Principles of Computer Graphics and Image Processing

Transformations, Projections (02)

• RNDr. Martin Madaras, PhD.

martin.madaras@stuba.sk

Overview

2

 2D Transformations

 Basic 2D transformations  Matrix representation  Matrix composition

 3D Transformations

 Basic 3D transformations  Same as 2D

3

• Ask questions, please!!!
• Be communicative
• www.slido.com #PPGSO02
• More active you are, the better for you!
• We will go into depth as far, as there are no questions

How the lectures should look like #1

Geometry space

4

 Scene

 Virtual representation of world

 Objects

 Visible objects

(“real world”)

 Invisible objects

(e.g. lights, cameras, etc.)

Full scene definition

5

 Objects

 What objects, where, how transformed

 To be discussed early during course

 How they look – color, material, texture...

 To be discussed later during course

 Camera

 Position, target, camera parameters

Coordinate system

6

 Cartesian coordinates in 2D

 Origin  x axis  y axis (5,3)

Coordinate systems

7

 Global

 One for whole scene

 Local

 Individual for every model  Pivot point

 Camera coordinates  Window coordinates  Units may differ  Conversion between coordinate spaces

Global/local/camera coords.

8

9

Essential basic algebra

Point

10

 Position in space  Cartesian coordinates  Homogeneous coordinates

 Subtraction of points  Translation

 Notation: P, A, …

) , ( y x ) , , ( z y x ) 1 , , , ( z y x ) 1 , , ( y x

Vector

11

 Direction in space  Has no position  Subtraction of 2 points  Cartesian coordinates  Homogeneous coordinates  Notation:

) , ( y x ) , , ( z y x ) , , , ( z y x

) , , ( y x

n v u    , ,

Vector

12

 Addition

Point + vector = point Vector + vector = vector

 Subtraction

Point – point = vector Point – vector = point + (-vector) = point Vector – vector = vector + (-vector) = vector

 Multiplication

Multiplier * vector = vector

13

• Ask questions, please!!!
• Be communicative
• www.slido.com #PPGSO02
• More active you are, the better for you!

Ask questions

14

Transformations

2D Modeling Transformations

15

 Modeling space and World space

2D Modeling Transformations

16

 Transformed instances

2D Modeling Transformations

17

 Transformation identity

2D Modeling Transformations

18

 Scaling applied…

2D Modeling Transformations

19

 Scaling and rotation applied…

2D Modeling Transformations

20

 Scaling, rotation and translation applied…

2D Modeling Transformations

21

 Translation:

 x’ = x + 𝑢𝑦  y’ = y + 𝑢𝑧

 Scale:

 x’ = x * 𝑡𝑦  y’ = y * 𝑡𝑧

 Rotation:

 x’ = x*cosΘ - y*sinΘ  y’ = x*sinΘ + y*cosΘ

2D Modeling Transformations

22

 Translation:

 x’ = x + 𝑢𝑦  y’ = y + 𝑢𝑧

 Scale:

 x’ = x * 𝑡𝑦  y’ = y * 𝑡𝑧

 Rotation:

 x’ = x*cosΘ - y*sinΘ  y’ = x*sinΘ + y*cosΘ

2D Modeling Transformations

23

 Translation:

 x’ = x + 𝑢𝑦  y’ = y + 𝑢𝑧

 Scale:

 x’ = x * 𝑡𝑦  y’ = y * 𝑡𝑧

 Rotation:

 x’ = x*cosΘ - y*sinΘ  y’ = x*sinΘ + y*cosΘ

2D Modeling Transformations

24

 Translation:

 x’ = x + 𝑢𝑦  y’ = y + 𝑢𝑧

 Scale:

 x’ = x * 𝑡𝑦  y’ = y * 𝑡𝑧

 Rotation:

 x’ = x*cosΘ - y*sinΘ  y’ = x*sinΘ + y*cosΘ

2D Modeling Transformations

25

 Translation:

