The Journey of Continuous Improvement in the Reliability and Availability of the OPAL Reactor Jason Chakovski & Andrew Frikken IGORR 18 Sydney, Australia OPAL Reactor 20MW Thermal Multi-Purpose Reactor Facility 16 LEU FAs

slide-1
SLIDE 1

The Journey of Continuous Improvement in the Reliability and Availability of the OPAL Reactor

IGORR 18 – Sydney, Australia

Jason Chakovski & Andrew Frikken

slide-2
SLIDE 2
slide-3
SLIDE 3

OPAL Reactor

  • 20MW Thermal Multi-Purpose

Reactor Facility

  • 16 LEU FAs
  • Compact Core (~300kW/L)
  • D2O Reflector
  • Light Water Cooled and Moderated
  • 2 x Independent and Diverse

Protection and Shutdown Systems

  • Inherent Passive Safety Systems
  • >5000 I/O Control and Monitoring

System

slide-4
SLIDE 4

OPAL Reactor

slide-5
SLIDE 5

OPAL Reactor

slide-6
SLIDE 6

OPAL Utilisation

Neutrons for Health Neutrons for Science Neutrons for Industry

slide-7
SLIDE 7

Reactor Based Health Products

Product Indication

Mo-99

Bulk export

Gentech /Tc-99m

Organ imaging of the liver, lung, bone, kidney & heart

Sodium Iodide I-131

Hyperthyroidism & Thyroid cancer

Quadramet Sm-153

The relief of bone pain in patients with painful osteoblastic skeletal metastases

Chromium Cr-51

The determination of GFR rate

Lutetium-177

Diagnosis and treatment of Neuroendocrine. Tumors

slide-8
SLIDE 8

Neutrons – For Health

10,000 hospitals in the world use radioisotopes 40 million patients per year

Diagnostics (cardiology,

  • ncology, neurology)

Therapy / palliative care

10% 90%

slide-9
SLIDE 9

ANM Mo-99 Facility OPAL ANM Mo-99 Facility ANM ILLW Transfer Synroc Waste Plant Irradiated LEU Targets

slide-10
SLIDE 10

OPAL Reactor Processing Plant (ANM) Global distribution Local distribution

  • f finished goods

Hospital and Pharmacy Clinical Imaging Health Outcomes LEU U235 targets irradiated in OPAL Mo-99 separated and purified Bulk Mo-99 Shipped to meet global demand Tc-99m Generators dispensed and transported Tc-99m eluted and combined with cold kits Product administered to patients for imaging Imaging helps diagnosis & leads to appropriate treatments

Supply Chain

Challenging supply chain

7-12 days 1 day 1 day 1 day 5 minutes

slide-11
SLIDE 11

Neutrons for Science

slide-12
SLIDE 12

Neutron Beam Instruments at OPAL

Platypus

(Neutron Reflectometer)

Wombat

(Hi-Intensity Powder Diffractometer)

Kowari

(Residual Stress / Strain Scanner)

Koala

(Single Crystal Laue Diffractomter)

Quokka

(SANS)

Echidna

(Hi-Resolution Powder Diffractometer)

Taipan

(Thermal Triple Axis Spectrometer)

slide-13
SLIDE 13

Kookaburra (Ultra Small Angle Neutron Scattering) Pelican (Time of Flight Polarised Spectrometer) Sika (Cold Triple Axis Spectrometer) Bilby (SANS) Dingo (Neutron Radiography) Emu (Backscattering)

Neutron Beam Instruments at OPAL

slide-14
SLIDE 14

Neutrons – For Industry

Source: Topsil and Yole Development

  • High and very high voltage markets
  • Low volume specialty products
  • High and medium voltage markets
  • Medium volume specialty products

