SLIDE 1

TRICKLE ICE

SLIDE 2

TRICKLE ICE

Emil Ivov, Eric Rescorla, Justin Uberti

draft-ietf-mmusic-trickle-ice

Emil Ivov, Enrico Marocco, Christer Holmberg

draft-ietf-mmusic-trickle-ice-sip

90% 90%

Emil Ivov, Adam Roach, Anyone Else?

draft-ivov-disspatch-sdpfrag-03

30%

SLIDE 3

Reminder: Vanilla ICE

STUN Server STUN Server Bob Alice

Vanilla ICE as per RFC 5245

disco disco

ffer and

candidates … connectivity checks … answer and candidates

3/35

SLIDE 4

Reminder: Vanilla ICE vs Trickle ICE

STUN Server STUN Server

Bob Alice

Vanilla ICE as per RFC 5245

disco disco

ffer and

candidates … connectivity checks … answer and candidates

STUN Server STUN Server

Bob Alice

disco disco O/A with host

r no cands

… more cands & conn checks …

Trickle ICE

4/35

SLIDE 5

Vanilla ICE as per RFC 5245

STUN Server STUN Server

Bob Alice

disco disco

ffer and

candidates … connectivity checks … answer and candidates

STUN Server STUN Server

Bob Alice

disco disco O/A with host

r no cands

… more cands & conn checks …

Trickle ICE

SLIDE 6

Emil Ivov, Eric Rescorla, Justin Uberti

draft-ietf-mmusic-trickle-ice

90%

SLIDE 7

there was this one issue:

v=0 … c=IN IP6 :: a=ice-options:trickle a=ice-pwd:asd88fgpdd7 a=ice-ufrag:8hhY m=audio 9 RTP/AVP 0 96 a=rtpmap:0 PCMU/8000 a=rtpmap:96 opus/48000/2 m=audio 9 RTP/AVP 0 97 a=rtpmap:0 PCMU/8000 a=rtpmap:97 opus/48000/2 m=video 9 RTP/AVP 0 98 a=rtpmap:98 VP8/90000 m=video 9 RTP/AVP 0 99 a=rtpmap:99 VP8/90000

concerns that

multiple 9s

may anger

bundle/jsep

SLIDE 8

there was this one issue:

v=0 … c=IN IP6 :: a=ice-options:trickle a=ice-pwd:asd88fgpdd7 a=ice-ufrag:8hhY m=audio 9 RTP/AVP 0 96 a=rtpmap:0 PCMU/8000 a=rtpmap:96 opus/48000/2 m=audio 9 RTP/AVP 0 97 a=rtpmap:0 PCMU/8000 a=rtpmap:97 opus/48000/2 m=video 9 RTP/AVP 0 98 a=rtpmap:98 VP8/90000 m=video 9 RTP/AVP 0 99 a=rtpmap:99 VP8/90000

concerns that

multiple 9s

may anger

bundle/jsep

resolved in

bundle/jsep

SLIDE 9

Emil Ivov, Eric Rescorla, Justin Uberti

draft-ietf-mmusic-trickle-ice

90%

THERE HAVE BEEN NO CHANGES SINCE LAST TIME (IETF89) BUT THE DOCUMENT IS PRETTY MUCH READY FOR WORKING GROUP LAST CALL, SO PLEASE HAVE A READ

SLIDE 10

Emil Ivov, Enrico Marocco, Christer Holmberg

draft-ietf-mmusic-trickle-ice-sip

Emil Ivov, Adam Roach, Anyone Else?