 x’ = x + 𝑢𝑦  y’ = y + 𝑢𝑧

 Scale:

 x’ = x * 𝑡𝑦  y’ = y * 𝑡𝑧

 Rotation:

 x’ = x*cosΘ - y*sinΘ  y’ = x*sinΘ + y*cosΘ

2D Modeling Transformations

26

 Translation:

 x’ = x + 𝑢𝑦  y’ = y + 𝑢𝑧

 Scale:

 x’ = x * 𝑡𝑦  y’ = y * 𝑡𝑧

 Rotation:

 x’ = x*cosΘ - y*sinΘ  y’ = x*sinΘ + y*cosΘ

Overview

27

 2D Transformations

 Basic 2D transformations  Matrix representation  Matrix composition

 3D Transformations

 Basic 3D transformations  Same as 2D

Matrix Representation

28

 Represent 2D transformation by a matrix

𝑏 𝑐 𝑑 𝑒

 Multiply matrix by column vector ⇔ transformation of a point

𝑦′ 𝑧′ = 𝑏 𝑐 𝑑 𝑒 𝑦 𝑧 𝑦′ = 𝑏𝑦 + 𝑐𝑧 𝑧′ = 𝑑𝑦 + 𝑒𝑧

Matrix Representation

29

 Transformations combined by multiplication

𝑦′ 𝑧′ = 𝑏 𝑐 𝑑 𝑒 𝑓 𝑔 𝑕 ℎ 𝑗 𝑘 𝑙 𝑚 𝑦 𝑧 Matrices are a convenient and efficient way to represent a sequence of transformations!

2x2 Matrices

30

 What transformations can be represented by a 2x2

matrix?

 2D Identity?

𝑦′ = 𝑦 𝑧 = 𝑧 𝑦′ 𝑧′ = 1 1 𝑦 𝑧

 2D Scale around origin (0,0)?

𝑦′ = 𝑡𝑦 ∗ 𝑦 𝑧 = 𝑡𝑧 ∗ 𝑧 𝑦′ 𝑧′ = 𝑡𝑦 𝑡𝑧 𝑦 𝑧

2x2 Matrices

31

 What transformations can be represented by a 2x2 matrix?

 2D Rotate around origin (0,0)?

𝑦′ = x ∗ cos 𝜄 − y ∗ sin 𝜄 𝑧′ = x ∗ 𝑡𝑗𝑜 𝜄 + y ∗ 𝑑𝑝𝑡 𝜄 𝑦′ 𝑧′ = cos 𝜄 − sin 𝜄 𝑡𝑗𝑜 𝜄 𝑑𝑝𝑡 𝜄 𝑦 𝑧

 2D Shear?

𝑦′ = 𝑦 + 𝑡ℎ𝑦 ∗ 𝑧 𝑧′ = 𝑡ℎ𝑧 ∗ 𝑦 + 𝑧 𝑦′ 𝑧′ = 1 𝑡ℎ𝑦 𝑡ℎ𝑧 1 𝑦 𝑧

2x2 Matrices

32

 What transformations can be represented by a 2x2

matrix?

 2D Mirror over Y axis?

𝑦′ = −𝑦 𝑧′ = 𝑧 𝑦′ 𝑧′ = −1 1 𝑦 𝑧

 2D Mirror over (0,0)?

𝑦′ = −𝑦 𝑧′ = −𝑧 𝑦′ 𝑧′ = −1 −1 𝑦 𝑧

2x2 Matrices

33

 What transformations can be represented by a 2x2

matrix?

 2D Translation?

𝑦′ = 𝑦 + 𝑢𝑦 𝑧′ = 𝑧 + 𝑢𝑧 𝑦′ 𝑧′ = ? ? ? ? 𝑦 𝑧

Only a linear 2D transformations can be represented by a 2x2 matrix

Linear Transformations

34

 Linear transformations are combinations of ..

