T h e i n v i s i b l e s a n i t a r y c o n t r o l

Page 2

The advantages of SanTec INSIDE The invisible sanitar y contr ol Vandal-proof

due hidden installation behind the ceramic urinal.

Freedom in formation

in consequence of the control, there are no spacial minimum distances necessary

Prompt ready for use

Plug & Play device, there are no device settings necessary on site.

Flushing stops immediately if urinal is blocked

The intelligent sensor-siphon also recognises blockages of the uri- nal and assures that no further flushing is effected.

Dehydration protection of siphon

Should the siphon dry up (if it is not used for a longer period of time), the sensor siphon also detects it and reconditions the stench trap through an automatic flushing.

Edition 10 08 2006; Präsentation SanTec INSIDE English, Art. No.: 903 294

S a n Te c I N S I D E

W I M T E C

Elektronische Steuerungs- u. Meßgeräte GmbH A - 3325 Ferschnitz, Freidegg Nr. 50 Phone: ++43 (0) 7473 5000 ● Fax: ++43 (0) 7473 5000 - 10 Internet: http://www.wimtec.at ● Email: office@wimtec.at

S a n Te c I N S I D E

Page 3

Application and function

Dehydration protection

hygiene flushing if siphon becomes dry

Flushing stop

immediate flushing stop, if urinal is blocked

Automatic release

as function-check. By pooring 1l water into urinal a flushing takes place.

Mains flushing

after use The non-contact single urinal control SanTec INSIDE is invisible for the user and consequently offers maxi- mum protection against vandalism. Due to the blind mounting of the intelligent sensor- siphon, at designing a modern toilet room all possibili- ties remains open. SanTec INSIDE is an ideal solution for small and narrow toilet rooms, because the flushing is solely dependent

• n the direct use. Due to the integrated sensor, there

is no minimum distance to the opposite or beside wall necessary.

The invisible sanitar y contr ol

S a n Te c I N S I D E

Page 4

Mounting dimensions and technical specifications

Operating voltage: 230V / 50Hz Power input: Standby: approx. 3VA; Flushing: approx. 8VA Magnetic valve: 24V / 50Hz Main flushing: 1 - 10 sec. adjustable Flow pressure: 0,5 - 6 bar Flow rate: 0,3 - 0,7 l/sec. can be reduced acc.to DIN 3265 Water inlet: R 1/2“ IG Water outlet : R 1/2“ AG Wall-recess-mounted box: 135 x 165 x 77 mm Urinals: Only for urinals with a level urinal outlet on the backside. For Laufen Taro Nova only with siphon-adaptor (art.no. 231 311) dimensions in cm 51,5 9 - 20 OK-FFB OK-RFB 65

(adults)

floor- construction

0-20 115 (Laufen Caprino) 115 (Laufen Taro Nova) 4,5 Minimum depth of urinal assembly element 90 mm

The invisible sanitar y contr ol

DN 15 230V

S a n Te c I N S I D E

Page 5

Product layout

SanTec FIX INSIDE Urinal assembly element

SanTec FIX INSIDE - Caprino art.no.: 102 543 SanTec FIX INSIDE - Taro Nova art.no.: 102 550

Wall-recess-mounted box

art.no.: 200 027

Shut-off valve

art.no.: 221 206

Filter

art.no.: 221 220

Magnetic valve

art.no.: 221 008

Threaded connecting piece R 1/2“ AG

art.no.: 221 053

Gasket

art.no.: 222 074

SanTec INSIDE electronics

art.no.: 102 567

SanTec INSIDE sensor sifon

art.no.: 231 328

Sifon adaptor for Taro Nova

art.no.: 231 311

The invisible sanitar y contr ol

S a n Te c I N S I D E

Page 6

Installation

zu close

The invisible sanitar y contr ol

Install SanTec FIX urinal assembly element. Establish connection to mains and water. Afterwards cover with plaster boards and tile. Carry out pre-flushing with flexible pipe. Close shut-off valve and insert dirt filter. Afterwards shut-off water connection as well as mains

• connection. Do not open

before the control as well as the urinal ceramic are ready installed. Insert magnetic valve with gaskets. Attention! Watch out for flow direction at magnetic valve. Afterwards open shut-off valve. Amend length of sensorsiphon to the outlet. Attention! Do not damage the cable. Establish connection to mains.

1 2 3 6 5 4

230V DN15

• ffen
• pen

S a n Te c I N S I D E

Page 7

Installation The invisible sanitar y contr ol

Connect sensorsiphon to the plug on the electronic module Plug in electronic module in wall mounted box. Connect magnetic valve. Plug in sensorsiphon. Put on urinal ceramics. Attention! Do not pen in sen- sor cable.

7 8

11 10 9

Function check. By pooring 1l water into the urinal a flushing takes place. Establish a water-proof silicon- grout around the urinal cera- mics.

14 13 12

230V

Turn on mains supply

DN15

Open main water connection

Pressure in bar Flushing volume in l 1,0 2,0 3,0 4,0 5,0 2,0 5,5 s 4,5 s 3,0 s 2,5 s 2,5 s 2,5 6,5 s 4,5 s 4,0 s 3,5 s 3,0 s 3,0 7,0 s 5,5 s 4,5 s 4,0 s 4,0 s 3,5 9,0 s 6,5 s 5,5 s 4,5 s 4,0 s 4,0 10,0 s 7,5 s 6,0 s 5,5 s 5,0 s Flushing time

S a n Te c I N S I D E

Page 8

Adjustment of flushing time

Flushing time adjustment 1 - 10 sec. (5 sec. preadjusted) Connection sensorsiphon 1 5 10 Connection 230V / 50Hz Magnetic valve connection

The invisible sanitar y contr ol
