Simon Saunders, Real Wireless

Study overview – the workshop in context

2

Overview

• Study context and objectives
• Methodology
• LE bands, applications and devices
• Scope
• Approach
• Initial outcomes

3

Study context

Key contextual issues include:-

• Usage of equipment in licence-exempt bands is increasing, bringing

economic and social benefits, but there is little data on actual usage and no protection for users;

• RSPP and Commission Communication “Promoting shared use of

radio resources” identify goal to ensure sufficient harmonised LE spectrum (incl. SRD bands and 2.4/5GHz);

• The results should support the implementation of the Article 9

"Inventory" of the Radio Spectrum Policy Programme (RSPP) by developing a reliable approximation approach to assess the medium and long-term spectrum usage densities in harmonised license-exempt frequency bands;

• EU-US free trade negotiations in context of context of TTIP cover radio

equipment, giving rise to potential trans-Atlantic scale economies.

4

Study Objectives

The overall objective of the study is to enable a better understanding of the use of harmonised licence-exempt frequency bands by different categories of radio equipment in Europe. Operational objectives include:-

• Assess density of current Europe usage of harmonised licence-

exempt spectrum bands;

• Create proxy-based medium- and long-term forecasts of Europe

usage density in LE bands;

• Determine LE spectrum required to support such usage compared

with current levels;

• Compare Europe and US LE equipment volumes and spectrum

allocation policies in common bands.

5

4 Stage Methodology

• LE bands
• Equipment categories & parameters
• Equipment sold in ‘06-’13
• Equipment in use
• Proxy-based tool for equipment density

by category and band

• Density forecasts for next 5 years and

to 2030

• Spectrum estimates by band
• Identify congestion by band
• US sales volumes in ‘06-’13

compared with Europe

• Compare US LE spectrum policies

with Europe

Tasks Outcomes

6

Timetable

• The study started with an inception meeting with the

European Commission on 3rd December

• December RSC initial presentation
• Today’s industry workshop is the first of two
• Interim report due in early April reflecting this workshop
• Second interim report in early June
• Study completion in August, followed by presentation to

RSC

7

Structuring our study

Harmonised LE spectrum Inductive devices Audio capture Band A Band B Wireless charging Band C Band D .. Active medical implants Pacemakers Band C Band D Cochlear implants.. Band C Band E Transport and Traffic Telematics Anti-collision radar Band F …

Application categories Device types Harmonised LE bands

8

Regulatory framework

• EC and ECC decisions were considered
• EC Decisions are compulsory legal requirements for national regulatory authorities to implement in line

with specific technical and regulatory conditions of the technical annex contained within the EC Decision.

• ECC Decisions are not binding legal requirements but rather recommendations by the European

Communications Committee that National Regulatory Authorities (NRAs) are strongly urged to follow. They provide measures on significant harmonisation matters, are normally implemented by CEPT member NRAs.

• There could be cases in which bands are licence exempt but do not fall within the EC or ECC Decision

framework – but none located so far

9

EC Decisions relating to LE bands (1)

Decision Scope Frequencies Applications 2004/545/EC 79 GHz range for the use of automotive SRR 77 – 81 GHz Automotive short-range radar equipment 2005/50/EC 24 GHz band for the time-limited use by automotive SRR 21.65 – 26.65 GHz Automotive short-range radar equipment 2005/513/EC 5 GHz band for the implementation of WAS/RLANs networks 5150 -5350 MHz, 5470 – 5725 MHz Wireless Access system and Radio LANs 2006/771/EC Use by short-range devices Multiple Med implants, non specific SRDs, 2008/432/EC Amendment to 2006/771/EC Multiple 2006/804/EC RFID devices operating in the UHF band 865 – 868 MHz RFID 2007/90/EC Amending 2005/513/EC 5150 -5350 MHz, 5470 – 5725 MHz Wireless Access system and Radio LANs 2007/131/EC Equipment using UWB technology <1.6 GHz up to 10.6 GHz UWB for applications using bandwidths wider than 50 MHz 2008/671/EC 5 875-5905 MHz frequency band for safety- related applications of Intelligent Transport Systems (ITS 5875 - 5905 MHz Intelligent Transport Systems (ITS) 2008/673/EC Amending Decision 2005/928 169.4 – 169.8125 MHz SRDs, Assistive listening devices, metering 2009/381/EC Amending the Decision 2006/771/EC Multiple frequency bands Med implants, non specific SRDs

