TAKOMA PARK MIDDLE SCHOOL Montgomery County Public Schools Facility Advisory Group Meeting #2 September 16, 2015 -- 3:20pm TAKOMA PARK MIDDLE SCHOOL Schedule Feasibility Study Meeting #1 September 10, 2015, 7:00pm Meeting #2

slide-1
SLIDE 1

TAKOMA PARK MIDDLE SCHOOL Montgomery County Public Schools

September 16, 2015 -- 3:20pm Facility Advisory Group Meeting #2

slide-2
SLIDE 2

TAKOMA PARK MIDDLE SCHOOL

Schedule

Feasibility Study

  • Meeting #1 – September 10,

2015, 7:00pm

  • Meeting #2 – September 16,

2015, 3:20pm

  • PTA Presentation – October 13,

2015, 7:00 pm

2

slide-3
SLIDE 3

TAKOMA PARK MIDDLE SCHOOL

Objectives / Considerations

  • Addition Location
  • Program & Site Adjacencies
  • Student Circulation
  • Access to Fields & Paved Play

Areas

  • Community use of site
  • Maintain Natural Light
  • Sustainability
  • 21st Century Learning

3

slide-4
SLIDE 4

TAKOMA PARK MIDDLE SCHOOL

Program Analysis

4

slide-5
SLIDE 5

TAKOMA PARK MIDDLE SCHOOL

Existing Site

5

N

slide-6
SLIDE 6

TAKOMA PARK MIDDLE SCHOOL

Existing Site Fields & Play Areas

6

N

slide-7
SLIDE 7

TAKOMA PARK MIDDLE SCHOOL

Existing Site Parking

7

N

slide-8
SLIDE 8

TAKOMA PARK MIDDLE SCHOOL

Existing Site Public vs. Private

8

N

slide-9
SLIDE 9

TAKOMA PARK MIDDLE SCHOOL

Existing Site Analysis

9

N

W S E

slide-10
SLIDE 10

TAKOMA PARK MIDDLE SCHOOL

Existing Public vs. Private

Public Private Main Street

10

N

slide-11
SLIDE 11

TAKOMA PARK MIDDLE SCHOOL

Existing Horizontal Circulation

11

N

Public Private Main Street

slide-12
SLIDE 12

TAKOMA PARK MIDDLE SCHOOL

Existing Horizontal and Vertical Circulation

12

N

Public Private Main Street

slide-13
SLIDE 13

TAKOMA PARK MIDDLE SCHOOL

Existing 1st Floor Plan

13

cafeteria music lab lab p p cr cr cr cr cr cr cr lab esol admin guidance art home econ aux gym gym girls lockers boys lockers cr cr gh main entrance

N

cr cr cr dance

slide-14
SLIDE 14

TAKOMA PARK MIDDLE SCHOOL

Existing 2nd Floor Plan

14

lab lab cr cr cr cr cr cr cr lab cr media center cr

N

p p

slide-15
SLIDE 15

TAKOMA PARK MIDDLE SCHOOL

Existing 3rd Floor Plan

15

lab lab cr cr cr cr cr cr lab cr cr cr

N

p p cr mech

slide-16
SLIDE 16

TAKOMA PARK MIDDLE SCHOOL

Existing Site Layout

16

N

slide-17
SLIDE 17

TAKOMA PARK MIDDLE SCHOOL

Potential Addition Areas

17

Four Potential Addition Areas 4 3 2 1

N

slide-18
SLIDE 18

TAKOMA PARK MIDDLE SCHOOL

Potential Addition Areas

18

Four Potential Addition Areas Area 1 – East of Building

  • Adjacent to programs

requiring additional program (gym, cafeteria, performing arts)

  • Sufficient area
  • Ability to tie into existing

corridors

  • Located on blacktop

used by community 1

N

slide-19
SLIDE 19

TAKOMA PARK MIDDLE SCHOOL

Potential Addition Areas

19

Four Potential Addition Areas Area 2 – North Side of Building

  • Sufficient area for

construction

  • Room to plan for future

expansion

  • Adjacent to main

academic area

  • Ability to tie into existing

corridors

  • Sloping terrain
  • Impacts existing

amphitheater 2

N

slide-20
SLIDE 20

TAKOMA PARK MIDDLE SCHOOL

Potential Addition Areas

20

Four Potential Addition Areas Area 3 – Along Piney Branch Rd.

  • Adjacent to existing science

laboratories

  • Not adjacent to existing

corridors

  • Adjacent to street
  • Very small area
  • Would require additional

academic expansion area

  • Interrupts site

circulation 3

N

slide-21
SLIDE 21

TAKOMA PARK MIDDLE SCHOOL

Potential Addition Areas

21

Four Potential Addition Areas Area 4 – Front of School 4

  • Adjacent to programs requiring

additional square footage (administration, guidance, general academics)

