Ice and Stride [ a ] Common User Complaints Common User Complaints - - PowerPoint PPT Presentation

Aug 20, 2023 436 likes •605 views

Ice and Stride [ a ] Common User Complaints Common User Complaints Difficult to Ice Specific Areas Common User Complaints Difficult to Ice Inconvenience of Specific Areas Getting Ice Common User Complaints Difficult to Ice Inconvenience

slide-1
SLIDE 1

Ice and Stride [ a ]

slide-2
SLIDE 2

Common User Complaints

slide-3
SLIDE 3

Difficult to Ice Specific Areas

Common User Complaints

slide-4
SLIDE 4

Difficult to Ice Specific Areas Inconvenience of Getting Ice

Common User Complaints

slide-5
SLIDE 5

Ice Leakage Difficult to Ice Specific Areas Inconvenience of Getting Ice

Common User Complaints

slide-6
SLIDE 6

51%

Did Not Ice

slide-7
SLIDE 7

91%

Want Icing Boot

51%

Did Not Ice

slide-8
SLIDE 8

Customer Need Product Attribute Engineering Specification Ices the injury Temperature Maintain temperature < 0℉ Operate continuously for a cooling cycle Power Total power > 45 W Comfortable Weight Total weight < 5 lbs Keeps user & environment dry Condensation 0 mL Ease of Use Embedded Cooling Yes/No

Product Contract

slide-9
SLIDE 9

Customer Need Product Attribute Engineering Specification Ices the injury Temperature Maintain temperature < 0℉ Operate continuously for a cooling cycle Power Total power > 45 W Comfortable Weight Total weight < 5 lbs Keeps user & environment dry Condensation 0 mL Ease of Use Embedded Cooling Yes/No

Product Contract

slide-10
SLIDE 10

Product Vision

Thermoelectric Cooling (TEC) Cooling side ices the injury No leakage

Peltier/TEC

slide-11
SLIDE 11

Critical Risk

Key Finding: The TEC can get to an adequate cold temperature

Temperature

Layer of ice

slide-12
SLIDE 12

Critical Risk

Key Finding: Requires heat sink and forced convection

Heat Dissipation

slide-13
SLIDE 13

Critical Risk

Power

Key Finding: Current system runs at 14V and 3A

slide-14
SLIDE 14

Market Definition

User Customer Target Selling Price Individuals with acute foot/lower leg injuries Insurance companies, distributed by hospitals $180-300

slide-15
SLIDE 15

Next Steps

  • Reducing size and weight
  • Localized cooling
  • Maintaining the icing temperature with human contact
  • Market Entrance Strategy
  • User Testing
slide-16
SLIDE 16

Sources

  • Ice vs. Heat: https://www.scoi.com/patient-resources/education/articles/should-you-ice-or-heat-

injury

  • Heat dissipation: https://www.amazon.com/Portable-Cooling-Semiconductor-Refrigeration-

Thermoelectric/dp/B073J8HZR4/ref=asc_df_B073J8HZR4/?tag=hyprod- 20&linkCode=df0&hvadid=198068632238&hvpos=1o7&hvnetw=g&hvrand=5653032602279774361 &hvpone=&hvptwo=&hvqmt=&hvdev=c&hvdvcmdl=&hvlocint=&hvlocphy=9002029&hvtargid=pla- 350015891005&psc=1
