Third Generation PV and Other Ways to Utilize Solar Energy Solar - PowerPoint PPT Presentation

Jan 11, 2024 •457 likes •569 views

Third Generation PV and Other Ways to Utilize Solar Energy Solar Thermal Energy III - Solar Thermal Power Week 6.2.3 Arno Smets Solar thermal power plant Solar thermal power system Mechanical Storage energy Boiler Collector Heat engine

  1. Third Generation PV and Other Ways to Utilize Solar Energy Solar Thermal Energy III - Solar Thermal Power Week 6.2.3 Arno Smets

  2. Solar thermal power plant

  3. Solar thermal power system Mechanical Storage energy Boiler Collector Heat engine Heat rejected

  4. Solar concentrators

  5. Types of concentrators: Parabolic Focal point

  6. Types of concentrators: Fresnel Reflector

  7. Types of concentrators: Dish stirling

  8. Types of concentrators: Power towers

  9. Thank you for your attention!
