Transportation: San Francisco Capital Planning City and County of - - PowerPoint PPT Presentation

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Transportation: San Francisco

General Obligation Bond Oversight Committee March 16,2020 City and County of San Francisco 10-Year Capital Plan Update 2014 Transportation and Road Improvement GO Bond Update SFMTA 5-Year Capital Improvement Program

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Transportation:

System NeedsUpdate System Management Update System Improvement Update System Financial Update

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Transportation:

System NeedsUpdate

• SFMTA 20-Year Capital Plan Update
• CCSF 10-Year Capital Plan Update

Transportation: San Francisco

SFMTA 20-Year Capital Plan

4

Needs Management Improvement Financial

The San Francisco Municipal Transportation Agency’s (SFMTA) 20-year Capital Plan is a need-based assessment of the SFMTA’s anticipated capital needs for the upcoming 20 years.

• It is a financially unconstrained plan and includes capital

needs for which funding has not yet been committed

• The purpose of the Capital Plan is to identify all of the

potential capital investment needs to achieve the City’s transportation goals

Transportation: San Francisco

SFMTA 20-Year Capital Plan

5

Needs Management Improvement Financial

Transportation: San Francisco

SFMTA 20-Year Capital Plan

6

Needs Management Improvement Financial

SFMTA 20-Year Capital Plan needs for the transportation system grew by $8.9 billion between 2017 and 2019. $21.9 B 2017 $30.7 B 2019

Transportation: San Francisco

SFMTA 20-Year Capital Plan

7

Needs Management Improvement Financial

• Increased investment needs in Streets to achieve

Vision Zero safety goals.

• Increased investment in Fleet and Facility to support

transition to an all-battery-electric fleet.

• Revised cost estimates in the Traffic Signals & Signs to

better account for the total cost of the work.

• Investments in the Streets and Facility Program

needed to better regulate emerging mobility.

• Increased investment needs in Transit Fixed Guideway

to maintain the system in a state of good repair.

• Increased investment needs in Transit Optimization &

Expansion include the next step in the Muni Forward program, building on current efforts to improve travel time and reliability.

Vision Zero Electric Bus Fleet Transition Updating Costs based on Actuals State of Good Repair Next Generation of Muni Forward

Why the increase from 2017 to 2019?

Transportation: San Francisco

SFMTA 20-Year Capital Plan

8

Needs Management Improvement Financial

PROGRAM 2017 Total Capital Needs (constant 2017 dollars, rounded) Percent of 2017 Capital Needs 2019 Total Capital Needs (constant 2019 dollars, rounded) Percent of 2019 Capital Needs Percent Change from 2017 Communications & Information Technology $237 M 1.1 % $218 M 0.7 %

• 8.1 %

Facility $3,490 M 15.9 % $4,599 M 14.9 % 31.8 % Fleet $4,540 M 20.7 % $5,419 M 17.6 % 19.4 % Parking $671 M 3.1 % $681 M 2.2 % 1.4 % Security $545 M 2.5 % $557 M 1.8 % 2.2 % Streets $2,456 M 11.2 % $4,936 M 16.0 % 101.0 % Taxi $65 M 0.3 % $65 M 0.2 % 0.1 % Traffic Signals & Signs $576 M 2.6 % $1,488 M 4.8 % 158.3 % Transit Fixed Guideway $1,310 M 6.0 % $1,755 M 5.7 % 34.0 % Transit Optimization & Expansion $8,046 M 36.7 % $11,068 M 36.0 % 37.6 % Total (all programs) $21,937 M $30,784 M

2019 Capital Plan Update Details:

Transportation: San Francisco

9

Needs Management Improvement Financial

PROGRAM 2017 Total Capital Needs (constant 2017 dollars, rounded) Percent of 2017 Capital Needs 2019 Total Capital Needs (constant 2019 dollars, rounded) Percent of 2019 Capital Needs Percent Change from 2017 Communications & Information Technology $237 M 1.1 % $218 M 0.7 %

• 8.1 %

Facility $3,490 M 15.9 % $4,599 M 14.9 % 31.8 % Fleet $4,540 M 20.7 % $5,419 M 17.6 % 19.4 % Parking $671 M 3.1 % $681 M 2.2 % 1.4 % Security $545 M 2.5 % $557 M 1.8 % 2.2 % Streets $2,456 M 11.2 % $4,936 M 16.0 % 101.0 % Taxi $65 M 0.3 % $65 M 0.2 % 0.1 % Traffic Signals & Signs $576 M 2.6 % $1,488 M 4.8 % 158.3 % Transit Fixed Guideway $1,310 M 6.0 % $1,755 M 5.7 % 34.0 % Transit Optimization & Expansion $8,046 M 36.7 % $11,068 M 36.0 % 37.6 % Total (all programs) $21,937 M $30,784 M

