Tacho Lycos CDR Presentation January 16, 2018 Overview Vehicle Design Dimensions Performance Recovery Avionics Payload Design Integration Rover Subscale Flight Summary Compliance Plan 2 Vehicle Design


slide-1
SLIDE 1

Tacho Lycos

CDR Presentation

January 16, 2018

slide-2
SLIDE 2

Overview

  • Vehicle Design
  • Dimensions
  • Performance
  • Recovery
  • Avionics
  • Payload Design
  • Integration
  • Rover
  • Subscale Flight Summary
  • Compliance Plan

2

slide-3
SLIDE 3

Vehicle Design

Final Dimensions Section Breakdown Design Features

slide-4
SLIDE 4

Final Dimensions

  • Body Diameter: 7.5 in.
  • Length: 128.0 in.
  • Body Material: Blue Tube
  • Launch Weight: 47.1 lb
  • Empty Weight: 41.5 lb
  • Ballast: 3.0 lb (6.4%)

4

slide-5
SLIDE 5

Nosecone

  • Shape: 5:1 Ogive
  • 7.5 in. base, 37.5 in. length
  • Material: ABS Plastic
  • Main parachute compartment

5

slide-6
SLIDE 6

Midsection

  • 7.5 in. OD
  • Blue Tube 2.0
  • Payload/Avionics bays
  • Main/Drogue compartments
  • Removable upper section and access hatch

6

slide-7
SLIDE 7

Fin Can

  • 7.5 in. OD, Blue Tube 2.0
  • Drogue compartment
  • 4 mounted fins
  • 1.25 in. engine block
  • Rail buttons

7

slide-8
SLIDE 8

Fins

  • 2 layers of 0.125 in. birch
  • Alignment tabs for fabrication

8

slide-9
SLIDE 9

Performance

Final Motor Choice Aerodynamics Simulated Flight Profiles

slide-10
SLIDE 10

Motor Choice: AeroTech L2200G-P

  • 75/5120 Reload Kit
  • Propellant: Mojave Green
  • Total Impulse: 5,104 N-s
  • Burn Time: 2.4 s
  • Max Thrust: 3,100 N
  • Cost: $269.00
  • TWR: 14.97

10

slide-11
SLIDE 11

Aerodynamics

  • XCP = 94.9 in.
  • XCG = 79.5 in.
  • Stability Margin = 2.05 cal
  • CD = 0.42
  • Wood filler to fill surface grooves
  • Rounded leading/trailing edges
  • Spray paint to finish

11

slide-12
SLIDE 12

OpenRocket Flight Simulations

  • Location: Huntsville, AL
  • Windspeed: 10 mph
  • Launch Rail: 8 ft (1515)
  • Angle: 5° from vertical
  • Apogee: 5,351 ft AGL
  • Max Velocity: 703 ft/s
  • M = 0.63
  • Rail Exit = 73.3 ft/s
  • Max Acceleration: 458 ft/s2

12

slide-13
SLIDE 13

Recovery

Recovery Devices Recovery Harnesses Wind Drift Predictions Avionics

slide-14
SLIDE 14

Recovery Devices

  • Drogue Parachute – Apogee
  • 24 in. Fruity Chutes Std. Elliptical
  • Vdescent = 93.2 ft/s
  • Low Altitude Recovery Device – 1,000 ft AGL
  • Reduce structural forces on rover latch
  • Same shock cord as drogue
  • Jolly Logic Chute Release
  • 60 in. Fruity Chutes Iris Ultra Std.
  • Vdescent = 28.5 ft/s
  • Main Parachute – 700 ft AGL
  • 120 in. Fruity Chutes Iris Ultra Std.
  • 38.2 lb empty weight
  • Vdescent = 13.85 ft/s

14

slide-15
SLIDE 15

Recovery Harness

  • (2) 480 in. x ½ in. tubular kevlar
  • 2200 lb strength
  • (2) Nomex blankets (Drogue and LARD)
  • (1) Deployment bag (Main Parachute)

15

480” 480 in.

120” 180” 180”

slide-16
SLIDE 16

Wind Drift

  • OpenRocket simulations at varying windspeeds

16

slide-17
SLIDE 17

Wind Drift

17

  • Hand Calculations:
  • Higher than OpenRocket
  • Assumes one direction and

constant wind

  • Does not include lag from

deployment bag

  • Confident that results will be

more like OpenRocket

slide-18
SLIDE 18

Avionics

  • 2 altimeters to deploy

parachutes

  • StratoLoggerCF
  • Entacore AIM
  • Jolly Logic Chute Release for

LARD

  • Each altimeter will be

independently powered to add redundancy

  • Each altimeter will be armed

by a key switch mounted to rocket exterior

18

Drogue Black Powder Charge at Apogee Redundant Drogue Black Powder Charge at Apogee + 1 second StratoLoggerCF Altimeter Main Black Powder Charge at 700 ft. Redundant Main Black Powder Charge at 700
  • ft. + 1 second
Duracell 9 V Battery Key Switch Key Switch Drogue Parachute release Main Parachute release Low Altitude Recovery Device release Jolly Logic Chute Release activates at 1000 ft. Electrical activation Physical activation Battery Altimeter Black Powder Charge Parachute Entacore AIM USB 3 Altimeter Duracell 9 V Battery
slide-19
SLIDE 19

