Synchrotron radiation Marcin Sikora Academic Centre for Materials and Nanotechnology, AGH-UST, Krakow, Poland marcin.sikora@agh.edu.pl ESM-2018, Krakow, 26/9/2018 1 Origin of light 1. Charge: a source of electric field, = 0 .

slide-1
SLIDE 1

ESM-2018, Krakow, 26/9/2018 1

Synchrotron radiation

Marcin Sikora

Academic Centre for Materials and Nanotechnology, AGH-UST, Krakow, Poland marcin.sikora@agh.edu.pl

slide-2
SLIDE 2

ESM-2018, Krakow, 26/9/2018 2 thebigblogtheory.wordpress.com

Origin of light

  • 1. Charge: a source of

electric field, 𝑬 = 𝜁0𝑭.

  • 2. Charge motion results in

variable field, πœ–π‘¬ 𝑒𝑒 β‰  0, a source of perpendicular magnetic field, π‘ͺ = 𝜈0𝑰.

  • 3. Variable magnetic field,

πœ–π‘° 𝑒𝑒 β‰  0, a source of perpendicular 𝑭 field … Emission of light (E-M wave) requires that ί²2𝑭 𝑒𝑒2 β‰  0, i.e. acceleration of charge

~

slide-3
SLIDE 3

ESM-2018, Krakow, 26/9/2018 3

Origin of synchrotron light

Electric dipol Electron in ring

centripetal force

𝒃 𝒃 𝒃 Electron in ring

relativistic

𝒃

slide-4
SLIDE 4

ESM-2018, Krakow, 26/9/2018 4

Synchrotron light spectrum

𝒃

Radiated power Critical energy Orbital radius

slide-5
SLIDE 5

ESM-2018, Krakow, 26/9/2018 5

Electromagnetic spectrum

nasa.gov; www.lightsources.org

𝑔 = 𝑑 πœ‡

slide-6
SLIDE 6

ESM-2018, Krakow, 26/9/2018 6

Topology of synchrotrons

lightsources.org, cern.ch, lynceantech.com

LHC: 27km ESRF: 840m ERL: 768m+ CLS:171m 234m ~10m

slide-7
SLIDE 7

ESM-2018, Krakow, 26/9/2018 7

Outline

Development of SR sources Properties of SR, instrumentation Applications of SR

  • diffraction
  • imaging
  • spectroscopy

Applications to magnetism

  • magnetic structure
  • element selective magnetometry
  • magnetic imaging
  • time resolved study
  • extreme conditions
slide-8
SLIDE 8

ESM-2018, Krakow, 26/9/2018 8

Theoretical and experimental foundations

1865: J.C.Maxwell’s paper A Dynamical Theory of the Electromagnetic Field 1887: experimental observation of E-M waves by H.Hertz 1897: discovery of electron by J.J.Thompson 1898-1900: LiΓ©nard and Wiechert formulate the theory of retarded potential 1907: G.A.Schott’s formulates the full theory of radiation from electrons travelling at close to the speed of light

Appleyard R. Electrical Communication 6 (1927) 63

slide-9
SLIDE 9

ESM-2018, Krakow, 26/9/2018 9

Cyclic particle accelerators

1932: First cyclotron build by S.GaΓ‘l and E.O.Lawrence (4.8 MeV,  = 69 cm) 1935: First betatron build by M.Steenbeck (original concept from Rolf WiderΓΈe) 1944-1945: First synchrotrons by Vladimir Veksler and Edvin McMillan’s

wikipedia.org

slide-10
SLIDE 10

ESM-2018, Krakow, 26/9/2018 10

Discovery

1944: Ivanenko and Pomeranchouk calculate energy loss of electrons in betatron 1945: observation of modified trajectory of electrons in 100MeV betatron (Blewett), no traces of radiation detected 1947, April 24: Pollock, Langmuir, Elder and Gurewitsch observe light produced inside vacuum tube of newly built 70MeV synchrotron (GE, Schenectady, Nowy Jork), called synchrotron radiation 1949: Schwinger’s theory of SR 1969: Ginzburg & Syrovatskiy publish Development of the Theory of Synchrotron Radiation and Its Reabsorption based on Shklovsky’s theory of cosmic radiation

slide-11
SLIDE 11

ESM-2018, Krakow, 26/9/2018 11

Synchrotron lattice

β€žRace track” synchrotron by D. Crane (Univ. of Michigan, 1949)