2019 Capital Plan Update Details:

SFMTA 20-Year Capital Plan

Transportation: San Francisco

CCSF-10 Year Capital Plan Update

10

Needs Management Improvement Financial YEARLY SPENDING PLAN ($ Millions)

PLAN TOTAL DEFERRED

FY 20 FY 21 FY 22 FY 23 FY 24 FY 25-29 Original 667.3 751.2 528.6 436.1 626.2 1,999.2 5,008.7 4,549.7 Updated 470.7 523.1 403.7 496.8 491.2 2,197.0 4,582.5 10,383.4 Change (196.6) (228.1) (124.9) 60.7 (135.0) 197.8 (462.6) 5,833.7 SGR 227.8 246.9 211.0 274.6 244.2 1,242.1 Non-SGR 243.0 276.2 192.7 222.3 247.0 1,246.7

With the update of the SFMTA 20-Year Capital Plan and new 5-Year Capital Improvement Program revenue estimates the 10-Year Capital Plan requires

• update. Revenues are revised down and transportation system needs are

revised up, deferrals have increased from $4.6 billion to $10.9 billion.

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Transportation:

System Management Update

• Asset Management Program
• 10-Year Asset Management Strategy
• Transit Asset Management Plan
• State of Good Repair Report

Transportation: San Francisco

SFMTA Asset Management Program

12

Needs Management Improvement Financial

A key objective of the SFMTA’s Asset Management Program to shift the business philosophy, advancing the SFMTA from a reactive to preventative operational environment. Reactive Preventative

Transportation: San Francisco

SFMTA Asset Management Program

13

Needs Management Improvement Financial

Program Objective: Asset Management connects information about the San Francisco Municipal Transportation Agency’s assets to decision making processes in order to maximize the performance, reliability and safety of the transportation system. The result, excellent transportation choices.

Transportation: San Francisco

10-Year Asset Management Strategy

14

Needs Management Improvement Financial

Inventory Categorize Prioritize Assess Deliver Update

Capital Asset Inventory (CAI) Asset Hierarchy 5-Year CIP Condition Assessments Asset Validation Project Delivery EAMS/ Systems

Enable consistent and accurate capital planning and reporting Improve data accuracy and overall integrity Address needs in capital budgets based on the criticality to the transportation system Determine and/or confirm the real condition of assets Ensure systems of record are updated as assets are capitalized and maintained

Transportation: San Francisco

Transit Asset Management Plan –49 CFR 625.25

15

Needs Management Improvement Financial

Element/Requirement

Asset Inventory Asset Condition Assessment Analytical Process + Decision Support Tool Investment Prioritization

(Ranked List of programs and projects)

Asset Management & State of Good Repair Policy Implementation Strategy

(How to implement the TAM Plan)

Key Activities

(Actions over 4 years)

Resources

(Required resources for implementation)

Monitoring & Evaluation Strategy

Transportation: San Francisco

State of Good Repair Report

16

Needs Management Improvement Financial

The SFMTA has been producing an annual State of Good Repair Report since 2015.

• Provides an overview of the transportation

system’s rehabilitation and replacement needs and invest impacts

• Outlines the state of the practice of

transportation asset management

• The 2018 report was completed in June 2019
• The 2019 report is in development, and is

expected to be complete in March 2020

https://www.sfmta.com/asset-management-program

Transportation: San Francisco

State of Good Repair Report –Asset Total Replacement Value (2018)

17

Needs Management Improvement Financial

$3,514 $2,781 $1,938 $1,582 $1,126 $816 $891 $517 $566 $308 $- $500 $1,000 $1,500 $2,000 $2,500 $3,000 $3,500 $4,000

Stations Overhead Traction Power System Facilities Parking & Traffic Track Light Rail Vehicles Train Control & Communications Other Systems & Vehicles Motor Coach Vehicles Trolley Coach Vehicles 2016 Replacement Value 2017 Replacement Value 2018 Replacement Value

The total replacement value of the SFMTA’s assets in 2018 is $14.04 billion, broken up into the following asset classes. In FY 2018, fleet asset data was updated, reflecting the contract and actual cost of the new Muni

• Fleet. Preliminary data from the 2019 analysis reflects changes due to inflation adjustments and fleet

procurement.

Transportation: San Francisco

State of Good Repair Report –Asset Reporting Classification Matrix

18

Needs Management Improvement Financial The SFMTA categorizes asset classes into Transit Service Critical (TSC) and Other SGR. Transit Service Critical is defined as assets and systems that are essential to ensuring the safe and reliable functioning of the transit system, such as maintaining or replacing overhead wires, rail track, or transit vehicles. Other SGR signifies investments that help to make the transportation network more efficient, and enjoyable for riders, along with maintenance of non-transit/street related assets such as pedestrian, bicycle, enforcement and administration.

