SLIDE 1
Temperature Sensors
Mailani Neal
Project Objectives
2
Generate color-indicated animations
Clarify name + location conventions
Improve Python3 competency
Temperature Sensors Mailani Neal Project Objectives Generate - - PowerPoint PPT Presentation
Temperature Sensors Mailani Neal Project Objectives Generate - - PowerPoint PPT Presentation
Temperature Sensors Mailani Neal Project Objectives Generate Improve Python3 Clarify name + location conventions color-indicated competency animations 2 Temperature Sensor Types Thermistor Thermocouple Semiconductor-Based Resistance
SLIDE 2
SLIDE 3
3
Temperature Sensor Types
Thermocouple
Uses the proportionality between temperature and voltage variations
Thermistor
Resistance varies by temperature
Semiconductor-Based
Two identical diodes (effectively) with temperature-sensitive voltage
- vs. current characteristics
SLIDE 4
4
Resistance Temperature Detector (RTD)
- Correlates RTD resistance with
temperature
- Film/wire wrapped around a ceramic or
glass core
- PT-100
○ Range: 0.6499K - 1235K ○ 100Ω at 0°C
SLIDE 5
Sensor Names
5
- Given by structure that the sensor is located on
○ Backing-Structure-(# of sector) ○ Cabin-Beams ○ Cone-Bars ○ Cone-Heads ○ Spine-Bars ○ Plus a few more...
SLIDE 6
Sensor Locations at JCMT
6
SLIDE 7
Sensor Locations at JCMT
7
SLIDE 8
Sensor Locations Diagrams
8
SLIDE 9
9
SLIDE 10
10
SLIDE 11
11
Coding Methodology
Matching
Sensor locations, temperature values
Debugging
Disregarding faulty sensors
Formatting
Converting strings and arrays to compatible forms
Plotting
Parametrization, plotting functions, etc.
SLIDE 12
12
Result
SLIDE 13
Room for Improvement
- Hardware improvements
○ Fixing faulty sensors
- Code improvements
○ More autonomy
- Plot improvements
○ File size uniformity
SLIDE 14
Conclusion and Progression
- Dish deformation to be considered in observations
- May suggest ventilation improvements
- Subsequent ideas
○ Adding quantitative analytical processes: averages, deviation, long-term trends, etc.
SLIDE 15
15
