This is where Virtual System Design starts! Our virtual testing capabilities enable us to deliver better solutions in less time – and to provide fast and strong support in the field.

2 | Danfoss Power Solutions

Model based design and virtual testing of software

System architecture design System requirements Software requirements Software design Software implementation System test System integration test Software test

vADC vADC ADC ADC vADC vADC

: application development centers in Nordborg, Ames, and Haiyan with actual test vehicles : virtual application development center with simulation models of vehicles that include hydraulics, mechanics, and software

ADC

*

vADC

*

There is an ongoing trend for systems and applications to become more complex, while the demand for customization, optimization and functional safety increases. Model-based design and virtual testing are powerful tools to face these challenges and to ensure high SW quality and system performance, while shortening development time.

3 | Danfoss Power Solutions

Virtual Application Development Center (vADC)

Danfoss has been using simulation, model- based design, and Hardware-in-the-Loop testing for years and is a strong partner for virtual system development and software test. With the Virtual ADC, we take the next step toward a fully virtual 3D environment for interactive driving tests. The Virtual ADC combines real-time models of Danfoss products and application software with a dynamic 3D vehicle model and digital copies

• f our actual Application Development Centers’

test tracks. Customers can benefit directly in joint development projects, by customer model export, or via Testing-as-a-Service.

4 | Danfoss Power Solutions

Digital Twin concept

Compared with traditional vehicle tests, virtual testing can be integrated much earlier into the development process,

• ffers a much more flexible, accessible

and safe test environment, and enables the use of automated testing and tuning routines. At the heart of system simulations are digital twins of Danfoss products verified with laboratory tests. Please contact your sales representative for a Danfoss digital twin.