draft-ivov-disspatch-sdpfrag-03

30% 90%

SLIDE 11

individual-01

this is the boring part

Δs since

SLIDE 12 12/35

added protocol overview and rationale

+-------------------------------+ +-------------------------------+ | Alice +--------------+ | | +--------------+ Bob | | | Offer/Answer | | | | Offer/Answer | | | +-------+ | Module | | | | Module | +-------+ | | | ICE | +--------------+ | | +--------------+ | ICE | | | | Agent | | | | | | Agent | | | +-------+ | | | | +-------+ | +-------------------------------+ +-------------------------------+ | | | | | | INVITE (Offer) | | | |--------------------->| | | | 183 (Answer) | | | |<---------------------| | | | | | | | | SIP INFO (more candidates) | |----------------------------------------------------->| | SIP INFO (more candidates) | |<-----------------------------------------------------| | | | STUN Binding Requests/Responses | |----------------------------------------------------->| | STUN Binding Requests/Responses | |<-----------------------------------------------------| | | | | | | | | 5245 SIP re-INVITE | | | |--------------------->| | | | 200 OK | | | |<---------------------| |

SLIDE 13 13/35

asserting offer/answer delivery and state

Alice Bob | | | INVITE (Offer) | |------------------------>| | 183 (Answer) | |<------------------------| | | +----------------------+ | |Alice: I know Bob can| | |trickle and I know his| | |dialog is in the early| | |state. Send INFO! | | +----------------------+ | | | | INFO/OK (SRFLX Cand.) | |------------------------>| | | Alice Bob | | | INVITE | |------------------------>| | 183 (Offer) | |<------------------------| | PRACK (Answer) | |------------------------>| | | | +----------------------+ | |Bob: I know Alice can| | |trickle and I know her| | |dialog is in the early| | |state. Send INFO! | | +----------------------+ | | | INFO/OK (SRFLX Cand.) | |<------------------------| | |

SLIDE 14 14/35

ffer/answer and working around the PRACK

Alice Bob | | | INVITE (Offer) | |------------------------>| | 183 (Answer) | |<------------------------| | | | +----------------------+ | |Bob: I don't know if | | |Alice got my 183 or if| | |her dialog is already | | |in the early state. | | | Can I send INFO??? | | +----------------------+ | | Alice Bob | | | INVITE (Offer) | |------------------------>| | 183 (Answer) | |<------------------------| | INFO/OK (SRFLX Cand.) | |------------------------>| | | | +----------------------+ | |Bob: Now I know Alice| | | is ready. Send INFO! | | +----------------------+ | INFO/OK (SRFLX Cand.) | |<------------------------| | |

SLIDE 15 15/35

5 other ways trickle ICE makes the world a better place

1. Candidates are sent incrementally. In addition to the newly discovered candidates,

every INFO message contains all local candidates an agent has previously sent. This allows misordered/lost INFOs to not be a problem.

SLIDE 16 16/35

5 other ways trickle ICE makes the world a better place

1. Candidates are sent incrementally. In addition to the newly discovered candidates,

every INFO message contains all local candidates an agent has previously sent. This allows misordered/lost INFOs to not be a problem.

2. INFO requests must always carry the a=ice-ufrag and a=ice-pwd attributes (as either

session or media-level attributes) so that the requests can be matched to a specific ICE generation (i.e., or an offer/answer negotiation). a=ice-pwd:asd88fgpdd777uzjYhagZg a=ice-ufrag:8hhY a=mid:1 a=candidate:1 1 UDP 1658497328 192.168.100.33 5000 typ host a=candidate:2 1 UDP 1658497328 96.1.2.3 5000 typ srflx a=mid:2 a=candidate:2 1 UDP 1658497328 96.1.2.3 5002 typ srflx a=end-of-candidates

SLIDE 17 17/35

5 other ways trickle ICE makes the world a better place

1. Candidates are sent incrementally. In addition to the newly discovered candidates,

every INFO message contains all local candidates an agent has previously sent. This allows misordered/lost INFOs to not be a problem.

2. INFO requests must always carry the a=ice-ufrag and a=ice-pwd attributes (as either

session or media-level attributes) so that the requests can be matched to a specific ICE generation (i.e., or an offer/answer negotiation).

3. SIP User Agents may be configured to force use of full trickle where maintainers

expect all endpoints to support it. This would likely be the case for WebRTC environments.