Asset Class Transit Service Critical 1. Light Rail Vehicles 2. Motor Coach Vehicles 3. Overhead Catenary System 4. Track 5. Train Control & Communications 6. Trolley Coach Vehicles 7. Other Systems/Vehicles (TSC) Other SGR

8.

Facilities 9. Parking & Traffic

• 10. Stations
• 11. Other Systems/Vehicles (Other)

Transportation: San Francisco

State of Good Repair Report –TERM Modeling

19

Needs Management Improvement Financial

Transit Economics Requirement Model (TERM) Lite is a modeling tool developed by the Federal Transit Administration (FTA) used to assess the current physical condition and future investment needs of the nation’s transit assets/operators.

• The TERM model produces a condition score for each asset in the capital

asset inventory based on the age and useful life of the asset.

• State of good repair analysis uses weighted condition scores based on

the total replacement cost for asset condition scores.

• This creates a more accurate representation of the state of good repair
• f transportation system assets as it is more detrimental if a high-value

asset has a low condition score than a low value asset.

• An asset is considered to be in a State of Good Repair if its score is 2.5 or

higher.

Transportation: San Francisco

State of Good Repair Report –TERM Modeling

20

Needs Management Improvement Financial

The average agency TERM Score in 2018 was 3.19. Overall transportation assets remain in a state of good repair.

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

2014 2018

All Assets

3.24 3.19

Excellent Good Adequate Marginal Poor 2014 2018

TSC

3.38 3.32

2014 2018

Other SGR

2.93 3.13

Transportation: San Francisco

State of Good Repair Report –Condition Score Trends

21

Needs Management Improvement Financial

Asset Class 2014 2015 2016 2017 2018 2019 Facilities

3.4 3.2 3.2 3.3 3.3

Light Rail Vehicles

3.1 3.8 3.8 3.7 3.8

Motor Coach Vehicles

3.2 3.7 3.5 3.7 3.6

Other Systems & Vehicles

3.2 3 3.1 3.1 2.6

Overhead Traction Power System

3.7 3.7 3.7 3.6 3.5

Parking & Traffic

2.8 2.8 3 2.9 2.4

Stations

3.2 3.1 3.1 3.1 3

Track

3.3 3.3 3.2 3.2 3.1

Train Control & Communications

2.9 3.7 3.6 3.5 3.4

Trolley Coach Vehicles

2.5 3.4 3.3 3.2 3.6

Total Condition Score 3.24 3.33 3.32 3.3 3.19

2019 Data Pending

The average agency TERM Score in 2018 is 3.19. The replacement of the trolley coach fleet resulted in a significant increase in the TERM score in 2018. Other Systems & Vehicles and Traffic Signal Infrastructure were reduced in 2018 as data was updated in the Capital Asset Inventory. Condition assessments are planned for 2020.

Transportation: San Francisco

State of Good Repair Report –Estimated Backlog

22

Needs Management Improvement Financial

The transportation asset estimated backlog grew to $3.13 billion in 2018. Parking and Traffic assets represent the largest asset class in backlog at $950 million followed by Stations ($473 million), Facilities ($466 million) and Overhead ($420 million). .

$ M $500 M $1000 M $1500 M $2000 M $2500 M $3000 M $3500 M

2016 $2.41 Billion 2017 $2.62 Billion 2018 $3.13 Billion

Transit Service Critical Other SGR

Transportation: San Francisco

State of Good Repair Report –Spending FY 2015 –FY 2018

23

Needs Management Improvement Financial

$28.54 $66.93 $9.61 $1.77 $2.71 $10.08 $61.23 $14.94 $- $20 $40 $60 $80 $100 $120 $140 $160 $180 $200 Communication / IT Infastructure Facility Fleet Parking Security Streets* Traffic / Signals Transit Fixed Guideway Transit Optimization / Expansion Millions FY 2015 FY 2016 FY 2017 FY 2018 $206.56

Transportation: San Francisco

State of Good Repair Report –Planned Future Needs

24

Needs Management Improvement Financial $578 M / Year

Full scheduled asset replacement, eliminate backlog

$500 M / Year

Reduce backlog by 50%

$422 M / Year

No growth in backlog

$281 M / Year

Transit service critical needs met

$250 M / Year

SGR investment commitment

$756 M / Year

Full scheduled asset replacement, eliminate backlog

$678 M / Year

Reduce backlog by 50%

$600 M / Year

No growth in backlog

$401 M / Year

Transit service critical needs met

$250 M / Year

SGR investment commitment

Annual SGR Need ($2018) Annual SGR Need (Escalated @ 3% per year)

Transportation: San Francisco

State of Good Repair Report –Next Steps

25

Needs Management Improvement Financial

• In 2020, a condition assessment of Traffic Signal Assets will be

completed, resulting in a new inventory, condition score and

• perational condition data.
• Additional condition assessments being initiated for Stations,

Guideway, and Sustainable Streets assets.

