UK COMPLETED PIPELINES FT Completed Pipelines WING PIPELINE ANGLIAN WATER 1000mm water pipe Ejoint 3M Epoxy lined 3LPE coated Bespoke fittings WLO Canusa HSS FT Completed Pipelines ABBERTON ENHANCEMENT ESSEX &

slide-1
SLIDE 1

UK COMPLETED PIPELINES

slide-2
SLIDE 2

FT Completed Pipelines

WING PIPELINE – ANGLIAN WATER

  • 1000mm water pipe
  • Ejoint
  • 3M Epoxy lined
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS
slide-3
SLIDE 3

FT Completed Pipelines

ABBERTON ENHANCEMENT – ESSEX & SUFFOLK WATER

  • 1200mm, 1000mm, 900mm and

600mm water pipes

  • Ejoint
  • 3M Epoxy lining
  • 3LPE coated
  • 100+ bespoke connection pieces

& fittings

  • WLO Canusa HSS
slide-4
SLIDE 4

FT Completed Pipelines

PURTON WTW – BRISTOL WATER

  • 420m of 1400mm Water pipes
  • Ejoint
  • 3M Epoxy lining
  • 3LPE coated
  • 20 bespoke connection pieces &

fittings

  • WLO Canusa HSS
slide-5
SLIDE 5

FT Completed Pipelines

GLOUCESTER SECURITY OF SUPPLY – SEVERN TRENT

  • 26kms of 600mm water pipes
  • Socket weld
  • Seal coated cement lining
  • 3LPE coated
  • Bends, tees and other fittings
  • WLO Canusa HSS
slide-6
SLIDE 6

FT Completed Pipelines

FINSBURY PARK REPLACEMENT MAINS – THAMES WATER

  • 1200mm water pipes
  • Ejoint
  • 3M epoxy lining
  • 3LPE coated
  • WLO Canusa HSS
slide-7
SLIDE 7

FT Completed Pipelines

TAUNTON WTW – WESSEX WATER

  • 100mm & 600mm water

pipes

  • Socket weld and butt weld
  • Seal coated cement lining
  • 3LPE coated
  • Bespoke bends
  • PLA and WLO Canusa HSS
slide-8
SLIDE 8

FT Completed Pipelines

CARSTAIRS PIPEBRIDGE – SCOTTISH WATER

  • 300mm pipes
  • Pipebridge carrying sewage

sludge

  • Epoxy internal lining (capable of

dealing with aggressive nature of sludge)

  • Epoxy coating
  • Dark green exterior (in keeping with

the environment)

slide-9
SLIDE 9

FT Completed Pipelines

GASPORT – ACCELERATE ENERGY

  • 200mm seamless gas pipes
  • Butt weld
  • 3LPE coating
  • GTS-65 Canusa HSS
slide-10
SLIDE 10

FT Completed Pipelines

BARROW HYDROCARBON PIPELINE

  • 700mm & 150mm hydrocarbon pipes
  • WLO Canusa HSS

INTERCONNECTOR – N GRID

  • 1200mm gas pipeline
  • WLO Canusa HSS
slide-11
SLIDE 11

FT Completed Pipelines

  • 800mm water pipe
  • Socket weld
  • Cement lined
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

SEAL SANDS - BOC

slide-12
SLIDE 12

FT Completed Pipelines

  • 450mm DI pipe
  • Spigot and socket
  • WLOX Canusa HSS

ALBERT DOCKS – THAMES WATER

slide-13
SLIDE 13

FT Completed Pipelines

  • 800mm water pipe
  • Socket weld
  • Cement lined
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

BARCOMBE PIPELINE – SOUTH EAST WATER

slide-14
SLIDE 14

FT Completed Pipelines

  • 500mm & 700mm

water pipe

  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

GREAT BARFORD – ANGLIAN WATER

slide-15
SLIDE 15

FT Completed Pipelines

  • 400mm water pipe
  • Socket weld
  • Seal coated cement
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

BLYTH MAIN – NORTHUMBRIAN WATER

slide-16
SLIDE 16

FT Completed Pipelines

  • 500mm brine main
  • Ejoint
  • 3M Epoxy lined
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

BRINE MAIN – E-ON POWER

slide-17
SLIDE 17

FT Completed Pipelines

  • 1400mm water pipe
  • Square ends
  • 3M Epoxy lined
  • Sinta PE coated
  • Bespoke fittings
  • WLO Canusa HSS

BUDDS FARM – 4D / SOUTHERN WATER

slide-18
SLIDE 18

FT Completed Pipelines

  • 600mm water pipe
  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

CANOE PARK – THAMES WATER

slide-19
SLIDE 19

FT Completed Pipelines

  • 600mm, 350mm &

300mm water pipe

  • Ejoint and

spigot & socket

  • 3M Epoxy & Cement lined
  • 3LPE coated
  • Bespoke fittings
  • WLO and PMA

Canusa HSS DARTFORD PARK – THAMES WATER

slide-20
SLIDE 20

FT Completed Pipelines

  • 1200mm water pipe
  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

DUNORE TO HYDEPARK – NIWE

slide-21
SLIDE 21

FT Completed Pipelines

  • 900mm & 1200mm

water pipe

  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

BARROW – ANGLIAN WATER

slide-22
SLIDE 22

FT Completed Pipelines

  • 700mm water pipe
  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

HOLYWELL DENE – NORTHUMBRIAN WATER

slide-23
SLIDE 23

FT Completed Pipelines

  • 1200mm water pipe
  • Flanged and tie bars
  • 3M Epoxy
  • 3M Skotchkote coating
  • Bespoke fittings

