Theoretical Bounds on Image Search

16-423 - Designing Computer Vision Apps

Instructor - Simon Lucey

Today

• Exhaustive Search & Sampling
• Motivation for Descriptors
• Overcoming the Curse of Dimensionality in Search

2

3 Biggest Problems in Computer Vision?

3

3 Biggest Problems in Computer Vision?

3

REGISTRATION

REGISTRATION

REGISTRATION

(Prof. Takeo Kanade - Robotics Institute - CMU.)

x

What is Registration?

4

“Source” “Template”

Our goal is to find the warp parameter vector !

W(x; p) x W(x; p) = warping function such that x0 = W(x; p) p = parameter vector describing warp x = coordinate in template [x, y]T x0 = corresponding coordinate in source [x0, y0]T

p

What is Registration?

4

x0

“Source” “Template”

Warp Functions

5

W(x; p) = x + p p = [p1 p2]T W(x; p) = x + p p = [p1 p2]T

translation

translation

aspect

W(x; p) = M  x 1

• affine

rotation

M = 1 − p1 p2 p3 p4 1 − p5 p6

• p = [p1 . . . p6]T

Warp Functions

6

W(x; p)

Warp Functions

6

W(x; p)

(p)

Naive Approach

“Images at various warps ”

7

p

“Template image”

(p)

Naive Approach

“Images at various warps ” “Vectors of pixel values at each warp position”

[255,134,45,.......,34,12,124,67] [123,244,12,.......,134,122,24,02] [67,13,245,.......,112,51,92,181] [65,09,67,.......,78,66,76,215]

...........

7

p

“Template image”

• bject

≥ < background Th

Naive Approach

• If you were a person coming straight from machine learning

you might suggest,

“Vectors of pixel values at each warp position”

[255,134,45,.......,34,12,124,67] [123,244,12,.......,134,122,24,02] [67,13,245,.......,112,51,92,181] [65,09,67,.......,78,66,76,215]

...........

D( )

“matching function”

8

• bject

≥ < background Th

Naive Approach

• If you were a person coming straight from machine learning

you might suggest,

“Vectors of pixel values at each warp position”

[255,134,45,.......,34,12,124,67] [123,244,12,.......,134,122,24,02] [67,13,245,.......,112,51,92,181] [65,09,67,.......,78,66,76,215]

...........

D( )

“matching function”

8

We refer to this as Exhaustive Search!!!

p = {p1, p2} p1 p2

Sampling?

“Possible Source Warps”

• How do we sample every warp parameter value?

9

p = {p1, p2} p1 p2

Sampling?

“Possible Source Warps”

• How do we sample every warp parameter value?

∆p2

∆p1

9

I T

W(x1; p)

x1

D(p) =

M

X

i=1

||I(W(xi; p)) − T(xi)||2

I T

Measures of Similarity

“Model” “Source Image”

10

• Sampling strategy dependent on similarity measure,
• Sum of squared differences (SSD)

Measures of Similarity

• Sampling strategy dependent on similarity measure,
• Sum of squared differences (SSD)

“Vector Form”

11

D(p) = ||I(p) − T(0)||2

I T

“Model” “Source Image”

I T z

D(p) = −I(p)T T(0)

Measures of Similarity

“Template” “Source Image”

12

“Can be done efficiently using 2D convolutions....”

• Sampling strategy dependent on similarity measure,
• Linear Correlation,

Sampling

• Shannon sampling theorem:

13

if you sample densely enough (at the Nyquist rate) you can perfectly reconstruct the original data.

• We will show the desired sampling rate is

dependent on the “centre frequency” of the salient edges.

Sampling

• Shannon sampling theorem:

13

if you sample densely enough (at the Nyquist rate) you can perfectly reconstruct the original data.

• We will show the desired sampling rate is

dependent on the “centre frequency” of the salient edges.

Nyquist Rate:- Signal must be sampled at twice the highest frequency!!!

Under Sampling = “Aliasing”

• Common phenomenon
• Wagon wheels rolling the wrong way in movies.