 Scale  Rotation  Shear  Mirror

 Properties of linear transformations:

 Satisfies:

𝑈 𝑡1𝑞1 + 𝑡2𝑞2 = 𝑡1𝑈 𝑞1 + 𝑡2𝑈(𝑞1)

 Origin maps to origin  Lines map to lines  Parallel lines remain parallel  Ratios are preserved  Closed under composition

2D Translation

35

 2D translation represented by a 3x3 matrix  Point represented in homogenous coordinates

𝑦′ = 𝑦 + 𝑢𝑦 𝑧′ = 𝑧 + 𝑢𝑧 𝑦′ 𝑧′ 1 = 1 𝑢𝑦 1 𝑢𝑧 1 𝑦 𝑧 1

Homogenous Coordinates

36

 Add a 3rd coordinate to every 2D point

 (x,y,w) represents a point at location (x/w, y/w)  (x,y,0) represents a point at infinity  (0,0,0) is not allowed

Basic 2D Transformations

37

 Basic 2D transformations as 3x3 matrices

𝑦′ 𝑧′ 1 = 1 𝑢𝑦 1 𝑢𝑧 1 𝑦 𝑧 1 𝑦′ 𝑧′ 1 = 𝑡𝑦 𝑡𝑧 1 𝑦 𝑧 1 Translate Scale 𝑦′ 𝑧′ 1 = cos 𝜄 −sin 𝜄 sin 𝜄 cos 𝜄 1 𝑦 𝑧 1 𝑦′ 𝑧′ 1 = 1 𝑡ℎ𝑦 𝑡ℎ𝑧 1 1 𝑦 𝑧 1 Rotate Shear

Affine Transformations

38

 Affine transformations are combinations of...

 Linear transformations, and  Translations

𝑦′ 𝑧′ 𝑥′ = 𝑏 𝑐 𝑑 𝑒 𝑓 𝑔 1 𝑦 𝑧 𝑥

 Properties of affine transformations:

 Origin does not necessarily map to origin

 Lines map to lines  Parallel lines remain parallel  Ratios are preserved  Closed under composition

Projective Transformations

39

 Projective transformations:

𝑦′ 𝑧′ 𝑥′ = 𝑏 𝑐 𝑑 𝑒 𝑓 𝑔 𝑕 ℎ 𝑗 𝑦 𝑧 𝑥

 Properties of projective transformations:

 Origin does not necessarily map to origin

 Lines map to lines  Parallel lines do not necessarily remain parallel  Ratios are not preserved  Closed under composition

Overview

40

 2D Transformations

 Basic 2D transformations  Matrix representation  Matrix composition

 3D Transformations

 Basic 3D transformations  Same as 2D

Matrix Composition

41

 Transformations can be combined by matrix

multiplication P’ = T(𝑢𝑦, 𝑢𝑧) R(𝜄) S(𝑡𝑦, 𝑡𝑧) P

𝑦′ 𝑧′ 𝑥′ = 1 𝑢𝑦 1 𝑢𝑧 1 cos 𝜄 −sin 𝜄 sin 𝜄 cos 𝜄 1 𝑡𝑦 𝑡𝑧 1 𝑦 𝑧 𝑥

Matrix Composition

42

 Matrices are a convenient and efficient way to represent a

sequence of transformations

 General purpose representation  Hardware matrix multiply  Efficiency with premultiplication

 Matrix multiplication is associative

P’ = (T * (S * (R * p))) P’ = (T * S * R) * p

Matrix Composition

43

 Be aware: order of transformations matters

 Matrix multiplication is not commutative

transformation order

P’ = T * S * R * p

“Global” “Local”

Matrix Composition

44

 Be aware: order of transformations matters

 Matrix multiplication is not commutative

Problem: local rotation

45

angle φ

Matrix Composition

46

 Rotate around an arbitrary point (a,b)

