System Administration

CSE598K/CSE545 - Advanced Network Security Luke St.Clair - Spring 2008

1

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Why do we care?

• This is probably the most

important thing you can learn to secure systems?

• The idea
• to learn a couple practical things
• learn some tools to learn more

2

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

How to get in...

• ssh - secure shell
• rhosts - it’s great! I

want that.

• .rhosts - list of users that

can log in

• ssh remotehost

command - simply run a command on a remote host (useful for scripts)

• server not installed on

Ubuntu by default (no

• pen ports!)

3

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Garage door opener

• Open the door easier
• let’s just say who can access
• we’ll do it by what people have
• .ssh/authorized_keys
• ssh-keygen -t dsa - we’ll

make some keys

4

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Giving out keys

• We made keys, now each host just has to make a list
• f what keys are okay
• Who needs to know this?
• scp your .ssh/id_dsa.pub (or similar) to your

VM

• scp .ssh/id_dsa.pub 130.203.83.20:~/coriakin-key.pub
• ssh 130.203.83.20 “cat ~/coriakin-key.pub >> ~/.ssh/

authorized_keys”

5

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Shortcomings of SSH

• pairwise keys - gets annoying
• it’s really too many for me to use everywhere
• You have to trust where your host key is
• You just forget things
• MitM
• how do you check

host key?

• ssh-keygen -l -f

/etc/ssh/ssh_host_dsa_key.pub

6

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

It can be a little easier

7

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Being privileged

• sudo - superuser do
• there’s no root user!
• sudo visudo - you can see what the

policy is

• your policy says anyone in the group “admin”

can do anything, if they put their password in

• note that you had to sudo to change

sudoers, the file that controls sudo policy

8

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Let’s get some $\/\/33t w@r3z

• What if there was a way to

install things as long as you know what sort of thing you want?

• What if you could update

everything with a command?

9

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

WINDOWS UPDATE!!?!?!?

• WINDOWS UPDATE!!!!!! Rulz!
• roflcopter.

10

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Aptitude

• Basic Principles
• aptitude update - refreshes the list of what exists -

practically, do this before you do things

• aptitude search - look in the whole repository for matches to

your search terms (even descriptions!)

• aptitude install <package name> - installs a package.

You have to type the name right

• aptitude (safe|full)-upgrade - upgrade all your packages, safely,
• r fully

11

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Let’s get a Desktop

• Some packages are “meta” packages, which are just

shorthand for listing tons of packages

• let’s aptitude install apache2
• installs, basically configures, and starts apache2
• then aptitude install xubuntu-desktop, which will install a full

desktop system, and tightvncserver

12

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Visit your website

• Point your browserz at your ip address
• You’ve been hax0r3d!

13

Apache 2 Test Page

• rganization that builds CentOS.

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Alternately...

14

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

init.d

• Nearly every service that would run in the background

(apache, ssh, etc) has a script that controls it

• instead of trying to figure out which process (ps aux) does

what, and how to start/stop the process correctly (not kill!), just ask

• they all start/stop/restart - restart is always a safe bet
• you’d do this if you change the config of a running program
• let’s restart apache
• sudo /etc/init.d/apache restart (remember to tab complete!)

15

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

VNC

• this is all easier on the command line...
• but some stuff isn’t (adding users w/ adduser, adding

users to groups with usermod -G group user)

• so we want a

desktop, which runs on a remote system, but that we see on our local system

16

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Tunneling

• To get this, we have to tunnel our data
• Clever firewall admins don’t let VNC through
• ssh -L 5900:firsthost:5901 -TN secondhost
• forwards local port 5900 to

port 5901 on firsthost via secondhost - remember this description

• set up a tunnel from port 5900
• n your machine, to 5901 on

your VM, via your VM

17

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

All that’s left is to connect...

