Turnkey solutions for critical areas The Company Germany Spain Italy Headquarter: Branchoffices: Nexor Medical GmbH Nexor Medical Italia Nexor Medical Espaa Stockacher Str. 134 Via Venezia 15A C / Maria de Guzman 61 78532 Tuttlingen
Headquarter: Branchoffices:
Nexor Medical GmbH Nexor Medical Italia Nexor Medical España Stockacher Str. 134 Via Venezia 15A C / Maria de Guzman 61 78532 Tuttlingen 38510 San Martino di Lupari (PD) 28003 Madrid Germany Italy Spain info@nexormedical.com s.agostinelli@nexormedical.com r.munoz@nexormedical.com
Headquarter: Branchoffices:
Nexor Medical GmbH Nexor Medical Italia Nexor Medical España Stockacher Str. 134 Via Venezia 15A C / Maria de Guzman 61 78532 Tuttlingen 38510 San Martino di Lupari (PD) 28003 Madrid Germany Italy Spain info@nexormedical.com s.agostinelli@nexormedical.com r.munoz@nexormedical.com
Rafael Muñoz Navarro, Managing Partner Nexor Medical GmbH. More than 30 years experience in medical devices industry. Stefano Agostinelli, Partner at Nexor Medical GmbH. Directing Manager Medical Lab System S.R.L. Strong experience in turnkey projects and design of clean-rooms for critical
Ingolf Diez, Partner at Nexor Medical GmbH. Directing Manager Cival Medtech GmbH. More than 30 years experience in medical devices industry
Headquarter: Branchoffices:
Nexor Medical GmbH Nexor Medical Italia Nexor Medical España Stockacher Str. 134 Via Venezia 15A C / Maria de Guzman 61 78532 Tuttlingen 38510 San Martino di Lupari (PD) 28003 Madrid Germany Italy Spain info@nexormedical.com s.agostinelli@nexormedical.com r.munoz@nexormedical.com
360° Projects Design and Engineering of critical areas Projectmanagement Supply of materials and medical devices Installation and Commissioning Customized Solutions Each hospital and each project is different it´s our goal to support the Implementation of an environment that allows the medical staff to perform their tasks efficiently and the patient to be treated safely and feel comfortable. Design and efficiency We combine german engineering excellence with Italian passion for design. State of the art technology at reasonable prices We are convinced that any technological innovation should reduce costs at the same time that it creates value for the hospital and the patient.
16
17
18
Cod.Progetto: 5999004A Off.Data 01/01/2017
Item code Description Unit Quantity Unit Price Total OPERATING ROOM
WALL PANEL
1
MLW .PN.P VC.0 1 WALL PANEL in GALVANIZED STEEL WITH HOT LAYING OF ANTI-BACTERIAL PVC FILM 100-200micron The blind modules are made of micronised and galvanized steel sheet, standard thickness 8/10 mm, with rounded edges, especially shaped to allow for the coupling with the track hooks placed on the corner posts of the supporting structure. The shells are internally plated with fire-retardant plasterboards 12.5 mm thick. The low carbon hot dip galvanized steel finishing 8/10 thick for cold forming with hot application of 100-200µ stiff film in phthalates-free antibacterial polyvinyl chloride (PVC) with self- adhesive protective polyester film. Gloss 30 non-glare smooth surface. Reaction to fire class B s1-do, based on European directive 98/48/EC in compliance with standard EN 13501-1:2009
Sq.m 72,00 € 127,50 € 9.180,00 2
MLW .PN.I VA.0 1 WALL PANEL in 8/10 ANTIBACTERIAL PAINTED AISI 304 STAINLESS STEEL 65/80micron The blind modules are made of steel sheet, with rounded edges, especially shaped to allow for the coupling with the track hooks placed on the corner posts of the supporting structure. The shells are internally plated with fire- retardant plasterboards 12.5 mm thick. The low carbon cold-rolled nickel- chrome steel finishing, 8/10 thick, covered by a layer of “TGIC FREE” powder paint suitable for electrostatic application, thickness 80micron, designed to have an antibacterial film according to international standard JISZ 2801, counter-plated by a plasterboard 12.5 mm thick with self-adhesive protective polyester film. Gloss 30 non-glare smooth surface Reaction to fire class Bs1-do, based on European directive 98/48/EC in compliance with standard EN 13501-1:2009
Sq.m 72,00 € 255,00 € 18.360,00 3
MLW .PN.S M1.0 1 WALL PANEL in SOLID MINERAL SURFACE (Corian type) 3mm counter- plated with 6/10 steel support Panel in SOLID MINERAL SURFACE (pure acrylic stone), thickness 30/10, GLOSS 30 non-glare smooth finishing counter-plated on panel in low carbon hot dip galvanized steel panel for cold forming covered by an 8micron primer on both faces to favour adhesion in face n.1 of SOLID MINERAL SURFACE finishing and in face n.2 of counter-plating of a plasterboard, 9 mm thick. Smooth surface. Reaction to fire class Bs1-do, based on European directive 98/48/EC in compliance with standard EN 13501-1:2009.
