SLIDE 1
April 3, 2004 LDTA 2004 2
Tools and Analyses for Ambiguous Input Streams Andrew Begel and - - PowerPoint PPT Presentation
Tools and Analyses for Ambiguous Input Streams Andrew Begel and - - PowerPoint PPT Presentation
Tools and Analyses for Ambiguous Input Streams Andrew Begel and Susan L. Graham University of California, Berkeley LDTA Workshop - April 3, 2004 Harmonia: Language-aware Editing Programming by Voice Code dictation Voice-based
SLIDE 2
SLIDE 3
April 3, 2004 LDTA 2004 3
Harmonia: Language-aware Editing
Programming by Voice
– Code dictation – Voice-based editing commands
Program Transformations
– Transformation actions – Pattern-matching constructs Human Speech
SLIDE 4
April 3, 2004 LDTA 2004 4
Harmonia: Language-aware Editing
Programming by Voice
– Code dictation – Voice-based editing commands
Program Transformations
– Transformation actions – Pattern-matching constructs Human Speech Embedded Languages
SLIDE 5
April 3, 2004 LDTA 2004 5
Harmonia: Language-aware Editing
Programming by Voice
– Code dictation – Voice-based editing commands
Program Transformations
– Transformation actions – Pattern-matching constructs
Each kind of input stream ambiguity requires new language analyses
Human Speech Embedded Languages
SLIDE 6
April 3, 2004 LDTA 2004 6
Speech Example
for (int i = 0; i < 10; i++ ) { ❙ }
for int i equals zero i less than ten i plus plus
SLIDE 7
April 3, 2004 LDTA 2004 7
Ambiguities
for (int i = 0; i < 10; i++ ) { ❙ }
4 int eye equals 0 aye less then 10 i plus plus
SLIDE 8
April 3, 2004 LDTA 2004 8
Ambiguities
for (int i = 0; i < 10; i++ ) { ❙ }
4 int eye equals 0 aye less then 10 i plus plus
KW or #? ID Spelling? KW or ID?
SLIDE 9
April 3, 2004 LDTA 2004 9
Another Utterance
for times ate equals zero two plus equals one
SLIDE 10
April 3, 2004 LDTA 2004 10
Many Valid Parses!
4 * 8 = zero; to += won ❙
for times ate equals zero two plus equals one
for (times; ate == 0; to += 1) { ❙ } fore.times(8).equalsZero(2, plus == 1) ❙
SLIDE 11
April 3, 2004 LDTA 2004 11
Embedded Language Example
C and Regexps embedded in Flex
Flex Rule for Identifiers
[_a-zA-Z]([_a-zA-Z0-9])* i++; RETURN_TOKEN(ID);
SLIDE 12
April 3, 2004 LDTA 2004 12
Embedded Language Example
C and Regexps embedded in Flex
Flex Rule for Identifiers
[_a-zA-Z]([_a-zA-Z0-9])* i++; RETURN_TOKEN(ID);
Why not this interpretation?
[_a-zA-Z]([_a-zA-Z0-9])* i++; RETURN_TOKEN(ID);
SLIDE 13
April 3, 2004 LDTA 2004 13
Legacy Language Example
Fortran
DO 57 I = 3,10
SLIDE 14
April 3, 2004 LDTA 2004 14
Legacy Language Example
Fortran
- Do Loop
DO 57 I = 3,10
SLIDE 15
April 3, 2004 LDTA 2004 15
Legacy Language Example
Fortran
- Do Loop
DO 57 I = 3,10 DO 57 I = 3
SLIDE 16
April 3, 2004 LDTA 2004 16
Legacy Language Example
Fortran
- Do Loop
DO 57 I = 3,10
- Assignment
DO 57 I = 3
SLIDE 17
April 3, 2004 LDTA 2004 17
Legacy Language Example
Fortran
- Do Loop
DO 57 I = 3,10
- Assignment
DO57I = 3
SLIDE 18
April 3, 2004 LDTA 2004 18
Legacy Language Example
PL/I
- Non-reserved Keywords
IF IF = THEN THEN THEN = ELSE ELSE ELSE = END END
SLIDE 19
April 3, 2004 LDTA 2004 19
Legacy Language Example
PL/I
- Non-reserved Keywords
IF IF = THEN THEN THEN = ELSE ELSE ELSE = END END KW ID ID ID
SLIDE 20
April 3, 2004 LDTA 2004 20
Homophones Non-reserved keywords Ambiguous interpretations Multiple Lexical Categories Homophone IDs Lexical misspellings Unambiguous Single Lexical Category Multiple Spellings Single Spelling
Input Stream Classification
SLIDE 21
April 3, 2004 LDTA 2004 21
Homophones Non-reserved keywords Ambiguous interpretations Multiple Lexical Categories Homophone IDs Lexical misspellings Unambiguous Single Lexical Category Multiple Spellings Single Spelling
Input Stream Classification
Embedded Languages Fall in all Four Categories!