• Integrate Asset Management data into the development of the FY

2021 – 2025 Capital Improvement Program.

• Target investments in the Capital Improvement Program that will

deliver the most impact to the backlog and asset condition scores.

• Continue trend of investing a minimum of $250 million per year

in the State of Good Repair of the Transportation System.

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Transportation:

System ImprovementUpdate

• 5-Year Capital Improvement Program
• Proposed FY 21 –25 CIP
• 2014 Transportation & Road

Improvement GO Bond

Transportation: San Francisco

SFMTA 5-Year Capital Improvement Program

27

Needs Management Improvement Financial

The SFMTA 5-Year Capital Improvement Program is a fiscally constrained 5-year program of capital improvement and operational projects.

• An implementation plan for

regional, citywide, and agency-wide strategies and policy goals

• Maintains credibility with external

funding agencies (eg. MTC, FTA)

Transportation: San Francisco

SFMTA 5-Year Capital Improvement Program –CIP Programs/Descriptions

28

Needs Management Improvement Financial

Purchase and rehabilitate transit vehicles including motor coaches, trolley coaches, light rail vehicles and paratransit vans

Fleet

Plan, design, engineer and construct traffic signals and associated infrastructure to improve mobility and safety on San Francisco streets and decrease transit travel time

Signals

Plan, design, rehabilitate and construct public parking facilities or street infrastructure related to public parking

Parking

Implement systems to optimize and support the taxi system in San Francisco to provide a better rider experience and promote low-emissions taxi vehicle use

Taxi

Plan, design and implement technology infrastructure upgrades to improve the efficiency and efficacy of the SFMTA and provide a better experience for customers and Employees.

Comm & IT

Plan, design, engineer and construct infrastructure improvements to improve travel time and increase the capacity and reliability of the transit system

Transit Optimization

Plan, design, engineer and construct improvements to critical infrastructure including rail track, overhead wires, and train control technology

Fixed Guideway

Plan, design and construct or implement systems to improve the security of the transit system

Security

Acquire, develop and/or rehabilitate transit station areas and maintenance facilities used for transit, traffic, and parking operations.

Facilities

Plan, design, engineer and construct improvements to street safety that promote walking, bicycling, and taking transit

Streets

29

157 Projects $2.5 Billion Investment (down from $3.4 Billion in FY 2017-21 CIP)

• FY 2021-25 CIP project prioritization in

progress

• Several large projects:
• Central Subway
• LRV Replacement and Expansion

Acceleration

• Train Control System Upgrade
• Better Market Street
• Muni Forward
• Potrero Modernization
• Reserves proposed within each capital

program

Streets (e.g. Bicycle and Pedestrian) Transit Optimization State of Good Repair (e.g. Fleet, Transit FG)

$- $500,000,000 $1,000,000,000 $1,500,000,000 $2,000,000,000 $2,500,000,000 $3,000,000,000 $3,500,000,000

Proposed FY21-25 CIP $2.5B

SFMTA 5-Year Capital Improvement Program –Proposed FY 2021-25 CIP

Needs Management Improvement Financial

30

CIP Revenue Assumptions CIP Potential Revenues

Scheduled to go on the ballot in November 2022. Not included in current revenue assumptions.

2nd $500M GO Bond

Potential re-authorization of the Proposition K sales tax is not included in current revenue assumptions.

Proposition K

Significant capacity available but has impact on

• perating budget: debts service payments = ~$7M

annually per $100M issued at current interest rates.

Revenue Bonds

One cent sales tax potentially scheduled to go on the ballot in November 2020. Expected to generate $100.6 billion over 40 years. Not included in revenue assumptions.

Regional Measure

Conservatively included at 80% of the three-year average of awarded amounts to SFMTA.

Competitive Grants

$140M in Regional Measure 3 (RM3) is included starting in FY2020-21. RM3 Core Capacity is included at $18 million starting in FY2020-21.

Regional Measure 3

The Transportation Network Tax (Proposition D) is assumed at $62 million from FY21-25 based on available data.

Proposition D

The Federal Transit Administration (FTA) Transit Capital Priorities (TCP) is based on the Core Capacity Challenge Grant Program (CCGP) estimate.

FTA Transit Capital Priorities

The Transit and Intercity Rail Capacity Program (TIRCP) cap and trade grant is assumed at $60M in FY2024-25.