Replenishment of electron energy and longitudinal focussing using RF cavities Guiding and lateral focussing of el. bunches using magnets: dipole, quadrupole, sextupole, N-pole …

Willmott P. An Introduction to Synchrotron Radiation, Willey 2011

slide-12
SLIDE 12

ESM-2018, Krakow, 26/9/2018 12

Insertion devices

Willmott P. An Introduction to Synchrotron Radiation, Willey 2011

Wiggler

K~10

Undulator

K~1

Wavelength shifter

Maximum angular deviation

  • f the electron orbit, πœšπ‘›π‘π‘¦,

define undulator parameter:

𝐽𝑛𝑏𝑦~π‘œπ‘“π‘šπ‘‚ π½π‘žπ‘“π‘π‘™~π‘œπ‘“π‘šπ‘‚2

slide-13
SLIDE 13

ESM-2018, Krakow, 26/9/2018 13

Generations of SR sources

Willmott P. An Introduction to Synchrotron Radiation, Willey 2011

1st: refurbished storage rings & parasitic operation 2nd: dedicated storage rings 3rd: optimized for brilliance (insertion devices) 4th: optimized for coherence free electron lasers (FEL) & diffraction limited storage rings (DLSR)

slide-14
SLIDE 14

ESM-2018, Krakow, 26/9/2018 14

Generations of SR sources

Willmott P. An Introduction to Synchrotron Radiation, Willey 2011

1st: refurbished storage rings & parasitic operation 2nd: dedicated storage rings 3rd: optimized for brilliance (insertion devices) 4th: optimized for coherence free electron lasers (FEL) & diffraction limited storage rings (DLSR)

slide-15
SLIDE 15

ESM-2018, Krakow, 26/9/2018 15

Unique properties od SR

Attwood D. Soft X-Rays and Extreme Ultraviolet Radiation, Cambridge University Press 1999

  • Stable, high flux source of photons
  • Broad spectrum
  • Collimated and coherent
  • Discrete time structure
  • Polarized

(linearly, circularly)

e-

slide-16
SLIDE 16

ESM-2018, Krakow, 26/9/2018 16

Synchrotron radiation labs

There are more than 50 light sources in the world (operational, or under construction). Most of them offer free of charge access upon succesful beamtime applications (peer-reviewed). www.lightsources.org

slide-17
SLIDE 17

ESM-2018, Krakow, 26/9/2018 17

Elements of X-ray optics and instrumentation

Slits Mirrors

deflecting & focusing

Monochromators Detectors/endstations

www.synchrotron.pl

slide-18
SLIDE 18

ESM-2018, Krakow, 26/9/2018 18

X-ray mirrors

http://ftp.esrf.fr/pub/scisoft/xop2.3/

cut-off energy

Deflection Focusing Filtering

slide-19
SLIDE 19

ESM-2018, Krakow, 26/9/2018 19

Monochromators

Attwood D. Soft X-Rays and Extreme Ultraviolet Radiation, Cambridge University Press 1999

Pinhole Grating

VUV & soft X-rays

slide-20
SLIDE 20

ESM-2018, Krakow, 26/9/2018 20

Monochromators

Attwood D. Soft X-Rays and Extreme Ultraviolet Radiation, Cambridge University Press 1999