SLIDE 22
April 3, 2004 LDTA 2004 22
GLR Analysis Architecture
Lexer GLR Parser Semantics FOR I
FOR I
for (i = 0; i < 10; i++ ) { ❙ }
(
SLIDE 23
April 3, 2004 LDTA 2004 23
GLR Analysis Architecture
Lexer GLR Parser Semantics FOR I
FOR I
for (i = 0; i < 10; i++ ) { ❙ }
( Handles syntactic ambiguities
SLIDE 24
April 3, 2004 LDTA 2004 24
Our Contribution: XGLR Analysis Architecture
Lexer XGLR Parser Semantics for i equals zero ... FOR I
FOR I
SLIDE 25
April 3, 2004 LDTA 2004 25
Our Contribution: XGLR Analysis Architecture
Lexer XGLR Parser Semantics for i equals zero ... FOR I 4 EYE
FOR I
Handles input stream ambiguities
SLIDE 26
April 3, 2004 LDTA 2004 26
LR Parsing
S7 R3 S9 3 Err S4 R1 2 Err S3 S2 1 # KW ID
I
ID
FOR
KW
=
KW
1 Parse Table
#
Input Stream Parse Stack
SLIDE 27
April 3, 2004 LDTA 2004 27
LR Parsing
S7 R3 S9 3 Err S4 R1 2 Err S3 S2 1 # KW ID
I
ID
FOR
KW
=
KW
1 Parse Table
#
Input Stream Parse Stack
SLIDE 28
April 3, 2004 LDTA 2004 28
LR Parsing
S7 R3 S9 3 Err S4 R1 2 Err S3 S2 1 # KW ID
I
ID
=
KW
1 Parse Table
#
Input Stream Parse Stack FOR
KW
3
SLIDE 29
April 3, 2004 LDTA 2004 29
GLR Parsing
S7 R3 S9 3 Err S4 R1 R2 2 Err S3 R5 S2 1 # KW ID
I
ID
FOR
KW
=
KW
1 Parse Table
#
Input Stream Parse Stack
SLIDE 30
April 3, 2004 LDTA 2004 30
GLR Parsing
S7 R3 S9 3 Err S4 R1 R2 2 Err S3 R5 S2 1 # KW ID
I
ID
FOR
KW
=
KW
1 Parse Table
#
Input Stream Parse Stack
SLIDE 31
April 3, 2004 LDTA 2004 31
GLR Parsing
S7 R3 S9 3 Err S4 R1 R2 2 Err S3 R5 S2 1 # KW ID
I
ID
FOR
KW
=
KW
1 Parse Table
#
Input Stream Parse Stack 2 5
SLIDE 32
April 3, 2004 LDTA 2004 32
GLR Parsing
S7 R3 S9 3 Err S4 R1 R2 2 Err S3 R5 S2 1 # KW ID
I
ID
=
KW
1 Parse Table
#
Input Stream Parse Stack 2 FOR
KW
3 FOR
KW
4 5
SLIDE 33
April 3, 2004 LDTA 2004 33
Example 1 Example 2 Multiple Lexical Categories Example 1 Not Shown Single Lexical Category Multiple Spellings Single Spelling
XGLR in Action
SLIDE 34
April 3, 2004 LDTA 2004 34
23 FOR
Parsing Homophones
BAR
SLIDE 35
April 3, 2004 LDTA 2004 35
23 FOR FORE 4
ID KW NUM
XGLR Extension: Multiple Spellings, Single and Multiple Lexical Categories BAR FOUR
SLIDE 36
April 3, 2004 LDTA 2004 36
23 FOR FORE 4 23 23
ID KW NUM
XGLR Extension: Parsers fork due to input ambiguity BAR FOUR
SLIDE 37
April 3, 2004 LDTA 2004 37
23 26 FOR FORE 4 29 35 23 23
ID KW NUM
Each parser shifts its now unambiguous input BAR FOUR
SLIDE 38
April 3, 2004 LDTA 2004 38
23 26 FOR FORE 4 29 35 BAR 23 23
ID ID KW NUM
The next input is lexed unambiguously FOUR
SLIDE 39
April 3, 2004 LDTA 2004 39
23 26 FOR FORE 4 29 35 BAR 23 23 42 49
ID ID KW NUM
ID is only a valid lookahead for two parsers FOUR
SLIDE 40
April 3, 2004 LDTA 2004 40
Parsing Embedded Languages
Example BNF Grammar Contains Languages L and W bL → loopL dW ENDL loopL → LOOPL | ε dW → WHILEW NUMW doW doW → DOW | ε
L W
SLIDE 41
April 3, 2004 LDTA 2004 41