10

EC Decisions relating to LE bands (2)

Decision Scope Frequencies Applications 2010/368/EU amending the Decision 2006/771/EC Multiple frequency bands Med implants, non specific SRDs 2011/485/EU 24 GHz range radio spectrum band for the time-limited use by automotive SRR 21.65 – 26.65 GHz Automotive short range radar – time limited for review June 2013 2011/829/EU amending Decision 2006/771/EC Multiple frequency bands Med implants, non specific SRDs 2013/752/EU for use by short-range devices and repealing Decision 2005/928/EC Multiple frequency bands Med implants, non specific SRDs 2014/702/EU equipment using ultra-wideband technology <1.6 GHz up to 10.6 GHz More streamlined approach to the mitigation techniques and parameters

11

ECC Decisions relating to LE bands (1)

Decision Scope Frequencies Applications ERC/DEC(94 )03 Frequencies for DECT 1880 – 1900 MHz DECT equipment fixed and portable ERC/DEC/(9 8)22 Exemption from Individual Licensing of DECT equipment 1880 – 1900 MHz DECT equipment fixed and portable ERC/DEC/(9 8)25 Harmonised frequency band for PMR 446 446.0-446.1 MHz Handheld portable analogue voice communications ERC/DEC/(0 1)12 Model control SRDs in 40.665, 40.675, 40.685 and 40.695 MHz 40.665, 40.675, 40.685 and 40.695 MHz Model control in SRD category ERC/DEC/(0 1)11 Flying Model control SRDs in 34.995 - 35.225 MHz 34.995 - 35.225 MHz Flying Model control in SRD category ERC/DEC/(0 1)08 Movement Detection and Alert SRDs in 2400 - 2483.5 MHz 2400 - 2483.5 MHz Equipment for movement detection and alert in SRD category ERC/DEC/(0 1)17 Medical Implant SRDs in 401 - 406 MHz 401- 406 MHz Ultra low power active medical implant short range devices ECC/DEC/(0 3)04 Exemption from individual licensing of VSAT

• perating in the frequency bands 14.25 -

14.50 GHz Earth-to-space and 10.70-11.70 GHz space-to-Earth 14.25 - 14.50 GHz Earth-to-space and 10.70-11.70 GHz space-to-Earth Very Small Aperture Terminal communications equipment ECC/DEC/(0 4)03 Automotive Short Range Radars in band 77- 81 GHz 77- 81 GHz Automotive Short Range Radar

12

ECC Decisions relating to LE bands (2)

Decision Scope Frequencies Applications ECC/DEC/(0 4)08 Harmonised use of 5 GHz for the implementation of WAS/RLAN 5 150-5 350 MHz and 5 470-5 725 MHz including radio local area networks (WAS/RLAN) ECC/DEC/(0 4)10 Designated for the temporary introduction of Automotive SRR 21.65 GHz – 26.65 GHz Automotive SRR ECC/DEC/(0 5)02 Frequency band 169.4-169.8125 MHz 169.4-169.8125 MHz SRDs: Assistive listening devices, Meter reading, ECC/DEC/(0 5)09 Free circulation and use of Earth Stations on board Vessels operating in FSS networks 5925 – 6245 MHz and 3700 – 4200 MHz Earth Stations on board vessels ECC/DEC/(0 5)11 Free circulation and use of Aircraft Earth Stations (AES) 14.0-14.5 GHz (Earth-to-space), 10.7-11.7 GHz (space-to-Earth) and 12.5-12.75 GHz (space-to-Earth) Earth Station on board aircraft ECC/DEC/(0 5)12 Digital PMR 446 applications operating in 446.1-446.2 MHz 446.1-446.2 MHz Handheld portable digital voice communications ECC/DEC/(0 6)02 Exemption from Individual Licensing of LEST 10.70–12.75 GHz or 19.70–20.20 GHz space-to-Earth and 14.00–14.25 GHz or 29.50–30.00 GHz Earth-to-Space Low EIRP Satellite Terminals (LEST)

