SLIDE 1

Stories, Not Words: Abstract Datatype Instruction Sets

Martha Kim Columbia University Workshop on New Directions in Computer Architecture 6/5/2011

Sunday, June 5, 2011

SLIDE 2

The Utilization Wall

Exponential decrease in percentage of transistors

that can be operated at full frequency.

In 45nm TSMC process, 7% of 300mm die can
perate at full frequency
In 32nm, 3.5%

Moore’s Law (manufacturable transistors) Power budget (operable transistors)

Goulding et al. Conservation cores: Reducing the energy of mature computations. In Proceedings of the International Conference on Architectural Support for Programming Languages and Operating Systems (ASPLOS), pages 205–218, Pittsburgh, Pennsylvania, March 2010.

2

Sunday, June 5, 2011

SLIDE 3

Specialization Is a Promising Approach

R. Hameed et al., “Understanding sources of inefficiency in general-purpose chips,” ISCA '10
G. Venkatesh et al., “Conservation cores: reducing the energy of mature computations,” ASPLOS

'10

J. Kelm, D. Johnson, W. Tuohy, S. Lumetta, and S. Patel, “Cohesion: a hybrid memory model for

accelerators,” ISCA '10

H. Franke et al., “Introduction to the wire-speed processor and architecture,” IBM Journal of

Research and Development, vol. 54, no. 1, pp. 3:1–3:11, 2010.

V. Govindaraju, C. Ho, and K. Sankaralingam, “Dynamically Specialized Datapaths for energy

efficient computing,” HPCA ’11

M. Lyons, M. Hempstead, G. Wei, and D. Brooks, “The Accelerator Store framework for high-

performance, low-power accelerator-based systems,” Computer Architecture Letters, vol. 9, no. 2, pp. 53–56, 2010.

C. Cascaval, S. Chatterjee, H. Franke, K. Gildea, and P. Pattnaik, “A taxonomy of accelerator

architectures and their programming models,” IBM Journal of Research and Development, vol. 54, no. 5, p. 5, 2010.

R. Hou et al., “Efficient data streaming with on-chip accelerators: Opportunities and

challenges,” HPCA ’11

N. Goulding et al., “GreenDroid: A Mobile Application Processor for Silicon’s Dark Future,”

Hotchips ‘10.

Sunday, June 5, 2011

SLIDE 4

An Ideal Accelerator System

High Performance Low Energy Easy to Program Software Portability

Sunday, June 5, 2011

SLIDE 5

Accelerator Design Processes

Application

Sunday, June 5, 2011

SLIDE 6

Accelerator Design Processes

Application Microarch.

Sunday, June 5, 2011

SLIDE 7

Accelerator Design Processes

Application Microarch. Arch.

Sunday, June 5, 2011

SLIDE 8

Accelerator Design Processes

!

Application Microarch. Arch.

Sunday, June 5, 2011

SLIDE 9

Accelerator Design Processes

!

Application Microarch. Arch.

Application Arch.

Sunday, June 5, 2011

SLIDE 10

Accelerator Design Processes

!

Application Microarch. Arch.

Application Arch. Microarch.

Sunday, June 5, 2011

SLIDE 11

Extending Software Abstractions to Hardware

Application Libraries Machine Code Micro-ops Execution core Caches Memory

Sunday, June 5, 2011

SLIDE 12

Extending Software Abstractions to Hardware

Application Libraries Machine Code Micro-ops Execution core Caches Memory

Sunday, June 5, 2011

SLIDE 13

Extending Software Abstractions to Hardware

Application Libraries Machine Code Micro-ops Execution core Caches Memory Raise HW/SW interface

Sunday, June 5, 2011

SLIDE 14

Extending Software Abstractions to Hardware

Application Libraries Machine Code Micro-ops Execution core Caches Memory Raise HW/SW interface

Extend interfaces from libraries to hardware

Sunday, June 5, 2011

SLIDE 15

Extending Software Abstractions to Hardware

Application Libraries Machine Code Micro-ops Execution core Caches Memory Raise HW/SW interface

Extend interfaces from libraries to hardware Exploit interfaces with specialized hardware

Sunday, June 5, 2011

SLIDE 16

Abstract Datatype Processing SW Arch UArch

Sunday, June 5, 2011

SLIDE 17

Abstract Datatype Processing

class HashTable

put(k,v) v get(k)

