STM32 Ecosystem workshop

T.O.M.A.S Team

slide-2
SLIDE 2

We will continue a bit more with software activities.

  • Let’s try to rewrite our L4_DAC_ADC application using Low Layer libraries.
  • In this step we will create an empty STM32CubeMX template and then, we will

try to write complete application (except clock configuration) using only Low Layer library. Then we will compare the code size

  • We have two ways to complete this task:
  • Usage of unitary init functions requiring good knowledge of the peripherals (following reference

manual configuration steps)

  • Usage init functions (similar method to Standard Peripherals Library)
  • Let’s try second option, then we can compare the code size of the projects
  • What would be the difference?

2

slide-3
SLIDE 3

Creating the L4_DAC_ADC project with full usage of LL library

slide-4
SLIDE 4

New project creation

  • Open STM32CubeMX
  • Select New Project
  • Menu  File  New project
  • Select STM32L4
  • STM32L4x6
  • LQFP64 package
  • STM32L476RGTx
  • Do not select any peripherals (will be

added manually in software)

4

slide-5
SLIDE 5

Template project generation

  • Go to Clock Configuration Tab
  • Set clocks to 80MHz (based on 16MHz HSI*PLL)
  • Save project as LL_L4_DAC_ADC_Init
  • Generate the C project for SW4STM32
  • Import new project into the SW4STM32 workspace used in previous exercises

5

80 PLLCLK HSI

slide-6
SLIDE 6
  • Generate the code with added new features
  • Open newly generated project in SW4STM32

6

slide-7
SLIDE 7

7

STM32 snippets

Init functions Unitary functions LL Drivers

Standard peripheral library HAL Drivers

  • Common services (portability)
  • High level state machine based processes
  • Init services
  • Hardware basic services
  • Atomic register access
  • Compliancy with the HAL drivers
  • Low footprint

LL_L4_DAC_ADC_Init

using init functions

slide-8
SLIDE 8

Copy LL library files into the project

8

  • From repository CubeMX  Menu  Help  Updater Settings get repository path (marked .\ below)
  • From .\STM32Cube_FW_L4_Vx.x.x\Drivers\STM32L4xx_HAL_Driver\src copy:

stm32l4xx_ll_adc.c stm32l4xx_ll_dac.c stm32l4xx_ll_dma.c stm32l4xx_ll_gpio.c stm32l4xx_ll_rcc.c stm32l4xx_ll_tim.c

  • From .\STM32Cube_FW_L4_Vx.x.x\Drivers\STM32L4xx_HAL_Driver\inc copy:

stm32l4xx_ll_adc.h stm32l4xx_ll_bus.h stm32l4xx_ll_dac.h stm32l4xx_ll_dma.h stm32l4xx_ll_gpio.h stm32l4xx_ll_rcc.h stm32l4xx_ll_tim.h

  • Refresh (F5) the project source files – now, new files will become visible

$PROJ_DIR\Drivers\STM32L4xx_HAL_Driver\Src\ $PROJ_DIR\Drivers\STM32L4xx_HAL_Driver\Inc\

slide-9
SLIDE 9

Project configuration

enable usage of init functions in Low Layer Library

1. Select project 2. Menu>Project>Properties>C/C++ Build>Settings 3. MCU GCC Compiler>Symbols 4. Add … 5. Define USE_FULL_LL_DRIVER to allow use of LL library It will allow us to use the Init…() functions like in Standard Peripherals Library (SPL) 9

1 2 3 4 5

slide-10
SLIDE 10

Writing the code

LL_L4_DAC_ADC_Init project - tasks

Within main.c file perform the following actions

1. Include necessary low layer header files. 2. Declare initialization structures for used peripherals and buffers for DAC and ADC. 3. Initialize peripherals one by one (mind to connect the clock to the peripheral first). 4. Start the peripheral using low layer functions.

As a reference please use already copied header and source files for low layer part of the library.

10

slide-11
SLIDE 11

Replacing HAL functions with init LL

1 - LL_L4_DAC_ADC_Init project - includes

/* USER CODE BEGIN Includes */ #include "stm32l4xx_ll_???.h" … … … … … … /* USER CODE END Includes */ 11

  • All used peripherals (ppp) need dedicated low layer header file stm32l4xx_ll_ppp.h
  • We have to include them in main.c file in USER CODE section.
  • There is a complete list of needed structures below. Please try to find and declare proper ones.
slide-12
SLIDE 12

Replacing HAL functions with init LL

1 - LL_L4_DAC_ADC_Init project - includes

/* USER CODE BEGIN Includes */ #include "stm32l4xx_ll_adc.h" #include "stm32l4xx_ll_dac.h" #include "stm32l4xx_ll_dma.h" #include "stm32l4xx_ll_gpio.h" #include "stm32l4xx_ll_rcc.h" #include "stm32l4xx_ll_tim.h" #include "stm32l4xx_ll_bus.h" /* USER CODE END Includes */ 12