 Translate (a,b) to the origin  Rotate around origin  Translate back

Matrix Composition

47

 Rotate around an arbitrary point (a,b)

 Translate (a,b) to the origin  Rotate around origin  Translate back

M = T(a, b) * R(𝜄) * T(-a, -b)

Matrix Composition

48

1.

translate rotation center to origin: t(tx,ty)

2.

rotate by φ

3.

inverse translate by t´(-tx,-ty) Matrix notation:

            − −           −             = 1 1 1 1 cos sin sin cos 1 1 1 ) 1 , , ( ) 1 , ' , ' ( y t x t y t x t y x y x    

Matrix Composition

49

 Scale by sx, sy around arbitrary point (a, b)

 Use the same approach …

Matrix Composition

50

 Scale by sx, sy around arbitrary point (a, b)

 Use the same approach …

M = T(a, b) * S(𝑡𝑦, 𝑡𝑧) * T(-a, -b)

Overview

51

 2D Transformations

 Basic 2D transformations  Matrix representation  Matrix composition

 3D Transformations

 Basic 3D transformations  Same as 2D

3D Transformations

52

 Right-handed coordinate system  Left-handed coordinate system  rotation direction

3D Transformations

53

 Same idea as 2D transformations

 Homogenous coordinates (x,y,z,w)  4x4 transformation matrices

𝑦′ 𝑧′ 𝑨′ 𝑥′ = 𝑏 𝑐 𝑑 𝑒 𝑓 𝑔 𝑕 ℎ 𝑗 𝑘 𝑙 𝑚 𝑛 𝑜 𝑝 𝑞 𝑦 𝑧 𝑨 𝑥

Basic 3D Transformations

54

Identity Scale Translation Mirror over X 𝑦′ 𝑧′ 𝑨′ 𝑥′ = 1 1 1 1 𝑦 𝑧 𝑨 𝑥 𝑦′ 𝑧′ 𝑨′ 𝑥′ = 1 𝑢𝑦 1 𝑢𝑧 1 𝑢𝑨 1 𝑦 𝑧 𝑨 𝑥 𝑦′ 𝑧′ 𝑨′ 𝑥′ = 𝑡𝑦 𝑡𝑧 𝑡𝑨 1 𝑦 𝑧 𝑨 𝑥 𝑦′ 𝑧′ 𝑨′ 𝑥′ = 1 −1 −1 1 𝑦 𝑧 𝑨 𝑥

Basic 3D Transformations

55  Rotation around Z axis  Rotation around

Y axis

 Rotation around X axis

𝑦′ 𝑧′ 𝑨′ 𝑥′ = cos 𝜄 −sin 𝜄 sin 𝜄 cos 𝜄 1 1 𝑦 𝑧 𝑨 𝑥 𝑦′ 𝑧′ 𝑨′ 𝑥′ = cos 𝜄 sin 𝜄 1 −sin 𝜄 cos 𝜄 1 𝑦 𝑧 𝑨 𝑥 𝑦′ 𝑧′ 𝑨′ 𝑥′ = 1 cos 𝜄 −sin 𝜄 sin 𝜄 cos 𝜄 1 𝑦 𝑧 𝑨 𝑥

Same as 2D

56

 Everything else is the same as 2D

 In fact 2D is actually 3D in OpenGL

 z is either 0 or ignored

57

• Ask questions, please!!!
• Be communicative
• www.slido.com #PPGSO02
• More active you are, the better for you!

