Surface Mining... Surface Mining... Draglines... ... and mining Dragline Methods Dragline Methods History of Draglines History of Draglines First dragline built in 1904 by Page & Schnable Built for a specific need on the

slide-1
SLIDE 1

Draglines... ... and mining

Surface Mining... Surface Mining... … Dragline Methods … Dragline Methods

slide-2
SLIDE 2

History of Draglines History of Draglines

✔ First dragline built in 1904

by Page & Schnable

✔ Built for a specific need

  • n the Chicago Drainage

Canal project

✔ In 1912, Page Engineering

Company incorporated when Page discovered building draglines more profitable than contracting

slide-3
SLIDE 3

History, continued History, continued

✔ Up until 1912 no one had

developed a means of propelling the machine

✔ In 1913 an engineer for

Monighan Machine Company revolutionized dragline by placing two shoes, one on each side of the revolving frame

✔ The Model 1-T became

the first walking dragline

slide-4
SLIDE 4

History, continued History, continued

World’s Largest Machines

✔ 1935 12 CY manufactured by Bucyrus Erie ✔ 1942 30 CY manufactured by Marion ✔ 1961 40CY manufactured by Ransom & Rapier (British) ✔ 1963 85 CY manufactured by Marion ✔ 1965 145 CY manufactured by Marion ✔ 1969 220 CY manufactured by Bucyrus Erie

slide-5
SLIDE 5

History, continued History, continued

World’s Largest Machines

✔ BIG MUSKIE ✔ Muskinghum Mine of

Central Ohio Coal Company (AEP)

✔ Operated until June

1991

✔ Attempting to preserve

as a public historical facility

slide-6
SLIDE 6

History, continued History, continued

✔ Today only two remaining manufactures of

draglines:

– Bucyrus Erie – P & H

slide-7
SLIDE 7

History of Dragline Operations in West Virginia History of Dragline Operations in West Virginia

✔ Joe Hughes of Northeast Mining Company operated a 4

yard Page near Beaver Creek in Tucker County in 1963

✔ During late 1960’s and 1970’s several operations

including:

Imperial Coal & Construction Co. Grant County Coal Corp.L Byron Construction Company Bitner Mining Island Creek Coal

slide-8
SLIDE 8

History of Dragline Operations in West Virginia History of Dragline Operations in West Virginia

✔ 1983 Hobet Mining began operations with a BE 1570 - 80 CY dragline

at Hobet 21 near Madison

✔ 1983 Taywood Mining operated a Marion 183M - 9 CY ✔ 1987 Hobet Mining installed Marion 8200 - 72 CY machine at the

Hobet 07 operations (transferred to Dal-Tex in August 1996)

✔ 1989 Morrison Knudsen began contract mining operations at

Cannelton with a Marion 8200 - 72 CY

✔ 1989 AOWV/Ruffner added Marion 8400 - 49 CY machine ✔ 1994 Catenary Coal Company installed a BE 2570 - 100 CY machine

at the Samples Mine (upgraded 1998 to 118 CY)

✔ 1998 Evergreen Mining comissioned a BE 1570 - 75 CY machine in

Webster County

slide-9
SLIDE 9

History of History of Draglines Draglines Operating in West Virginia Operating in West Virginia

✔ 1999 - 6 draglines in operation:

  • BE 1570 at Hobet 21 Mine
  • Marion 8400 at AOWV/Ruffner Mine
  • Marion 8200 at Dal-Tex Mine
  • BE 2570 at Catenary/Samples Mine
  • Marion 8200 at Cannelton Mine
  • BE 1570 at Evergreen Mine
slide-10
SLIDE 10

West Virginia Dragline Operations Arch Coal, Inc. West Virginia Dragline Operations Arch Coal, Inc.

Ruffner/Wylo Ruffner/Wylo Dal-Tex Dal-Tex Samples Samples Hobet 21 Hobet 21

slide-11
SLIDE 11

Mine Planning.. Mine Planning..

slide-12
SLIDE 12

General Considerations in WV General Considerations in WV

✔ Topographical constraints ✔ Pit geometry (length/width/bench height) ✔ Need for added mobility of machine ✔ Single vs. multiple seam ✔ Development requirements ✔ Contemporaneous reclamation ✔ Economics

slide-13
SLIDE 13

Topographic Map of Dragline Area Topographic Map of Dragline Area

slide-14
SLIDE 14

Coal Seam Correlation Coal Seam Correlation

Coal Seam Correlation Coal Seam Correlation

slide-15
SLIDE 15

Coal Crops / Reserve Boundaries Coal Crops / Reserve Boundaries

slide-16
SLIDE 16

Volumetric Gridding Volumetric Gridding

dding

slide-17
SLIDE 17

Mine Sequencing Mine Sequencing

slide-18
SLIDE 18

3-Dimensional Modeling 3-Dimensional Modeling

slide-19
SLIDE 19

Pit Geometry Pit Geometry

slide-20
SLIDE 20

BE 2570 - Samples Mine BE 2570 - Samples Mine

slide-21
SLIDE 21

Schematic Showing Typical Dragline Operation Schematic Showing Typical Dragline Operation