Sq.m 72,00 € 322,50 € 23.220,00 4
MLW .PN.G L1.TR S WALL PANEL in LAYERED SAFETY GLASS (3+3+0.38pvb) positioned flush with the wall with insertion of CLEAR PVB FILM inside the glass coupling (available colours MATT WHITE and other possible colours based on availability) The glazed modules are made up of a bearing frame made of extruded aluminium profiles (painted with polyester paints or anodized) where a safety glass 6 mm thick layered with 0.38 polished PVB (POLYVINIL BUTYRAL) (clear or coloured). The frames are hooked on the structural corner posts through the same rack connection of the blind panels and are perfectly level and allow for the insertion of directable slat blinds, decorative films for a better harmonization of settings with chromatic
and horizontally based on the technical specifications.
Sq.m 72,00 € 390,00 € 28.080,00
Standard OR-ROOM
Dimension 6 x 6 m
Copia de 5999004A OFF NR 03_NP(3260) Pag.1/7 NEXOR MEDICAL GmbH Stockacher Strasse, 134 - 78532 Tuttlingen - Germany
Cod.Progetto: 5999004A Off.Data 01/01/2017
Item code Description Unit Quantity Unit Price Total
Standard OR-ROOM
Dimension 6 x 6 m
STRUCTURE AND DOORS
5
MLW .ST.A UT.1 PREFABRICATED FREE-STANDING STRUCTURE for WALL and SUPPORTING WALL: The bearing structure is made up of vertical corner posts placed at modular centre distances, sliding on upper and lower tracks. They are made
(pivots 6 mm diameter inserted in the C profiles at 160 mm distance) for “bayonet” hooking of wall curtain panels or accessories. Corner posts also include screw-adjustable feet and spring clamps to choose adjustments or connector with the upper stiffening profile. This system has been designed to salvage imperfections or slopes of concrete screed up to 20 mm and allow for very fast and precise installation of panels. To reinforce the structure between the corner posts galvanized steel sheet intermediate cross girders 0.8mm thick are placed, designed to allow for cables and technological utilities passing. On the floor pre-painted and structured 15/10 mm thick steel sheet tracks are placed, equipped with ad-hoc pins to install supporting corner posts. The tracks have holes for electrical systems, telephone utilities, data and technological installations. The track has a cove base designed so that it can assure connection between floor and wall
sealed connecting gaskets is positioned between the wall and the false ceiling.
Sq.m 76,00 € 82,50 € 6.270,00 6 MLD.