  • Provide a new

building front

  • Too close to existing bus

loop

  • Very small area
  • Would require

additional academic expansion area

  • Would require

significant interior renovation

N

slide-22
SLIDE 22

TAKOMA PARK MIDDLE SCHOOL

Concepts

22

slide-23
SLIDE 23

TAKOMA PARK MIDDLE SCHOOL

Music, Physical Ed. & Building Services Addition

23

4

N

Area to relocate hardtop/basketball courts PE/Music Addition

slide-24
SLIDE 24
  • addition
  • renovation

TAKOMA PARK MIDDLE SCHOOL

Music, Physical Ed. & Building Services Addition

cafeteria stage st aux gym st icb t health cr music bsf

24

fitness aux gym gym cafeteria stage st music aux gym gym

N

Existing Partial 1st Floor Plan Proposed Floor Plan

girls lockers boys lockers dance dance girls lockers boys lockers

slide-25
SLIDE 25

TAKOMA PARK MIDDLE SCHOOL

Existing Site Layout

25

N

slide-26
SLIDE 26

TAKOMA PARK MIDDLE SCHOOL

Concept 1 Layout

26

N

PE/Music Addition Academic Addition

slide-27
SLIDE 27

CONCEPT 1

Renovation / Repurpose Areas

cafeteria stage st

27

lab lab p p cr cr cr cr cr cr cr cr esol admin art home econ aux gym gym

N

cr cr girls lockers boys lockers

  • renovation

guidance cr cr cr dance

slide-28
SLIDE 28

CONCEPT 1

1st Floor Plan

cr cr mp lab p t cafeteria stage st aux gym st icb t health cr music bsf

28

cr cr fitness lab lab cr cr cr cr cr cr cr cr esol admin art home econ aux gym gym

N

s girls lockers boys lockers p p

admin

guidance cr cr cr dance

slide-29
SLIDE 29

CONCEPT 1

2ND Floor Plan

29

cr cr res lab t cr cr lab lab cr cr cr cr cr cr lab cr media center

N

p s p p

slide-30
SLIDE 30

CONCEPT 1

3RD Floor Plan

30

esol cr cr lab t cr cr lab lab cr cr cr cr cr cr lab cr sp ed

N

p s p p mech

slide-31
SLIDE 31

CONCEPT 1

Circulation

cafeteria stage st st icb t health cr music bsf

31

cr cr cr cr aux gym fitness

admin

t lab lab cr cr cr cr cr cr cr cr esol admin art home econ aux gym gym

N

p girls lockers boys lockers mp lab s p p guidance cr cr cr dance

slide-32
SLIDE 32

TAKOMA PARK MIDDLE SCHOOL

Existing Site Layout

32

N

slide-33
SLIDE 33

TAKOMA PARK MIDDLE SCHOOL

Concept 2 Layout

33

N

PE/Music Addition Academic Addition

slide-34
SLIDE 34

CONCEPT 2

Renovation / Repurpose Areas

cafeteria stage st

34

lab lab cr cr cr cr cr cr cr esol admin guid art home econ aux gym gym

N

cr cr girls lockers boys lockers

  • renovation
  • renovation

(1st floor only) p p lab cr cr cr dance

slide-35
SLIDE 35

CONCEPT 2

1st Floor Plan

cafeteria stage st st icb t admn p t health cr music cr cr cr bsf

35

aux gym fitness

N

s admn lab lab p p cr cr cr cr cr cr cr esol admin guid art home econ aux gym gym girls lockers boys lockers res mp lab lab cr cr cr dance

slide-36
SLIDE 36

CONCEPT 2

2nd Floor Plan

36

t cr cr cr cr lab lab lab cr cr cr cr cr cr cr lab cr media center p s p p

N

slide-37
SLIDE 37

CONCEPT 2

3rd Floor Plan

37

t cr cr cr esol lab lab lab cr cr cr sp ed lab cr cr cr cr cr

N

p s p p mech

slide-38
SLIDE 38

CONCEPT 2

Circulation

cafeteria stage st st icb t health cr music bsf

38

aux gym fitness t cr cr cr res mp lab admn lab lab cr cr cr cr cr cr cr cr esol admin guid art home econ aux gym gym

N

p s p p girls lockers boys lockers cr cr cr dance

slide-39
SLIDE 39

CONCEPT 1

Future Expansion

39

Area For Future Addition

  • 3 stories – 12 classrooms (single

loaded corridor)

N

slide-40
SLIDE 40

CONCEPT 2

Future Expansion

40

Area For Future Addition

  • 3 stories – 12 Classrooms

N

slide-41
SLIDE 41

TAKOMA PARK MIDDLE SCHOOL

Concept 1 - Pros and Cons

Concept 1

Renovated Square Footage – 15,190 sf Addition Square Footage – 27,500 sf Efficiency Factor – 78.1 %

  • Pros

Efficient double loaded corridor Compact floor plan Minimal site impact Natural light in all spaces Views to exterior (vs. courtyard) in all spaces

  • Cons

Corridor dead ends into stair More renovation of existing classrooms (6 total)

41

Academic Addition PE/Music Addition

slide-42
SLIDE 42

TAKOMA PARK MIDDLE SCHOOL

Concept 2 - Pros and Cons

Concept 2

Renovated Square Footage – 13,285 sf Addition Square Footage – 30,808 sf Efficiency Factor – 69.7 %

  • Pros

Loop corridor improves circulation Forms courtyard for outdoor teaching area Natural light in all spaces Less renovation of existing classrooms (4 total)

  • Cons

Single loaded corridor is inefficient (cost) Forms courtyard requiring maintenance Some classrooms have courtyard views

42

Academic Addition PE/Music Addition

slide-43
SLIDE 43

TAKOMA PARK MIDDLE SCHOOL

Project Schedule

Feasibility Study

  • Meeting #1 – September 10,

2015, 7:00pm

  • Meeting #2 – September 16,

2015, 3:20pm

  • PTA Presentation – October 13,

2015, 7:00 pm

43

slide-44
SLIDE 44

TAKOMA PARK MIDDLE SCHOOL

Questions / Comments

WE WELCOME AND APPRECIATE YOUR FEEDBACK! This process is oriented around the collaboration of all involved. Please feel free to ask us questions.

44
