SUSE OpenStack Cloud

127

What is SUSE OpenStack Cloud

• You know of Cloud Compute right?

Maybe you use AWS or Azure?

• Allowing pay-as-you-go model for IT infrastructure and

toward dynamic software-defined service delivery.

• But you may need a capital investment that resides in

your control domain (data center).

• Whilst you need the same multi-tenant, agile, cloud

scale characteristics for this cloud service.

• That is where SUSE OpenStack Cloud comes in.

128

Why OpenStack?

• OpenStack is an open source software platform for cloud
• computing. Mostly deployed as infrastructure-as-a-service

(IaaS), whereby virtual servers and other resources are made available to customers.

• Manages multi-vendor hardware pools of processing,

storage and networking resources throughout a data center.

• Managed through a web-based dashboard, command-line

tools, or via RESTful web services.

• The OpenStack Foundation began managing

OpenStack in 2010.

• More than 500 companies have joined the project.

129

How SUSE Works in OpenStack

• This is great with Cloud Native because you can

not only orchestrate VM’s but also Bare Metal and containers.

• But why not manage the more traditional

workloads in your environments?

• We influence the leadership (Alan Clark and

Helion).

• Give back: our message of HA for the

Cloud was critical.

• It also helps that SUSE is in open source

generally, Linux, KVM, Xen, Networking, Storage etc.

130

Scheduler

SUSE Choice and Support

Investment protection and enhanced value

Admin/Deployer Server

SUSE Linux Enterprise Chef* / Ansible Server Crowbar* Software mirror DHCP/TFTP

Control Node

SUSE Linux Enterprise Database Message queue Identity Image store Cinder Neutron Dashboard Scheduler Other

Cloud UI

OpenStack compute

z/VM Hyper-V

OpenStack compute KVM/XEN/ Containers OpenStack Compute SUSE OpenStack Monitoring z/VM OpenStack Compute Vmware Proxy OpenStack Compute +

Deployer UI

CLM

131

High-Availability OpenStack Infrastructure

Because downtime is not an option

HA Proxy Node 1 Node 2 Node 3

COROSYNC PACEMAKER

Services Cluster

SUSE Linux KVM or Xen

OpenStack compute PACEMAKER REMOTE

SUSE Linux KVM or Xen

OpenStack compute PACEMAKER REMOTE

SUSE Linux KVM or Xen

OpenStack compute PACEMAKER REMOTE

SUSE Linux KVM or Xen

OpenStack compute PACEMAKER REMOTE

PACEMAKER

Keep my workload running Keep my cloud running

132

This Section Covered:

• SUSE is the most experienced vendor in delivering open source IaaS

Clouds with OpenStack.

• We are a key representative on behalf of any customer in that community.
• It is all built on core SUSE technology and we bring value to you.
• We have a mature, powerful, replicable deployment technology providing

broad support of other technologies.

• SUSE has augmented this with newer powerful capabilities. Be that with

HA in the Compute Plane, project support or SUSE OpenStack Cloud Monitoring.

• The real value to you is what you can deliver with Software-defined

Infrastructure service delivery.

133 133

SDI Demo

134

HEAT Script

The Cloud Operator will get the cloud and Project ready, adding all the resources needed, then pass to the consumers in the Projects.

135

What is a HEAT Template

• This is a YAML (simple) script form (be careful of spacing).
• Define the variables under the “parameters” section.
• The “resources” section actually creates the virtual infrastructure
• As this has developed you are able to use many simple scripting

techniques (if, then, else, etc.)

• When combined with Cloud-Init (Cloud-init is a package that contains

utilities for early initialization of cloud instances) you have great versatility in how the Virtual resources boot.

• Like all scripts remember to use a version management system such as

GIT and maybe adopt CI development.

136

HEAT and How it Brings SDI

• This is not a training session but,
• Simple yaml based scripting that takes the

resources available in the cloud you build and can trigger all that once the script is ran.

• This is the engine that delivers, adaptive,

agile, tenant resources at cloud scale on demand.

137

This Demo Showed

• With SUSE delivering such a robust,

powerful easy to use private cloud via SUSE OpenStack Cloud you can start to deliver highly elastic, cloud scale, service infrastructure at the click of a single button.

• This “code” the becomes an asset that

can be built upon, augmented and used as many times as required.

138 138

SUSE OpenStack Cloud Lifecycle

139

2018 2019 2020 2021 8 9 10 8 Built On

• OpenStack Pike Release
• SUSE Linux Enterprise Server 12 SP3

New or Expanded Services

• SUSE CAP Integration
• Physical Server as a Service (Ironic)
• SDN Support for NSX-V
• Dual lifecycle manager options

Operational Enhancements

• Non-disruptive Upgrade to Cloud 8
• Planning and Pre-install Validation
• Simple Deployment UI
• Scale Testing 200 nodes
• Monitor Capacity and Performance
• 3-year support

Built On

• OpenStack Rocky Release
• SUSE Linux Enterprise

Server 12 SP4

New or Expanded Services

• Containerized Control Plane**

Operational Enhancements

• IPV6 Support
• Policy-based Optimization**

Built on

• OpenStack Pike Release
• SUSE Linux Enterprise Server

12 SP3

New or Expanded Services

• SDN Support for Cisco ACI
• SDN Support for Juniper

Contrail

• SDN Support for NSX-T
• SDN Support for Nuage
• OpenDaylight integration
• OPNFV framework integration

Operational Enhancements

• Lifecycle Tools Improvements
• mkcloud support
• SES Integration

8 Updates 9 10 Built On

• OpenStack T Release
• SUSE Linux Enterprise Server 15

New or Expanded Services

• Containerized Control Plane
• Accelerator Engine Support

Operational Enhancements

• Multiple Site Enhancements
• DR Enhancements
• Root Cause

Detection/Analysis/Repair

• Kubernetes Networking

Configurations

• Workflow Automation

9 Updates Built On

• OpenStack Rocky Release
• SUSE Linux Enterprise

Server 12 SP4

New or Expanded Services

• GPU Support

Operational Enhancements

• Scalability Improvements
• Multiple Site Support
• Region Support
• Federation
• Multi-Data Center Support
• Cloud Monitoring
• Lifecycle Events Monitoring
• Advanced Log Analysis
• Monitoring Analytics
• Integration with SUMA, SES
• Integration with SUSE Single

Sign-on

SUSE OpenStack Cloud

** Items are tech preview * Information is forward looking and subject to change at any time.

140

How This Fits with Everything Else

• OpenStack can help you

manage the changing demands

• n your organisation
• Whether you need to deliver

cloud Native, Virtualised or traditional services

141
