Maximising durability and sustainability in the Middle East climate using precast concrete Welcome Why sustainability? The Middle East has five per cent of the world's population but only one per cent of the water. Source: World

slide-1
SLIDE 1

Maximising durability and sustainability in the Middle East climate using precast concrete

slide-2
SLIDE 2

ابحرم

Welcome

slide-3
SLIDE 3

Why sustainability?

slide-4
SLIDE 4

The Middle East has five per cent of the world's population but only one per cent of the water.

Source: World Bank

Every day the worldwide economy burns an amount of energy the planet required 10,000 days to create - the stored solar energy is burned and released by utilities, cars, houses, factories and farms.

Source: Paul Hawken, The Ecology of Commerce
slide-5
SLIDE 5
slide-6
SLIDE 6

What is the environmental impact of buildings?

slide-7
SLIDE 7

39% of energy use

  • 80–85% operational

energy during lifetime

  • 70% reductions possible
slide-8
SLIDE 8

solar reflective paints reduce heat by 50%

slide-9
SLIDE 9

12% of water use

  • 50-60% reductions possible
slide-10
SLIDE 10

Recycle greywater . . . and use it for

slide-11
SLIDE 11

irrigating gardens with 100% greywater to supply all irrigation and save 30% of water total household use

slide-12
SLIDE 12

Rooftop gardens

slide-13
SLIDE 13
slide-14
SLIDE 14

68% of total electricity use

  • Energy conservation has twice the

financial return of renewables

  • Alternative energy creation
  • Electrical efficient design
  • Insulation
  • Passive design
  • Natural lighting
slide-15
SLIDE 15
  • Lighting

consumes 19%

  • f the world’s

electricity

  • Eco bulb’s use

80% less power

  • Integration with

good daylighting design can reduce this a further 50%

slide-16
SLIDE 16

38% of carbon emissions

  • Reduction of energy use
  • Reduction of water use
  • Reduction of electricity use
slide-17
SLIDE 17

A thought . . .

  • Buildings mortgage the

energy and environmental future

slide-18
SLIDE 18

start searching for

sustainability

slide-19
SLIDE 19

IMAGINE a building system

slide-20
SLIDE 20

that makes building

as simple as LEGO

slide-21
SLIDE 21

Green Precast Systems

Stack complete “wall and ceiling” precast components one at a time

slide-22
SLIDE 22

Green Precast Systems

Up to 2 times faster than other precast

systems with modular room sized units stacked 5 stories high in a day

slide-23
SLIDE 23

factory fit out

slide-24
SLIDE 24

factory fit out

Windows & door frames cast in

slide-25
SLIDE 25

factory fit out

slide-26
SLIDE 26

factory fit out

First fit electrical & MEP

slide-27
SLIDE 27
  • Painting
  • Balustrades
  • Floor polishing
  • Kitchens & Bathrooms

factory fit out

slide-28
SLIDE 28
  • Painting
  • Balustrades
  • Floor polishing
  • Kitchens & Bathrooms

factory fit out

slide-29
SLIDE 29

Large multi story projects

slide-30
SLIDE 30

Multi story comparison

slide-31
SLIDE 31

Multi story comparison

Green Precast Systems Tilt Slab

  • ne lift per module

many lifts no props many props no formwork formwork required safe working platform no working platform few joints many joints 4-5 floors per day 1-2 floors per day less materials (5-25%) inflexible material qty

Multi storey comparison

slide-32
SLIDE 32

Multi storey comparison

Green Precast Systems Tilt Slab

  • ne lift per module

many lifts no props many props no formwork formwork required safe working platform no working platform few joints many joints 4-5 floors per day 1-2 floors per day less materials (5-25%) inflexible material qty

slide-33
SLIDE 33

. . . contemporary townhouses

slide-34
SLIDE 34

. . . and villas

slide-35
SLIDE 35

Al Ghadeer prototype villa

Construction January 2009

slide-36
SLIDE 36

Al Ghadeer (ground & 1st floor)

slide-37
SLIDE 37

Al Ghadeer (module placement)

6x4m

slide-38
SLIDE 38

Al Ghadeer (module placement)

6x4m

slide-39
SLIDE 39

Al Ghadeer (module placement)

slide-40
SLIDE 40

Al Ghadeer (module placement)

6x3m 6x4m

slide-41
SLIDE 41

Al Ghadeer (module placement)

6x3m 6x4m

slide-42
SLIDE 42

Al Ghadeer (module plans)

6x3m 6x4m

slide-43
SLIDE 43

Al Ghadeer (additional internal walls)

6x3m 6x4m

slide-44
SLIDE 44

Al Ghadeer

slide-45
SLIDE 45

Green Precast Systems can be specified and designed into a project to the benefit of the environment and the project’s bottom line

slide-46
SLIDE 46

Concrete lasts thousands of years

The earth’s resources are best conserved if the service life

  • f a building is

prolonged, so the durability and longevity of concrete makes it an ideal choice.

Photo: the Pantheon the largest Roman concrete structure
slide-47
SLIDE 47

Life Cycle of Green Precast Systems The embodied energy of concrete is high yet it has a very long life and is low maintenance When the embodied energy resources used to maintain it over this time are divided in to its operational life it is highly sustainable compared with other materials

slide-48
SLIDE 48

No formwork

slide-49
SLIDE 49

Reduced site

slide-50
SLIDE 50

Waste onsite is not lost . . .