  • All used peripherals (ppp) need dedicated low layer header file stm32l4xx_ll_ppp.h
  • We have to include them in main.c file in USER CODE section.
slide-13
SLIDE 13

Replacing HAL functions with init LL

2 - LL_L4_DAC_ADC_Init project – structures declaration

/* USER CODE BEGIN PV */ /* Private variables ---------------------------------------------------------*/ LL_GPIO_InitTypeDef GPIO_InitStruct; //GPIO init structure LL_TIM_InitTypeDef TIM2_InitStruct; //TIM2 init structure LL_TIM_OC_InitTypeDef TIM2_OCInitStruct; //TIM2 OC init structure LL_DAC_InitTypeDef DAC_InitStruct; //DAC init structure LL_ADC_InitTypeDef ADC_InitStruct; //ADC init structure LL_ADC_CommonInitTypeDef ADC_ComInitStruct; //ADC common init structure LL_ADC_REG_InitTypeDef ADC_RegInitStruct; //ADC regular conversion init structure LL_DMA_InitTypeDef DMA_DAC_InitStruct; //DMA init structure LL_DMA_InitTypeDef DMA_ADC_InitStruct; //DMA init structure /* USER CODE END PV */ 13

  • Each peripheral needs its own initialization structure (PPP_InitStruct)
  • Some of the peripherals (i.e. timers, ADC, …) need additional one for configuration one of the modes they

should be configured in (i.e. Output Capture, Input Capture for timers etc.).

  • There is a complete list of needed structures below. Please try to find and declare proper ones.
slide-14
SLIDE 14

Replacing HAL functions with init LL

2 - LL_L4_DAC_ADC_Init project – structures declaration

/* USER CODE BEGIN PV */ /* Private variables ---------------------------------------------------------*/ LL_GPIO_InitTypeDef GPIO_InitStruct; //GPIO init structure LL_TIM_InitTypeDef TIM2_InitStruct; //TIM2 init structure LL_TIM_OC_InitTypeDef TIM2_OCInitStruct; //TIM2 OC init structure LL_DAC_InitTypeDef DAC_InitStruct; //DAC init structure LL_ADC_InitTypeDef ADC_InitStruct; //ADC init structure LL_ADC_CommonInitTypeDef ADC_ComInitStruct; //ADC common init structure LL_ADC_REG_InitTypeDef ADC_RegInitStruct; //ADC regular conversion init structure LL_DMA_InitTypeDef DMA_DAC_InitStruct; //DMA init structure LL_DMA_InitTypeDef DMA_ADC_InitStruct; //DMA init structure /* USER CODE END PV */ 14

  • Each peripheral needs its own initialization structure (PPP_InitStruct)
  • Some of the peripherals (i.e. timers, ADC, …) need additional one for configuration one of the modes they

should be configured in (i.e. Output Capture, Input Capture for timers etc.).

  • There is a complete list of needed structures below. Please try to find and declare proper ones.
slide-15
SLIDE 15

Replacing HAL functions with init LL

2 - LL_L4_DAC_ADC_Init project – data buffers declaration

/* USER CODE BEGIN PV */ /* Private variables ---------------------------------------------------------*/ #define ADCBUFSIZE 32 #define DACBUFSIZE 32 const uint16_t dacbuf[DACBUFSIZE] = { 2047, 2447, 2831, 3185, 3498, 3750, 3939, 4056, 4095, 4056, 3939, 3750, 3495, 3185, 2831, 2447, 2047, 1647, 1263, 909, 599, 344, 155, 38, 0, 38, 155, 344, 599, 909, 1263, 1647}; uint32_t adcbuf[ADCBUFSIZE]; /* USER CODE END PV */ 15

  • It is necessary to define the source buffer for DAC (dacbuf[]) and destination buffer for ADC to store

the measured data (adcbuf[]). Size for both can be 32.

slide-16
SLIDE 16

Replacing HAL functions with init LL

2 - LL_L4_DAC_ADC_Init project – data buffers declaration

/* USER CODE BEGIN PV */ /* Private variables ---------------------------------------------------------*/ #define ADCBUFSIZE 32 #define DACBUFSIZE 32 const uint16_t dacbuf[DACBUFSIZE] = { 2047, 2447, 2831, 3185, 3498, 3750, 3939, 4056, 4095, 4056, 3939, 3750, 3495, 3185, 2831, 2447, 2047, 1647, 1263, 909, 599, 344, 155, 38, 0, 38, 155, 344, 599, 909, 1263, 1647}; uint16_t adcbuf[ADCBUFSIZE]; /* USER CODE END PV */ 16

  • It is necessary to define the source buffer for DAC (dacbuf[]) and destination buffer for ADC to store

the measured data (adcbuf[]). Size for both can be 32.