How the lectures should look like #3

58

Projections

Projection

59

 General definition:

 Maps points in n-space to m-space (m<n)

 In Computer Graphics:

 Map 3D camera coordinates to 2D screen coordinates

Viewing transformation

60



Convert from local/world coordinates to camera/viewport coordinates

1.

rotate scene so that camera lies in z-axis

2.

projection transformation

3.

viewport transformation

Stage 0

61

Stage 1 - translate P→P’

62

Stage 2 - rotate P’→P’’→P’’’

63

Stage 2 - rotate P’→P’’→P’’’

64

Orthogonal projection

65

Orthogonal projection

66

 𝑦𝑄 = x’’’  𝑧𝑄 = y’’’  z’’’ is simply left out  Matrix notation

              = 1 1 1 ) 1 , ' ' ' , ' ' ' , ' ' ' ( ) 1 , , , ( z y x z y x

p P P

Perspective projection

67

Taxonomy of Projections

68

Taxonomy of Projections

69

Parallel Projection

70

 Center of projection is at infinity  Direction of projection (DOP) same for all points

Orthographic Projections

71

 DOP perpendicular to view plane

Oblique Projections

72

 DOP not perpendicular to view plane

Parallel Projection View Volume

73

Parallel Projection Matrix

74

 General parallel projection transformation

Taxonomy of Projections

75

Perspective Projection

76

 Maps points onto a view plane along projectors emitting

from center of projection (COP)

Perspective Projection

77

 N-point perspective

 How many vanishing points? 3-point perspective 2-point perspective 1-point perspective

