AECS

Research Reactor (RR) Types

• Miniature neutron source reactor (MNSR) of 30kW

to about 100MW(t) RR (1–10 MW more common)

• Industrial manufacturer supplied RR to custom­built

indigenous RR

• Neutron flux ranging from 10

11 to 10 14

– Neutron beam facilities – Sample irradiation facilities (radioisotope production, material testing) – Rabbit facility for NAA – Analytical and other services facilities

AECS

Enrichment fuel U­235: HEU 90%

• No. of fuel pins:

344

• No. of dummy pins:

3

Reflector:

Beryllium

MNSR Reactor Characteristics

Moderator:

Water & Beryllium

Type:

Tank­in­Pool

Low Power Research Reactor

Nominal power:

30Kw

Maximum Flux:

1E12 n.cm

­2

.s

­1

Reactor core:

Cylindrical 230mm

AECS

Criticality: Mar15,1996

Research Reactor Utilisation Techniques and Purposes

Education & Training Neutron Activation Analysis (NAA) Radioisotope Production Neutron Radiography Fuel testing and qualification Supporting power reactor programmes Neutron Scattering Material science investigations Neutron transmutation doping

AECS

Development of different Disciplines

Radiochemistry

Analytical applications Isotopic ad tracer techniques Separations for trams uranium elements

Ion beam techniques PGNAA Short lived radionuclides Cyclic Psedocyclic NAA, RNAA Thermal, epithermal Mossbauer Spectrometry Age determination C­14 Radio pharmaceutical “new” isotopes Super heavy elements SHE Actinide chemistry Fuel cycle AECS

Analytical applications Epithermal NAA Cyclic NAA PsedoCyclic NAA INAA by delayed neutron k

NAA

Prompt gamma NAA Large Sample NAA Radiochemical NAA

AECS

Major felids of applications

Geological mapping Environmental mentoring Trace elements in agriculture and food

industry

Certification of reference materials Toxic elements In biological samples

( blood, hair, tissue)

Archeology studies

AECS

International Comparison Program,

Proficiency test (ISE, IRNS, IAEA)

Neutron Activation Analysis

AECS

Total number of irradiated samples

1530 1414 1290 1614 957 1257 981 1038

500 1000 1500 2000

1999 2000 2001 2002 2003 2004 2005 2006

Year Number of samples

Total number of irradiated samples

Biological Soil Plant Sludge Phosphate Water Others Coal Pottary Filter Foils Sedem ent 500 1000 1500 2000 2500 3000

Sample type Num ber of sample

Total samples 10049

AECS

Clean room Samples preparation lab. measurement lab. Samples container

AECS

Neutron Activation Analysis Laboratory

IAEA PROJECT CODE RAW/2/005 94.6 Global Ratio % 94.5 Ratio 94.7 Ratio % 310 293 Total 285 270 Total

Max Score Score Management requirements Max Score Score Management requirements

• A. Fajgelj, J. Kucera

Auditors

05/07/2004

Audit date

Syria, AECS, INAA

Participant's name INTERNATIONAL ATOMIC ENERGY AGENCY

AECS

Research Reactor (RR) Utilisation ­ Applications

Education and Training

• Science teachers & students
• Engineering teachers & students
• Nuclear power plant operator trainees
• Operational health physicists
• Regulators
• Public awareness

AECS

Research Reactor issues and needs

• Need exists for beneficial utilization to be the basis for
• peration & utilization of RR in safe and secure manner.
• RR as the symbol of nuclear science and technology
• RR as the cradle of all development and availability of nuclear

technology

• RR utilisation needs and requirements for safety & security

upgrades vis­à­vis resources availability and national support/ priorities/ policies

• RR fuel issues – conversion of HEU fuel to LEU fuel;

development & qualification of high density LEU fuels

AECS

Thanks for your attention

AECS

MNSR Core View