NTD - Silicon

slide-15
SLIDE 15

Neutrons for Industry Neutron Activation Analysis

energy → element identification intensity → concentration

slide-16
SLIDE 16

ANSTO Corporate Plan

slide-17
SLIDE 17

Investment in Asset ANSTO Asset Management System

Asset Management Policy ANSTO Corporate Plan Strategic Asset Management Plan

17

“Enabling ANSTO to realise best value and outcomes from assets to achieve strategic objectives”

slide-18
SLIDE 18

RISK & REVIEW ORGANISATION & PEOPLE ENABLERS INFORMATION & KNOWLEDGE ENABLERS LIFECYCLE DELIVERY ACTIVITIES ASSET MANAGEMENT DECISION MAKING ASSET MANAGEMENT STRATEGY & PLANNING

Acquire Operate Dispose Maintain

INFORMATION & KNOWLEDGE RISK & REVIEW ORGANISATION & PEOPLE

Competence management Asset management leadership Organisational structure, roles & responsibilities Procurement and supply chain management

ASSET MANAGEMENT DECISION MAKING

Systems engineering Reliability engineering Shutdown /

  • utage mgmt

Resource management Configuration management Tech standards & legislation Fault & incident response

LIFECYCLE DELIVERY ACTIVITIES

Asset operations / production Asset creation & acquisition Maintenance delivery Decommissioning & disposal Asset information strategy and standards Asset information systems Data & information management

ASSET MANAGEMENT STRATEGY & PLANNING

Demand analysis Asset management planning (AM Plans) Asset management strategy & objectives (Strategic Asset Management Plan - SAMP) Asset Management Policy Strategic planning

ANSTO Corporate Plan

Operations (Supply) plans Capital investment program Maintenance strategies Capital investment decision making Operations decision making Maintenance decision making Resourcing strategy Lifecycle value realisation Shutdown /outage strategy

ASSET MANAGEMENT FRAMEWORK

Organisational culture RISK MANAGEMENT, REVIEW AND ANALYSIS MONITORING, REVIEW AND IMPROVEMENT Management review, audit and assurance Asset management system monitoring Asset performance and health monitoring Management of change Asset costing and valuation Stakeholder engagement Risk assessment and management

Contingency planning & business resilience

Sustainable development

slide-19
SLIDE 19

Condition Monitoring Task feasible, effective and worth doing? Scheduled Restoration Task feasible, effective and worth doing? Scheduled Discard Task feasible, effective and worth doing? Failure Finding Task feasible, effective and worth doing? Condition Monitoring Task feasible, effective and worth doing? Fixed Time Restoration Task feasible, effective and worth doing? Fixed Time Discard Task feasible, effective and worth doing? Failure Finding Task feasible, effective and worth doing?

HIDDEN

Safety or Environmental Operational Loss Repair Only CONDITION MONITORING FIXED TIME RESTORATION FIXED TIME DISCARD REDESIGN NO SCHEDULED MAINTENANCE

(Redesign may be desirable)

FAILURE FINDING

Reliability Engineering RCM Approach

Multiple failure affects safety or environment?

FAILURE MODE EVIDENT

When is a task “feasible, effective and worth doing”?

slide-20
SLIDE 20

Maintenance Strategy

slide-21
SLIDE 21

Operational Excellence

  • Managing the Strategic Planning

Process

  • Managing and Leading People
  • Driving Business Improvement
  • Integrated Business Planning
  • Managing Demand
  • Managing Internal and External

Supply Chain

  • Decision Making in Line with

Business Objective

  • Best For Business Decision Making
slide-22
SLIDE 22

50 100 150 200 250 300 350 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 39 94 128 248 286 282 270 296 290 300 305

OPAL Safe Days at Power - Calendar Year

slide-23
SLIDE 23

86 88 90 92 94 96 98 100 2009 2010 2011 2012 2013 2014 2015 2016 90,74 93,22 92,02 96,92 93,66 96,53 97,98 98,74

OPAL Reliability - Calendar Year

slide-24
SLIDE 24

10 20 30 40 50 60 70 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 63 8 9 21 6 11 18 7 8 6 8 4

Reactor Trip per Year

Trip 1 Trip 2

slide-25
SLIDE 25

2 4 6 8 10 12 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017

Reactor Trip From Human or Procedural Error

slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29

OPAL Prioritisation Process

slide-30
SLIDE 30

20 Year Schedule

slide-31
SLIDE 31

Investment in People

slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34
