The all new

by Kromer Co LLC

1

A totally new approach to Athletic Field Machines.

2

Evolutionary and Revolutionary

New concepts, improved capacity, increased reliability, lower cost of lifetime ownership.

The first Kromer CAD/CAM machine

3

Precision design and testing. Modular construction for manufacturing and

• maintenance. Lower cost-higher performance.

By customers, for customers.

4

Input from the above resulted in improved capacity, easier access, higher productivity, more speed, greatly enhanced ergonomics and convenience.

Precisely variable control of grooming on all surfaces

5

Ability to control down pressure hydraulically on harrow tines, blade and brush to effectively maintain the playing surface for safer, cushioned conditions. Can groom in locked or float position Ability to add water for dust control

• r to increase moisture to improve field conditions. Will rejuvenate hardened, dried surfaces quickly with just the

right amount of down pressure. Can groom a too wet surface so that it dries out more rapidly. Can groom with just the brush to level and restore appearance rapidly between tournament games.

More versatility with more options

6

Change with ease from grooming to painting, general purpose utility, natural to synthetic turf, extend the seasonality, spray chemicals, etc.

Easily change from painting to utility

7

One machine-one

• perator-increased

productivity.

Quick change attachments-no tools

8

More versatility, improved productivity.

Multipurpose natural and synthetic

9

Now one machine can do both types

• f fields which

saves both capitol and

• perating

expenses

Sideline Remove only option

10

Ability to remove sidelines, goal boxes, center circles, etc. as events change

Or remove end zones, logos, coaches boxes , etc

11

Greatly increases labor productivity and allows much more adaptability to change and schedule events

Synthetic Groomer in various sizes12

Includes tines for decompacting, infill spreading and leveling, magnet for metal pickup, and a double brush for grooming and appearance enhancements.

One machine for multipurpose venues

13

Can be used indoors and

• utdoors.

Honda 16.6 (18 gross) HP Twin V

14

Reliable, high quality, efficient, powerful engine. Certified by Honda for Kromer

• applications. Unmatched serviceability.

All hydraulic propulsion system

15

Top quality, thoroughly tested components. Hydro-Gear propelling pump, Sauer-Danfoss accessory pump and wheel motors, ASA Hydraulik oil cooler, Parker Hannifin hoses and fittings, Hypro paint pump.

16

Direct drive, direct coupled hydraulics

Lower maintenance, no loss of power due to belt slipping, fewer parts, more reliability, easy access.

17

Direct drive motors and wheel hubs

Eliminates transmission, differentials, axles, belts and guards, bushings, grease points, pinch points, exposed moving parts. A much stronger load bearing capacity at 7250 lbs at the rear wheels. Improved safety and ruggedness.

18

Accessibility ,strength, reliability, safety

Simplified assembly and maintenance. Modular design improves quality and reliability, and lowers cost of ownership over the life of the product.

19

Steering solid, precise, rugged, reliable

Proven, easy to hold a straight line steering for precise line striping, yard line marking, curb painting, chalking, and removing paint on synthetic surfaces.

20

Electrical controls, switches, gauges

Hour meter, pressure gauge, 12 volt charger outlet, rugged weather proof toggle switches. Graphics permanently infused and color coded into the paint.

21

Steering column gauges

Voltmeter, pressure gauge, front control toggles

22

Modular instrument panels

Easy access, color coded wiring, Waytek, Tyco Electronics, AMP components – top quality and reputation.

23

Easily removed for maintenance

Bench assembled and pretested assures high quality and reliability.

24

Solenoid controls

Solid terminals to control all hydraulic functions. Protected and accessible

25

Front panel easy access connectors

High quality commercial soft shell pin and socket for all front end connections.

26

Tank paint and spraying system

Custom designed with increased capacity has a 62.5 gal solution tank and a 2.5 gal fresh water rinse tank. Side opening lids provide easier fill with positive closures, no spillage. Easy Fast Fill™ Gulper pump means no more lifting of 70 lb paint pails-much safer and operator appreciated. Retractable hose reel paint and chemical wands easily accessible. Controls clearly marked and color coded.

