SLIDE 1

Truncated Differential Analysis of Reduced-Round LBlock

Sareh Emami, Cameron McDonald, Josef Pieprzyk and Ron Steinfeld Joint work between Macquarie University, Qualcomm Inc. Australia and Monash University CANS 2013, Paraty, Brazil

SLIDE 2

Outline

Preliminaries
Truncated differential distribution
Truncated differential analysis of LBlock
Complexity Analysis
Experiments
Results

CANS 2013 2/29

SLIDE 3

Our Contribution

Truncated differential analysis
Differential probability distributions
Log-likelihood ratio (LLR) test
Presented framework
Merges the truncated differential distributions with classical differential

analysis

Application to LBlock
Single-key attack - 18 rounds
Related-key attacks – 21 rounds

CANS 2013 3/29

SLIDE 4

LBlock

Was submitted to ACNS 2011
Lightweight block cipher
64-bit block
80-bit secret key
Balanced Feistel network
32-round

CANS 2013

<<< 8

x15 x14 x13 x12 x11 x10 x9 x8 x7 x6 x5 x4 x3 x2 x1 x0

F

<<< 8

F

30 rounds

y15 y14 y13 y12 y11 y10 y9 y8 y7 y6 y5 y4 y3 y2 y1 y0 SK0 SK31

4/29

SLIDE 5

LBlock

SPN round function
Key Schedule
32-bit sub-keys: 𝑇𝐿0, 𝑇𝐿1, … , 𝑇𝐿31

CANS 2013

x15 x14 x13 x12 x11 x10 x9 x8

SKi s7 s6 s5 s4 s3 s2 s1 s0

𝑙79 𝑙78 … … 𝑙49 𝑙48 𝑙47 𝑙46 … … … … … 𝑙1 𝑙0

SKi

<<< 29 𝑙50 𝑙49 𝑙48 𝑙47 𝑙46 𝑙45 𝑙44 𝑙43 𝑙42 … 𝑙21 … 𝑙17 … 𝑙51 𝑻𝟘 𝑻𝟗

i

5/29

SLIDE 6

Likelihood test

Statistical test which compares two distributions
Let 𝑄 and 𝑅 be two discrete probability distributions
Kullback-Leibler (𝐿𝑀) divergence
Measures the distance between 𝑄 and 𝑅
The log-likelihood ratio (𝑀𝑀𝑆)
Empirical dataset 𝑦 taken from 𝑂 samples
Determines the probability distribution (𝑄 or 𝑅 ) that the sample

data 𝑦 belongs to

CANS 2013 6/29

SLIDE 7

Related Work

All-in-one approach to differential analysis of lightweight

block ciphers

Albrecht and Leander (SAC 2012)
Multiple differential cryptanalysis using the 𝑀𝑀𝑆 and 𝜓2

tests

Blondeau et. al. (SCN 2012)
Both analyses work on ciphers with small block sizes

CANS 2013 7/29

SLIDE 8

Outline

Preliminaries
Truncated differential distribution
Truncated differential analysis of LBlock
Complexity Analysis
Experiments
Results

CANS 2013 8/29

SLIDE 9

Truncated Differential Distribution (TDD)

Assumes the cipher follows the Marcov assumption
The probability distribution of round 𝑠 only depends on round

𝑠 − 1

Finds the differential distribution for the state symbols
Nibbles in LBlock
Starts from a fixed differential
Propagates the differences through 𝑠 rounds
Finds the probability of every difference for each nibble

CANS 2013 9/29

SLIDE 10

Truncated Differential

CANS 2013

<<< 8

00000010 00000000 00000010

SKi s0 s1 s2 s3 s4 s5 s6 s7

1

* *

<<< 8

SKi+1 s0 s1 s2 s3 s4 s5 s6 s7 * * *

00001000 0000000* 0000000* 0000000* 00000*00 00001*00 0000000*

10/29

SLIDE 11

Computing TDD

S-box transformation

𝑧𝑗 = 𝑦𝑘 ∙ Ρ(𝑡 𝑘 = 𝑗)

15 𝑘=0

XOR addition

𝑨𝑗 = 𝑦𝑘 ∙ 𝑧𝑗⊕𝑘

15 𝑘=0

CANS 2013

𝑡

Δ𝑗𝑜: 𝑦

1

. . . 15

. . .

Ρ(𝑡 1 = 1)

Δ𝑝𝑣𝑢: 𝑧

1

. . . 15 Δ𝑗𝑜: 𝑦

1

. . . 15 Δ𝑗𝑜: 𝑧

1

. . 14 15 Δ𝑝𝑣𝑢: 𝑨

1

. . . 15

11/29

SLIDE 12

Sample TDD

Input difference: 00000000 10000000
TDD is computed through 8 rounds of LBlock encryption
The right-hand half truncated differential distribution is:

CANS 2013

KL-divergence (distance from the uniform distribution)

12/29

SLIDE 13

Outline

Preliminaries
Truncated differential distribution
Truncated differential analysis of LBlock
Complexity Analysis
Experiments
Results

CANS 2013 13/29

SLIDE 14

LBlock Attack

The TDD is extended on both sides
Benefits from the key schedule properties
The attack model
Standard differential phase (SD)
Truncated differential distribution phase (TDD)
Partial-key recovery phase (PKR)

