Trade-off relation between generalized which-way information and fringe visibility A. R. Usha Devi Department of physics Bangalore University Bengaluru-560 056 India IOP, , Bhuban banes eswar ar February 9-18, 2016 Einstein and Bohr

slide-1
SLIDE 1

Trade-off relation between generalized which-way information and fringe visibility

  • A. R. Usha Devi

Department of physics Bangalore University Bengaluru-560 056 India

IOP, , Bhuban banes eswar ar February 9-18, 2016

slide-2
SLIDE 2

Einstein and Bohr debated over quantum theory for years, and never agreed. The debates represent one of the highest points of scientific research in the first half of the twentieth century because it called attention to quirky elements of quantum theory, complementarity, non-locality and entanglement, which are central to the modern quantum information science.

2/16/2016 ARU 2

slide-3
SLIDE 3

The most beautiful experiment Sep 1, 2002

The most beautiful experiment in physics, according to a poll of Physics World readers, is the interference of single electrons in a Young's double slit.

  • Which is the most beautiful experiment in physics according to you?

This question was asked to Physics World readers - and more than 200

  • replied. Majority vote was for the classic experiments by Galileo,

Millikan, Newton and Thomas Young. But uniquely among the top 10, Young's double-slit experiment applied to the interference of single electrons remained as one of the most beautiful experiments in physics.

2/16/2016 ARU 3

slide-4
SLIDE 4

Wave or particle?

  • First decade of 1800: Young – Double slit interference.
  • 1909: Geoffrey Ingram (G I) Taylor – Interference with

feeblest light (equiuivalent to "a candle burning at a distance slightly exceeding a mile“) leads to interference.

  • --- Dirac’s famous statement “each photon interferes with

itself” 1927: Clinton Davisson and Lester Germer -- Diffraction

  • f electrons from Nickel crystal – wave nature of particles

(electrons) -- 1937 Nobel prize for the "discovery of the interference phenomena arising when crystals are exposed to electronic beams“ along with G. P. Thomson.

Thomas Young's sketch of two-slit interference based on observations

  • f water waves.

2/16/2016 ARU 4

slide-5
SLIDE 5

2/16/2016 ARU 5

slide-6
SLIDE 6

Wave nature of electrons in a double slit interference

  • C. Jönsson , Tübingen,

Germany, 1961 4000 clicks

2/16/2016 ARU 6

slide-7
SLIDE 7
  • Not a wave of particles
  • Single particles interfere with themselves !!

Intensity so low that

  • nly one electron at a time

Akira Tonomura and co-workers, Hitachi, 1989

Single Particle at a time

2/16/2016 ARU 7

slide-8
SLIDE 8
  • Two-slit wave packet collapsing
  • Eventually builds up pattern
  • Particle interferes with itself !!

Single particle interference

2/16/2016 ARU 8

slide-9
SLIDE 9

Single electron interference at Hitachi (captured at different times)

2/16/2016 ARU 9

slide-10
SLIDE 10
  • A classical particle would follow some single path
  • Can we say a quantum particle does, too?
  • Can we measure it going through one slit or another?

Which path ?

2/16/2016 ARU 10

slide-11
SLIDE 11
  • Einstein proposed different ways to

measure which slit the particle went through, without blocking it

  • Each time, Bohr showed how that

measurement would wash out the wave function.

Movable wall; measure recoil Source No: Movement of slit washes out pattern Niels Bohr Albert Einstein

Which path ?

2/16/2016 ARU 11

slide-12
SLIDE 12
  • Short answer: no, we can’t tell
  • Anything that blocks one slit washes out the

interference pattern

Which path ?

2/16/2016 ARU 12

slide-13
SLIDE 13

Bohr’s Complementarity principle (1933)

Niels Bohr

  • Wave and particle natures are complementary !!
  • Depending on the experimental setup one obtains

either wave nature or particle nature – not both at a time

2/16/2016 ARU 13

slide-14
SLIDE 14

Mach-Zehnder Interferometer -- Open Setup 

Single quanton

D0 D1 1 Only one detector clicks at a time

BS1

2/16/2016 ARU 14

slide-15
SLIDE 15

Single photon

D0 D1 1 Trajectory can be assigned

BS1

2 1  

 i

e

Mach-Zehnder Interferometer -- Open Setup

2/16/2016 ARU 15

slide-16
SLIDE 16

Single photon

D0 D1 1 Trajectory can be assigned

BS1

1 2 1  

 i

e

Mach-Zehnder Interferometer -- Open Setup

2/16/2016 ARU 16

slide-17
SLIDE 17

Single photon

D0 D1 1 Trajectory can be assigned : Particle nature !!

BS1

Mach-Zehnder Interferometer -- Open Setup

2/16/2016 ARU 17

slide-18
SLIDE 18

Intensity

Intensities are independent of  i.e., no interference

2 / 1 ) 1 ( ...... 1 2 1 2 / 1 ) ( ...... 2 1       p e p e

i i  

Mach-Zehnder Interferometer -- Open Setup

2/16/2016 ARU 18

slide-19
SLIDE 19

Single photon

D0 D1 1 Again only one detector clicks at a time !!

BS1 BS2

Mach-Zehnder Interferometer -- Closed Setup

2/16/2016 ARU 19

slide-20
SLIDE 20

Single photon

D0 D1 1 Again only one detector clicks at a time !!

