Vertical Emittance Tuning at the Australian Synchrotron Light Source Rohan Dowd Presented by Eugene Tan Overview Machine overview LOCO method and minimisation technique Minimisation results and Measurements Sextupole


slide-1
SLIDE 1

Vertical Emittance Tuning at the Australian Synchrotron Light Source

Rohan Dowd Presented by Eugene Tan

slide-2
SLIDE 2

Overview

  • Machine overview
  • LOCO method and minimisation technique
  • Minimisation results and Measurements
  • Sextupole alignment measurements
  • Conclusion

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-3
SLIDE 3

Australian Synchrotron Light Source Overview

  • Storage Ring Parameters

Energy 3 GeV Circumference 216 m RF Frequency 499.654 MHz Peak RF Voltage 3.0 MV Current 200 mA Betatron Tune (h/v) 13.3/5.2 Momentum Compaction 0.002 εx (nominal) 10.4 nm∙rad

  • Double bend lattice
  • 14 fold symmetric
  • Gradient dipoles
  • Corrector and skew quad coils on sextupoles.
  • Independent power supplies for all

multipoles.

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-4
SLIDE 4

LOCO method

  • LOCO – Linear Optics from Closed Orbits.
  • Adjusts the linear optics in the model to fit the real machine data
  • Model response matrix – Machine response matrix = Error
  • Minimise error by adjusting the model ‘fit parameters’
  • Fit Parameters normally include:

– BPM/Corrector gains and coupling – Corrector gains and coupling – Quadrupole strengths – Skew Quadrupole strengths

  • We fit skew quadrupole components in all multipole magnets in our model

lattice to represent rolls and misalignments.

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-5
SLIDE 5

LOCO Outputs

Outputs:

  • BPM Gains + Couplings
  • Skew components
  • Quad Strengths
  • Corrector gains/tilts

From these outputs we can calibrate the model and calculate skew corrections needed to adjust coupling Consistent BPM/corrector coupling results for differing machine coupling settings – LOCO is not attributing the machine coupling to BPM/corrector coupling

Fits to varying machine coupling states (0.01- 17% coupling) Fits to identical machine coupling (10 samples)

ICFA - Low Emittance Ring Workshop 3-5 October 2011

Verified from attenuation measurements for the BPM.

slide-6
SLIDE 6

Emittance Coupling minimisation

  • Emittance coupling (εy/εx) calculated from LOCO Calibrated model.
  • Minimisation algorithm used to adjust skew quads to desired emittance

coupling.

  • Emittance coupling can be adjusted to arbitrary amounts with this

method.

Set Coupling LOCO Measured Coupling Calculated εy (pm) 0.0% 0.01% 1.0 0.1% 0.12% 12.2 0.2% 0.23% 23.5 0.3% 0.33% 33.7 0.4% 0.43% 43.9 0.5% 0.54% 55.1 0.6% 0.64% 65.3 0.7% 0.74% 75.5 0.8% 0.84% 85.7 0.9% 0.92% 93.8 1.0% 1.04% 106.1

  • Phys. Rev. ST Accel Beams, 14, 012804 (2011)
slide-7
SLIDE 7

Touschek Lifetime vs RF

  • By taking single bunch lifetime over extended period the Touschek

component of the lifetime can be extracted.

                       

 

       

                 du u e du u u e e D D c Nr

u u x x y x z e

) 2 ) ln( 3 ( 2 1 ) ln( 2 2 3 ) ( , , ) ( 8 1

max 3 max 2 2

) 1 ( ) (

1 1 2 a a

e a i b be i t i b i a i dt di

 

     

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-8
SLIDE 8

Touschek Lifetime vs RF

  • Touschek component will also change with RF voltage.
  • 2.1% energy acceptance

(measured)

  • Curve fit by varying εy/εx ,
  • ther values fixed.
  • Blue curve fit corresponds to

εy = 1.24 pm Set εy/εx (%) Fitted εy/εx (%) εy (pm)

0.01 0.012 ± 0.003 1.2 ± 0.3 0.06 0.043 ± 0.013 4.5 ± 1.3 0.10 0.093 ± 0.025 9.4 ± 2.6 ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-9
SLIDE 9

Tune Crossing Results

LOCO Model εy (pm) ηy Component (pm) Betatron Coupling Component (pm) Total Measured εy (pm) Model – Measured (pm)

92.31 ± 2.77 2.24 ± 0.09 86.90 ± 2.65 89.55 ± 2.65 2.76 ± 3.83 76.30 ± 2.23 2.96 ± 0.12 76.50 ± 2.14 78.64 ± 2.14 2.34 ± 3.09 41.41 ± 1.24 1.73 ± 0.07 40.39 ± 1.84 42.23 ± 1.84 0.82 ± 2.22 22.75 ± 0.68 2.04 ± 0.08 19.69 ± 1.33 21.72 ± 1.33 1.03 ± 1.49 12.75 ± 0.38 2.14 ± 0.09 10.71± 1.02 12.85 ± 1.02 0.10 ± 1.09 7.55 ± 0.23 1.73 ± 0.07 5.41 ± 0.71 7.14 ± 0.71 0.41 ± 0.75 1.05 ± 0.03 0.73 ± 0.09 0.59 ± 0.30 1.32 ± 0.31 0.27 ± 0.31 ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-10
SLIDE 10

How to improve?

  • With current correction scheme we are stuck at 1-2 pm.
  • Instead of correcting for misalignments, lets eliminate

them.

  • Recent ring alignments have made the coupling worse!
  • Need to measure them independently – Beam based

method

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-11
SLIDE 11

Sextupole offsets

  • Shunt each sextupole

magnet family to different strengths and take a response matrix at each point

  • Perform LOCO analysis

and fit skew quadrupole terms to each sextupole.

  • Gradient of skew field vs

sextupole field gives vertical offset.

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-12
SLIDE 12

Sextupole Offset Results

  • Average offset:

70 microns

  • Systematic

alignment effect?

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-13
SLIDE 13

Cross Checks

Applied BPM Offset Measure Mean Beam Offset Difference from zero +125 234.6 ± 10.6 128.7 ± 18.8 +75 167.7 ± 16.5 61.8 ± 22.6 105.9 ± 15.5

  • 75

33.1 ± 17.8

  • 72.8 ± 23.6
  • 125
  • 16.1 ± 21.6
  • 122 ± 26.6

Magnet Original Offset (μm) Applied Shim (μm) New Offset (μm) Delta offset (μm) Sector 9 SFB

  • 108.4 ± 44.6

150

  • 249.3 ± 7.2

140.9 ± 45.2 Sector 11 SFB

  • 56.7 ± 10.0

100

  • 120.4 ± 56.0
  • 63.4 ± 57.4

Sector 9 SDA

  • 14.6 ± 9.9

100

  • 118.3 ± 8.3
  • 103.7 ± 14.1

Cross checks show that amplitude of offset is correct and individual magnets can be adjusted accurately.

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-14
SLIDE 14

Sextupole Realignment – latest results

Re-aligned section (girder #16-21) now has much lower offsets. Simulated minimal vertical emittance has reduced from 1pm to 0.7 pm.

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-15
SLIDE 15

Conclusions

  • εy of 1.3 pm.rad achieved through LOCO based minimisation.
  • We have developed tools to accurately measure sextupole

misalignments and eliminate them.

  • Aim to have all sextupoles realigned by end of year and expect to

reach < 1 pm emittance

  • Also working on an inexpensive way to increase available skew

correctors

ICFA - Low Emittance Ring Workshop 3-5 October 2011

slide-16
SLIDE 16

Thank you