slide-22
SLIDE 22

General Mining Sequence ‘A’ General Mining Sequence ‘A’

slide-23
SLIDE 23

General Mining Sequence ‘B’ General Mining Sequence ‘B’

slide-24
SLIDE 24

General Mining Sequence ‘C’ General Mining Sequence ‘C’

slide-25
SLIDE 25

Typical Multi-Seam Dragline Sequence ‘1’ Typical Multi-Seam Dragline Sequence ‘1’

slide-26
SLIDE 26

Typical Multi-Seam Dragline Sequence ‘2’ Typical Multi-Seam Dragline Sequence ‘2’

slide-27
SLIDE 27

Typical Multi-Seam Dragline Sequence ‘3’ Typical Multi-Seam Dragline Sequence ‘3’

slide-28
SLIDE 28

Typical Multi-Seam Dragline Sequence ‘4’ Typical Multi-Seam Dragline Sequence ‘4’

slide-29
SLIDE 29

Typical Multi-Seam Dragline Sequence ‘5’ Typical Multi-Seam Dragline Sequence ‘5’

slide-30
SLIDE 30

During Mining During Mining

slide-31
SLIDE 31

After Mining

(1+ yrs. reclamation)

After Mining

(1+ yrs. reclamation)

slide-32
SLIDE 32

Concept of Excess Spoil Original Cross Section Prior To Mining Concept of Excess Spoil Original Cross Section Prior To Mining

slide-33
SLIDE 33

Original Material Swelled 125% Original Material Swelled 125%

slide-34
SLIDE 34

Regraded Cross Section After Reclamation Regraded Cross Section After Reclamation

slide-35
SLIDE 35

Concept of Excess Spoil Disposal Alternatives Concept of Excess Spoil Disposal Alternatives

✔ Two primary disposal alternatives:

1 - Valley Fill (usually durable rock construction) 2 - Backfill on mined-out area

slide-36
SLIDE 36

Durable Rock Valley Fill Durable Rock Valley Fill Construction Construction

Phase 1

Sediment Pond Construction

slide-37
SLIDE 37

Phase 2

Initial Overburden Placement

slide-38
SLIDE 38

Phase 3

Continued Overburden Placement

slide-39
SLIDE 39

Phase 4

Overburden Placement Completed Surface Drainage Conveyances Constructed

slide-40
SLIDE 40

Phase 5

Regrading / Revegetation Completed

slide-41
SLIDE 41
slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44
slide-45
SLIDE 45

Backfilling Operations Backfilling Operations

slide-46
SLIDE 46

Drilling & Blasting Operations Drilling & Blasting Operations

slide-47
SLIDE 47
slide-48
SLIDE 48
slide-49
SLIDE 49

Coal Loading Operations Coal Loading Operations

slide-50
SLIDE 50
slide-51
SLIDE 51

Typical Cross Section Stockton Coal Zone Typical Cross Section Stockton Coal Zone

Stockton Coal Zone

S-1 2’ Parting 5’ Rash 5’ S-2 0’ Parting 2’ S-3 6’ Parting 1’ S-4 8’ Overburden 1. 1. 2. 2. 3. 2. 0. 1.

slide-52
SLIDE 52

30” S-3 2” S-4 Parting 24” S-4 2’ to 15’ S-3 Parting

slide-53
SLIDE 53

Environmental Considerations Environmental Considerations

slide-54
SLIDE 54

Establishment of Drainage and Sedimentation Controls Establishment of Drainage and Sedimentation Controls

slide-55
SLIDE 55
slide-56
SLIDE 56

Approximate Original Contour Approximate Original Contour

slide-57
SLIDE 57

Other... Other...

✔Waste Management Plan

Ground Water Protection Plan Spill Prevention Control & Countermeasure Plan

slide-58
SLIDE 58

Fixing the Scars of the Past Fixing the Scars of the Past

  • “Third Generation” Surface Mining

✔ Restoration of abandoned refuse sites eligible for AML

funding at no cost to the state

✔ Creation of wetlands and passive water treatment sites ✔ Elimination of miles of pre-SMCRA highwalls ✔ Extinguishment or isolation of abandoned underground

mine fires

slide-59
SLIDE 59

Pre-SMCRA Highwalls and Deep Mine Entries Pre-SMCRA Highwalls and Deep Mine Entries

slide-60
SLIDE 60
slide-61
SLIDE 61

Abandoned Coal Refuse Dumps Abandoned Coal Refuse Dumps

slide-62
SLIDE 62
slide-63
SLIDE 63

Acid Mine Drainage Acid Mine Drainage

slide-64
SLIDE 64

Reclaimed Pre-law Refuse Sites Reclaimed Pre-law Refuse Sites

slide-65
SLIDE 65

Wetlands Construction Wetlands Construction

slide-66
SLIDE 66

Related Benefits Related Benefits

✔ Resource recovery ✔ Can address prior environmental problems ✔ Provides opportunities for future use of

resource due to infrastructure development

slide-67
SLIDE 67

Russian Dragline Circa 1998 Russian Dragline -

  • Circa 1998