AUT. HPL TS.14 AUTOMATIC SLIDING DOOR 60mm thick with no. 2 built-in handles including programmer, safety sensors, elbow-operated buttons - h=2200 - HPL or ANTIBACTERICAL GALVANISED STEEL DOOR with aluminium profile L=1400
N 1,00 € 8.355,00 € 8.355,00
Copia de 5999004A OFF NR 03_NP(3260) Pag.2/7 NEXOR MEDICAL GmbH Stockacher Strasse, 134 - 78532 Tuttlingen - Germany
Cod.Progetto: 5999004A Off.Data 01/01/2017
Item code Description Unit Quantity Unit Price Total
Standard OR-ROOM
Dimension 6 x 6 m 8 MLD.
EXT.V IS See-through flush window for automatic sliding door 350x700
N 1,00 € 757,50 € 757,50 9
MLS. D.AN T. S80- 100 HINGED DOORS: The blind doors are complete with door frame on three sides in galvanized polyester-powder painted steel, subject to prior antioxidant treatment, supplied with adequate door striker seal, high- performance hinges and matching lock, made in stainless steel, both equipped with an adjustment system to ensure the right adjustment of the door panel. Blind door panels of thickness 60 mm, level with the door on the hinges side and are made with double shell of steel 0.8 mm thick with a high-density resin-coated mineral wool core for excellent noise abatement. At the bottom of the door panel there is a special differential cross-section seal especially made to secure overpressure resistance when the door is
electrical lock. The door modules are prepared for the insertion of see- through windows with double glazing level with the panel, supplied with lock and PVC lever handle, in stainless steel or with “push to open” system for white rooms. The door modules are available with one or double door, hinged or sliding. Single door 800 - 1050 h=2180 (INCLUDING DOOR FRAME up to 200 thickness)
N 2,00 € 1.458,00 € 2.916,00 10 MLD.
EXT.V IS See-through flush window for hinged door 350x700
N 1,00 € 82,50 € 82,50 11 MLS.
ARM. 04.10 00 Built-in STORAGE CABINET in the modular walls and level with them, made in AISI 304 STAINLESS STEEL internal and external SCOTCH BRITE finishing. Stainless steel shelves and GLASS and PAINTED STAINLESS steel doors, complete with stainless steel handles and sealed gaskets spanning the perimeter Dim 1000/1200 x 450 x 2100 mm (L x P x H)
N 1,00 € 4.687,50 € 4.687,50 € 0,00 € 0,00
Copia de 5999004A OFF NR 03_NP(3260) Pag.3/7 NEXOR MEDICAL GmbH Stockacher Strasse, 134 - 78532 Tuttlingen - Germany
Cod.Progetto: 5999004A Off.Data 01/01/2017
Item code Description Unit Quantity Unit Price Total
Standard OR-ROOM
Dimension 6 x 6 m OPTIONAL FOR OPERATING ROOM
€ 0,00 12 MLS.
EXTR A.CO M.03 OR Control panel (switch unit without touch panel and/or sensors)
N 1,00 € 1.140,00 € 1.140,00 13 MLS.
AIR.G RID.0 1 PAIR of AIR-INTAKE GRIDS in painted stainless steel dim 400x400 (excluding adjustment shutters/dumpers and regulators) including support and cut out
N 4,00 € 615,00 € 2.460,00 14
MLS. UTILI TY.01 MLS UTILITY WALL flush mounted: Medical gas intakes and electrical socket for the tecnical panel with supply and installation of: 1 x MLS UTILITY WALL - wall mounted , extruded aluminum epoxy painted in RAL coloring 4 x Predisposition for fixing of 1 gas outlet (gas outlet and prepiping not included) 4 x Electrical socket schuko 16A white - PEHA 4 x Equipotential ground sockets 1 x Double data sockets RJ45 cat. 6 UTP DIN support Gas outlet DIN standard Pres Block brand O2 NR.2 Gas outlet DIN standard Pres Block brand AIR4 NR.1 Gas outlet DIN standard Pres Block brand VAC NR.1 Pre-piping, installation and testing of Gas outletwith copper pipe for wall mounted BHU
N 2,00 € 1.305,00 € 2.610,00 15
