Thank you to our sponsors! 4CORE ~ Sustainable Building Education Program Case Study #1 Built in 1998 4 occupants + 24 sled dogs Motivation: Necessity and conservation Uses: Garden, Durango Dog Ranch & fruit trees Basic

slide-1
SLIDE 1

Thank you to our sponsors!

slide-2
SLIDE 2

4CORE ~ Sustainable Building Education Program

slide-3
SLIDE 3

Case Study #1

 Built in 1998  4 occupants + 24 sled dogs  Motivation: Necessity and conservation  Uses: Garden, Durango Dog Ranch & fruit trees

slide-4
SLIDE 4

Basic collection and transfer

slide-5
SLIDE 5

Submersible pump with float switch connecting to a garden hose

Northern Tool and equipment for $50 Home Depot for $90

slide-6
SLIDE 6
slide-7
SLIDE 7

5 galvanized steel stock tanks

slide-8
SLIDE 8

Roof overhang and ice damage Removed in winter

slide-9
SLIDE 9
slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12

Case Study #2

 Double wall adobe home  Built in 2009  Uses: Landscaping (ornamental and fruit trees) and

eventually a small vegetable garden

 Home featured in the 2009 Energy Tour and

2010 Parade of Homes

slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21

Case Study #4

 1164 sq ft (interior dimension) straw bale home  Built in 2006  2 occupants  Additional costs under $1000  Purchased parts locally  Motivation: Water wells in subdivision believed to be

tainted by gas well drilling

 Uses: Household use, garden, limited landscaping

slide-22
SLIDE 22

Roof Pitch: Lowered to hold snow Staggered snow guards 1 piece gutters Trusses: 25 lbs over snow load requirements

slide-23
SLIDE 23

4ft overhangs protect straw bale exterior and provide additional surface area for catchment 1 of 2 downspouts

  • n east side of home
slide-24
SLIDE 24

4” PVC pipe 8x galvanized window screen Cleanouts

slide-25
SLIDE 25

1800 gallon cistern Contains

  • verflow and

access to valves for future 2nd cistern

slide-26
SLIDE 26

Cistern contains float valve and well pump

slide-27
SLIDE 27

1800 Gallon Cistern

 Water delivered 2 – 4 times per year at $100 per fill  Approximately 400 gallons of dead space at bottom  Vacuums out sediment once a year  ¼ cup of Clorox for full cistern  No freeze issues in cistern or pipes

slide-28
SLIDE 28

Reverse osmosis filter under kitchen sink for drinking water. GE off-the-self from Home Depot - $400

slide-29
SLIDE 29

Expansion Tank Pre-filter

slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32

DIY Rain Barrel Information

slide-33
SLIDE 33

Jeff Titus

Colorado Division of Water Resources 160 Rockpoint Dr, Ste E Durango Tech Center (970) 247-1845 jeff.titus@state.co.us