$60M TIRCP

SFMTA 5-Year Capital Improvement Program –Revenue Assumptions and Options Needs Management Improvement Financial

31

Program FY21 FY22 FY23 FY24 FY25 Total (Current) Facility $47,213,263 $46,840,914 $71,862,148 $28,605,580 $5,232,380 $199,754,285 Fleet $156,442,559 $156,890,576 $173,717,887 $216,730,682 $266,474,279 $969,555,983 Security $2,048,291 $2,048,291 $2,048,291 $2,048,291 $2,048,291 $10,241,455 Signals $16,174,246 $3,115,000 $7,766,560 $1,515,986 $5,411,923 $33,983,715 Streets $63,560,800 $87,374,542 $51,098,909 $51,905,539 $49,854,904 $292,664,694 Taxi $330,000 $1,192,734 $430,000 $942,734 $230,000 $3,125,468 Transit Fixed Guideway $55,490,381 $65,578,218 $67,568,868 $83,789,306 $76,152,711 $348,579,484 Transit Optimization $217,520,809 $90,940,815 $141,954,073 $71,546,123 $92,089,841 $609,077,090 Central Subway $0 $0 $0 $0 $0 $0 Communications & IT $7,535,000 $3,740,000 $1,265,000 $9,350,000 $4,400,000 $26,290,000 Parking $0 $420,000 $80,000 $0 $0 $500,000 Total SGR $273,193,639 $245,863,489 $290,583,859 $276,238,350 $279,355,331 $1,362,292,381 Total $566,315,349 $458,141,090 $517,791,736 $466,434,241 $501,894,329 $2,510,576,745

Capital Budget

5-Year CIP

SFMTA 5-Year Capital Improvement Program –Proposed FY 2021-25 CIP

Needs Management Improvement Financial

32

• Muni Forward Quick Build Program
• Vision Zero Quick Build Program
• Major Streetscape Projects – Folsom Howard

Phase 1, 6th Street, Taylor Street, Hyde Street

• LRV Replacement & Expansion
• Electric Bus Procurement
• Automatic Train Control System (ATCS)
• Better Market Street
• Muni Forward – M-Oceanview TPP; K-Ingleside

TPP; J-Church TPP; L Taraval, 22 Fillmore: 16th St

• Accessible Pedestrian Signals

SFMTA 5-Year Capital Improvement Program –What are we delivering?

Needs Management Improvement Financial

Transportation: San Francisco

SFMTA 5-Year Capital Improvement Program –Projects with Phase Funded

33

Needs Management Improvement Financial

• Potrero Yard Modernization Project
• Presidio Facility Reconstruction
• Folsom-Howard Bids 2/3
• Muni Forward – N-Judah TPP, Embarcadero

Pocket Track, 14 Mission TPP

• Subway Mechanical Systems SGR Program
• Fire Life Safety SGR Program
• New Flyer Mid-Life Overhauls

Transportation: San Francisco

SFMTA 5-Year Capital Improvement Program –Muni Forward/Results

34

Needs Management Improvement Financial

Between 2016 –2018, ridership increased 14%

• n the Rapid Network.
• 8 Bayshore corridor: +12%
• Mission/Van Ness corridor: +9%
• Geary corridor: +8%
• 19th Ave corridor: +19%

Travel time savings of 10% or more were realized.

• Church Street: 15%
• 5R Fulton Rapid: 9-12%
• Mission: 13%
• 16th Street quick-build phase: 10%
• Potrero: 20%
• Two-Way Haight: Over 20%
• Sansome: Over 20%

Transportation: San Francisco

SFMTA 5-Year Capital Improvement Program –Vision Zero/Results

35

Needs Management Improvement Financial

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Transportation:

System ImprovementUpdate

• 2014 Transportation & Road
• 3rdIssuance Amount: $140 million
• Number of Projects: 7

Improvement GO Bond -3rdIssuance

Transportation: San Francisco

2014 Transportation and Road Improvement General Obligation Bond

37

Needs Management Improvement Financial

As part of Transportation 2030 a $500M G.O. bond for transportation included in 2014-2023 Capital Plan

• The Bond passed in November 2014

with nearly 72% of the vote

• Amount Issued To Date: $248.6M
• Next Planned Issuance: up to $140M
• Planned Issuance Date: Spring 2020

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Lessons Learned:

• Fewer projects
• Larger amounts per project
• Active or nearing construction

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

3

rdIssuance Projects

• 1. L-Taraval Muni Forward – $26,000,000
• 2. 22-Fillmore Muni Forward – $25,000,000
• 3. BART Canopies – $21,120,000
• 4. Taylor Safer Street – $20,192,170
• 5. 19th Avenue – $18,100,000
• 6. Caltrain Electrification – $11,220,000
• 7. Western Addition Signals – $7,693,259
• 8. Program Contingency – $4,974,571

Cost of Issuance /Fees– $5,800,000 (est.) Total – $140,000,000

Sources and Uses

Estimated Sources Par Amount: $136,090,000 Estimated Uses: $136,090,000 Project Fund Deposits: $134,568,600

• Project Fund: $134,300,000
• CSA Audit Fee: $268,600

Cost of Issuance: $700,000

• Additional Proceeds: $4,860

Underwriter’s Discount: $680,450 CGOBOC Fee: $136,090 Reserve for Market Uncertainty: $4,010,000 Maximum Not to Exceed: $140,000,000

