T owards An Application Objective-Aware Network Interface Sangeetha - - PowerPoint PPT Presentation

HotCloud’20

T

• wards An Application Objective-Aware Network Interface

Sangeetha Abdu Jyothi Sayed Hadi Hashemi Roy Campbell Brighten Godfrey

Evolution of Application Network Interface (ANI)

2

Network Fabric

ANI Packet Metrics Delay, jitter

Evolution of Application Network Interface (ANI)

2

Network Fabric

ANI Packet Flow Metrics Delay, jitter Flow Completion Time

Evolution of Application Network Interface (ANI)

2

Network Fabric

ANI Packet Flow Coflow Metrics Delay, jitter Flow Completion Time Coflow Completion Time

What is the ultimate goal of an ANI?

Translating application requirements to actionable network requirements

3

Are current ANIs sufficient?

Understanding an Application’s Objective

• Applications have complex interdependencies

between computation and communication

• Prioritizing flows based on computations in

succeeding stage is critical

4

A B C

f1 f2 c1 c3 f2 f1 c2

Network Compute

Coflow-Optimized

f1 f2 c1 c2 c3 1 1.5 2 2.5

Performance-Optimized

f1 f2 c1 c2 c3 0.5 1.5 1 2

Current abstractions fail to capture application

• bjective effectively

An Example Application: Distributed Deep Learning

5

• Gigabytes of data transferred in each iteration

which lasts milliseconds
 (e.g., VGG-16 send ~1GB data every 200ms)

• Parameters consumed in a particular order
• Parameter updates from PS to workers send in

the best order can accelerate training

Worker Worker Worker Parameter Server

• p1
• p2
• p4
• p3
• p4’
• p2’
• p1’
• p3’

Read A Read B Read C Read D Update A Update B Update C Update D

Sample TensorFlow Model: One Iteration

Input Data

Other Applications

• User-facing partition-aggregation workloads


(remote dependency resolution at a Web proxy)

• Graph processing systems
• Iterative analytics with deadlines (eg: Naiad) and so on …

6

Client Proxy Req 1 Req n

Gather Update Scatter

Towards A Novel Application Network Interface

• Computation completely represented by a DAG. What is the network equivalent?
• The goal is to capture an application’s network objective
• CadentFlow:

7

CF = {(f1, T1), (f2, T2), … , (fn, Tn), Γ} where Ti = (ti1, mi1), (ti2, mi2) …

Towards A Novel Application Network Interface

• Computation completely represented by a DAG. What is the network equivalent?
• The goal is to capture an application’s network objective
• CadentFlow:
• A set of flows with metrics AND

7

CF = {(f1, T1), (f2, T2), … , (fn, Tn), Γ} where Ti = (ti1, mi1), (ti2, mi2) …

Towards A Novel Application Network Interface

• Computation completely represented by a DAG. What is the network equivalent?
• The goal is to capture an application’s network objective
• CadentFlow:
• A set of flows with metrics AND
• An application-level objective

7

CF = {(f1, T1), (f2, T2), … , (fn, Tn), Γ} where Ti = (ti1, mi1), (ti2, mi2) …

Towards A Novel Application Network Interface

• Computation completely represented by a DAG. What is the network equivalent?
• The goal is to capture an application’s network objective
• CadentFlow:
• A set of flows with metrics AND
• An application-level objective
• Metrics may be priority, deadline, weight, etc.

7

CF = {(f1, T1), (f2, T2), … , (fn, Tn), Γ} where Ti = (ti1, mi1), (ti2, mi2) …

Towards A Novel Application Network Interface

• Computation completely represented by a DAG. What is the network equivalent?
• The goal is to capture an application’s network objective
• CadentFlow:
• A set of flows with metrics AND
• An application-level objective
• Metrics may be priority, deadline, weight, etc.

7

CF = {(f1, T1), (f2, T2), … , (fn, Tn), Γ} where Ti = (ti1, mi1), (ti2, mi2) …

Defining CCT flexibility ratio

• When computation is the bottleneck,

CadentFlow with deadlines provide flexibility for delaying some flows without affecting application performance

• In the example, best Coflow Completion Time

(CCT) is 1s, but upto 1.5s is tolerable without any impact

• CCT flexibility ratio = Max tolerable CCT

Min CCT

8

A B C

f1 f2 c1 c3 f2 f1 c2

Performance-Optimized

f1 f2 c1 c2 c3 0.5 1.5 1 2

c1 takes 0.5s c1 takes 1s

Performance-Optimized

f1 f2 c1 c2 0.5 1.5 2 c3 2.5

Distributed DNN Training CadentFlow

• Priority-based
• Assign priorities based on DAG structure
• Objective: Minimize completion time subject

to priorities

9

Sample TensorFlow Model: One Iteration

• p4’
• p2’
• p1’
• p3’
• p1
• p2
• p4
• p3

Read A Read B Read C Read D Update A Update B Update C Update D Input Data

p1 p2 p2 p3

Distributed DNN Training CadentFlow

• Priority-based
• Assign priorities based on DAG structure
• Objective: Minimize completion time subject

to priorities

• Deadline-based
• Assign deadlines based on per-op computation

time

• Objective: Minimize maxi(endTimei− deadlineii)
• 9

Sample TensorFlow Model: One Iteration

• p4’
• p2’
• p1’
• p3’
• p1
• p2
• p4
• p3

Read A Read B Read C Read D Update A Update B Update C Update D Input Data

t=3ms t=5ms t=4ms t=2ms

d=0ms d=3ms d=3ms d=12ms

Distributed DNN Training CadentFlow

• Priority-based
• Assign priorities based on DAG structure
• Objective: Minimize completion time subject