13

ECC Decisions relating to LE bands (3)

Decision Scope Frequencies Applications ECC/DEC/ (06)03 Exemption from Individual Licensing of high e.i.r.p. satellite terminals (HEST) operating within the frequency bands 10.70 - 12.75 GHz

• r 19.70 - 20.20 GHz space-to-Earth and 14.00
• 14.25 GHz or 29.50 - 30.00 GHz Earth-to-

space 10.70 - 12.75 GHz or 19.70 - 20.20 GHz space-to-Earth and 14.00 -14.25 GHz or 29.50 - 30.00 GHz Earth-to-space High EIRP satellite terminals (HEST) ECC/DEC/ (06)04 UWB technology in bands below 10.6 GHz <1.6 GHz up to 10.6 GHz Ultra Wideband for applications using bandwidths wider than 50 MHz ECC/DEC/ (07)01 Devices using UWB technology <1.6 GHz up to 10.6 GHz Ultra Wideband for applications using bandwidths wider than 50 MHz ECC/DEC/ (08)01 ITS in 5 GHz band 5875-5925 MHz Intelligent Transport System in SRD category ECC/DEC/ (09)01 Harmonised use of the 63-64 GHz band for ITS 63 – 64 GHz Intelligent Transport systems ECC/DEC/ (11)02 Industrial LPR 6 - 8.5 GHz, 24.05 - 26.5 GHz, 57 - 64 GHz and 75 - 85 GHz Industrial Level Probing Radar ECC/DEC/ (11)03 Harmonised use of frequencies for CB radio equipment 26.960-27.410 MHz CB radio equipment ECC/DEC/ (12)03 The harmonised conditions for UWB applications on-board aircraft <1.6 GHz up to 10.6 GHz Ultra Wideband for applications of use on board aircraft ECC/DEC/ (13)01 The use, free circulation, and exemption from individual licensing of ESOMPs 17.3-20.2 GHz and 27.5- 30.0 GHz Earth Stations on mobile platforms

14

Identified LE spectrum overview

• Total of 37,637 MHz harmonised

LE spectrum

• 1,869 MHz LE spectrum between

400 MHz and 6 GHz

58 MHz, 0% 1869 MHz, 5% 13700 MHz, 36% 22000 MHz, 59%

LE Spectrum Distribution per Range

<400 MHz 400 MHz - 6 GHz 6 GHz - 50 GHz 50 GHz - 250 GHz

9 kHz – 10 MHz 10 MHz – 400 MHz 400 - 1800 MHz 1800 – 4500 MHz 4500 – 6000 MHz 6 GHz – 10.6 GHz 10.6 – 21 GHz 21 – 50 GHz 50 – 70 GHz 70 – 250 GHz

Spectrum quantity (MHz)

Frequency range

Total LE Spectrum Available (by Frequency Range)

Band range Spectrum quantity <400 MHz 58 MHz 400 MHz - 6 GHz 1869 MHz 6 GHz - 50 GHz 13700 MHz 50 GHz - 250 GHz 22000 MHz

Our focus Our focus

15

Outcome: bands to be considered in this study

Frequency band range Specific bands EC/ECC decision Application & usage

400 - 1800 MHz 401 – 406 MHz 2013/752/EU ERC/DEC/(01)17 Med Implants potential for wide deployment due to type of application 433.05 – 434.79 MHz 2013/752/EU Non-specific SRDs potential for wide deployment due to type of application 446 – 446.1 MHz ERC/DEC/(98)25 PMR 446: potential for wide deployment due to type of application 446.1 – 446.2 MHz ECC/DEC/(05)12 dPMR 446: potential for wide deployment due to type of application 863 – 870 MHz 2013/752/EU Non-specific SRDs (telemetry, telecommand, alarms, data transmissions). RFID: potential for wide deployment due to type