Transportation: San Francisco

2014 Transportation and Road Improvement Program

40

Total Bond (in millions) Already Issued Proposed 3rd Issuance Amount Estimated 4th Issuance Amount

Improved Transit

Faster,More Reliable Transit

$191 $73.2 $69.1 $42

Accessibility Improvements

$30 $3 $21.1 $5

Muni Facility Upgrades

$70 $66.7 $0 $0

Major Transit Corridor Improvements

$28 $27 $0 $0

Caltrain Upgrades

$39 $27.8 $11.2 $0

Safer Streets

Pedestrian Safety Improvements

$68 $30.3 $27.9 $7

Traffic Signal Improvements

$22 $6 $0 $12

Complete Streets Improvements

$52 $4.6 $0 $42

Estimated Cost of Issuance and Fees and Contingency

$9.9 $10.7 $3.1 Total $500 $248.6 $140 $111

Program Summary

Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Improved Transit

41

• Improving reliability: Over 60 miles of

reliability improvements, including transit-only lanes, bus bulbs and traffic signal priority

• Creating a Rapid Network: More Rapid bus

lines and expanded frequency serving nearly 70% of all Muni customers

• More Service: Multiple service increases with

better connections since 2015

• Muni Service Equity Strategy: A focus on

improving service in Equity Strategy neighborhoods

• New Fleet: All new bus and rail vehicles;

deployment of larger Muni vehicles Needs Management Improvement Financial

Transportation: San Francisco

42

5 Rapid / 5 Fulton Service

• Route restructuring and optimizing of bus stop

locations, addition of 60-ft buses from 40 ft buses

• Safety improvements, including pedestrian bulbs,

pedestrian countdown signals and improved crosswalk markings

• Traffic modifications with right turn pockets,

replacement of all-way stop-controlled intersections with traffic signals, and installation of a traffic circle Key Highlights:

• 60% increase in ridership from 14,000 in 2009 to

21,000 daily passengers in 2019

• Reduced collision rate by almost 40% on the route
• Faster travel: Time savings of 9-12% on 5 Rapid

Outcomes: Improved Transit

Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Improved Transit

43

9 Rapid / 9 San Bruno Project

• Travel time improvements with transit signal priority

and stop consolidation/optimization

• Safety improvements including installation of transit

islands and transit bulbs Key Highlights:

• 40% increase in ridership since 2009
• Advances SFMTA’s Muni Service Equity Strategy,

especially for residents of Visitation Valley, who rely heavily on this route

• 9 Rapid runs every 8 mins instead of every 12 mins
• 9 Rapid extended to cover all existing local stops in

Visitation Valley Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Improved Transit

44

1 / 1AX / 1BX California

• Transit improvements: traffic signal priority and

stop optimization/consolidation

• Safety improvements include installation of

transit islands and transit bulbs Key Highlights:

• Improves Muni travel time and increases

daytime weekend service for over 30,000 daily riders

• Supports California Laurel Village Improvement

Project to improve safety, provide a more attractive pedestrian environment; and reinforce the neighborhood identity of the Laurel Village Shopping Center Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Improved Transit

45

10 Townsend Bus Line

• Installation of new contra-flow lane for transit,

bicyclists and commercial vehicles

• Upgrade of traffic signals to transit signal

priority

• Safety improvements include daylighting

corners, upgrading crosswalks, and adding curb ramps Key Highlights:

• Average savings of 3 minutes of travel time

with more direct route

• Service expansion from early evening to

midnight Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Safer Streets

46

• Over $300 million in infrastructure upgrades

to support Vision Zero

• Protect people walking with targeted safety

improvements, includes the 13% of streets where 75% of fatal injuries occur

• Build bicycle network upgrades; creating a

safer, more well-defined bicycle network to reduce conflict and improve safety for all users

Vision Zero’s goal is to eliminate all traffic deaths and reduce severe and fatal injuries in San Francisco by 2024. Bike lanes increase the safety of bikers while helping the flow of traffic, causing fewer collisions.

Needs Management Improvement Financial

Transportation: San Francisco

Traffic Fatalities – San Francisco: 2019 & 5-year Averages Outcomes: Safer Streets

Vision Zero High Injury Network 2017.

Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Safer Streets

7th & 8th St South of Folsom Streetscape Project

• Bicycle and pedestrian improvements along 7th and 8th Streets

between Harrison Street and Market Street

• Aligned with the Eastern Neighborhoods Transportation

Implementation Planning Study

• Includes a new concrete buffered bike lane, concrete boarding

islands, sidewalk bulbs, new striping, and safe hit posts Pedestrian Countdown Signals (PCS) Added on High Injury Corridors

• PCS added to 15 High Injury Corridor locations including

California/Jones and California/ Leavenworth

• PCS allow people to determine if they have enough time to

safely cross or if they should wait for the next cycle Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Safer Streets

Potrero Avenue Roadway Improvements

• Installation of audible pedestrian signals at 12 intersections on Potrero Avenue

between 17th Street and 25th Street 8th & Market Street Transit Boarding Island

• Introduced a Class IV bikeway to one of the busiest cycling intersections in the city –

at 8th, Market, Hyde, and Grove Streets – to separate bicyclists from transit

• Includes two-stage turn boxes, green pavement parking, and a safer transit boarding

design

• Connects to an existing buffered bicycle lane on 8th Street

Needs Management Improvement Financial

Transportation: San Francisco

Outcomes: Safer Streets

50

• New or improved signals at more than 28 high-

injury network intersections

• Curb bulbs at 19 high-injury network

intersections

• Construction of Geary Boulevard Pedestrian

Improvements

• Additional pedestrian safety improvements

coordinated with Muni Forward

For Geary Boulevard Pedestrian Improvements, the Steiner pedestrian overcrossing is proposed for removal to make way for an easier crossing at street level. Construction of a traffic signal on Jessie and 6th Streets.

Needs Management Improvement Financial

Transportation: San Francisco

Update –1stIssuance and 2ndIssuance

51

• The 1st Bond Issuance is currently 97%

expended and expected to be fully expended by mid-calendar year 2020.

• The 2nd Bond Issuance is currently 65%

expended and expected to be fully expended by end of calendar year 2021.

Needs Management Improvement Financial

Transportation: San Francisco

Update –1st Issuance

52

Needs Management Improvement Financial

Muni Forward Rapid Network Improvements Muni Facitlity Upgrades Pedestrian Safety Improvements Caltrain Upgrades Major Transit Corridor Improvements Balance $- $2,551,424 $291,565 $- $1,482 Encumbered $8,859 $134,650 $10,842 $28,030 $- Expended $22,980,422 $23,513,927 $3,778,335 $7,311,970 $5,498,518 $- $5,000,000 $10,000,000 $15,000,000 $20,000,000 $25,000,000 $30,000,000 Expended Encumbered Balance

1st Bond Issuance Expenditures

Transportation: San Francisco

Update –1st Issuance

53

1st Bond Issuance Expenditures Needs Management Improvement Financial

$39,768,945 $44,777,036 $56,371,079 $58,165,370 $60,589,492 $62,670,614 $63,624,386 $63,301,922

$- $10,000,000 $20,000,000 $30,000,000 $40,000,000 $50,000,000 $60,000,000 $70,000,000 12/1/2017 3/1/2018 6/1/2018 9/1/2018 12/1/2018 3/1/2019 6/1/2019 9/1/2019

Transportation: San Francisco

Update –2nd Issuance

54

2nd Bond Issuance Expenditures Needs Management Improvement Financial

Muni Forward Rapid Network Improvements Muni Facitlity Upgrades Pedestrian Safety Improvements Caltrain Upgrades Major Transit Corridor Improvements Balance $13,959,809 $5,130,806 $9,660,277 $- $1,375,024 Encumbered $6,012,630 $3,752,469 $4,866,066 $235,227 $6,828,816 Expended $29,616,332 $32,639,068 $10,922,182 $19,784,773 $13,385,098 $- $10,000,000 $20,000,000 $30,000,000 $40,000,000 $50,000,000 $60,000,000 Expended Encumbered Balance

Transportation: San Francisco

Update –2nd Issuance

55

2nd Bond Issuance Expenditures and Projections Needs Management Improvement Financial

$29,246 $13,449,008 $21,097,398 $36,556,066 $53,759,799 $83,550,219 $91,431,532 $107,071,572 $112,804,032 $138,927,584 $147,191,626 $152,640,533 $157,107,657 $159,519,227 $168,653,343

$- $20,000,000 $40,000,000 $60,000,000 $80,000,000 $100,000,000 $120,000,000 $140,000,000 $160,000,000 $180,000,000

9/1/2018 12/1/2018 3/1/2019 6/1/2019 9/1/2019 12/1/2019 3/1/2020 6/1/2020 9/1/2020 12/1/2020 3/1/2021 6/1/2021 9/1/2021 12/1/2021 3/1/2022

Transportation: San Francisco

Update –3rd Issuance

56

3rd Bond Issuance Projections Needs Management Improvement Financial

$4,420,000 $19,725,000 $38,130,000 $61,935,000 $86,841,813 $103,409,643 $114,709,643 $121,709,643 $128,209,643 $134,300,000

$- $20,000,000 $40,000,000 $60,000,000 $80,000,000 $100,000,000 $120,000,000 $140,000,000 $160,000,000 6/1/2020 9/1/2020 12/1/2020 3/1/2021 6/1/2021 9/1/2021 12/1/2021 3/1/2022 6/1/2022 9/1/2022

Transportation: San Francisco

57

Faster, More Reliable Transit $69.1 m $18.1 million – 19th Avenue

• Improve reliability, travel times and

pedestrian safety of the 28 and 28 Rapid. Implementing various enhancements throughout the corridor. $25 million – 22 Fillmore

• Transform the 16th Street corridor by

improving transit reliability, travel time, safety, and accessibility for all users. $26 million – L Taraval

• Replace track, Overhead Catenary System

wires, trolley wire and trolley poles and provide safety and pedestrian enhancements along the corridor.