SW Arch UArch

Sunday, June 5, 2011

SLIDE 18

Abstract Datatype Processing

class HashTable

put(k,v) v get(k) put $h, $k, $v get $h, $k, $v

SW Arch UArch

Sunday, June 5, 2011

SLIDE 19

Hash Table Processor

Abstract Datatype Processing

class HashTable

put(k,v) v get(k) put $h, $k, $v get $h, $k, $v

SW Arch UArch

Sunday, June 5, 2011

SLIDE 20

Compilation & Execution

Sequence Labeling SparseVec HashTable SV HT GP

Dispatch

Sunday, June 5, 2011

SLIDE 21

The Software Fallback

SV GP

Dispatch

SV GP

Dispatch

Sunday, June 5, 2011

SLIDE 22

An Ideal Accelerator System

High Performance Low Energy Easy Use - align hardware interfaces with those software is already using Portability - software fallback plan

Sunday, June 5, 2011

SLIDE 23

Sparse Vector Accelerator

Enforcing Data Encapsulation

set $v,$i,$x

CPU

get $v,$i,$x dot $v1,$v2,$p

Sunday, June 5, 2011

SLIDE 24

Sparse Vector Accelerator

Enforcing Data Encapsulation

set $v,$i,$x

CPU

get $v,$i,$x dot $v1,$v2,$p

v i x

A I B

Sunday, June 5, 2011

SLIDE 25

Sparse Vector Accelerator

Enforcing Data Encapsulation

set $v,$i,$x

CPU

get $v,$i,$x dot $v1,$v2,$p

v i x

A I B A I B I A B

Sunday, June 5, 2011

SLIDE 26

Sparse Vector Accelerator

Enforcing Data Encapsulation

set $v,$i,$x

CPU

get $v,$i,$x dot $v1,$v2,$p

v i x

A I B A I B I A B C D C D

Sunday, June 5, 2011

SLIDE 27

Specialized Caching for Sparse Vectors

0% 25% 50% 75% 100% 128 256 512 1024 2048

Hit Rate

Storage Capacity (B)

Standard Cache VecStore

Sunday, June 5, 2011

SLIDE 28

Key Reuse in Hash Tables

0% 25% 50% 75% 100% 0.1 1 10 100 1000 10000 100000

Pct. Hash Operations

Number of Keys

LZW Compress Parser

Sunday, June 5, 2011

SLIDE 29

Key Reuse in Hash Tables

0% 25% 50% 75% 100% 0.1 1 10 100 1000 10000 100000

Pct. Hash Operations

Number of Keys

LZW Compress Parser

Sunday, June 5, 2011

SLIDE 30

Key Reuse in Hash Tables

0% 25% 50% 75% 100% 0.1 1 10 100 1000 10000 100000

Pct. Hash Operations

Number of Keys

LZW Compress Parser

386 entry table 26% of table 99% of dynamic accesses

Sunday, June 5, 2011

SLIDE 31

Key Reuse in Hash Tables

0% 25% 50% 75% 100% 0.1 1 10 100 1000 10000 100000

Pct. Hash Operations

Number of Keys

LZW Compress Parser

386 entry table 26% of table 99% of dynamic accesses 94K entry table .1% of table 75% of dynamic accesses

Sunday, June 5, 2011

SLIDE 32

Exploiting Key Reuse

Compress HTX-M Parser HTX-M Accesses Compress HTX-M Entrystore Accesses Parser HTX-M Entrystore Accesses

Hash Table Accelerator (HTX)

put $h,$k,$v get $h,$k,$v HTX-M HTX-C

Sunday, June 5, 2011

SLIDE 33

Exploiting Key Reuse

0% 25% 50% 75% 100% 1 10 100 1000 Reduction In HTX-M Accesses Cache Capacity

Compress HTX-M Parser HTX-M Accesses Compress HTX-M Entrystore Accesses Parser HTX-M Entrystore Accesses

Hash Table Accelerator (HTX)

put $h,$k,$v get $h,$k,$v HTX-M HTX-C

Sunday, June 5, 2011

SLIDE 34

Summary

Extend software’s encapsulated datatypes into hardware accelerators Natural alignment with standard software engineering Accelerator utility on all applications that use a particular type A software fallback that ensures portability Aggressive optimization of computation and data movement

Sunday, June 5, 2011

SLIDE 35

Research Challenges

What are the appropriate types to target? What is the lower bound in complexity? Is there a max number

f types a hardware system can support?

How do I implment polymorphism efficiently? (e.g., priority queue with arbitrary types and user-defined sort function) How do I optimized enforcement of data encapsulation? (copy-on-read is conservative) Can the execution model support parallel execution? What is type-specific coherence like? Simpler? Uglier? What is the appropriate system-level resource allocation between general and specialized? Between different types?

Sunday, June 5, 2011

SLIDE 36

Thank You

Sunday, June 5, 2011