14

Under Sampling = “Aliasing”

• Common phenomenon
• Wagon wheels rolling the wrong way in movies.

14

Image = Summation of Oriented Edges

• Well known that natural images can be represented as a

linear summation of oriented edges,

15

...

... ... ... ... ...

∗

“Useful as edges capture ONLY relative local change in intensity....”

Sensitivity to Shift

16 Warp Pixel Intensity Pixel Intensity Pixel Coordinates

D(p)

(p)

Warp(p) Pixel Coordinates

D(p)

T(0)

I(p) “image”

“model”

Sensitivity to Shift

16 Warp Pixel Intensity Pixel Intensity Pixel Coordinates

D(p)

(p)

Warp(p) Pixel Coordinates

D(p)

T(0)

I(p) “image”

“model”

Sensitivity to Shift

16 Warp Pixel Intensity Pixel Intensity Pixel Coordinates

D(p)

(p)

Warp(p) Pixel Coordinates

D(p)

∆ph

∆pl

T(0)

I(p) “image”

“model”

p = {p1, p2} p1 p2

Sensitivity to Shift

“Possible Source Warps”

• Clear that sampling is linked to center frequency of edge.

17

∆pl

p = {p1, p2} p1 p2

Sensitivity to Shift

“Possible Source Warps”

• Clear that sampling is linked to center frequency of edge.

18

∆ph

Sensitivity to Shift

• Edges can be thought to have a center frequency/wavelength,

19

• Clear that wavelength of the most “salient” edge is proportional to

sample size:-

λ ∝ ∆p

Sensitivity to Shift

• Edges can be thought to have a center frequency/wavelength,

19

λ

• Clear that wavelength of the most “salient” edge is proportional to

sample size:-

λ ∝ ∆p

Sensitivity to Shift

• Edges can be thought to have a center frequency/wavelength,

19

λ

• Clear that wavelength of the most “salient” edge is proportional to

sample size:-

λ ∝ ∆p

Beyond Translation

• Is sensitivity to shift only for translation?

“Motion Field for Translation”

20

Beyond Translation

“Motion Field for Scale”

21

• Is sensitivity to shift only for translation?

Beyond Translation

“Motion Field for Rotation”

22

• Is sensitivity to shift only for translation?

Beyond Translation

23

Today

• Exhaustive Search & Sampling
• Motivation for Descriptors
• Overcoming the Curse of Dimensionality in Search

24

Primary Visual Cortex

25

            

Spatial Sensitivity

26

Spatial Sensitivity

27

Kingdom, Field, Olmos, 2007

Hierarchical Learning

28

View-tuned cells Complex Simple

Bob Crimi

Hierarchical Learning

28

View-tuned cells Complex Simple

Bob Crimi

V1

V2/V4

IT

Ventral Visual Stream

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint change.

• Two options to match local image patches:-

29

“1D Patch” “Distorted 1D Patch”

Source: A. C. Berg

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint change.

• Two options to match local image patches:-

29

“1D Patch” “Distorted 1D Patch”

Source: A. C. Berg

“match”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint change.

• Two options to match local image patches:-
• 1. simultaneously estimate the distortion and position of matching patch

30

“1D Patch” “Distorted 1D Patch”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint change.

• Two options to match local image patches:-
• 1. simultaneously estimate the distortion and position of matching patch

30

“1D Patch” “Distorted 1D Patch” “align”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint change.

• Two options to match local image patches:-
• 1. simultaneously estimate the distortion and position of matching patch

30

“1D Patch” “Distorted 1D Patch” “align”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint change.

• Two options to match local image patches:-
• 1. simultaneously estimate the distortion and position of matching patch

30

“1D Patch” “Distorted 1D Patch” “align” “match”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint and/or illumination change.

• Two options to match patches:-
• 1. simultaneously estimate the distortion and position of matching patch.
• 2. to “blur” the template window performing matching coarse-to-fine.