Custom tank for productivity & safety

27

Chemical resistant rotomolded extremely durable tank. Reinforced for extra strength and capacity. Tank marked in gallons and liters for precision mixing of paint and

• chemicals. Sloped bottom and sump easy to clean and drain 100%. The fresh water

tank quickly cleans the paint nozzles, all the paint lines, manifolds and pump throughout the system of the variable Ultra Pressure System™.

Accessibility & Cleanability

28

Dual mixing nozzles in tank can also be used for cleaning and rinsing after use. Tank has larger opening for easy cleaning. No sharp edges or pockets within tank to allow residue buildup. Paint and chemical tank has a lockable lid so no spills occur.

Durable hoses, quality fittings & valves

29

Precision, durable brass fittings and quality hoses and connections are readily accessible.

Ultra Pressure System™ saves 50% on paint

30

The heart of the system is the Hypro/Kromer customized paint pump readily accessible for routine maintenance. The Ultra Pressure Paint System™ developed by Kromer uses up to 50% less

• paint. A

significant cost saving that produces crisp sharp lines with minimal turf disruption and no

• verspray. Helps

recoup machine costs.

Spraying system and Gulper pump

31

Spraying system for water dust control, chemical applications comes in 4 sizes and can be customized. The Gulper pump helps prepare for mixing paints or thicker chemicals by increasing the liquidity as it passes through the pump and mixes with water in the tank.

Spray boom and water fill

32

The spray system folds up easily for

• transport. The

water fill hose connection is readily accessible on the far right side. It can also be used to flush the tank, lines and manifiolds after using paint or chemicals with the pump providing pressure through the mixing nozzles in the tank.

Ergonomics

33

Ergonomics have been greatly improved with a roomier operator compartment. Easy access to controls are at the

• perator’s
• fingertips. All

controls clearly labeled and color coded for ease of

• peration. All

labels are infused into the paint for clarity and durability.

Operator Comfort

34

The suspension seat is adjustable is for operator weight and comfort with a wide range of positions available. Adjustable arm rests included. Radio/cell phone storage and cup holder conveniently

• placed. Single foot

pedal more responsive and smoother motion in forward and reverse. Convenient parking brake position. Excellent sight lines for field line marking with center

• perator position.

Precision Response

35

All controls clearly marked and color coded with graphics infused into the paint. Switches and solenoids provide quick response for painting tasks for crisp sharp

• lines. And precision, fully adjustable grooming on natural and synthetic turfs is

easily controlled. Engine throttle control can be set and easily maintained at various tasks depending on the requirements which can provide fuel efficiencies.

Warning Labels

36

Warning labels are all infused in red.

Painter head foot lift design

37

Painter head in down operating setting-

Painter Head Retraction with foot

38

Use of foot pedal greatly reduces effort required-

Painter head locking procedure

39

Final locking requires minimal effort of 5 lbs of lift.

Painter head fully locked up

40

Effort to lift has been reduced by 72%. Less operator fatigue mean better quality performance and productivity for all tasks.

Dramatic, Attractive, Safer Playing Fields

41

Kromer versatility means the operator can do more tasks with greater labor saving and productivity.

Easy Accessibility

42

Routine maintenance made easy. The operator can keep equipment in good condition. Service and durability provide lower cost to own

• ver a longer
• wnership

cycle.

Quality design, quality components =quality results

43

Paint Mixing Station –Save $1000!

44

Another way to save labor, time and money. The paint mixing station can reduce your up front paint costs, keep your paint mixed and ready to go indefinitely. Bulk purchases of paints in large quantity tote systems lowers your overall cost. With Kromer’s special pricing for the purchase of a Field Commander and a Paint Mixing Station together you can save an extra $1000 !