Crystals, multilayers

hard X-rays

bent crystals/gratings

Rowland circle geometry

Bragg law π‘œπœ‡ = 2 𝑏 β„Ž2 + 𝑙2 +π‘š2 π‘‘π‘—π‘œπœ„

slide-21
SLIDE 21

ESM-2018, Krakow, 26/9/2018 21

Focusing optics

Compound refractive lenses

hard X-rays

Fresnel zone plates

soft X-rays

Willmott P. An Introduction to Synchrotron Radiation, Willey 2011

Coated glass capilary

hard X-rays

slide-22
SLIDE 22

ESM-2018, Krakow, 26/9/2018 22

Detectors

www.ketek.net; www.dectris.com; www.hamamatsu.com; www.canberra.com

  • Ionization chambers
  • Scintilators
  • Si/Ge pin diodes
  • Silicon drift detectors (SDD)
  • Avalanche photodiode (APD)
  • Position sensitive detectors (PSD)
  • Photocurent
  • Drain current
  • Phosphor screen + CCD
  • ….
slide-23
SLIDE 23

ESM-2018, Krakow, 26/9/2018 23

Outline

Development of SR sources Properties of SR, instrumentation Applications of SR

  • diffraction
  • imaging
  • spectroscopy

Applications to magnetism

  • magnetic structure
  • element selective magnetometry
  • magnetic imaging
  • time resolved study
  • extreme conditions
slide-24
SLIDE 24

ESM-2018, Krakow, 26/9/2018 24

Applications of synchrotron radiation

X-ray diffraction

Vimeo.com/diamondlightsource

slide-25
SLIDE 25

ESM-2018, Krakow, 26/9/2018 25

Applications of synchrotron radiation

www.wikipedia.org

active sites, where CO2 is bound

X-ray diffraction Crystal structure

  • f proteins

e.g. RuBisCO enzyme

slide-26
SLIDE 26

ESM-2018, Krakow, 26/9/2018 26

Applications of synchrotron radiation

Time resolved and in-situ study Release of oxygen from Myoglobine protein

Courtesy: esrf.eu

slide-27
SLIDE 27

ESM-2018, Krakow, 26/9/2018 27

Applications of synchrotron radiation

Coherent photon beam ~20mm lateral size up to 150m projection Contrast due to small variations of refractive index

Phase contrast image

Courtesy: esrf.eu

slide-28
SLIDE 28

ESM-2018, Krakow, 26/9/2018 28

Applications of synchrotron radiation

Phase contrast tomography

Courtesy: esrf.eu

Non-destructive testing of fossils e.g. anatomical details of ancient snakes

slide-29
SLIDE 29

ESM-2018, Krakow, 26/9/2018 29

Interaction of X-rays with matter

henke.lbl.gov

slide-30
SLIDE 30

ESM-2018, Krakow, 26/9/2018 30

X-ray absorption

Dipol selection rules:

βˆ†π‘š = Β±1 βˆ†π‘˜ = Β±1 𝑝𝑠 0 Ds = 0

3d 4p EF 1s TM K-edge RE L3,L2,L1 edges

Element selective & symmetry sensitive probe of unoccupied electronic structure

slide-31
SLIDE 31

ESM-2018, Krakow, 26/9/2018 31

Magnetic scattering and absorption

Atomic form factor

   

E if E f f f " '   =

Elastic Reflectivity Absorption

4 2

10 ~

ο‚Έ charge magnetic

f f

Magnetic vs. charge scattering

S B L A οƒ—  οƒ— ~ fmagnetic

Orbital Spin

C.C. Kao at al., Phys. Rev. B (1994)

slide-32
SLIDE 32

ESM-2018, Krakow, 26/9/2018 32

3d EF 2p1/2 2p3/2

X-ray magnetic circualar dichroism

Photon energy Mass absorption

mο‚­ο‚― mο‚­ο‚­ Dm

L3 L2 π‘ͺπ’‡π’šπ’–

  • G. van der Laan, J. Phys.: Conf. Series (2013)
slide-33
SLIDE 33

ESM-2018, Krakow, 26/9/2018 33

Sum rules

B.T.Thole et al., PRL 68 (1992) 1943 P.Carra et al., PRL 70 (1993) 694 where n denotes the number of holes in the final states

