

Collect TCP handshakes completion times and DNS lookups per FQDN

SLIDE 36

80% of the times ± 10ms → will use IPv6

Metrics for happy eyeballs (TCP vs DNS resolution)

36

SLIDE 37

Transition to IPv6: What if...

Optimistic: IPv4-only devices, happy eyeballs, etc.

37

SLIDE 38

Summary

Not every subscriber uses IPv6 connectivity at a dual-stack ISP 1) 17 % of the IPv4 traffic to IPv6-ready services is a result of the ISP policy 2) 53 % of the IPv4 traffic to IPv6-ready services is due to CPEs Devices want IPv6 but many services do not operate on IPv6 yet 1) At least 62% of the traffic to IPv4-only services from IPv6-active DSLs We may see substantial and fast changes in dual-stack networks!

38

SLIDE 39

Thank you! Questions?

(iii) CPE (i) OS (ii) applications

Home network Dual-stack ISP Service providers

IPv4 traffic IPv6 traffic (iv) ISP connectivity (v) service availability

Internet

39