Perspective Projection

78

 Compute 2D coordinates from 3D coordinates using

triangle similarity principle

Perspective Projection

79

 Compute 2D coordinates from 3D coordinates using

triangle similarity principle

Perspective Projection

80

 4x4 matrix representation

 𝑦𝑇 = 𝑦𝐷𝐸/𝑨𝐷  𝑧𝑇 = 𝑧𝐷𝐸/𝑨𝐷  𝑨𝑇 = 𝐸  𝑥𝑇 = 1

𝑦𝑡 𝑧𝑡 𝑨𝑡 𝑥𝑡

= 𝑏 𝑐 𝑑 𝑒 𝑓 𝑔 𝑕 ℎ 𝑗 𝑘 𝑙 𝑚 𝑛 𝑜 𝑝 𝑞

𝑦𝑑 𝑧𝑑 𝑨𝑑

1

Perspective Projection

81

 4x4 matrix representation

 𝑦𝑇 = 𝑦𝐷𝐸/𝑨𝐷

𝑦𝑇 = 𝑦𝐷

 𝑧𝑇 = 𝑧𝐷𝐸/𝑨𝐷

𝑧𝑇 = 𝑧𝐷

 𝑨𝑇 = 𝐸

depth is stored 𝑨𝑇 = 𝑨𝐷

 𝑥𝑇 = 1

𝑥𝑇 = 𝑨𝐷/𝐸

𝑦𝑡 𝑧𝑡 𝑨𝑡 𝑥𝑡

= 𝑏 𝑐 𝑑 𝑒 𝑓 𝑔 𝑕 ℎ 𝑗 𝑘 𝑙 𝑚 𝑛 𝑜 𝑝 𝑞

𝑦𝑑 𝑧𝑑 𝑨𝑑

1

Perspective Projection

82

 4x4 matrix representation

 𝑦𝑇 = 𝑦𝐷𝐸/𝑨𝐷

𝑦𝑇 = 𝑦𝐷

 𝑧𝑇 = 𝑧𝐷𝐸/𝑨𝐷

𝑧𝑇 = 𝑧𝐷

 𝑨𝑇 = 𝐸

𝑨𝑇 = 𝑨𝐷

 𝑥𝑇 = 1

𝑥𝑇 = 𝑨𝐷/𝐸

𝑦𝑡 𝑧𝑡 𝑨𝑡 𝑥𝑡

= 1 𝑓 𝑔 𝑕 ℎ 𝑗 𝑘 𝑙 𝑚 𝑛 𝑜 𝑝 𝑞

𝑦𝑑 𝑧𝑑 𝑨𝑑

1

Perspective Projection

83

 4x4 matrix representation

 𝑦𝑇 = 𝑦𝐷𝐸/𝑨𝐷

𝑦𝑇 = 𝑦𝐷

 𝑧𝑇 = 𝑧𝐷𝐸/𝑨𝐷

𝑧𝑇 = 𝑧𝐷

 𝑨𝑇 = 𝐸

𝑨𝑇 = 𝑨𝐷

 𝑥𝑇 = 1

𝑥𝑇 = 𝑨𝐷/𝐸

𝑦𝑡 𝑧𝑡 𝑨𝑡 𝑥𝑡

= 1 1 𝑗 𝑘 𝑙 𝑚 𝑛 𝑜 𝑝 𝑞

𝑦𝑑 𝑧𝑑 𝑨𝑑

1

Perspective Projection

84

 4x4 matrix representation

 𝑦𝑇 = 𝑦𝐷𝐸/𝑨𝐷

𝑦𝑇 = 𝑦𝐷

 𝑧𝑇 = 𝑧𝐷𝐸/𝑨𝐷

𝑧𝑇 = 𝑧𝐷

 𝑨𝑇 = 𝐸

𝑨𝑇 = 𝑨𝐷

 𝑥𝑇 = 1

𝑥𝑇 = 𝑨𝐷/𝐸

𝑦𝑡 𝑧𝑡 𝑨𝑡 𝑥𝑡

= 1 1 1 𝑛 𝑜 𝑝 𝑞

𝑦𝑑 𝑧𝑑 𝑨𝑑

1

Perspective Projection

85

 4x4 matrix representation

 𝑦𝑇 = 𝑦𝐷𝐸/𝑨𝐷

𝑦𝑇 = 𝑦𝐷

 𝑧𝑇 = 𝑧𝐷𝐸/𝑨𝐷

𝑧𝑇 = 𝑧𝐷

 𝑨𝑇 = 𝐸

𝑨𝑇 = 𝑨𝐷

 𝑥𝑇 = 1

𝑥𝑇 = 𝑨𝐷/𝐸

𝑦𝑡 𝑧𝑡 𝑨𝑡 𝑥𝑡

= 1 1 1 1/𝐸

𝑦𝑑 𝑧𝑑 𝑨𝑑

1

Perspective vs. Parallel

86

 Perspective Projection

 + Size varies inversely with distance - looks realistic  - Distance and angles are not (in general) preserved  - Parallel lines do not (in general) remain parallel

 Parallel Projection

 + Good for exact measurements  + Parallel lines remain parallel  - Angles are not (in general) preserved  - Less realistic looking

Classical Projections

87

Viewport transformation

88

Viewport transformation

89

 sx, sy – scale factors  Matrix notation

min max min max

xc xc xv xv sx − − =

min max min max

yc yc yv yv sy − − =

          + − + − = 1 ) 1 , , ( ) 1 , , (

min min min min

yv yc s xv xc s s s y x y x

y x y x p p v v

Welcome to the matrix!

90

1.

local → global coordinates



translate, rotate, scale, translate

2.

global → camera



translate, rotate, rotate, project

3.

camera → viewport



translate, scale, translate



Transformation combine = matrix multiply

3D rendering pipeline

91

3D polygons Modeling Transformation Lighting Viewing Transformation Projection Transformation Clipping Scan Conversion 2D Image

1 Model transformation local → global / world coordinates Viewport transformation global → camera Projection transformation global → normalized device Clipping Rasterization Texturing & Lighting

92

• Ask questions, please!!!
• Be communicative
• www.slido.com #PPGSO02
• More active you are, the better for you!

How the lectures should look like #2

Fast Forward to Practical Assignment

93

Bezier Curve

Drawing Curves

94

 Parametric curves  Both x and y are functions of additional parameter

Drawing Curves

95

 How to display?

Drawing Curves

96

 Draw many direct line segments  Careful at the ends  How long should each segment be?

Drawing Curves

97

 Draw many direct line segments  Careful at the ends  What about variable segment length?