MLW .EX.G M.42 “GLASS-MONITOR” GLAZED MODULE (without keyboard module) for 42- inch monitor: Structural safety glass element (3+3+0.38pvb) positioned flush with the wall with RAL rear lacquering and development of a clear shaped area for monitor housing, including monitor internal structural supports, excluding 42” MONITOR. STANDARD DIMENSIONS L1200xH3000mm
N 1,00 € 2.632,50 € 2.632,50 16 MLW
.EX.G M.M NT.4 2 Full HD PROFESSIONAL 24/7 MONITOR (dim.42") Edge LED Slim Bezel Display, OPS, HTML5 browser - Non medical Monitor
N 1,00 € 2.028,00 € 2.028,00 17
MLS. NEG. 97 X-RAY VIEWER dim.970x430 - X-RAY VIEWERS with LED technology installed flush with the wall, complete with 24V power unit, button or touchscreen power on system and complete with X-ray supporting track and built in the MLW wall corner posts
N 1,00 € 1.560,00 € 1.560,00
Copia de 5999004A OFF NR 03_NP(3260) Pag.4/7 NEXOR MEDICAL GmbH Stockacher Strasse, 134 - 78532 Tuttlingen - Germany
Cod.Progetto: 5999004A Off.Data 01/01/2017
Item code Description Unit Quantity Unit Price Total
Standard OR-ROOM
Dimension 6 x 6 m 18
MLF. PVC. TEL.2 MM. SDS Static dissipative PVC in reel, 2 mm thick Static dissipative, double-grip rolling-press finished homogeneous PVC. The floor, thanks to its special reverse side with static dissipative features allows for the installation of cloths with a standard bonding agent. The grounding connection is made through a copper wire positioned 20cm from the shorter wall. The floor is provided with a total thickness of 2.00 mm with a weight 2950 g/sqm. High resistant to intense traffic, non porous and sealed with pure Polyurethane; This floor does not require any waxing and is easy to maintain forever. The surface thanks to the high quality of raw materials and finishing is renewable through dry polishing. The cloths and floor tiles will be heat-welded with the PVC kerb of the same quality and colour.
Sq.m 35,00 € 73,50 € 2.572,50 19
MLC. CLN. 01 AIR TIGHT FALSE CEILING - False ceiling in white painted steel, module 600x600 mm, with hidden supporting structure and complete with sealed perimeter profile: False ceiling Clip-in System with panels format mm. 600 x 600, in electrogalvanized steel, thickness mm. 0.5, boxed on four sides with sharp edges, properly levelled before stamping, with non-punched smooth
micron of paint thickness. Reflected light calculated with a impact angle of 60 degrees with RAL 9010 colour reference is approximately 22% according to “Gardner” and “DIN 67530 standards. Single-adhesive seal in neoprene, to be attached to one of the internal ribs of the panel to protect underlying locations from dust. Cross supporting structure is made up of primary warping in “U” shaped profiles arranged with centre distance of mm. 1,700, and secondary profiles arranged with centre distance of mm. 600, including all connection accessories. Such system guarantees the perfect levelling of panels and does not allow for any movement of the false ceiling in case of
Adjustable stiff suspension system in “M6” threaded rods fixed to the slabs with centre distance of mm. 1,200, and with proper plugs.
Sq.m 35,00 € 73,50 € 2.572,50 20
MLS. AIR.0 1 Air flow ceiling mounted for diffusion of sterile air with low
system offers a controlled distribution of filtered air thanks to absolute filters positioned above the operating theatre for the washingof the surgical area. Realized in stainless steel AISI 304, complete with absolute filters HEPA 14, efficiency 99,98%. the internal part is made in stainless steel also in the finshing and the protection grids; The filtrating panel is divided into sections in which the diffuser are mounted the filters class H14.
