The future of cyber security exercises more than just education? The Problem: how can we run large cyber security exercises once a week? 2 Stepping back Looking at the configuration management problem, e.g., the gap

slide-1
SLIDE 1

The future of
 cyber security exercises


more than just education?

slide-2
SLIDE 2

The Problem:

2

  • how can we run large cyber security exercises once a week?
slide-3
SLIDE 3

Stepping back

3

  • Looking at the configuration management problem,


e.g., the “gap” between how we talk about network and
 what we need to do to get it really working.

  • Goal: Simplify the setup of complex network
  • Towards a tool that allows specification of higher-level

network-wide abstractions ?


  • “A programming language is low level when its programs

require attention to the irrelevant.”


Epigrams on Programming — Alan J. Perils

slide-4
SLIDE 4

1/15/2008 1/15/2008

4

slide-5
SLIDE 5

1/15/2008 1/15/2008

5

slide-6
SLIDE 6

1/15/2008 1/15/2008

`

6

slide-7
SLIDE 7

1/15/2008 1/15/2008

7

slide-8
SLIDE 8

Configuration Management Problem

Whiteboard Idea ➠ Network Configuration?

8

interface FastEthernet0/0 description Interface 1b.AS1 -> 1a.AS1 ip address 10.0.0.14 255.255.255.252 ip ospf cost 1 no shutdown duplex auto speed auto inferface FastEthernet0/1 description Interface 1b.AS1 -> 3a.AS3 ip address 10.0.0.9 255.255.255.252

?

slide-9
SLIDE 9

9

1. Development of the abstract descriptions of networks and services themselves;
 2. Building a “compiler” to convert abstractions into real network configurations;
 3. Extending formal, mathematical methods to provide proofs

  • f network properties; and


4. Test and verification of the above methods.


Outline

slide-10
SLIDE 10

10

Abstract model of: TOPOLOGY

mple subgraphs.

  • Fig. 1.

Cartesian product of a path and a single edge forms a ladder networ

  • Fig. 2.

Tensor product.

  • Fig. 3.

Strong and Lexicographic products give the same result in this

  • Fig. 4.

Lexicographic product showing non-commutativity when com with Fig. 3.

– to Hobart, Alice Springs and Darwin.

  • Fig. 6.

AARNET router level network 2009.

Matt Roughan et al.

slide-11
SLIDE 11

11

Abstract model of: ROUTING

What algebraic properties are associated with global

  • ptimality?

Distributivity

L.D : a ⊗ (b ⊕ c) = (a ⊗ b) ⊕ (a ⊗ c), R.D : (a ⊕ b) ⊗ c = (a ⊗ c) ⊕ (b ⊗ c).

What is this in sp = (N∞, min, +)?

L.DIST

: a + (b min c) = (a + b) min (a + c),

R.DIST

: (a min b) + c = (a + c) min (b + c).

  • T. Griffin (cl.cam.ac.uk)

Exploring the Stratified Shortest-Paths Problem June 2010 7 / 33

(Left) Local Optimality

Say that L is a left-locally optimal solution when L = (A ⌦ L) I. That is, for i 6= j we have L(i, j) = M

q∈V

A(i, q) ⌦ L(q, j) = M

(i, q)∈E

w(i, q) ⌦ L(q, j), In other words, L(i, j) is the best possible value given the values L(q, j), for all out-neighbors q of source i.

  • T. Griffin (cl.cam.ac.uk)

Exploring the Stratified Shortest-Paths Problem June 2010 8 / 33

Tim Griffin et al.

slide-12
SLIDE 12

ANK (AutoNetkit): The “Compiler”

12

Compiler Network Model Policy Fragments Netkit Configuration Files Verification

Netkit Host

Network Description Resource Allocation Deployment Plugins Physical & Logical Topologies

Support more Routing Protocols (RIP, IS-IS) Deploy to Cisco and Juniper routers Add GUI, Network Design Formal Methods for Verification New Plugins (Optimisation, Analysis)

slide-13
SLIDE 13

Simulated & software routers Emulated Routers (real router code)

13

  • Cisco’s CSR1000v





  • Juniper’s Junosphere







  • NetKit / Quagga (Roma Tre University)
  • C-BGP (Bruno Quoitin)
  • ….


Deployment Platforms

slide-14
SLIDE 14

Configuration Management Cycle

Networks consist of services and infrastructure.

High-level abstractions


(e.g. SLAs, constraints)

Deploy to real network Model


(e.g. emulated network)


Measure deployment 14

slide-15
SLIDE 15

The Topology Zoo

http://topology-zoo.org/

15

slide-16
SLIDE 16

ANK: Explore what matters

Draw, auto-configure, auto-deploy: autonetkit -f bad-gadget.graphml --deploy

16

AS Y AS X

prefix p BR = Border Router RR = Route Reflector = BGP session = Physical link 3 3 3 BR1 RR3 3 3 3 BR3 2 2 2

slide-17
SLIDE 17

Applications

17

  • Cyber Security Exercises

  • Scalability Evaluation (e.g., for the RPKI/BGPsec)


with “real-world” complexity


  • “Network Flight Simulator”


for operators to play


  • Later: configure real networks
  • But how about: a new paradigm how we view network

and system integration.

slide-18
SLIDE 18

Conclusion

18

  • Hands-on Cyber Labs are a good learning source for

“students” (or should i say: “blue teams”?).

  • Sharpens our perspective of networks as a whole: services,

infrastructure, security.

  • But also a good environment to study what “high-level

abstractions” work well?

  • In the future this will change how we talk, view and

configure networks — at all levels.



  • ( Plus: Cyber Security Labs are good fun. :-) )
slide-19
SLIDE 19

Questions?

slide-20
SLIDE 20

Thank You!