BS1 BS2

2 1

 i

e 

   

   

) 2 / ( sin ) 1 ( ) 2 / ( cos ) ( 2 1 1 2 1 2 1 1

2 2

 

  

         p p e e e

i i i

Mach-Zehnder Interferometer -- Closed Setup

2/16/2016 ARU 20

slide-21
SLIDE 21

Mach-Zehnder Interferometer -- Closed Setup

Intensities depend on  : Interference!!

2/16/2016 ARU 21

Intensity

slide-22
SLIDE 22

BS2 removes ‘which path’ information Trajectory can not be assigned : Wave nature !! 

Single photon

D0 D1 1

BS1 BS2

Mach-Zehnder Interferometer -- Closed Setup

2/16/2016 ARU 22

slide-23
SLIDE 23

Does quanton know the setup ?

 D0 D1 1 Open Setup Closed Setup  D0 D1 1

BS2 BS1 BS1

Particle behavior Wave behavior

2/16/2016 ARU 23

slide-24
SLIDE 24

Two schools of thought

Bohr, Pauli, Dirac, ….

  • Intrinsic wave-particle duality
  • Reality depends on observation
  • Complementarity principle

Einstein, Bohm, ….

  • Apparent wave-particle duality
  • Reality is independent of observation
  • Hidden variable theory

2/16/2016 ARU 24

Bohr's complementarity principle: Every quantum system has mutually incompatible properties which cannot be simultaneously measured.

slide-25
SLIDE 25

Delayed Choice Experiments

An idea introduced by John A Wheeler of the University of Texas at Austin in 1978

  • J. A. Wheeler, Mathematical Foundations of Quantum Mechanics, edited by

A.R. Marlow (Academic, New-York, 1978) pp. 9-48; Quantum Theory and Measurement, J. A. Wheeler, W. H. Zurek, Eds. (Princeton Univ. Press, Princeton, NJ, 1984), pp. 182–213.

2/16/2016 ARU 25

Suppose that the path lengths of a Mach-Zehnder interferometer have been tuned to make the quanton come out of one port of the final beam splitter with probability 1. After the quanton has passed the first beam splitter so that it is fully inside the interferometer, and before it has reached the second beam splitter, you decide to whisk away that second beam splitter, preventing any interference between the quanton’s two paths from taking place. Without interference, the quanton behaves like a particle and emerges with equal probability out of either of the two ports of the apparatus where the second beam splitter used to be.

slide-26
SLIDE 26

2/16/2016 ARU 26

slide-27
SLIDE 27

B.-G. Englert, Fringe Visibility and Which-Way Information: An Inequality,

  • Phys. Rev. Lett. 77, 2154 (1996).

The trade-off between the amount of which-way information encoded in the detector system and the fringe visibility is captured in terms of a generalized complementarity relation

2/16/2016 ARU 27

slide-28
SLIDE 28

2/16/2016 ARU 28

Which way information

slide-29
SLIDE 29

2/16/2016 ARU 29

Visibility |V|

slide-30
SLIDE 30

2/16/2016 ARU 30

Trade-off

slide-31
SLIDE 31

D =1 (particle nature) V=0 D=0 (wave nature) V=1

2/16/2016 ARU 31

slide-32
SLIDE 32

2/16/2016 ARU 32

General Scenario

slide-33
SLIDE 33

2/16/2016 ARU 33

slide-34
SLIDE 34

2/16/2016 ARU 34

slide-35
SLIDE 35

2/16/2016 ARU 35

slide-36
SLIDE 36

2/16/2016 ARU 36

slide-37
SLIDE 37

2/16/2016 ARU 37

slide-38
SLIDE 38

2/16/2016 ARU 38

slide-39
SLIDE 39

2/16/2016 ARU 39

slide-40
SLIDE 40

2/16/2016 ARU 40

slide-41
SLIDE 41

2/16/2016 ARU 41

slide-42
SLIDE 42

So far….

The trade-off between interference visibility and which-path distinguishability for a quantum particle possessing an internal structure -- such as spin or polarization is useful to erase ‘which- path’ information (by appropriate preparations of states of the internal degree of freedom). One can thus recover interference

  • the internal structure could play a manipulative role in

controlling the information about which path in the interferometer arms is taken by the particle.

  • Generalized fringe visibility and detector state distinguishability

show complementarity (trade-off)

  • What happens if detector state has an internal structure??

2/16/2016 ARU 42

slide-43
SLIDE 43

Channel discrimination and which-path information in two-slit interference

2/16/2016 ARU 43

slide-44
SLIDE 44

2/16/2016 ARU 44

slide-45
SLIDE 45

Channel Discrimination Distinguishing two channels with input state :

1 0, 

 

Input state Channel Output state

1

1

Channel discrimination  which path information

2/16/2016 ARU

slide-46
SLIDE 46

All entangled states are useful for Channel discrimination task

  • M. F. Sacchi, Phys. Rev. A 71, 062340 (2005); 72, 014305 (2005)
  • M. Piani and J. Watrous, Phys. Rev. Lett. 102, 250501 (2009)

2/16/2016 ARU 46

slide-47
SLIDE 47

We put forth some instances where distinguishability is 0, yet generalized fringe visibility is not equal to 1. Where is the missing information? Our work: Tracking missing ‘which-path’ information via Generalized distinguishability when detector is assisted by an ancilla.