Avionics Sled

StratoLogger (red), Entacore (green) Batteries (brown)

  • Altimeters can be viewed face-up

from open hatch

  • Made of 1/8 in. plywood
  • Total Weight = 0.96 lb
  • Max Weight = 2.0 lb

19

slide-20
SLIDE 20

GPS Tracker

  • BigRedBee BRB900
  • 250 MW, 900 Mhz frequency
  • 6 mile range, 2.5hr memory
  • Internal battery
  • Attached to nosecone

bulkhead beside U-bolt

  • Transmits lat/long

coordinates to receiver

20

slide-21
SLIDE 21

Payload Integration

Design Fabrication Electronics

slide-22
SLIDE 22

Structure

Payload Tube

  • 5.25” x .125” wall acrylic tube - 14” long
  • In between two Lazy Susan Bearings
  • Will prevent the payload from moving with

the rocket during flight

  • Allow the rover to self right during descent

for landing

  • A .25” thickbirch disk will be attached

inside the aft end for Lazy Susan

  • The entire structure will be between

two bulkheads

22

slide-23
SLIDE 23

Lazy Susan Bearings (LSB)

  • The aft payload will be a VXB 120mm

Lazy Susan Aluminum Bearing Turntable bearings

  • OD: 120mm (4.7”), ID: 60mm (2.36”),

thickness: 9.5mm (.37”)

  • Contains two concentric bearing rings
  • Attaches to the the bulkhead and tube

disk via four opposing countersink screws

  • The forward LSB will be a 3D printed

custom designed bearing carrier and schedule 40 PVC contacting piece

  • Considering manufacturing the piece out
  • f aluminum for strength increase and

friction decrease

23

3D Printed Bearing Carrier Ball Bearing PVC Connector Foam Spacer

slide-24
SLIDE 24

Rover Support

  • The rover will rest on a .25” 3D

printed platform

  • fits the curve of the interior of the tube.
  • Rests 1.25” below the central axis of the

tube

  • the front face fills the entirety of the

tube for an inch

  • The rover is supported from above

by two extended runners

  • Attached to the interior face of the tube

directly above the treads

  • Will be 3D printed and adhered using

epoxy resin

24

slide-25
SLIDE 25

Electronic Latch & Receiver

  • Rover will secured laterally using a

Southco R4-EM-63-161 Electronic Rotary Latch

  • The latch with hold the rover by the

bolt on the rover

  • It is controlled via a remote controller
  • The Latch will be controlled with a

EA-R02-202 receiver

  • Controlled via key fob up to 60 ft away
  • The latch and receiver are powered by

a single A23 battery

25

slide-26
SLIDE 26

Payload Plug

  • The payload will be sealed by a

plug

  • Made out of two .25” birch

plywood disks

  • Outside edge with be wrapped in

a rubber gasket to create seal

  • Possesses a U-bolt that the main

shock chord loops around

  • Will be pulled during the main

parachute deployment

26

slide-27
SLIDE 27

Deployable Rover

Design Fabrication Electronics

slide-28
SLIDE 28

Rover Goals

  • Custom rover deployed from

internal structure

  • Remote activation
  • Autonomously move 5 ft laterally in

any direction

  • Deploy a set of foldable solar panels

after reaching its final destination

28

slide-29
SLIDE 29

Remote Activation and Autonomy

29

MSP430 RN-42 Bluetooth Module

slide-30
SLIDE 30

Motion

30

Front wheel with servo

slide-31
SLIDE 31

Solar Sail

31

slide-32
SLIDE 32

Subscale Summary

Launch Conditions Flight Profile Results

slide-33
SLIDE 33

Launch Day Conditions

  • November 18, 2017 in Bayboro, NC
  • 10 knot (11.5 mph) steady winds
  • Gusting up to 20 knots (23.0 mph)
  • Experimental payload built at field

33

slide-34
SLIDE 34

Subscale Flight

  • Apogee = 2,093 ft AGL
  • Predicted = 2,006 ft AGL
  • Max Velocity = 387 ft/s
  • Predicted = 386 ft/s
  • Impact Velocity = 8 ft/s
  • Predicted = 12 ft/s
  • Total Flight Time = 181.7 s
  • Predicted = 169.3 s
  • Accurate predictions

34

slide-35
SLIDE 35

Subscale Recovery

  • Main parachute set to 800 ft AGL
  • Both parachutes deployed at apogee
  • Main primary charge wired to drogue redundant altimeter
  • Impact on full-scale design:
  • Color-coded, labelled wiring to be installed
  • Multiple people in charge of checking wiring
  • Train more team members to recognize errors
  • Additional practice assembly sessions to train
  • Re-designed avionics sled, altimeters more accessible

35

slide-36
SLIDE 36

Subscale Payload Results

  • Payload damaged and

waterlogged from landing

  • Onboard computer failed to

record roll rate during flight

  • Minimal damage to payload

structure after landing

  • After bearing fractured to

allow ball bearings to escape

36

slide-37
SLIDE 37

Compliance

Experiments Tests

slide-38
SLIDE 38

Test Plans and Compliance

Launch Vehicle Testing:

  • Black powder ground testing
  • Rover bay plug seal testing
  • Electronics interference testing
  • GPS location tracking test

Payload Testing:

  • Rover capabilities testing
  • Determining physical limits of the design

38

slide-39
SLIDE 39

39

Questions?
