The Kind 2 Model Checker

Adrien Champion Christoph Sticksel Alain Mebsout Cesare Tinelli

Kind 2

Kind 2 is for safety analysis

Reactive System Model (Lustre) Safety Property (Extension of Lustre) State Transition System

hs, I(s), T(s, s0)i

Proof Certificate Counter- example

safe unsafe P

Kind 2 has multiple inductive, cooperating engines

BMC k-induction IC3 invariant discovery SMT SMT SMT SMT Supervisor

Kind 2 exploits the modularity of the system

Component-level invariant discovery Assume-guarantee contracts

node max (x:real) returns (m:real); let m = x -> if x > pre x then x else pre x; tel node avg (x,y:real) returns (a:real); (*@contract assume x <= y; guarantee x <= a and a <= y; *) let a = (x + y) / 2.0; tel node sav (x:real) returns (s:real); (*@contract assume x > 0.0 and x > pre x; guarantee s <= max(x); *) let s = avg(x -> pre s, x); tel

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

l 1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

l 1 2 3 4

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

Kind 2 reasons compositionally and modularly about the system

Bottom-up verification of contracts of nodes one at a time Abstract behavior of components to their contract and refine with implementation only on failure.

l 1 2 3 4

LFSC script contains

• Proofs from CVC4
• k-inductive argument

Independently checkable

Kind 2 certifies its results with counterexamples and proofs

SMT proofs SMT proofs SMT proofs

Φ | = P Φk ∧ T k | = Φ0 I ∧ T k | = Φ ⇤Φ ⇤P

We have just released Kind 2 v1.0.0

Download or try it out at http://kind.cs.uiowa.edu/ Ongoing and Future Work

• Explicitly mode aware contracts
• Test case generation from contracts
• Compilation to Rust
• Parameterized reasoning through arrays

Kind 2 is competitive

1 10 100 1000 10000 100 200 300 400 500 600 700 800 Time in s Number of benchmarks solved Kind 2 (866 solved) jKind (863 solved) NuXmv (842 solved) PKind (780 solved) Zustre (845 solved)
