TRC1803 Mapping Subsurface Conditions for Transportation Applications Clinton M. Wood 1 , PhD PE 1 Department of Civil Engineering, The University of Arkansas, Fayetteville, USA. 2018 TRC Meeting Hot Springs, AR; 17 May, 2018 1 Arkansas

slide-1
SLIDE 1

TRC1803 Mapping Subsurface Conditions for Transportation Applications

1

Clinton M. Wood1, PhD PE

1Department of Civil Engineering, The University of Arkansas, Fayetteville, USA.

2018 TRC Meeting Hot Springs, AR; 17 May, 2018

slide-2
SLIDE 2

TRC 1803

2

Arkansas Department of Transportation (ARDOT) Unexpected subsurface conditions (soft layers on slopes or bedrock) Expensive change

  • rders and time and cost
  • verruns or slope

stability issues on transportation projects

slide-3
SLIDE 3

TRC 1803

3

Better mapping of subsurface conditions maybe possible using geophysical methods

  • Drilling and Sampling only

provides information at discrete locations.

  • Geophysical methods can

provide a more continuous image

  • f the subsurface.
  • This more complete image can be

used to inform slope stability remediation designs and bedrock cut requirements.

slide-4
SLIDE 4

TRC 1803

4

Project Objectives

  • Identify AHTD project sites which could benefit from geophysical testing.
  • Develop a proposed field investigation plan for each site and perform testing using

various geophysical methods.

  • Analyze collected field data to determine accuracy, advantages, benefits, cost, and

limitations of each geophysical method for specific tasks.

  • Recommend a system for purchase.
  • Conduct field trials on ARDOT sites to develop best practices and sample datasets for the

equipment.

  • Conduct slope stability analyses on sites using geophysical and other data from the

tested slope stability site.

  • Produce project deliverables and provide training.
slide-5
SLIDE 5

TRC 1803

5

Task 1: Identification of project sites, collection of data, and analysis of data.

slide-6
SLIDE 6

TRC 1803

Task 1: Identification of project sites, collection of data, and analysis of data.

6

slide-7
SLIDE 7

TRC 1803

7

Task 1: Identification of project sites, collection of data, and analysis of data.

slide-8
SLIDE 8

TRC 1803

Task 1: Identification of project sites, collection of data, and analysis of data.

8

Slope Stability Site near Sand Gap, AR

slide-9
SLIDE 9

TRC 1803

Task 1: Identification of project sites, collection of data, and analysis of data.

9

Slope Stability Site near Sand Gap, AR (Hwy 7)

slide-10
SLIDE 10

TRC 1803

Task 2: Develop a proposed field investigation plan for each site and perform testing using various geophysical methods.

10

slide-11
SLIDE 11

TRC 1803

11

Methods used for Geophysical Testing

  • 1. Multi‐Channel Analysis of Surface Waves (MASW)

I. With Rayleigh Waves II. With Love Waves

  • 2. Seismic Refraction
  • 3. Capacitively Coupled Resistivity (CCR)
  • 4. Electrical Resistivity Tomography (ERT) (Sand Gap
  • nly)
  • 5. Horizontal to Vertical Spectral Ratio (HVSR)
  • 6. Ground Penetrating Radar (GPR)
slide-12
SLIDE 12

TRC 1803

Task 2: Develop a proposed field investigation plan for each site and perform testing using various geophysical methods.

12

Sand Gap Slope Stability

slide-13
SLIDE 13

TRC 1803

Task 2: Develop a proposed field investigation plan for each site and perform testing using various geophysical methods.

13

Sand Gap Slope Stability

slide-14
SLIDE 14

TRC 1803

Surface Wave Testing (MASW)/Seismic Refraction

14

Receivers (24 total)

Laptop and Geode seismograph

Array Length (46 m) Source Locations Vertical Geophone on Landstreamer Strike Plate Sledgehammer (3‐5 Averages) Strike Beam

slide-15
SLIDE 15

TRC 1803

Resistivity Testing CCR

15

Receivers Transmitter GPS Unit Laptop Dipole Cable Dipole Length (5‐10 m)

Rope Length (2.5‐40 m)

Receivers Dipole Cables Transmitter Controller

Rope Length

Transmitter Dipole Length

slide-16
SLIDE 16

TRC 1803

Resistivity Testing ERT

16

SuperSting Control Box Pin and Electrode Cable

slide-17
SLIDE 17

TRC 1803

Ground Penetrating Radar Testing

17

Antennas Computer

slide-18
SLIDE 18

TRC 1803

Horizontal to Vertical Spectral Ratio Testing

18

Sensor Recorder

slide-19
SLIDE 19

TRC 1803

Preliminary Results for Hardy Site (Love Wave MASW)

19

Section A

BH 155+00 Soil Bedrock

slide-20
SLIDE 20

TRC 1803

Preliminary Results for Hardy Site (Rayleigh Wave MASW)

20

BH 155+00 Soil Bedrock

Section A

slide-21
SLIDE 21

TRC 1803

Preliminary Results for Hardy Site (CCR)

21

100 200 300 400 500 600 700 800 900 120 140 160

Section A

Soil Bedrock BH 155+00

slide-22
SLIDE 22

TRC 1803

Preliminary Results for Hardy Site (GPR)

22

slide-23
SLIDE 23

TRC 1803

Preliminary Results for Hardy Site

23

10 20 30 40 50 60 Error index value (%)

Love HVSR Phase-Love Rayleigh Phase-Rayleigh P-wave refraction CCR

Comparison of methods to Borehole logs along the Alignment

slide-24
SLIDE 24

TRC 1803

24

Final Thoughts

  • Geophysical methods can provide a rapid means of mapping subsurface conditions.
  • Each geophysical methods has strengths and limitations which make them more useful for

certain applications.

  • Based on preliminary results, the geophysical methods can provide an accurate and continuous

estimate of bedrock depth.

  • Future work includes completing data analysis and comparison of results and methods.
  • Providing recommendation regarding the most appropriate method.
  • Completing the Tasks for Year 2 of the project.
slide-25
SLIDE 25

TRC 1803

25

Questions?