Drawing Curves

98

 Midpoint-test subdivision

Drawing Curves

99

 Midpoint-test subdivision

Drawing Curves

100

 Midpoint-test subdivision

Drawing Curves

101

 Midpoint-test subdivision  Not perfect  We need different strategies

Bézier Curves

102

 Developed independently in 1960 by

 Pierre Bézier, Renault  Paul de Casteljau, Citroen

 Curve Q(u) is defined by nested interpolation

 Vx are control points. {V0, ....,

Vn} is control polygon

Linear Bézier Curve

103

Quadratic Bézier Curve

104

Cubic Bézier Curve

105

Higher order Bézier Curve

106

Complex shapes

107

 For complex curves, piece together Béziers

108

Make sure you have an OpenGL project assigned!!!

Final word

109

OpenGL Project (simple demo / scene / game )

PPGSO Project

110

• No engines allowed (NO Unity, Unreal engine etc.)
• You can cooperate, help each other
• Libraries for resource loading are allowed
• Evaluated is graphical output, interaction and animation
• Gameplay is secondary (is not scope of this lecture)

OpenGL Project

111

 Specification [6p]

 Data structures (1p)  Class diagrams (1p)  Pseudocodes (1p)  User interaction diagrams (1p)  Structure rendering algorithms (1p)  Modul connection diagrams (1p)

 Use of texture mapping on 3D geometry [4p]

 Unique 3D meshes (2p)  Unique texturing using uv coordinates (2p)

 Camera transformations [6p]

 Camera with perspective projection (1p)  Animated camera (2p)  Interactive camera (2p)  Use of multiple camera view positions (1p)

OpenGL Project

112

 Scene logic [5p]

 Implementation of a scene with logically relative objects (1p)  Changing scenes and multiple areas/scenes (2p)

 At least 2 different scenes

 Scene has a logical ground and background (sky, ceiling, walls…) (1p)  Presented demo must have a beginning and a logical ending (1p)

 Objects and interactions [6b]

 Dynamic scene with objects being created and destroyed during demo

simulation (1p)

 At least 2 different types of objects

 Procedurally generated scene (2b)



Constraints and deterministic definitions for object localization

 Effective object to object collisions and interactions (3p)

 Dynamic response to collisions

OpenGL Project

113

 Transformations and animation [9b]

 Procedurally driven animation (2p)

 Encapsulated method with parameters  Logical branching

 Basic simulated animation with at least 2 forces using matrix algebra (2p)



• Eg. gravity + wind

 Hierarchical object transformation (2p)

 At least 2 levels with 3 objects  Using the aggregation and transformation matrices

 Data driven animations, recommended using key-frames (3p)

 Key-frame sequence represented by code structure of transformation matrix

and time information

 Interpolation using curves or quaternions and spherical linear interpolation

OpenGL Project

114

 Lighting with multiple light sources [7b]

 Diffuse scene lighting with materials (2p)  Changeable color of light (1b)  Correct Phong lighting with multiple light sources (2p)

 Correct depth-based attenuation  At least 3 material and light components  Correctly combine material and light components

 Correct shadows or reflections using any approach you can think of (2p)

 Project report (pdf) [7b]

 1xA4 description of the project manual + runnable package (1b)  2xA4 screens from the projects + game video (2b)  Critical evaluation and update of the specification (4b)

OpenGL Project

115

 Get a project!

 https://tinyurl.com/y3jdfms4

 Subject information:

 https://tinyurl.com/y6244wyn

OpenGL Project

116

Rasterization Rendering Pipeline

Next Week

117

Acknowledgements

 Thanks to all the people, whose work is shown here and whose

slides were used as a material for creation of these slides:

Matej Novotný, GSVM lectures at FMFI UK Peter Drahoš, PPGSO lectures at FIIT STU

118

www.slido.com #PPGSO02 martin.madaras@stuba.sk

Questions ?!