OLDHAM WTW – UNITED UTILITIES

slide-24
SLIDE 24

FT Completed Pipelines

RIVER MAIN – E-ON POWER

  • 500mm raw water pipe
  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS
slide-25
SLIDE 25

FT Completed Pipelines

  • 500mm water pipe
  • Socket weld and

Spigot & socket

  • Seal coated cement
  • 3LPE coating
  • Bespoke and DI fittings
  • WLO & PMA Canus

Canusa HSS a HSS BISHOPSTON – SEVERN TRENT WATER

slide-26
SLIDE 26

FT Completed Pipelines

  • 250mm water pipe
  • butt weld
  • Seal coated cement
  • 3LPE
  • Bespoke fittings
  • TBK Canus

Canusa a HSS HSS HAMS HALL – SEVERN TRENT WATER

slide-27
SLIDE 27

FT Completed Pipelines

TRIMPLEY – SEVERN TRENT WATER

  • 500mm water pipe
  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS
slide-28
SLIDE 28

FT Completed Pipelines

  • 1100mm water pipe
  • Socket weld
  • 3M Epoxy
  • 3M Skotchkote coating
  • Bespoke fittings
  • WLO Canusa HSS

BIRMINGHAM HOSPITAL – SEVERN TRENT WATER

slide-29
SLIDE 29

FT Completed Pipelines

  • 800mm water pipe
  • Square ends
  • 3M Epoxy
  • 3M Skotchkote coating
  • Bespoke fittings
  • Cold tapes

SNIPERLEY GRANGE – NORTHUMBRIAN WATER

slide-30
SLIDE 30

FT Completed Pipelines

  • 400mm & 600mm

water pipe

  • Socket weld
  • Cement mortar
  • 3LPE coating
  • TBK Canusa HSS

STOURPORT – SOUTH STAFFORDSHIRE WATER

slide-31
SLIDE 31

FT Completed Pipelines

  • 150mm water pipe
  • Socket weld
  • Seal coated cement
  • 3LPE coating
  • Bespoke fittings
  • WLO Canusa HSS

ST CATHERINE’S – SOUTHERN WATER

slide-32
SLIDE 32

FT Completed Pipelines

  • 450mm water pipe
  • Socket weld
  • Seal coated cement
  • 3LPE coating
  • Bespoke fittings
  • TBK Canusa HSS

SWAYTHLING – 4D / SOUTHERN WATER

slide-33
SLIDE 33

FT Completed Pipelines

  • 400mm & 600mm

water pipe

  • Flanged
  • Cement lined
  • 3LPE coated
  • WLO Canusa HSS

ELRED – THAMES WATER

slide-34
SLIDE 34

FT Completed Pipelines

  • 1200mm water pipe
  • Ejoint
  • 3M Epoxy
  • 3LPE coated
  • Bespoke fittings
  • WLO Canusa HSS

WOODFORD – THAMES WATER

slide-35
SLIDE 35

FT Completed Pipelines

  • 100mm to 300mm

water pipe

  • Spigot & socket
  • Cement lined
  • 3LPE coated
  • WLO Canusa HSS

VARIOUS SCHEMES – THAMES WATER

slide-36
SLIDE 36

FT Completed Pipelines

  • 300mm water pipe
  • DKM
  • Cement lined
  • 3LPE coated
  • Bespoke fittings
  • PMA Canusa HSS

PERRY OAKS – THAMES WATER

slide-37
SLIDE 37

FT Completed Pipelines

BRAY MAIN – SOUTH EAST WATER

  • 17km 1200mm water pipe
  • Socket weld
  • Cement lined
  • 3LPE coated
  • 150+ fittings
  • 1500 Canusa sleeves
slide-38
SLIDE 38

FT Completed Pipelines

  • Multiple km 80mm to 1200mm

water pipe

  • Spigot and Socket, Ejoint and

socket weld

  • Cement lined and epoxy lined
  • 3LPE coated
  • 100+ fittings for welded

systems and 100s for spigot & socket, including valves, couplings, bolt sets

  • 100s of Canusa sleeves

STRATFORD PARK, LONDON

slide-39
SLIDE 39

Project Management

The FT Group has many years experience in project management. This starts with the marketing and promotion of the materials available through to presentations and complex negotiations on requirements and price. Once an order has been secured the FT Project Team work with the supply chain to facilitate the supply to the

  • client. This includes provision of relevant documentation and manufacturing schedules.

The FT Project Team then arranges the logistics, collaborating with the client and the site in order to deliver the required materials in the time frame required. Finally, by attending site, the FT Project Team are on hand to provide training and to advise where and if

  • required. This includes for QA checks on materials arriving on site.
slide-40
SLIDE 40

Contacts

Duncan Frazer – Managing Director +44 7768 132900 Ian Harding – Sales & Technical Director +44 7974 217905 Tel: +44 1543 416024 Fax: +44 1543 416261 Email: enquiries @ftpipelinesystems.co.uk www.ftpipelinesystems.co.uk Certified for : ISO 9001 ISO 14001 OHSAS 18001