31

“1D Patch” “Distorted 1D Patch”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint and/or illumination change.

• Two options to match patches:-
• 1. simultaneously estimate the distortion and position of matching patch.
• 2. to “blur” the template window performing matching coarse-to-fine.

31

“1D Patch” “Distorted 1D Patch” “blur”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint and/or illumination change.

• Two options to match patches:-
• 1. simultaneously estimate the distortion and position of matching patch.
• 2. to “blur” the template window performing matching coarse-to-fine.

31

“1D Patch” “Distorted 1D Patch” “blur” “match”

Handling Geometric Distortion

• As pointed out in seminal work by Berg and Malik (CVPR’01)

the effectiveness of SSD will degrade with significant viewpoint and/or illumination change.

• Two options to match patches:-
• 1. simultaneously estimate the distortion and position of matching patch.
• 2. to “blur” the template window performing matching coarse-to-fine.

31

“1D Patch” “Distorted 1D Patch” “blur” “match”

Option 2 is attractive, low computational cost!

x

x

x

P

Not Always Zero Always Zero

x

P Px

Not Always Zero Always Zero

x

x

φ{x} = Px

x

φ{x} = Px

x

φ{x} = Px

x

φ{x} = Px

P ∈ G

P ∈ G

“Similarity” “Rotation” “Translation” “Circular Shift”

P ∈ G

“Similarity” “Rotation” “Translation” “Circular Shift”

“Similarity” “Rotation” “Translation” “Circular Shift”

φ{x} = 1 |G| X

P∈G

Px

“Similarity” “Rotation” “Translation” “Circular Shift”

φ{x} = 1 |G| X

P∈G

Px

“Similarity” “Rotation” “Translation” “Circular Shift”

φ{x} = X

P∈G

Px

“Similarity” “Rotation” “Translation” “Circular Shift”

φ{x} = X

P∈G

Px

“throws away information”

What About Blurring?

37

“Blur Kernel” “Edge Filter” “Edge Blur Filter”

∗

What About Blurring?

37

“Blur Kernel” “Edge Filter” “Edge Blur Filter”

∗

What About Blurring?

38

“Blur Kernel” “Edge Filter” “Edge Blur Filter”

∗

“Power Normalized”

What About Blurring?

38

“Blur Kernel” “Edge Filter” “Edge Blur Filter”

∗

“Power Normalized”

What About Blurring

• Clearly, blurring a high-frequency edge filter simply lowers the

centre frequency (not what we want).

39

λb > λe

“High Frequency Edge Wavelength” “Blurred Edge Wavelength”

∗

Sparseness and Positiveness

• Blurring only works if the signals being matched are sparse

and positive.

• Unfortunately natural images are neither.
• Combination of oriented filter banks and rectification can

remedy this problem with little loss in performance.

...

... ... ... ... ...

“Rectification”

40

r

Sparseness and Positiveness

• Blurring only works if the signals being matched are sparse

and positive.

• Unfortunately natural images are neither.
• Combination of oriented filter banks and rectification can

remedy this problem with little loss in performance.

“Rectification”

41

r · r

“Non-Linearly sets Centre Frequency to Zero”

Sensitivity to Shift

42 Warp Edge Energy Pixel Coordinates

D(p)

(p)

No Blurring

Sensitivity to Shift

42 Warp Edge Energy Pixel Coordinates

D(p)

(p)

No Blurring

Sensitivity to Shift

43 Warp Rectified Edge Pixel Coordinates

D(p)

(p)

Gaussian Blur

Sensitivity to Shift

43 Warp Rectified Edge Pixel Coordinates

D(p)

(p)

Gaussian Blur

Sensitivity to Shift

44 Warp Rectified Edge Pixel Coordinates

D(p)

(p)

Histogram Blur

Sensitivity to Shift

44 Warp Rectified Edge Pixel Coordinates

D(p)

(p)

Histogram Blur

I(p) φ{I(p)}

Sparseness and Positiveness

• Comes at additional computational cost, as new

representation is F times larger (where F is the number of filters employed).

