Athmospheric Surface Treatments of Niobium A. Camacho*^, A.A. Rossi* and V. Palmieri*^, * INFN Legnaro National Laboratories ^ University of Padua Samples or Cavities? Material Study or Cavity construction? Low research budget Large

slide-1
SLIDE 1

Athmospheric Surface Treatments of Niobium

  • A. Camacho*^, A.A. Rossi* and V. Palmieri*^,

* INFN – Legnaro National Laboratories ^ University of Padua

slide-2
SLIDE 2

Material Study or Cavity construction?

Samples or Cavities?

slide-3
SLIDE 3

Low research budget  Large amount of cavities

6 6 GHz GHz

slide-4
SLIDE 4

Resistive

Samples Real cavities

Inductive Hc1 Measurement Calorimetric methods RS Differential measurements Microstrip Resonators 6 GHz cavities 1,5 /1,3 GHz monocells 1,3 GHz 3-cell cavity 1,3 GHz 9-cell cavities

Pillbox cavities, etc

slide-5
SLIDE 5
  • No electron beam welding, neither for flanges
  • Obtained by spinning from Nb scraps
  • Short fabrication time
  • Fast and low cost BCP and EP treatments
  • Inexpensive Cryogenics
  • Quick RF Measurements

6 GHz CAVITY MINILAB

slide-6
SLIDE 6

6 Ghz Cavity Geometry

20 mm 36 mm

Seamless flanges [mm]

Flange Area = 7 cm2

slide-7
SLIDE 7
slide-8
SLIDE 8

Mini Mechanical Tumbling

SiC ZrO2 Al2O3 + SiO2

slide-9
SLIDE 9

Mini EP

slide-10
SLIDE 10

6 GHz CAVITY MINI-furnace

slide-11
SLIDE 11

6 GHz CAVITY MINI-Camera

slide-12
SLIDE 12

Ready for the RF measurement

slide-13
SLIDE 13

6 GHz CAVITY: MINI-Kapton gasket

slide-14
SLIDE 14

Quick RF Measurements

The insert has been conceived to even enter into a 450 lt Helium dewar INSERT DEWAR RF measuring system

slide-15
SLIDE 15

High Temperature Rapid Metathesis (Nitriding in Mushy State)

slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18

The Homologous Temperature

1

T [K]

q =

Tm [K]

for Nb 2467 °C

slide-19
SLIDE 19

T [K]

q =

Tm [K]

0,98 0,9 1 2467 °C 2196 °C

Mushy State

0,96 2357 °C 2412 °C

Premelting

slide-20
SLIDE 20

6 Ghz @4,2K

1 2 3 4 5 6 10

7

10

8 PureNb NbN2 NbN2a NbN2b NbN3 NbN4 NbN5 NbN6 NbN8 NbN8Ox NbN9 NbN11 NbN12 NbN13 NbN13 3'' BCP NbN14

Q EPk(MV/m)

Bulk Nb

slide-21
SLIDE 21
  • Fast ( takes only few sec)
  • Cheap (Vacuum Technology Free)
  • Simple (No need of special expertise)

High Temperature Rapid Metathesis (Nitriding in Mushy State) The Process is:

slide-22
SLIDE 22

Pr Premelting emelting (also Surf Surface ace melting melting)

Even below its melting point (Tm),

quasi-liquid films can be

  • bserved on crystalline surfaces
slide-23
SLIDE 23

The thickness of the quasi-liquid film is T - dependent This effect is common for all crystalline materials

Pr Premelting emelting (also Surf Surface ace melting melting)

slide-24
SLIDE 24

Nb NbN

3 mm

Nb NbN

slide-25
SLIDE 25

 Nb5N6; N4N3 Over-Stoichiometric

 d-NbN 1-x;

 g-Nb4N3-x Under-Stoichiometric  a-Nb (N) (bcc solid solution)  Niobium

slide-26
SLIDE 26

Nb5N6; N4N3 d-NbN 1-x; h-NbN (hexagonal); d’-NbN (hexagonal); b-Nb2N (hexagonal); g-Nb4N3-x a-Nb (N) (bcc solid solution) Niobium

slide-27
SLIDE 27

Surface layers

slide-28
SLIDE 28

Temp emper eratu ture Ti Time me

Tm of Nb

3 3 – 30 sec 30 sec

slide-29
SLIDE 29

g-Nb N d-Nb N

slide-30
SLIDE 30

As the d-NbN  g-Nb4N3-x phase transformation is a

very fast, quasi-continuous

Transition,

it cannot be avoided by quenching

slide-31
SLIDE 31

The good layer is the most

external one

slide-32
SLIDE 32

1 2 3 4 5 6 10

7

10

8

PureNb NbN13 NbN13 - BCP 3' Q EPk (MV/m)

BCP 3’

BCP 3’ Pure Nb NbN

slide-33
SLIDE 33

1 2 3 4 5 10

6

10

7

10

8

PureNb NbN NbN He Annealing NbN N2 Annealing

Q EPk (MV/m)

slide-34
SLIDE 34

NbN @4,2K

T = 4,2 K

Bulk Nb

slide-35
SLIDE 35

High Temperatures for

Nb Purification

slide-36
SLIDE 36

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 10

6

10

7

10

8

Nb 26 Nb 17 Nb 1 Nb 27 Nb 37 Nb 13 G Nb 111 Q EPk [MV/m]

IL - EP IL - EP Classical – EP Classical – EP Classical – EP Classical – EP

5 min at 2300°C

5 min at 2300°C

slide-37
SLIDE 37

Conclusions 1

  • 6 Ghz cavities allow a fast and

dense statistics

slide-38
SLIDE 38

Conclusions 2

  • No vacuum required!
  • 5min @ 2300°C seem to purify Nb
  • Nitriding performed atAtmospheric pressure
  • At 4,2 K the Q-value at low field increases of

even a factor 5
