SLIDE 1
Craftsmanship and Technology 04.01.16
2
The Future of Craftsmanship in a Technologically Advancing Business - - PowerPoint PPT Presentation
The Future of Craftsmanship in a Technologically Advancing Business - - PowerPoint PPT Presentation
The Future of Craftsmanship in a Technologically Advancing Business Sub heading 24pts The Pico-second Laser Craftsmanship and Technology 2 04.01.16 Pico-second laser Craftsmanship and Technology 3 04.01.16 Traditional Full Route Process
SLIDE 2
SLIDE 3
Craftsmanship and Technology 04.01.16
3
Pico-second laser
SLIDE 4
Traditional Full Route Process
Craftsmanship and Technology 04.01.16
1
Stage Description Resource 00040 MAN.DATA CREATE L/UP ENGRAVERS 00042 ADD FROSTING DIAGRAM ENGRAVERS 00045 CUST APPROVE DESIGN CUSTOMER 00050 PRODUCE REDN (K605) KUHLMANN 00070 FINISH/MK/VERIFY RP ENGRAVERS 00079 STRESS RELIEVE RP STRESS RELIEVE 00080 HARDEN & TEMPER RP HARDENING 00090 SINK MATRIX (CALMAX) SINKING 00100 1ST S/RELIEVE MAT STRESS RELIEVE 00110 2ND BLOW (MAT) SINKING 00113 2ND S/RELIEVE MAT STRESS RELIEVE 00115 3RD BLOW (MAT) SINKING 00120 FIN TURN & EDGE MAT TURNING 00150 FINISH/MK/VERIFY MAT ENGRAVERS 00159 STRESS RELIEVE MAT STRESS RELIEVE 00160 HARDEN & TEMPER MAT HARDENING 00165 GRIND I/EDGE OF MAT GRINDING 00170 SINK WP (CALMAX) SINKING 00180 1ST S/RELIEVE WP STRESS RELIEVE 00190 2ND BLOW (WP) SINKING 00193 2ND S/RELIEVE WP STRESS RELIEVE 00195 3RD BLOW (WP) SINKING 00200 TURN BODY & AL (WP) TURNING 00210 FMV WP & CHECK PHOTO ENGRAVERS 00219 STRESS RELIEVE WP STRESS RELIEVE 00220 HARDEN & TEMPER WP HARDENING 00230 CHECK/ADJUST EDGE GRINDING 00240 A/L & DEBURR WP GRINDING
Stage Description Resource 00010 SINK DIE (CP1V) SINKING 00020 1ST S/RELIEVE DIE STRESS RELIEVE 00030 2ND BLOW DIE SINKING 00032 2ND S/RELIEVE DIE STRESS RELIEVE 00034 3RD BLOW DIE SINKING 00040 TURN BODY (PCU DIE) TURNING 00041 CHECK BODY DIAMETER 81900003 00043 BACK OFF (PCU DIE) TURNING 00047 FINISH TURN NECK TURNING 00048 FINISHING (PCU DIE) FINISH DIE 00049 STRESS RELIEVE DIE STRESS RELIEVE 00050 HARDEN & TEMPER DIE HARDENING 00060 GRIND BASE (PCU DIE) GRINDING 00070 CLEAN & INSPECT DIES CLEAN 00100 IDENTITY STAMP DIE LASER MARK 00110 CHECK & VERIFY MARK 81900003
SLIDE 5
Craftsmanship and Technology 04.01.16
5
Laser Die Production Process
SLIDE 6
Name of presentation 00.00.00
1
Turn Die
SLIDE 7
Name of presentation 00.00.00
1
Harden Die
SLIDE 8
Name of presentation 00.00.00
1
Polish Die
SLIDE 9
Name of presentation 00.00.00
1
Laser-cut Die
SLIDE 10
Name of presentation 00.00.00
1
Laser-frost Die
SLIDE 11
Name of presentation 00.00.00
1
Coat Die
SLIDE 12
Craftsmanship and Technology 04.01.16
12
The Fifth Effigy
SLIDE 13
Craftsmanship and Technology 04.01.16
13
The Public Launch of the Fifth Effigy
SLIDE 14
Craftsmanship and Technology 04.01.16
14
The Public Launch of the Fifth Effigy
SLIDE 15
Craftsmanship and Technology 04.01.16
15
The Public Launch of the Fifth Effigy
SLIDE 16
Craftsmanship and Technology 04.01.16
16
The Public Launch of the Fifth Effigy
SLIDE 17
Craftsmanship and Technology 04.01.16
17
The Customer’s Perception
SLIDE 18
Craftsmanship and Technology 04.01.16
18
The Perception of Craftsmanship
SLIDE 19
Craftsmanship and Technology 04.01.16
19
The Perception of Craftsmanship
SLIDE 20
Craftsmanship and Technology 04.01.16
20
The Perception of Craftsmanship
SLIDE 21
Craftsmanship and Technology 04.01.16
21
The Perception of Craftsmanship
SLIDE 22
Craftsmanship and Technology 04.01.16
22
The Response?
SLIDE 23
The Response?
- Champion the technology?
Craftsmanship and Technology 04.01.16
23
SLIDE 24
The Response?
- Champion the technology?
- Reject the technology?
Craftsmanship and Technology 04.01.16
24
SLIDE 25
The Response?
- Champion the technology?
- Reject the technology?
- Change the customer’s preconceptions?
Craftsmanship and Technology 04.01.16
25
SLIDE 26
Craftsmanship and Technology 04.01.16
26
Cave Painting
SLIDE 27
Craftsmanship and Technology 04.01.16
27
Lydian Stater
SLIDE 28
Craftsmanship and Technology 04.01.16
28
Wyon’s portrait of George IV
SLIDE 29
Craftsmanship and Technology 04.01.16
29
Craftsmanship in Design
SLIDE 30
Craftsmanship and Technology 04.01.16
30
The Royal Mint’s Coin Design Team
SLIDE 31
Craftsmanship and Technology 04.01.16
31
The Phoenix Ascendant
SLIDE 32
Craftsmanship and Technology 04.01.16
32
The Phoenix Ascendant
SLIDE 33
Craftsmanship and Technology 04.01.16
33
The Phoenix Ascendant
SLIDE 34
Craftsmanship and Technology 04.01.16
34
The Phoenix Ascendant
SLIDE 35
Name of presentation 00.00.00
35
The Phoenix Ascendant