…it often never even appears …up to 90% reduction from Green Precast Systems

slide-51
SLIDE 51

relocatable

slide-52
SLIDE 52

recyclable

slide-53
SLIDE 53
  • High tech mould 12-24 hour cycle
  • Cast in doors, window frames and MEP
slide-54
SLIDE 54

Re-usable forms

Forms have a long life span Re-use of forms reduces waste and debris at the job site. Construction sites are cleaner, neater and quieter

slide-55
SLIDE 55

up to 70% labour savings on installation

slide-56
SLIDE 56

up to 50% faster construction times

slide-57
SLIDE 57

Speed > velocity of capital invested

  • Significant advantage of speed is that

capital invested is returned in up to half the time

  • Less risk of liquidated damages on late

delivery of projects

  • Income stream much sooner
slide-58
SLIDE 58

Less materials

Monolithic construction uses 5-25% materials to achieve the same strength

slide-59
SLIDE 59
  • for sustainability initiatives
  • at no extra cost to the project
slide-60
SLIDE 60

Sustainability Design Considerations

slide-61
SLIDE 61

Efficient Building Modules

An efficient building is one that integrates and optimises insulation levels, glazing, shading, thermal mass, air leakage control, and UV reflective exterior surfaces to minimise heat gains. Green Precast Systems achieve this.

slide-62
SLIDE 62

Sustainability & Green Precast Systems

A sustainable building lies in long- life, adaptable, low- energy design All features of Green Precast Systems

slide-63
SLIDE 63

Reducing operational energy

  • High reflectivity
  • Thermal mass
  • Insulation
  • Shading
  • Interior air quality
  • Durability
slide-64
SLIDE 64

Cooler communities

 Reflective precast concrete can moderate the heat island urban effect  “Cool” roofs and walls have proven to lower the need for a/c up to 50%  Solar reflective paints can increase this efficiency. Green Precast Systems paints have the highest reflectivity in world. Available to wider market.

slide-65
SLIDE 65

Thermal Mass

Use thermal mass in combination with insulation Thermal mass with insulation provides energy benefits that exceed the benefits of mass or insulation alone

slide-66
SLIDE 66

Thermal mass

By storing and releasing the energy needed for cooling, concrete's thermal mass delivers year- round energy benefits by reducing temperature swings in buildings. Thermal mass impacts the size of HVAC systems. Thermal mass can reduce energy for cooling by up to 50%.

slide-67
SLIDE 67

Insulation

Heat Energy Warm Air Cool Air

Improving wall and roof assembly performance

Energy transfer is minimized by wall design: Add insulation Add mass Minimize thermal bridging Minimize infiltration & exfiltration Control moisture

slide-68
SLIDE 68

Insulation

Sandwich core insulation

slide-69
SLIDE 69

Insulation

Cement render finish Reinforcing mesh Fire proof polystyrene

  • External Insulation System
  • Abu Dhabi municipality approved
  • Applied externally to modules for

thermal mass benefit and rendered

Save Energy Costs up to 40%!

slide-70
SLIDE 70

Window treatments

  • verhang

double skin

slide-71
SLIDE 71

Shading

Deep recessed windows allow indoor daylighting without heat buildup Double and insulating glazing reduce heat transfer through glass

slide-72
SLIDE 72

Shading

The inclusion of shading over windows can greatly reduce heat gain and air con use.

Photo: Photovoltaic awnings over windows
slide-73
SLIDE 73

Indoor air quality

Indoor environmental quality Excellent sound and fire protection and high thermal mass touch on every aspect

  • f sustainable design as well as the

important aspect of increased consideration for people’s health and safety

slide-74
SLIDE 74

Indoor air quality

People spend up to 90% of their time indoors.

The simple lines and smart edges of Green Precast Systems are easy to keep clean. Concrete is an inert substance so it doesn’t give off any gasses, toxic compounds or volatile organic compounds.

slide-75
SLIDE 75

Durability

Fire resistance Because precast concrete is non- combustible – it does not require additional fire- proofing applications. 1-2 hour fire rated.

slide-76
SLIDE 76

Durability

Corrosion Resistance  Quality control in manufacture  40+Mpa concrete less porous  Vibration reduces air content  Waterproof -painted or rendered with Green Precast products

slide-77
SLIDE 77

Durability

Inedible to Vermin & Insects

  • Vermin and insects cannot destroy

concrete because it is inedible.

slide-78
SLIDE 78

How to achieve Sustainable Design

slide-79
SLIDE 79

The complexity of sustainability

slide-80
SLIDE 80

Evolution of holistic design

No focus on sustainability outcomes

slide-81
SLIDE 81

Evolution of holistic design

Focus on sustainability from their perspective

slide-82
SLIDE 82

Evolution of holistic design

Group defines sustainability outcomes they wish to achieve, defines links and

  • pportunities. Require high degree of ongoing

communication.

slide-83
SLIDE 83

Sustainability cost-effectiveness

Good design produces cost neutral

  • utcomes

Holistic design must be undertaken at

  • utset of project to achieve this

Stages in design effort Level of effort Level of effort Opportunities to implement cost effective integration

slide-84
SLIDE 84

كل اركش

Thank you
