Systems Engineering Expedient Prototyping Modeling and Design for Military Vehicles with Evolving Requirements & Developing Interface Control Documents with Specifications for Competing Military Hardware. James Capouellez, TARDEC, CSI

SLIDE 1

Systems Engineering

7/23/2018

Expedient Prototyping Modeling and Design for Military Vehicles with Evolving Requirements & Developing Interface Control Documents with Specifications for Competing Military Hardware.

DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

James Capouellez, TARDEC, CSI

SLIDE 2

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

M939 Add on Armor Kit Hand sketched on a drafting board and converted into Computer Aided Design (CAD). Kit was designed and first prototype built in two months. 3,000 kits produced for OIF/OEF

SLIDE 3

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Top Down Design for Optimization Typical bottom up approach initially used to develop mine blast cab. Top down design used to reduce weight and size and maintain mine blast performance.

SLIDE 4

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Traditional/Typical Top Down Design Typical Approach of Top Down Modeling Using One Skeleton per Assembly

SLIDE 5

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Alternative Top Down Design for Larger Assemblies For more complex models, the idea is to make skeleton model assemblies to reduce the amount of features in each skeleton and keep the models clean

SLIDE 6

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Alternative Skeleton Models for Larger Assemblies

Industrial Design Concept Design Detailed Design

The idea of a more collaborative effort between concepts and detailed design that would allow for

ptimization

simultaneously is possible using this approach.

SLIDE 7

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Geometry Driven Top Down Design

SLIDE 8

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

TARDEC Amphibious Combat Vehicle (ACV) Skeleton Model This is the top skeleton model for the TARDEC Amphibious Combat Vehicle Hull Survivability Demonstrator. This skeleton will drive all the individual parts

shape. This

skeleton controls thousands of features.

SLIDE 9

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Concept Skeleton Model (Upper Hull) This is the upper hull skeleton that is simplistic geometry that can be easily

modified. This is

a model that can be made by Advanced Concepts and transitioned to Detailed Design.

SLIDE 10

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Concept Skeleton Model Edge Prep This is the upper hull skeleton that has added sketches and sweeps to cut the parts. If done correctly, the conceptual model shown in the previous slide can change shape and the edge preparation will update. Sketches for sweeping

r extruding the edge

cuts Sweep in the Skeleton Model

SLIDE 11

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Transition from Concept Design to Detailed Design Part with copied geometry

r published geometry from

the skeleton These sketches are used to create the cut for the J-Weld between the Parts and Mechanical Lock Finished Joint Geometry with J-Weld Edge Prep and Mechanical Lock

SLIDE 12

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Concept Skeleton Model (Driver’s Side)

SLIDE 13

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Lower Hull with V-Weld, Mechanical Lock, & Tab/Slot Plate geometry driven by skeleton model

SLIDE 14

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Lower Hull Skeleton Model Iso View Complex skeleton model for full edge prep including tab and slots

SLIDE 15

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Skeleton Model of Lower Hull (Front View) Wireframe view of the lower hull skeleton with edge preparation sketches Sample sketch that will cut the V-groove for welding and the mechanical lock between plates

SLIDE 16

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.

Plate geometry driven by skeleton model

SLIDE 17

Systems Engineering

7/23/2018 DISTRIBUTION STATEMENT A. Approved for public release; distribution unlimited.