4. Support for trickle ICE may also be dynamically discover with RFC 3840 but *only if*

GRUU is also supported (otherwise there is no way to guarantee that the endpoint responding to caps query will be the same as the one that will get a subsequent INVITE

5. For those with an aversion to the above discovery hacks, trickle ICE for SIP can also

be used in half trickle mode where the offerer starts with a regular ICE offer and, if the answerer can trickle, it just does.

SLIDE 18

new suggestion

this is the fun part!

courtesy of Thomas Stach. thanks!

SLIDE 19 19/35

disco disco 5245 SIP re-INVITE / 200 OK / ACK 200 OK (Answer from 183) / ACK

media

INVITE (Offer) PRACK / INFO (more cands / end-of-candidates) 183 (Answer) 183 (Answer)

…

typical tricle flow

more candidates & conn checks

TURN Server Bob TURN Server Alice

SLIDE 20 20/35

disco disco 5245 SIP re-INVITE / 200 OK / ACK or NOT! 200 OK (Answer) / ACK

media

INVITE (Offer) PRACK / INFO (more cands / end-of-candidates) 183 (trickling) 183 (trickling)

…

typical tricle flow

more candidates & conn checks

TURN Server Bob TURN Server Alice a=ice-pwd:asd88fgpdd777uzjYhagZg a=ice-ufrag:8hhY a=mid:1 a=candidate:1 1 UDP 1658497328 192.168.100.33 5000 typ host a=candidate:2 1 UDP 1658497328 96.1.2.3 5000 typ srflx a=mid:2 a=candidate:2 1 UDP 1658497328 96.1.2.3 5002 typ srflx

SLIDE 21

Content-Type: application/sdpfrag

Emil Ivov, Adam Roach, Anyone Else?

draft-ivov-disspatch-sdpfrag-03

30%

21/35

SLIDE 22

Content-Type: application/sdpfrag

Emil Ivov, Adam Roach, Anyone Else?

draft-ivov-disspatch-sdpfrag-03

30%

means: any syntactically valid line of SDP

any combination of such lines in no particular order

22/35

a=ice-pwd:asd88fgpdd777uzjYhagZg a=ice-ufrag:8hhY a=mid:1 a=candidate:1 1 UDP 165 1.18.10.33 5000 typ host a=candidate:2 1 UDP 168 91.21.2.3 5000 typ srflx a=mid:2 a=candidate:2 1 UDP 164 96.11.2.3 5002 typ srflx a=end-of-candidates

SLIDE 23

Content-Type: application/sdpfrag

Emil Ivov, Adam Roach, Anyone Else?

draft-ivov-disspatch-sdpfrag-03

30%

London: why don’t we give it some structure

23/35

a=ice-pwd:asd88fgpdd777uzjYhagZg a=ice-ufrag:8hhY a=mid:1 a=candidate:1 1 UDP 165 1.18.10.33 5000 typ host a=candidate:2 1 UDP 168 91.21.2.3 5000 typ srflx a=mid:2 a=candidate:2 1 UDP 164 96.11.2.3 5002 typ srflx a=end-of-candidates

SLIDE 24

Content-Type: application/sdpfrag

Emil Ivov, Adam Roach, Anyone Else?

draft-ivov-disspatch-sdpfrag-03

30%

London: why don’t we give it some structure

24/35

a=ice-pwd:asd88fgpdd777uzjYhagZg a=ice-ufrag:8hhY m=audio 54400 RTP/SAVPF 0 96 a=mid:1 a=candidate:1 1 UDP 165 1.18.10.33 5000 typ host a=candidate:2 1 UDP 168 91.21.2.3 5000 typ srflx m=video 55400 RTP/SAVPF 96 97 a=mid:2 a=candidate:2 1 UDP 164 96.11.2.3 5002 typ srflx a=end-of-candidates

but then how would that work with POF/PAN?