• Have to start a server on the remote host
• this is per-user: vncserver :1
• set a password
• On your local host, point your

VNC viewer at yourself (remember, 5900, the VNC port gets tunneled to a remote party via someone’s ssh service), password is your VNC password, NOT ssh password

• You’ll be prompted for your

VNC password if you didn’t put it in already

18

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Ugly Desktop

• See help.ubuntu.com/community/VNCOverSSH
• basically, just put something in your .vnc/xstartup
• wget http://www.lukestclair.com/tools/config/xstartup
• put it in your .vnc file

in your home directory

19

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Where to get more help

• Ubuntuforums.org - by far the best source
• IRC - lots of noise to signal ratio - irc.freenode.org,

#ubuntu

• wiki.ubuntu.org

20

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Certificate creation

• Let’s make a certificate
• Don’t try to remember this, just look it up
• Make a CA:
• openssl genrsa -des3 -out cakey.key 4096
• openssl req -new -x509 -days 365 -key cakey.key -out cacert.crt
• Create server key, request, sign
• openssl rsa -des3 -out server.key 4096
• openssl req -new -key server.key -out server.csr
• openssl x509 -req -days 365 -in server.csr -CA cacert.crt -CAkey

cakey.key -set_serial 01 server.crt

• this avoids reissuing the same certificate

21

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Setting up Apache

• sudo a2enmod ssl (enables the SSL module)
• add to /etc/apache2/sites-available/default, right under

virtualhost:

• SSLEngine on
• SSLProtocol all
• SSLCertificateFile /etc/ssl/certs/ssl-cert-snakeoil.pem
• SSLCertificateKeyFile /etc/ssl/private/ssl-cert-snakeoil.key
• In /usr/share/doc/ directory, allow all
• Order allow, deny
• Allow all

22

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Firewalls

• There are so many ways to do this

23

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

GUIs, or G-U-I’s

• Let’s make a firewall, simple-style
• You can do all of these things with iptables, and there

are many good tutorials

24

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Basic settings

• Setup pokes some holes in the firewall
• your ethernet device may be different - there should only be
• ne to choose from anyway

25

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Policy

• Play around with this. Firewall your website’s port 80,

to stop normal http connections (this is not really the best way to do this, but whatever)

• Don’t forget

to “Apply” policy once you create it

• Browse port

80 and check logs

26

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

IPsec

• set up rules for when we want ipsec
• first, add
• #!/usr/sbin/setkey -f
• flush; spdflush; to the top of the file - this gets rid of stuff

before

• spdadd 130.203.32.21 130.203.32.20 any -P in ipsec esp/transport//

require;

• packets from .21 to .20 incoming match this rule - require ipsec
• spdadd 130.203.32.20 130.203.32.21 any -P out ipsec esp/

transport//require

• packets from .20 to .21 outgoing match this rule
• what does spdadd 130.203.32.20 130.203.32.21 any -P in ... do?

27

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Racoon

• This is the program that listens for

connections

• get racoon.conf from http://lukestclair.com/

tools/config/racoon

• put it in /etc/racoon.conf
• Let’s look through it...

28

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

Racoon.conf

• remote anonymous applies this to everything
• alternative is to configure by ip addr, as in comments
• proposal is what you propose - other side picks
• here we only propose one

hash, one encryption, and we only auth by pre-shared key, not certs

• dh_group defines

diffie-hellman group - don’t worry about this

29

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

SA in racoon.conf

• Defines how long your connection is good for
• Defines what encryption you support
• That’s it!

30

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

What did we miss?

31

CSE598K/CSE545 - Advanced Network Security - McDaniel Page

psk

• Fill in /etc/racoon/psk.txt
• mine is l33th@x0R
• Try to ping my machine (130.203.83.20)
• note the delay or failure
• sudo setkey -F, sudo setkey -FP should show you

something, if you want to check errors or just see what’s happening

• if this doesn’t work /etc/init.d/racoon stop, sudo

racoon -f /etc/racoon/racoon.conf, and we can see what happens

32
