S P A C E A D V I S O R Y C O M P A N Y ( P T Y ) L T D [ S A C ] South Africas contribution to the Netherlands China Low-Frequency Explorer Presented by : Dr Francois Malan Date : 12 December 2017 Stellenbosch, South Africa the

slide-1
SLIDE 1

S P A C E A D V I S O R Y C O M P A N Y ( P T Y ) L T D [ S A C ]

South Africa’s contribution to the Netherlands China Low-Frequency Explorer

Presented by : Dr Francois Malan Date : 12 December 2017 Stellenbosch, South Africa

slide-2
SLIDE 2

the Netherlands China Low Frequency Explorer NCLE

slide-3
SLIDE 3

NCLE: Part of Chang’e 4

  • Chang’e is part of the Chinese Lunar

Exploration Program – CLEP

  • “Chang’e” = Chinese Moon Goddess
  • a series of robotic lunar missions

from the Chinese National Space Administration (CNSA)

  • Chang’e 1-6, all to be launched

with Long March Rockets

Chang’e - Chinese Moon Goddess

slide-4
SLIDE 4

Chang’e Missions

  • 1 : Lunar Orbiter (2007)
  • 2 : Lunar Orbiter (2010)
  • 3 : Lander + Rover (2013)
  • 4 : Orbiter + Lander + Rover

(2018)

  • 5 : Lander + Sample Return (2019)
  • 6 : Follow-up of Chang’e 5 (2020?)

Long March 5 Rocket

slide-5
SLIDE 5

Chang’e 3 (2013) – success

Image: CNSA

slide-6
SLIDE 6
  • Originally: a backup for Chang’e 3

– i.e. Lunar lander + Rover

  • Chang’e 3 was a success

– Chang’e 4 mission expanded – Different landing site – More science

Chang’e 4

slide-7
SLIDE 7

Chang’e 3 Landing Site

slide-8
SLIDE 8

Chang’e 4 Landing Site (far side of Moon)

Aitken Basin

slide-9
SLIDE 9

The Dark Side of the Moon

Pink Floyd, 1973

slide-10
SLIDE 10

“Dark Side”? No, actually “Far Side”

Gary Larson, “The Far Side”

slide-11
SLIDE 11

Far Side of the Moon always faces away

Akash Tiwari, http://astronomywithastrophysics.blogspot.co.za/

slide-12
SLIDE 12

Chang’e 4 : two components

  • Two parts:

– “Mother Ship Satellite” –

at Earth-Moon L2 point

– Lunar Rover – on the far side

  • f the Moon (e.g. Aitken Basin)
  • Launch of the Chang’e 4 satellite

expected June 2018, the Lander and Rover follow half a year later.

Images: CNSA

slide-13
SLIDE 13
  • Smaller mass orbiting larger mass, e.g.

– Sun and Earth – Earth and Moon

  • Gravity in equilibrium

L2 = second Lagrange Point

Earth Moon

slide-14
SLIDE 14

Lagrangian Points : animation

User:cmglee, Wikimedia Commons

slide-15
SLIDE 15

CHANG’E 4 MISSION

  • Dr. Marc Klein-Wolt : RRL / NCLE Consortium
slide-16
SLIDE 16

Science : Unexplored Frequency Domain

Funded through ESA PRODEX program

slide-17
SLIDE 17

Detect the history of the Universe

Marc Klein-Wolt : RRL / NCLE Consortium

Atomic hydrogen emission = 21cm (1.4 GHz) microwave

slide-18
SLIDE 18

NCLE Science Objectives

RFI Characterisation AKR, QTN Characterisation Constraining Dark Ages/Cosmic Dawn Galactic Background Spectrum Low-Frequency Sky Map Solar Burst

Priority

Radio Transients, Crab like pulses

Frequency 100 kHz 80 kHz 1 MHz 10 MHz 30 MHz 50 MHz 80 MHz

Technical Objective Science Objective VLBI with Earth-based, Lunar-based and Space-based facilities Science potential Planetary Science (Jupiter/Saturn Emission) Planetary Science (Jovian S Burst & DAM)

  • Dr. Marc Klein-Wolt : RRL / NCLE Consortium
slide-19
SLIDE 19

NCLE on Chang’e 4

The first in many ways..

Launch in May 2018 Payload delivery: QM in October 2017, FM in April 2018

  • Dr. Marc Klein-Wolt : RRL / NCLE Consortium
slide-20
SLIDE 20

Chang’e 4 spacecraft

slide-21
SLIDE 21

Chang’e 4 spacecraft

slide-22
SLIDE 22

NCLE Science Payload

slide-23
SLIDE 23

NCLE receiver & data processing unit

slide-24
SLIDE 24

S P A C E A D V I S O R Y C O M P A N Y ( P T Y ) L T D [ S A C ]

  • Modular design
  • Compatible with CubeSats
  • High-speed high-capacity mass data storage
  • FPGA processor for real-time image processing
  • High frame rate capability (for larger optics)

Characteristics

Form factor < 1U

Mass

< 480 g GSD 31 m from ISS orbit Image Sensor 2.2 Megapixel RGB Storage 128 GB

  • Rad. tolerance

Tested to 30 krad TID Space heritage 2017 !

Origin: SCS Gecko Imager

slide-25
SLIDE 25

S P A C E A D V I S O R Y C O M P A N Y ( P T Y ) L T D [ S A C ]

Succesfully Flown in

slide-26
SLIDE 26

Deployed from the ISS

25 May 2017

51.6°, 400km orbit. Expected lifetime: 12-18 months.

slide-27
SLIDE 27

S P A C E A D V I S O R Y C O M P A N Y ( P T Y ) L T D [ S A C ]

Commercialized (CubeSatShop.com)

slide-28
SLIDE 28

Modular design

Sensor Unit Control Unit Mechanics Optics

slide-29
SLIDE 29

Versatile “Control Unit”

PC/104 form-factor (~100 mm x 100 mm x 15 mm)

  • Mass data storage (128 GB or more)
  • Automatic wear levelling
  • Error-correction
  • High data capture rate
  • Thumbnails
  • RGB Bayer demosaicing
  • JPEG2000 (post nSight-1)
slide-30
SLIDE 30

SCS Tegu EO-1 shares heritage

  • 2m PAN, 10m multispectral GSD
  • 24 km swath
  • VIS-NIR coverage in 11 bands
  • 1 Terabyte on-board storage
  • JPEG2000 compression
slide-31
SLIDE 31

ADC board (RU/SRON) Back plane (RU/SRON) Processing & Storage unit (Space Advisory Company) Housing (RU)

NCLE receiver & data processing unit

slide-32
SLIDE 32

Engineering Model

RRL / NCLE Consortium

slide-33
SLIDE 33

NLCE Development

Qualification Model integration of NCLE instrument at ISISpace NCLE Receiver at Radboud Radio Lab Thermal test of NCLE receiver

RRL / NCLE Consortium

slide-34
SLIDE 34

The (first) FM Board : delivered!

slide-35
SLIDE 35

Looking towards success in 2018

Image: CNSA

slide-36
SLIDE 36

Some of our partners and customers

slide-37
SLIDE 37
  • Dr. Francois Malan

francois@spaceadvisory.com

Tel : +27 (0)21 300 0060 http://www.spaceadvisorycompany.com