Enable to separate spin and orbital moments

slide-34
SLIDE 34

ESM-2018, Krakow, 26/9/2018 34

Magnetic X-ray microscopy

XMCD using ultrasmall X-ray beam or magnification optics & position sensitive detector for photons/photoelectrons

A.P. Hitchcock, J. Electron Spectrosc. Relat. Phenom. (2015)

slide-35
SLIDE 35

ESM-2018, Krakow, 26/9/2018 35

Magnetic X-ray microscopy

  • F. Noltig in Magnetism and Synchrotron Radiation New Trends, Springer 2010

XMCD contrast proportional to the magnetization projection on incoming photon direction 3d EF 2p1/2 2p3/2

slide-36
SLIDE 36

ESM-2018, Krakow, 26/9/2018 36

X-ray Emission

x 8 x 500

Ka2 Kb1,3 Ka1 Kb2,5

3d 4p EF 1s 3p Fe2O3 S=5/2 K3Fe(CN)6 S=1/2 K4Fe(CN)6 S=0 Theory Experiment

P.Glatzel & U.Bergmann, Coord. Chem. Rev. (2005)

Similar information to XPS, but for (diluted, insulating, buried …) bulky samples Sensitive to nominal spin of transition metals

slide-37
SLIDE 37

ESM-2018, Krakow, 26/9/2018 37

(Resonant) Inelastic X-ray Scattering

A.Baron, arxiv.org/1504.01098

Continuum EF Core level Energy transfer (loss) Magnon

(R)IXS

High resolution probe of elementary excitations including Q dependence

slide-38
SLIDE 38

ESM-2018, Krakow, 26/9/2018 38

Resonant (Inelastic) X-ray Scattering

  • L. Ament et al., Phys. Rev. Lett. (2009)

magnon

  • rbital (d-d) excitation

elastic scattering

Complete polarisation analysis allows to disentangle the origin of elementary excitation probed:

slide-39
SLIDE 39

ESM-2018, Krakow, 26/9/2018 39

Outline

Development of SR sources Properties of SR, instrumentation Applications of SR

  • diffraction
  • imaging
  • spectroscopy

Applications to magnetism

  • magnetic structure
  • element selective magnetometry
  • magnetic imaging
  • time resolved study
  • extreme conditions
slide-40
SLIDE 40

ESM-2018, Krakow, 26/9/2018 40

Magnetic diffraction

slide-41
SLIDE 41

ESM-2018, Krakow, 26/9/2018 41

XMCD spectroscopy

slide-42
SLIDE 42

ESM-2018, Krakow, 26/9/2018 42

XMCD – sum rules

slide-43
SLIDE 43

ESM-2018, Krakow, 26/9/2018 43

Element selective magnetometry

gFe2O3

R=5.0nm

(MnFe)3O4

d=1.1nm

Mn3O4

d=0.3nm

TEM-EELS Fe 1s2p RIXS-MCD MnFe2O4 Mn: NPs

slide-44
SLIDE 44

ESM-2018, Krakow, 26/9/2018 44

Nature Nanotechnology 12 (2017) 980

X-ray magnetic microscopy

slide-45
SLIDE 45

ESM-2018, Krakow, 26/9/2018 45

Tomography

Magnetization topology inside GdCo2 nanopillar

slide-46
SLIDE 46

ESM-2018, Krakow, 26/9/2018 46

Tomography

1um

300nm

300nm

Magnetization topology inside GdCo2 nanopillar

slide-47
SLIDE 47

ESM-2018, Krakow, 26/9/2018 47

Extreme conditions

  • R. Torchio et al., Coordination Chem. Rev. (2014)

www.esrf.eu

slide-48
SLIDE 48

ESM-2018, Krakow, 26/9/2018 48

Extreme conditions

Mg0.9Fe0.1SiO3

slide-49
SLIDE 49

ESM-2018, Krakow, 26/9/2018 49

Further reading

slide-50
SLIDE 50

ESM-2018, Krakow, 26/9/2018 50

Synchrotron training

For regional synchrotron schools and specialized workshops check regularly at www.lightsources.org, www.calipso.eu and www.ceric-eric.eu
