Two & Three Winding Transformers and Circulating Fault Currents

By: Abdur Rehman 2019 Hands on Relay School

PSE.com // GeneralPAC.com

SLIDE 2

Purpose at the 2019 HRS

• Intention is to share our knowledge and passion for Power

Systems Engineering & Protection

• NOT intended to replace any lecture…
• Intention is to supplement other lectures

PSE.com // GeneralPAC.com

SLIDE 3

Assumed Knowledge

• Basic understanding of symmetrical components - Phase &

Ground faults

• Working knowledge of Transformer Phase Shifts
• Fundamental understanding of power systems

PSE.com // GeneralPAC.com

SLIDE 4

Outcomes & Takeaways

• Better understanding of transformers under faulted conditions
• Practical application of sequence network diagrams
• Visual display of circulating sequence currents for 2 & 3

winding transformers

• Introduction to help better understand the handouts

PSE.com // GeneralPAC.com

SLIDE 5

Outcomes & Takeaways

• Sit back… Relax… and Enjoy the show.
• The step-by-step details are in the accompanying PDF for your

review… Presentation = Introduction

• Make sure to send me an email for the accompanying PDF

document, presentation, and videos… abdur.rehman@pse.com

PSE.com // GeneralPAC.com

SLIDE 6

Video Tutorial available on Youtube

• Search for “General PAC” or visit generalpac.com
• Topic “Fault Analysis in Power System”

PSE.com // GeneralPAC.com

SLIDE 7

2 Winding Transformer Example

DABY-G 30 MVA 115 kV 13.8 kV

MVASC = 600 MVA

Line A Line B Line C Line a Line b Line c

Y

AB PSE.com // GeneralPAC.com

SLIDE 8

PSE.com // GeneralPAC.com

SLIDE 9

PSE.com // GeneralPAC.com

SLIDE 10

6 Step Process to calculate fault current

Step 1: Convert the system quantities into per-unit quantities Step 2: Identify the type of fault Step 3: Draw the unfaulted sequence networks Step 4: Interconnect the faulted sequence networks Step 5: Hand Calculate Sequence Currents & Voltages Step 6: Convert to Phase currents & voltages

PSE.com // GeneralPAC.com

SLIDE 11

PSE.com // GeneralPAC.com

SLIDE 12

PSE.com // GeneralPAC.com

SLIDE 13

`

PSE.com // GeneralPAC.com

SLIDE 14

PSE.com // GeneralPAC.com

SLIDE 15

ZG

(1)

1pu ZG

(2)

ZG

(0)

ZT

(0)

ZG

(1)

1pu ZT

(1)

ZG

(0)

ZT

(0)

Open Open

ZT

(1)

ZT

(2)

Positive Sequence Negative Sequence Zero Sequence

115kV 13.8kV

ZG

(2)

ZT

(2) 115kV 13.8kV 115kV 13.8kV

+ + + = = =

Generator Transformer System

j0.05 j0.05 j0.05 j0.10 j0.10 j0.10 j0.05 j0.05 j0.05 j0.10 j0.10 j0.10

Sequence Components

Source

PSE.com // GeneralPAC.com

SLIDE 16

PSE.com // GeneralPAC.com

SLIDE 17

ZG

(1)

1 pu

ZT

(1) 115kV 13.8kV

ZG

(1)

1 PU

ZT

(1) 115kV 13.8kV

ZG

(2)

ZT

(2) 115kV 13.8kV

ZG

(0)

ZT

(0) 115kV 13.8kV

Open

3PH Fault 1LG Fault

PSE.com // GeneralPAC.com

SLIDE 18

PSE.com // GeneralPAC.com

SLIDE 19

PSE.com // GeneralPAC.com

SLIDE 20

Big Picture 1 of 5

3 Phase Fault

PSE.com // GeneralPAC.com

SLIDE 21

PSE.com // GeneralPAC.com

SLIDE 22

PSE.com // GeneralPAC.com

SLIDE 23

PSE.com // GeneralPAC.com

SLIDE 24

PSE.com // GeneralPAC.com

SLIDE 25

PSE.com // GeneralPAC.com

SLIDE 26

PSE.com // GeneralPAC.com

SLIDE 27

PSE.com // GeneralPAC.com

SLIDE 28

Big Picture Comparison

3 Phase Fault

8367|-90 8367|150 8367| 30 1004|-60 1004|180 1004| 60

PSE.com // GeneralPAC.com

SLIDE 29

Big Picture

1LG Fault

PSE.com // GeneralPAC.com

SLIDE 30

PSE.com // GeneralPAC.com

SLIDE 31

PSE.com // GeneralPAC.com

SLIDE 32

PSE.com // GeneralPAC.com

SLIDE 33

Step #4

PSE.com // GeneralPAC.com

SLIDE 34

Step #5

PSE.com // GeneralPAC.com

SLIDE 35

PSE.com // GeneralPAC.com

SLIDE 36

Big Picture Comparison

1LG Fault

PSE.com // GeneralPAC.com

SLIDE 37

Big Picture 1 of 1

LL Fault

PSE.com // GeneralPAC.com

SLIDE 38

PSE.com // GeneralPAC.com

SLIDE 39

PSE.com // GeneralPAC.com

SLIDE 40

PSE.com // GeneralPAC.com

SLIDE 41

PSE.com // GeneralPAC.com

SLIDE 42

PSE.com // GeneralPAC.com

SLIDE 43

PSE.com // GeneralPAC.com

SLIDE 44

Big Picture 1 of 1

2LG Fault

PSE.com // GeneralPAC.com

SLIDE 45

PSE.com // GeneralPAC.com

SLIDE 46

PSE.com // GeneralPAC.com

SLIDE 47

PSE.com // GeneralPAC.com

SLIDE 48

PSE.com // GeneralPAC.com

SLIDE 49

PSE.com // GeneralPAC.com

SLIDE 50

PSE.com // GeneralPAC.com

SLIDE 51

PSE.com // GeneralPAC.com

SLIDE 52

PSE.com // GeneralPAC.com

SLIDE 53

3 Winding Transformer Example

Y-D-YG 30 MVA 115 kV 13.8 kV

MVASC = 600 MVA

PSE.com // GeneralPAC.com

SLIDE 54

Sequence Components

ZG

(1)

1pu ZG

(2)

ZG

(0)

ZG

(0)

ZT

(0)

Open

ZH

(1)

Positive Sequence Negative Sequence Zero Sequence

ZG

(2) 115kV 13.8kV 115kV 13.8kV

+ + + = = =

Generator Transformer System

ZM

(1)

ZL

(1)

ZH

(2)

ZM

(2)

ZL

(2)

ZH

(0)

ZM

(0)

ZL

(0)

T

Open

T T

ZM

(0)

ZL

(0)

T

13.8kV

ZH

(2)

ZM

(2)

ZL

(2)

T

ZG

(1)) 115kV 13.8kV

ZH

(1)

ZM

(1)

ZL

(1)

T

1pu

PSE.com // GeneralPAC.com

SLIDE 55

Big Picture 1 of 1

3 Phase Fault

PSE.com // GeneralPAC.com

SLIDE 56

Big Picture 1 of 1

1LG Fault

PSE.com // GeneralPAC.com

SLIDE 57

Big Picture 1 of 1

LL Fault

PSE.com // GeneralPAC.com

SLIDE 58

Questions? Abdur.rehman@pse.com Generalpac.com