3rdIssuance Projects

Needs Management Improvement Financial

Passengers exit an L-Taraval Muni train at Taraval Street and 30th Avenue in Parkside..

Transportation: San Francisco Pedestrian Safety Improvements $27.9 m $7.7 million – Western Addition Area-Traffic Signal Upgrades

• Build pedestrian countdown signals (PCS) and/or

signal visibility improvements at 24 intersections.

• Build pedestrian-activated flashing beacons at 9

intersections in the Western Addition area. $20.2 million – Taylor Safer Streets

• Design and construct a new Taylor Street that

meets the city's Vision Zero goals of ending traffic fatalities for all road users.

• Widen sidewalks from Turk to Ellis, reduce travel

lanes from Market to Sutter, and upgrade signals in addition to other pedestrian safety improvements along the corridor.

Conceptual design of Taylor Safer Streets intersection.

58

Needs Management Improvement Financial

3rd Issuance Projects

Example Traffic Signal Visibility Improvement that will be created for Western Addition.

Transportation: San Francisco

59

Accessibility Improvements $21.1 m Caltrain Upgrades $11.2 m $21.1 million - BART Canopies

• Part of larger BART’s Escalator Renovation and

Canopy Program.

• Canopies will include a digital display to show train

arrival times, new security grille, new LED lighting, security cameras, and other improvements.

• Canopies will protect the escalators from the

elements, to help limit breakdowns. $11.2 million - Caltrain Electrification

• Funds the electrification at the northern terminal
• f the Caltrain Corridor starting at San Francisco’s

4th and King Caltrain Station

• Improves safety and service to the public

3rdIssuance Projects

BART canopy at Powell Station on Market Street.

Needs Management Improvement Financial

The current diesel trains will be replaced by electric multiple units (EMUs).

Transportation: San Francisco Transportation and Road Improvement Bond Program Schedules (Transit)

60

FY 19/20 FY 20/21 FY 21/22 FY 22/23

Program/Project Name Third Issuance

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4 Faster, More Reliable Transit (Muni Forward) *19th Avenue $ 18,100,000 *22-Fillmore Muni Forward $ 25,000,000 *L-Taraval Muni Forward $ 26,000,000 *Caltrain Electrification – San Francisco contribution $ 11,220,000 Accessibility Improvements *BART Canopies $ 21,120,000 Muni Facilities *Taylor Safer-Street $ 20,192,170 *Western Addition Signals $ 7,693,259

Planning Design, Bid & Award Construction

Needs Management Improvement Financial

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Transportation:

System FinancialUpdate

• Addressing the Need
• Future Revenue Measures

Transportation: San Francisco

Summary Needs

62

Needs Management Improvement Financial

SFMTA 20-Year Capital Plan: $30.7 billion needs CCSF 10-Year Capital Plan: $10.9 billion deferred needs 2018 SGR Backlog: $ 3.3 billion backlog State of Good Repair: $756 million/annual eliminate backlog $600 million/annual reduce backlog 50%

63

2014 Proposition A

General Obligation Bond Passed – 71.9% yes $500 million/one-time

2014 Proposition B

General Fund Population Baseline Passed – 61.4% yes $23 million/annually (est. at time)

Vehicle License Fee

Increase by 2% - Not Pursued Estimate: $73 million/annually

2016 Proposition J/K

3/4 cent Sales Tax Prop J Dedication: Passed – 67.2% yes Prop K Tax: Failed - 65.3% no $101.6 million/annually

2018 Proposition D

Ride Hailing Tax Passed – 67.7% yes $15 million Transit/annually $15 million Vision Zero/annually

Congestion Pricing

$80 million/annually (Estimated)

Proposition K Sales Tax Reauthorization

$100 million/annually (Post 2034) Voter approval of a new 30-year expenditure plan for the existing Proposition K ½ Transportation Sales Tax

+ ¼ Cent Sales Tax

$51 million/annually (Estimated)

General Obligation Bond

$500 million/one time (June 2022)

Community Benefit District

Varies Depending on District

Federal and State Grants

FTA Capital Investment Grant Program: $200 million/one-time State Transit and Intercity Rail Capital Program: $120 million/one-time

Other opportunities:

63

Transportation Task Forces –Revenue Measures/Past and Proposed Future

Needs Management Improvement Financial

Capital Planning

March 3,2020

San Francisco Municipal Transportation Agency

Committee Update

Thank you.