CANS 2013

𝑇𝐸 𝑈𝐸𝐸 𝑄𝐿𝑆 𝑇0 𝑇1 𝑇2 𝑇3

14/29

SLIDE 15

TDD Phase

8-round truncated

differential distribution

Target nibble
Its distribution has a

relatively high distance from the uniform

CANS 2013

<<< 8

00000000 10000000 00000010

F

<<< 8

F

0000000*

<<< 8

F

00001*00

<<< 8

F

0000***0

<<< 8

F

001**0**

<<< 8

F

Target Nibble

00000000 00000010 0000000* 00001*00 0000***0 0*******

<<< 8

F

********

<<< 8

F

001**0** 0******* ******** ********

15/29

SLIDE 16

PKR Phase

Additional rounds added to the end of TDD rounds
Partially decrypt the ciphertexts
Finds the differential distribution for the target nibble
LLR test
Example 3 rounds

CANS 2013 <<< 8

X*X*****

F

<<< 8

F

SK9: 00000000 SK10: 00000000 ******** Target Nibble ****X***

F

SK11: 00000000 **X*X*** X*******

<<< 8

XX****X* Key bits: 0-79-78-77- 76-75-74-73 Key bits: 13-12-11-10 Key bits: 58-57-56-55 **X*****

16/29

SLIDE 17

SD Phase

High probability differential characteristic
Assume we know some key-bits
Example 1-round differential:

(10000000 00002000) → (00000000 10000000)

CANS 2013

S

<<< 8

P

10000000

P=2-2

SK0: 00000000 00200000 00002000 00000000 10000000

1

79, 78, 77, 76

17/29

SLIDE 18

Merging Phase

Assume
Ρ

𝑇𝐸 = Ρ 𝛽 → 𝛾𝑗

Ρ𝑈𝐸𝐸 = Ρ 𝛾𝑗 → Γ
Ρ

𝑉 is the random probability

Ρ 𝛽 → Γ = Ρ

𝑇𝐸 ⋅ Ρ𝑈𝐸𝐸 + (1 − Ρ 𝑇𝐸) ⋅ Ρ 𝑉

CANS 2013

𝛽 𝛾𝑗 Ρ

𝑇𝐸

𝛾𝑘≠𝑗 1 − Ρ

𝑇𝐸

Ρ𝑈𝐸𝐸 Ρ

𝑉

Γ 𝑇𝐸 𝑈𝐸𝐸

18/29

SLIDE 19

12-Round Example

CANS 2013

S

<<< 8

P

10000000

P=2-2

SK0: 00000000 00200000 00002000 00000000 10000000

1

79, 78, 77, 76

<<< 8

00000000 10000000 00000010

F

<<< 8

F

0000000*

<<< 8

F

00001*00

<<< 8

F

0000***0

<<< 8

F

001**0**

<<< 8

F

Target Nibble

00000000 00000010 0000000* 00001*00 0000***0 0*******

<<< 8

F

********

<<< 8

F

001**0** 0******* ******** ******** Key bits: 0-79-78-77- 76-75-74-73 Key bits: 58-57-56-55 Key bits: 13-12-11-10

<<< 8

X*X*****

F

<<< 8

F

SK9: 00000000 SK10: 00000000 ******** Target Nibble ****X***

F

SK11: 00000000 **X*X*** X*******

<<< 8

XX****X* **X***** 19/29

SLIDE 20

Outline

Preliminaries
Truncated differential distribution
Truncated differential analysis of LBlock
Complexity Analysis
Experiments
Results

CANS 2013 20/29

SLIDE 21

LLR Distributions

𝑋 is a random variable for the LLR of the wrong keys
Wrong key randomization hypothesis
𝑆 is a random variable for the LLR of the right key
Is a binomial distribution

CANS 2013 21/29

SLIDE 22

Complexity Analysis

Cumulative distribution function (CDF)
Probability of 𝑌 falling into the interval [𝑦, ∞):
Denote Θ a threshold for the LLR
Success rate : Ρ 𝑆 ≥ Θ
Probability of a wrong key LLR becomes higher than Θ : Ρ 𝑋 ≥ Θ

CANS 2013

𝜤

22/29

SLIDE 23

Complexity

Number of wrong keys ranked higher than Θ

𝑂𝑥𝑙 = 𝑂𝐿 ⋅ Ρ 𝑋 ≥ Θ

We have to adjust Θ and 𝑂 (number of samples)
Compromise between the success rate and the complexity
Complexity of the full key-recovery

𝐷 = 𝑂2𝑐 + (𝑂𝑥𝑙 + 1)280−𝑐

CANS 2013 23/29

SLIDE 24

Outline

Preliminaries
Truncated differential distribution
Truncated differential analysis of LBlock
Complexity Analysis
Experiments
Results

CANS 2013 24/29

SLIDE 25

Experiments

12-round sample attack
𝑂 = 216 samples
The attack is repeated 100 times

CANS 2013 25/29

SLIDE 26

Experiments

CANS 2013

The attack is repeated 1000 times
𝑀𝑀𝑆 distribution of the right key
The average 𝑀𝑀𝑆 distribution of the wrong keys

26/29

SLIDE 27

Outline

Preliminaries
Truncated differential distribution
Truncated differential analysis of LBlock
Complexity Analysis
Experiments
Results

CANS 2013 27/29

SLIDE 28

Results

18-round single key attack
Data: 223 plaintext/ciphertext pairs
Time: 268.71 encryptions

CANS 2013 28/29

SLIDE 29

Results

Related-key attacks
20 rounds: Data: 227, time: 274.55
21 rounds: Data: 230, time: 277.56

CANS 2013 29/29

SLIDE 30

Thank you for your attention

CANS 2013
