SLIDE 1
Arno Smets, Wilson Smith, Paula Perez Rodriguez
Third Generation PV and Other Ways to Utilize Solar Energy Solar - - PowerPoint PPT Presentation
Third Generation PV and Other Ways to Utilize Solar Energy Solar - - PowerPoint PPT Presentation
Third Generation PV and Other Ways to Utilize Solar Energy Solar Fuels Week 6.3 Arno Smets, Wilson Smith, Paula Perez Rodriguez Electricity Heat Solar Fuels Ragone Plot: Energy vs Power Density Fuel Energy Energy [kJ/g] [kJ/l] Coal
SLIDE 2
SLIDE 3
Ragone Plot: Energy vs Power Density
Source: “Indication of anomalous heat energy production in a reactor device containing loaded nickel powder”. Levi et al. 2013
Fuel Energy [kJ/g] Energy [kJ/l] Coal 29.3
- Wood
14.6
- Gasoline
43.5 30590 Diesel 42.7 29890 Natural Gas 50.02 31.7 Hydrogen 119.9 10
SLIDE 4
Can we learn from Nature?
SLIDE 5
Hydrogen cycle
CO2 CO H2 O2 H2O CH4
Water Gas Shift Fisher-Tropsh Combustion Electrolysis
Energy Energy Energy Energy
SLIDE 6
Direct photoelectrolysis
Cathodic: 2H++2e- H2 Anodic: 2H2O O2+4H++4e- TOTAL: H2O H2 + ½ O2
Potential: 1.23 V
SLIDE 7
Band bending
N-type semiconductor: Anode P-type semiconductor: Cathode
SLIDE 8
Challenges for photoelectrochemistry
- 1. Absorption
- 2. Separation of charges
- 3. Catalysis
1 2 3 3
SLIDE 9
Materials for photoelectrodes
SLIDE 10
Improving photoelectrode efficiency
0.5 1.0 1.5 2.0 2 4 BiVO4 +Gradient doped +Catalyst
j (mA/cm
2)
V vs. RHE (V)
BiVO4 BiVO4 + Catalyst dark 0.5 1.0 1.5 2.0 2 4
j (mA/cm
2)
V vs. RHE (V)
BiVO4 dark 0.5 1.0 1.5 2.0 2 4
j (mA/cm
2)
V vs. RHE (V)
BiVO4 BiVO4 + Catalyst dark
SLIDE 11
Potential of the reaction
Reaction potential 1.23V Overpotential 0.8V
Needed voltage for the reaction to happen
Photoelectrode 0.6V Solar cell 1.5V
SLIDE 12
Hybrid photoelectrode
Photoelectrode Solar cell Counter electrode
SLIDE 13
Jsc
Voc
Current Potential
Hybrid photoelectrode
Jsc
Voc
Current Potential Jphoto Voperational
𝜃𝑇𝑈𝐼 = 𝐾𝑞ℎ𝑝𝑢𝑝 ⋅ 1.23𝑊 𝑄
Solar cell Photoanode
SLIDE 14
MECS PV-PEC Device
4.9% Solar to Hydrogen Conversion Efficiency!
