Technique of CO2 concentration profile retrieving from satellite data by means of neural network approach Kataev M.Yu., Andreev A.G. Goals of work: To develop the scientific computer program for modeling GOSAT NIR spectrums and their
SLIDE 2
SLIDE 3
3
The main trajectories of the solar beams in the system « earth + atmosphere ».
Green is the reflected from surface solar radiation Blue is the scattering in atmosphere solar radiation
SLIDE 4
4
τ τΘ0
Θ0 1
I2(λ) τΘ0
1 2
rλ I1(λ) ρ(λ)
Reflected and scattering parts of the signal
atmosphere I1(λ) =E0τΘ0cos(Θ0)ρλτ
SLIDE 5
5
Radiative transfer (RT)
(F-M. Breon, S. Boffies J.Appl.meteorol., 1996, Jan, pp. 69-76)
⎪ ⎭ ⎪ ⎬ ⎫ ⎪ ⎩ ⎪ ⎨ ⎧ + + − =
∫
2 1
)) , ( ) , ( ) , ( ( 1 exp ) , , , (
2 1 P P mol aer gas
dp p p p P P T λ α λ α λ α µ µ λ
) , , 1 , ( ) , , , ( ) ( ) ( ) (
1 surf surf sun surf
P T P T R S I λ µ λ λ π λ λ ⋅ = dp P p T P p T F p F p S I
surf surf sun P aer aer aer mol mol sun
surf
) , , 1 , ( ) , , , ( )) ( ) , ( ) ( ) , ( ( 1 ) ( ) (
2
λ µ λ γ λ α ψ γ λ α µ π λ λ ⋅ ⋅ + ⋅ =
∫
) cos( )] 1 )( 1 [( ) cos(
2 / 1
ϕ µ µ µ µ γ
sat sun sat sun
− − − − =
SLIDE 6
6
Databases for spectra calculation in global world
l 1 Solar spectra, Kurucz spectral resolution 1 cm-1, l 2 Spectroscopic information HITRAN2004 spectral
parameters database,
l 3 Meteorological parameters – NCEP Reanalysis
data 6 hours 2.5x2.5 grad,
l 4 Gases concentration profiles H2O – NCEP data,
CO2 – NIES (S.Maksyutov) data
l 5 Aerosol extinction – SPRINTARS (Toshihiko
Takemura,RIAM,Kyushu Univ.)
SLIDE 7
Variations of the CO2 concentration profile for West Siberia region
SLIDE 8
Data from NCEP with comparison
- f AFGL climatological model
SLIDE 9
Example of transmittance calculation for Channel 2 of GOSAT
SLIDE 10
SEARCH OF THE OPTIMAL SPECTRAL CHANNELS
⎥ ⎦ ⎤ ⎢ ⎣ ⎡ − ⋅ ⋅ = ) , ( ) , ( 1 ) , ( ) , ( 1 ) , , (
1 2 2 1 2 1
µ ν µ ν µ ν µ ν σ µ ν ν
- T
T T T L
where - dispersion of the measurements, - transmittance for all components of air besides gas under investigation, - transmittance (1 – lie in absorption lines of gas under investigation and 2 – very small absorption of gas under investigation).
) , (
2 , 1
µ ν
- T
σ ) , (
2 , 1
µ ν T
6040 6042 6044 6046 6048 6050 6052 6054 6056 6058 6060 0.0 0.2 0.4 0.6 0.8 1.0
ON OFF CH4 All
Transmittance Wavenumber, cm-1
SLIDE 11
Results of searching of the CO2 spectral channels
The 753 wavenumber with help of algorithm when selection criterion for retrieving error =0.1% was found.
SLIDE 12
Clusterization of the CO2 data
The clusterization is based on close structure analysis of matrix of the distances between objects. The algorithm is realized using of performance of graph theory.
SLIDE 13
Neural network approach for inverse task solving
) ( ) (
1
∑
=
+ = =
n i i i
w x w f g f y
Mathematical model of the neuron
y
w1 w2 wn
n
w0
∑
f(g) x1 x2 xn a1x1 a2x2 anxn
The neural network of one layer; f(g) is the activation function; inputs: х1, х2, ..., хn; weight factors: w11, w12, …,
- utputs: y
SLIDE 14
Scheme of Neural network in our work
SLIDE 15
Maximal relative error on training of NN for retrieving of the CO2 concentration profile
SLIDE 16
Resuls of retrieving of the CO2 concentration profile from test samples (A) and training samples (B).
A B
SLIDE 17
Relative error of CO2 concentration profile retrieving with changes of the aerosol optical thickness
SLIDE 18
l Technique of CO2 concentration profile
retrieving from satellite data by means of neural network approach Kataev M.Yu., Andreev A.G.
Tomsk state university of control systems and radioelectronics