to priorities

• Deadline-based
• Assign deadlines based on per-op computation

time

• Objective: Minimize maxi(endTimei− deadlineii)
• 9

Sample TensorFlow Model: One Iteration

• p4’
• p2’
• p1’
• p3’
• p1
• p2
• p4
• p3

Read A Read B Read C Read D Update A Update B Update C Update D Input Data

t=3ms t=5ms t=4ms t=2ms

d=0ms d=3ms d=3ms d=12ms

delay of flow i

Quantifying benefits achievable with a better network abstraction

• Representative application: distributed deep learning
• Methodology
• Tracing distributed deep learning workloads to obtain

dependencies and computation/communication times

• Simulate various network control schemes
• 1. TCP (max-min fairness across flows sharing

a link)

• 2. Minimum Allocation for Desired Duration

(MADD) [Coflow control in Varys]

• 3. CadentFlow-optimized scheme

10

Sample TensorFlow Model: One Iteration

• p4’
• p2’
• p1’
• p3’
• p1
• p2
• p4
• p3

Read A Read B Read C Read D Update A Update B Update C Update D Input Data

Performance Improvement

11

AlexNet-v2 CifarNet Inception-v1 Inception-v3 MobileNet-v2 ResNet-v1-50 ResNet-v1-152 ResNet-v1-200 ResNet-v2-101 ResNet-v2-152 VGG-19 0.2 0.4 0.6 0.8 1 1.2 Iteration time (relative to TCP)

Coflow optimized CadentFlow optimized

CadentFlow optimization Coflow-optimization

8 workers, 8 PS

Up to 25% improvement in iteration time with CadentFlow

Performance Improvement

11

AlexNet-v2 CifarNet Inception-v1 Inception-v3 MobileNet-v2 ResNet-v1-50 ResNet-v1-152 ResNet-v1-200 ResNet-v2-101 ResNet-v2-152 VGG-19 0.2 0.4 0.6 0.8 1 1.2 Iteration time (relative to TCP)

Coflow optimized CadentFlow optimized

CadentFlow optimization Coflow-optimization

8 workers, 8 PS

Coflow optimization may delay completion time because smaller parameters are delayed

Performance Improvement

11

AlexNet-v2 CifarNet Inception-v1 Inception-v3 MobileNet-v2 ResNet-v1-50 ResNet-v1-152 ResNet-v1-200 ResNet-v2-101 ResNet-v2-152 VGG-19 0.2 0.4 0.6 0.8 1 1.2 Iteration time (relative to TCP)

Coflow optimized CadentFlow optimized

CadentFlow optimization Coflow-optimization

8 workers, 8 PS

• v2

et

• v1
• v3
• v2

50 52 00 01 52 19 0.2 0.4 0.6 0.8 1 Iteration time (relative to TCP)

16 workers,16 PS

Performance Improvement

11

AlexNet-v2 CifarNet Inception-v1 Inception-v3 MobileNet-v2 ResNet-v1-50 ResNet-v1-152 ResNet-v1-200 ResNet-v2-101 ResNet-v2-152 VGG-19 0.2 0.4 0.6 0.8 1 1.2 Iteration time (relative to TCP)

Coflow optimized CadentFlow optimized

CadentFlow optimization Coflow-optimization

8 workers, 8 PS

• v2

et

• v1
• v3
• v2

50 52 00 01 52 19 0.2 0.4 0.6 0.8 1 Iteration time (relative to TCP)

16 workers,16 PS

• v2

et

• v1
• v3
• v2
• 50

52 00 01 52

• 19

0 0.2 0.4 0.6 0.8 1 1.2 1.4 CCT flexibility ratio (max feasible CCT/ min CCT)

• v2

et

• v1
• v3
• v2
• 50

52 00 01 52

• 19

0.4 0.8 1.2 1.6 CCT flexibility ratio (max feasible CCT/ min CCT)

Performance Improvement

11

AlexNet-v2 CifarNet Inception-v1 Inception-v3 MobileNet-v2 ResNet-v1-50 ResNet-v1-152 ResNet-v1-200 ResNet-v2-101 ResNet-v2-152 VGG-19 0.2 0.4 0.6 0.8 1 1.2 Iteration time (relative to TCP)

Coflow optimized CadentFlow optimized

CadentFlow optimization Coflow-optimization

8 workers, 8 PS

• v2

et

• v1
• v3
• v2

50 52 00 01 52 19 0.2 0.4 0.6 0.8 1 Iteration time (relative to TCP)

16 workers,16 PS

• v2

et

• v1
• v3
• v2
• 50

52 00 01 52

• 19

0 0.2 0.4 0.6 0.8 1 1.2 1.4 CCT flexibility ratio (max feasible CCT/ min CCT)

• v2

et

• v1
• v3
• v2
• 50

52 00 01 52

• 19

0.4 0.8 1.2 1.6 CCT flexibility ratio (max feasible CCT/ min CCT)

When gain in iteration time is lower, CCT flexibility ratio is higher

Open Challenges

• Extracting the application objective
• Designing network controllers that can handle multiple application objectives
• How to handle conflicting objectives?
• Implementation challenges
• Real-time decision making
• End host vs. in-network implementation

12

Thank You

Email: sangeetha.aj@uci.edu