Parsing Embedded Languages
Example BNF Grammar Contains Languages L and W bL → loopL dW ENDL loopL → LOOPL | ε dW → WHILEW NUMW doW doW → DOW | ε
LOOP WHILE 34 END WHILE 56 DO END
L W
SLIDE 42
April 3, 2004 LDTA 2004 42
SLIDE 43
April 3, 2004 LDTA 2004 43
SLIDE 44
April 3, 2004 LDTA 2004 44
SLIDE 45
April 3, 2004 LDTA 2004 45
SLIDE 46
April 3, 2004 LDTA 2004 46
S
Parsing Embedded Languages
LOOP WHILE 34
SLIDE 47
April 3, 2004 LDTA 2004 47
S LOOP WHILE 34 Current parse state has ambiguous lexical language
SLIDE 48
April 3, 2004 LDTA 2004 48
S
W L
LOOP WHILE 34 XGLR Extension: Fork parsers, assign one to each lexical language
SLIDE 49
April 3, 2004 LDTA 2004 49
S LOOP LOOP
W L W L KW ID
WHILE 34 XGLR Extension: Single spelling, Multiple lexical categories Lex lookahead both in language L and W
SLIDE 50
April 3, 2004 LDTA 2004 50
S 4
L
LOOP LOOP
W L W L KW ID
WHILE 34 Only LOOPL is valid lookahead, and is shifted
SLIDE 51
April 3, 2004 LDTA 2004 51
S 4
W
LOOP LOOP
W L W L KW ID
WHILE 34 XGLR Extension: State 4 has lexer lookaheads
- nly in language W
SLIDE 52
April 3, 2004 LDTA 2004 52
S 4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
Lex lookahead in language W
SLIDE 53
April 3, 2004 LDTA 2004 53
S 4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
REDUCE by rule 2 and GOTO state 1 loop
L
SLIDE 54
April 3, 2004 LDTA 2004 54
S 4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
loop
L
SLIDE 55
April 3, 2004 LDTA 2004 55
S 4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
2
W
Shift into state 2 loop
L
SLIDE 56
April 3, 2004 LDTA 2004 56
S 4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
2
W W NUM
XGLR Extension: Lex lookahead in language W loop
L
SLIDE 57
April 3, 2004 LDTA 2004 57
S 4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
2
W W NUM
loop
L
SLIDE 58
April 3, 2004 LDTA 2004 58
4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
2
W W NUM
3
W
Shift into state 3 S loop
L
SLIDE 59
April 3, 2004 LDTA 2004 59
4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
2
W W NUM
3
W
Shift into state 3, which has ambiguous lexical language S loop
L
SLIDE 60
April 3, 2004 LDTA 2004 60
4
W
LOOP LOOP
W L W L KW ID
WHILE 34
KW W
1
W
2
W W NUM
3
W
3
L
XGLR Extension: Single spelling, Multiple lexical categories Fork parsers, assign one to each lexical language S loop
L
SLIDE 61
April 3, 2004 LDTA 2004 61
GLR Ambiguity Support
1.
Fork parser on shift-reduce conflict
2.
Fork parser on reduce-reduce conflict
SLIDE 62
April 3, 2004 LDTA 2004 62
XGLR Ambiguity Support
1.
Fork parser on shift-reduce conflict
2.
Fork parser on reduce-reduce conflict
SLIDE 63
April 3, 2004 LDTA 2004 63
XGLR Ambiguity Support
1.
Fork parser on shift-reduce conflict
2.
Fork parser on reduce-reduce conflict
3.
Fork parsers on ambiguous lexical language
- Single spelling, Multiple lexical categories
4.
