Miniature Greenhouses for Precision Agriculture Advisor: Dr. Liang Dong Victor Gomez Jr., Esdras Murillo, Yufeng Huang, Patrick Martin, Romina Rivadeneira, and Austin Zehr GROUP: DEC1617 Goals Background Create Environmental 1 Growth

slide-1
SLIDE 1

Miniature Greenhouses for Precision Agriculture

Advisor: Dr. Liang Dong Victor Gomez Jr., Esdras Murillo, Yufeng Huang, Patrick Martin, Romina Rivadeneira, and Austin Zehr GROUP: DEC1617

slide-2
SLIDE 2

Miniature Greenhouses for Precision Agriculture – DEC1617

2

Goals

2

Background

2 3

Create Environmental Growth Chambers Implement an Autonomous Robotic Imaging System Functional Extended Automatic Water Pump System

1

Create a system for the Plant Sciences Institute that can manage environmental conditions and track plant growth progress

slide-3
SLIDE 3

DEC1617

3 3

System Components – At a Glance

Miniature Greenhouses for Precision Agriculture – DEC1617

1 2 3 4 5 6 7

  • 1. Large Cooling Chamber
  • 2. Robotic Imaging System
  • 3. Large Heating Chamber
  • 4. Cooling Chamber LED Lighting System
  • 5. Heating Chamber LED Lighting System
  • 6. Small Cooling Chamber
  • 7. Automated Water System
slide-4
SLIDE 4

DEC1617

4 4

Project Specifications

Miniature Greenhouses for Precision Agriculture – DEC1617

Soil Moisture Monitoring and Watering System Variable LED Lighting System Temperature Control Imaging and Documentation

  • f Plant Development
slide-5
SLIDE 5

System Demonstration

5

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-6
SLIDE 6

DEC1617

6 6

Large Chamber – Design Parameters

Miniature Greenhouses for Precision Agriculture – DEC1617

Dimensions 19.5” x 19.5” x 33” Dual layered acrylic containers with foam insulation Magnetic front door and top view hole for plant image capture

slide-7
SLIDE 7

LED Lighting System

Spring Semester Progress

  • 33W LED Strips
  • Red-Red-Blue, and White LED strips

New System Features

  • 201 3W LED Bulbs (~500W)
  • 117 Red, 36 Blue, 18 White, 30 Far Red
  • Variable light intensity using Arduino
  • External cooling system

7

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-8
SLIDE 8

DEC1617

8 8

Chamber Temperature Control System - Heating

Miniature Greenhouses for Precision Agriculture – DEC1617

Temperature Range: 21°C - 45°C. Arduino Logic:

  • User sets temperature
  • Calculate average temperature from 4

thermistors

  • Set space heater ON if:
  • Average temp < Set Temp
  • Set release fan ON and space heater OFF if:

○

Average temp > Set Temp

○

Temperature accuracy: +/- 1.8°C

System Layout

slide-9
SLIDE 9

MiDAS - Heating Chamber Testing

Mobile Data Acquisition System (MiDAS)

Large Heating Chamber - Temperature Range Test

9

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-10
SLIDE 10

DEC1617

10 10 10

Chamber Temperature Control System - Cooling

Miniature Greenhouses for Precision Agriculture – DEC1617

Temperature Range: 21°C - 10°C. Arduino Logic:

  • User sets temperature
  • Calculate average temperature from 4

thermistors

  • Set Cooler ON if:

○

Average temp > Set Temp

  • Set Cooler OFF if:

○

Average temp < Set Temp

○

Temperature accuracy: +/- 1.5°C

System Layout

slide-11
SLIDE 11

MiDAS - Cooling Chamber Testing

Large Cooling Chamber - Temperature Range Test

11

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-12
SLIDE 12

Small Chamber – Design Parameters

Dimensions 8” x 8” x 12” outer shell Easy access to add seeds Rotate between 90 and 0 degree 12

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-13
SLIDE 13

DEC1617

13 13 13

Miniature Greenhouses for Precision Agriculture – DEC1617

Small Cooling Chamber & Control

slide-14
SLIDE 14

Temperature Control Using Power Module

Moto Shield 12Vdc 30A Arduino Controlled Arduino Mega 2560

  • Min Temp required 10C
  • Control V and I to TEC
  • Calibration
  • User interface

Arduino Logic:

  • User sets

temperature by sending a serial temperature setting

  • Calculate average

temperature from a thermistors

14

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-15
SLIDE 15

DEC1617

15 15 15

Plant holder for small chamber

Miniature Greenhouses for Precision Agriculture – DEC1617

Servo Control Panel

  • Two-tier (7” x 1.5” x 0.12”) acrylic

panels

  • Arduino slave control servo rotation

Optional Wireless Connection

  • HC06 bluetooth connector
  • Servo controller interface adjust to

0-180 degree

slide-16
SLIDE 16

DEC1617

16 16 16

Automated Water Pump System

Miniature Greenhouses for Precision Agriculture – DEC1617

Arduino Uno Microcontroller Decoder 2 Decoder 1 MUX 1 MUX 2 MOSFET (x32) Soil Sensors (x32)

Selectors IO Pins

Water Pumps (x32)

System hardware System software

slide-17
SLIDE 17

DEC1617

17

Imaging System

  • Camera
  • Raspberry Pi
  • I/O port controlled MOSFET

Robotic Arm & Track

  • UR10
  • Yaskawa

Gripper Attachment

  • Used to move and doors for images

17

Robotic Imaging System

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-18
SLIDE 18

Special Thanks

  • Dr. Liang Dong
  • Dr. Chris Currey
  • Dr. Ulrike Passe

Xinran Wang Leland Harker David Severson 18

Miniature Greenhouses for Precision Agriculture – DEC1617

slide-19
SLIDE 19

Questions?

DEC1617

19 19

Miniature Greenhouses for Precision Agriculture – DEC1617