N 1,00 € 18.750,00 € 18.750,00 21
MLS. PEN. SUR. 01 Surgical Pendant Supporting unit with n° 1 rotating, extruded aluminum arm, length 800 mm. - max payload Kg. 80 – with swinging drive vertical movement with mm. 700 stroke. Anchoring set (plate, counter-plate, tie-rods, etc.) Electrical outlets, Equipotential pin - Hole for data outlets (data cable not included) Gas outlets (2xO2 – 2xVac – 2xAir)
N 1,00 € 10.500,00 € 10.500,00
Copia de 5999004A OFF NR 03_NP(3260) Pag.5/7 NEXOR MEDICAL GmbH Stockacher Strasse, 134 - 78532 Tuttlingen - Germany
Cod.Progetto: 5999004A Off.Data 01/01/2017
Item code Description Unit Quantity Unit Price Total
Standard OR-ROOM
Dimension 6 x 6 m 22
MLS. PEN. ANE, 01 Anesthesia Pendant Supporting unit with n° 1 rotating, extruded aluminum arm, approx. length 800 mm. - max payload Kg. 250 .) Electrical outlets Equipotential pin - Hole for data outlets (data cable not included) Gas outlets (3xO2 – 2xVac – 2xAir )
N 1,00 € 12.000,00 € 12.000,00 23
MLS. LIGH T.01 Main light and satellite (without battery back-up) : The characteristic feature of EVO LIGHT 500+ / 500+ is the modular concept. This system permits customers to adopt all future improvements in the luminous power of LEDs simply and independently and thus to integrate them into their personal surgical lights. With this revisable LED technology, we ensures that its customer will be able to enjoy surgical lights at everlower energy consumptions in the future. Cold, infrared-free lightprevents tissue from drying out Lossless dimming Precise light distribution Shock and vibration proof Color temperature continuously adjustable. Color rendering index > 95 Easiest maneuverability for the surgeon via the sterile grip Immediate 100% luminous power Highest light brilliance. Minimal energy requirements Upgradeable to the latest technology at any time No illuminant change needed as before Maximum luminous power on the wound area in the most compact form Easy adjustment of illumination intensity, color temperature and endolight mode on the light arm. Predisposition for HD camera ( not included)
N 1,00 € 14.250,00 € 14.250,00 € 0,00 € 0,00
Copia de 5999004A OFF NR 03_NP(3260) Pag.6/7 NEXOR MEDICAL GmbH Stockacher Strasse, 134 - 78532 Tuttlingen - Germany
Cod.Progetto: 5999004A Off.Data 01/01/2017
Item code Description Unit Quantity Unit Price Total
Standard OR-ROOM
Dimension 6 x 6 m INSTALLATION BUDGET ,STAFF FLIGHTS AND LOCAL ACCOMODATION 24
MLS. DIR.0 1 DESIGN and PROJECT MANAGEMENT: all activities related to the executive design and construction design of all elements subjected to supply and installation, including the coordination of each production and installation phase, in particular the coordination with the electro-mechanical and medical equipment companies active in the construction site
TO BE DEFINED 25
INSTALLATION BUDGET COST: Price for the activities related to installation
(including accessories), doors, medical devices, flooring and false ceiling
EXCLUDED 26
INSTALLATION TOOLS
EXCLUDED 27
SITE SURVAY
EXCLUDED 28
LOCAL ACCOMODATION - All cost related to the local accomodation of installation team
EXCLUDED 29
STAFF FLIGHTS: all cost related to the purchase of installation team flights form ITALY to LISBONA (PORTOGALLO)
EXCLUDED NEXOR MEDICAL GmbH GENERAL CONDITIONS APPLICALBE SPECIFIC SUPPLY TERMS AND CONDITIONS PRICES: VAT , LOCAL TAX and DUTIES Excluded - custom clearance excluded GOODS TRANSPORT: EXCLUDED INSTALLATION: quoted separately WORKING VISA NOT INCLUDED DELIVERY: As per agreed program PAYMENTS: By LC
Copia de 5999004A OFF NR 03_NP(3260) Pag.7/7 NEXOR MEDICAL GmbH Stockacher Strasse, 134 - 78532 Tuttlingen - Germany