Fork parsers on ambiguous lexical lookahead
- Single/Multiple Spellings, Multiple lexical
categories
- Shift-shift conflict resolution
SLIDE 64
April 3, 2004 LDTA 2004 64
XGLR Ambiguities
Many GLR programming language specs
have finite, few ambiguities
XGLR language specs also have finite, but
slightly more, ambiguities
– Lexical ambiguity due to ambiguous input does result in more ambiguous parse forests
SLIDE 65
April 3, 2004 LDTA 2004 65
XGLR Ambiguities
Many GLR programming language specs
have finite, few ambiguities
XGLR language specs also have finite, but
slightly more, ambiguities
– Lexical ambiguity due to ambiguous input does result in more ambiguous parse forests
Ambiguity causes parsers to fork GLR maintains efficiency by merging parsers
when ambiguity is over
SLIDE 66
April 3, 2004 LDTA 2004 66
Parser Merging
GLR: Parsers merge when in same parse state
DO
KW
8 3 1 DO
KW
5 57
#
5
SLIDE 67
April 3, 2004 LDTA 2004 67
Parser Merging
GLR: Parsers merge when in same parse state
DO
KW
8 3 1 DO
KW
5 57
#
4 5 57
#
SLIDE 68
April 3, 2004 LDTA 2004 68
Parser Merging
XGLR: Parsers merge when in same parse
state and same lexical state
DO
KW
8 3 1 DO
KW
5 57
# A A A A A W
5
A
SLIDE 69
April 3, 2004 LDTA 2004 69
Parser Merging
XGLR: Parsers merge when in same parse
state and same lexical state
DO
KW
8 3 1 DO
KW
5
A A A A A W
5
A
57
#
57
# A W
SLIDE 70
April 3, 2004 LDTA 2004 70
Parser Merging
XGLR: Parsers merge when in same parse
state and same lexical state
DO
KW
8 3 1 DO
KW
5
A A A A A W
5
A
57
#
57
# A W
4
W
SLIDE 71
April 3, 2004 LDTA 2004 71
Parser Merging
XGLR: Parsers merge when in same parse
state and same lexical state
DO
KW
8 3 1 DO
KW
5
A A A A A W
5
A
57
#
57
# A W
4
A
SLIDE 72
April 3, 2004 LDTA 2004 72
Parser Merging
XGLR: Parsers merge when in same parse
state and same lexical state
DO
KW
8 3 1 DO
KW
5
A A A A A W
5
A
57
#
57
# A W
4
A
SLIDE 73
April 3, 2004 LDTA 2004 73
Out of Sync Parsers
DO57I=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
SLIDE 74
April 3, 2004 LDTA 2004 74
Out of Sync Parsers
57I=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
DO
KW A
DO57I
ID W
=3
SLIDE 75
April 3, 2004 LDTA 2004 75
Out of Sync Parsers
57I=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
DO
KW A
DO57I
ID W
=3 3
A
5
W
SLIDE 76
April 3, 2004 LDTA 2004 76
Out of Sync Parsers
I=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
DO
KW A
DO57I
ID W
3 3
A
5
W
=
KW W
57
ID A
SLIDE 77
April 3, 2004 LDTA 2004 77
Out of Sync Parsers
I=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
DO
KW A
DO57I
ID W
3 3
A
5
W
=
KW W
57
ID A
6
W
4
A
SLIDE 78
April 3, 2004 LDTA 2004 78
Out of Sync Parsers
=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
DO
KW A
DO57I
ID W
3 3
A
5
W
=
KW W
57
ID A
6
W
4
A # W
I
ID A
SLIDE 79
April 3, 2004 LDTA 2004 79
Out of Sync Parsers
=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
DO
KW A
DO57I
ID W
3 3
A
5
W
=
KW W
57
ID A
6
W
4
A # W
I
ID A
9
W
SLIDE 80
April 3, 2004 LDTA 2004 80
Out of Sync Parsers
=3
XGLR: Parsers merge when in same parse
state and same lexical state and same input position
8 1
A W
5
A
DO
KW A
DO57I
ID W
3 3
A
5
W
=
KW W
57
ID A
6
W
4
A # W
I
ID A
9
W
SLIDE 81
April 3, 2004 LDTA 2004 81
Implementation
Keep map: lookahead → parser to use when
looking for parsers to merge with
Sort parsers by position of lookahead in the input
– Enables pruning of map as parsers move past a particular input location – Extra memory required is bounded by dynamic separation between first and last parsers
SLIDE 82
April 3, 2004 LDTA 2004 82
Related Work
GLR Parsing Algorithm
– Tomita [1985] – Farshi [1991] – Rekers [1992] – Johnstone et. al. [2002]
Incremental GLR
– Wagner [1997]
GLR Implementations
(that I heard of before today)
– ASF+SDF [1993] – Elkhound [2004] – Bison [2003] – DParser [2002] – Aycock and Horspool [1999]
Scannerless Parsing
(or Context-Free Scanning)
– Salomon and Cormack [1989] – Visser [1997] van den Brand [2002]
Ambiguous Input Streams
– Aycock and Horspool [2001]
Embedded Languages
– ASF+SDF [1997] – Van de Vanter and Boshernitsan (CodeProcessor) [2000]
SLIDE 83
April 3, 2004 LDTA 2004 83
Future Work
Semantic Analysis of Embedded
Languages
Automated Semantic Disambiguation
SLIDE 84
April 3, 2004 LDTA 2004 84
Contributions
1.
Generalized GLR to handle input stream ambiguities
2.
Classified input stream ambiguities into four categories
3.
Implemented XGLR algorithm in Harmonia framework
4.
Constructed combined lexer and parser generator to support embedded languages and lexical ambiguities at each stage of analysis
5.
Enabled analysis of embedded languages, programming by voice, and legacy languages
SLIDE 85
April 3, 2004 LDTA 2004 85