45

φ{} = image descriptor function

Reminder - SIFT Descriptor

46

• 1. Compute image gradients
• 2. Pool into local histograms
• 3. Concatenate histograms
• 4. Normalize histograms

Relationship to Deep Learning

47

Relationship to Deep Learning

47

Sensitivity of VGG to Geometric Variation

48

conv1 64@ (54x54) conv2 256@ (27x27) conv3 384@ (13x13) conv4 384@ (13x13) conv5 256@ (13x13) fc-6 (4096)

image patch 3@ (224x224)

SNR (dB) conv1 conv2 conv3 conv4 conv5 fc-6 fc-7

fc-7 (4096)

Sensitivity of VGG to Geometric Variation

48

conv1 64@ (54x54) conv2 256@ (27x27) conv3 384@ (13x13) conv4 384@ (13x13) conv5 256@ (13x13) fc-6 (4096)

image patch 3@ (224x224)

SNR (dB) conv1 conv2 conv3 conv4 conv5 fc-6 fc-7

fc-7 (4096)

Sensitivity of VGG to Geometric Variation

48

conv1 64@ (54x54) conv2 256@ (27x27) conv3 384@ (13x13) conv4 384@ (13x13) conv5 256@ (13x13) fc-6 (4096)

image patch 3@ (224x224)

SNR (dB) conv1 conv2 conv3 conv4 conv5 fc-6 fc-7

fc-7 (4096)

Today

• Exhaustive Search & Sampling
• Motivation for Descriptors
• Overcoming the Curse of Dimensionality in Search

49

Exhaustive Search

p = {p1, p2} p1 p2

“Possible Source Warps”

arg min

p ||I(p) − T (0)||2 2

p = 0 p 6= 0

d = dim(p)

where:

Exhaustive Search

p = {p1, p2} p1 p2

“Possible Source Warps”

arg min

p ||I(p) − T (0)||2 2

p = 0 p 6= 0

∆p

||∆p||2 = ✏

d = dim(p)

where:

• One can see that as accuracy linearly increases the number
• f required training samples increases exponentially as a function
• f .

Exhaustive Search

d

• O(1/ϵd)

O(Cd log 1/ϵ)

O(Cd

1 + C2 log 1/ϵ)

1/ϵ

Tian &

1/✏

d = dim(p)

where:

Can we do better?

• O(1/ϵd)

O(Cd log 1/ϵ)

O(Cd

1 + C2 log 1/ϵ)

1/ϵ

Tian & Narasimhan [ICCV 2013]

Can we do better?

• O(1/ϵd)

O(Cd log 1/ϵ)

O(Cd

1 + C2 log 1/ϵ)

1/ϵ

Tian & Narasimhan [ICCV 2013]

Data Driven Descent

Tian & Narasimhan 2012

Data Driven Descent

{T (∆pk)}K

k=1

Tian & Narasimhan 2012

Data Driven Descent

{T (∆pk)}K

k=1

T (0)

Tian & Narasimhan 2012

Data Driven Descent

Tian & Narasimhan 2012

Data Driven Descent

T (∆pi) I(p) T (0)

Tian & Narasimhan 2012

Data Driven Descent

Tian & Narasimhan 2012

Data Driven Descent

“inverse composition”

p ! p −1 ∆pi

Tian & Narasimhan 2012

Data Driven Descent

Tian & Narasimhan 2012

Data Driven Descent

Tian & Narasimhan 2012

Data Driven Descent

Tian & Narasimhan 2012

Tian & Narasimhan 2012

Tian & Narasimhan 2012

Can we do better?

• O(1/ϵd)

O(Cd log 1/ϵ)

O(Cd

1 + C2 log 1/ϵ)

1/ϵ

Tian & Narasimhan [ICCV 2013]

Can we do better?

• O(1/ϵd)

O(Cd log 1/ϵ)

O(Cd

1 + C2 log 1/ϵ)

1/ϵ

Tian & Narasimhan [ICCV 2013]