• f application

870-876 p/w 915-921 MHz No EC/ECC Decision (ERC/Rec 70-03) SRDs potential for wide deployment due to type of

• application. This spectrum is assumed to be a

good candidate band for Internet of Things (IoT). 1800 – 4500 MHz 1880 – 1900 MHz ERC/DEC(94)03 ERC/DEC/(98)22 2009/343/EC ECC/DEC/(06)04 DECT: potential for wide deployment due to type

• f application

1800 – 3000 MHz ECC/DEC/(06)022009/343/EC ECC/DEC/(06)04 UWB: potential for wide deployment due to type of application 2400 -2483.5 MHz 2013/752/EU 2009/343/EC ECC/DEC/(06)04 WAS/RLAN: potential for wide deployment due to type of application Radio determination devices 2483.5 – 2500 MHz ERC/DEC/(01)08 2013/752/EU 2009/343/EC ECC/DEC/(06)04 Movement detection: limited to specialist use in specific locations 4500 – 6000 MHz - 5150 -5350 MHz ECC/DEC/(04)08 2007/90/EC 2009/343/EC ECC/DEC/(06)04 WAS/RLAN: potential for wide deployment due to type of application 5470 – 5725 MHz ECC/DEC/(04)08 2005/513/EC 2009/343/EC ECC/DEC/(06)04 WAS/RLAN: potential for wide deployment due to type of application 5725 – 5875 MHz 2013/752/EU 2009/343/EC ECC/DEC/(06)04 TTT: potential for wide deployment due to type of application 5795-5805 MHz 2013/752/EU 2009/343/EC ECC/DEC/(06)04 TTT: potential for wide deployment due to type of application 5875-5925 MHz ECC/DEC/(08)012009/343/EC ECC/DEC/(06)04 ECC/DEC/(05)09 ECC/DEC/(11)02 ITS: potential for wide deployment due to type of application

16

Defining application categories

The following application categories are based on definition within ECC and EC Decisions and recommendations

• Inductive Devices
• Active medical implant
• RFID
• Transport and Traffic Telematics
• Alarms, telecommand and telemetry
• Audio/media wireless streaming
• Remote monitoring and wireless alarms
• Assistive listening device
• Radio determination
• Wideband data transmission devices
• Metering devices

17

Application, LE band and devices

Application category LE spectrum (GHz) Device type (2015) Active Medical implants 0.401-0.406 2.48-2.5 Implantable cardiac pacemakers, Cochlear implants, Nerve stimulators, Transmitters connected to other implantable devices RFID 2.446-2.454 Handheld, fixed payment, fixed tracker interrogators Transport and traffic telematics 5.795-5.805 Embedded vehicle anti-collision radar, electronic fee collection, mobile data terminals on board vehicles Alarms, telecommand and telemetry 0.433 – 0.434 0.863 – 0.865 5.72 – 5.87 Wireless alarms, key fobs, baby monitors, garage door/gate openers, telemetry equipment, telecommand devices Audio/media wireless streaming 0.863 – 0.87 Mini FM transmitters, cordless headphones, media players, speakers, wireless microphones Remote monitoring and wireless alarms 0.8686 – 0.869 Water meters, social alarms, distress alarms Radio determination 2.4 – 2.48 4.5 – 7 Speed camera devices, radio location and positioning, surface movement tracking Wideband data transmission 2.4 – 2.48 5.15 -5.35 5.47 – 5.725 Laptops, tablets, access points, smartphones, games consoles, media players, speakers, smart TVs, connected car, wearable devices

• Specific device types based on example devices and applications from

national regulatory SRD authorisations, ETSI SRDocs and standards

18

Questions

• Have we covered all relevant bands?
• Any significant national exceptions?
• Do the application and device types cover all

relevant usage per band today?

• What changes in the applications and device

types in each band are expected in future?

• Expected future changes in regulations affecting

these bands and devices?

19

Simon Saunders, Real Wireless

Study overview – the workshop in context