slide-17
SLIDE 17

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – GPIO configuration

/* USER CODE BEGIN 2 */ /* GPIO LL configuration */ __HAL_RCC_GPIOA_CLK_ENABLE(); //enable clock to the GPIOA peripheral LL_GPIO_StructInit(&GPIO_InitStruct); //structure initialization to default values GPIO_InitStruct.Pin= GPIO_PIN_1 | GPIO_PIN_4; //set pin 1 (ADC_IN6), 4 (DAC_OUT1) GPIO_InitStruct.Mode= LL_GPIO_MODE_ANALOG; //set GPIO as analog mode GPIO_InitStruct.Pull= LL_GPIO_PULL_NO; //no pull up or pull down LL_GPIO_Init(GPIOA,&GPIO_InitStruct); //initialize GPIOA, pins 1 and 4 17 The task is to configure 2 analog pins (PA1 – ADC1 Channel6 and PA4 – DAC output1) 1. Before PPP configuration it is necessary to connect the clock to the PPP peripheral. To do this we can use there dedicated macro: __HAL_RCC_PPP_CLK_ENABLE() 2. Initialize PPP init structure with default values using LL_PPP_StructInit() 3. Fill PPP init structure with required configuration parameters 4. Copy structure fields into PPP (GPIO in this case) registers using LL_PPP_Init() function (like in Standard Peripherals Library or in HAL library) 5. Connect GPIO analog switch to ADC input using LL_GPIO_EnablePinAnalogControl() function

slide-18
SLIDE 18

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – GPIO configuration

/* USER CODE BEGIN 2 */ /* GPIO LL configuration */ __HAL_RCC_GPIOA_CLK_ENABLE(); //enable clock to the GPIOA peripheral LL_GPIO_StructInit(&GPIO_InitStruct); //structure initialization to default values GPIO_InitStruct.Pin= GPIO_PIN_1 | GPIO_PIN_4; //set pin 1 (ADC_IN6), 4 (DAC_OUT1) GPIO_InitStruct.Mode= LL_GPIO_MODE_ANALOG; //set GPIO as analog mode GPIO_InitStruct.Pull= LL_GPIO_PULL_NO; //no pull up or pull down LL_GPIO_Init(GPIOA,&GPIO_InitStruct); //initialize GPIOA, pins 1 and 4 LL_GPIO_EnablePinAnalogControl(GPIOA, LL_GPIO_PIN_1); 18 The task is to configure 2 analog pins (PA1 – ADC1 Channel6 and PA4 – DAC output1) 1. Before PPP configuration it is necessary to connect the clock to the PPP peripheral. To do this we can use there dedicated macro: __HAL_RCC_PPP_CLK_ENABLE() 2. Initialize PPP init structure with default values using LL_PPP_StructInit() 3. Fill PPP init structure with required configuration parameters 4. Copy structure fields into PPP (GPIO in this case) registers using LL_PPP_Init() function (like in Standard Peripherals Library or in HAL library) 5. Connect GPIO analog switch to ADC input using LL_GPIO_EnablePinAnalogControl() function

1 2 3 4 5

slide-19
SLIDE 19

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – DAC configuration

/* USER CODE BEGIN 2 */ /* DAC LL configuration */ __HAL_RCC_DAC1_CLK_ENABLE(); //enable clock LL_DAC_StructInit(&DAC_InitStruct); DAC_InitStruct.TriggerSource = LL_DAC_TRIG_EXT_TIM2_TRGO; DAC_InitStruct.WaveAutoGeneration = LL_DAC_WAVE_AUTO_GENERATION_NONE; DAC_InitStruct.OutputBuffer = LL_DAC_OUTPUT_BUFFER_ENABLE; LL_DAC_Init(DAC1, LL_DAC_CHANNEL_1, &DAC_InitStruct); 19 The task is to configure DAC1, Channel1 to work without output buffer, triggered by Timer2 TRGO signal, without triangle nor noise wave generation 1. Before PPP configuration it is necessary to connect the clock to the PPP peripheral. To do this we can use there dedicated macro: __HAL_RCC_PPP_CLK_ENABLE() 2. Initialize PPP init structure with default values using LL_PPP_StructInit() 3. Fill PPP init structure with required configuration parameters 4. Copy structure fields into PPP (DAC in this case) registers using LL_PPP_Init() function (like in Standard Peripherals Library or in HAL library)

slide-20
SLIDE 20

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – DAC configuration

/* USER CODE BEGIN 2 */ /* DAC LL configuration */ __HAL_RCC_DAC1_CLK_ENABLE(); //enable clock LL_DAC_StructInit(&DAC_InitStruct); DAC_InitStruct.TriggerSource = LL_DAC_TRIG_EXT_TIM2_TRGO; DAC_InitStruct.OutputBuffer = LL_DAC_OUTPUT_BUFFER_ENABLE; LL_DAC_Init(DAC1, LL_DAC_CHANNEL_1, &DAC_InitStruct); 20 The task is to configure DAC1, Channel1 to work without output buffer, triggered by Timer2 TRGO signal, without triangle nor noise wave generation 1. Before PPP configuration it is necessary to connect the clock to the PPP peripheral. To do this we can use there dedicated macro: __HAL_RCC_PPP_CLK_ENABLE() 2. Initialize PPP init structure with default values using LL_PPP_StructInit() 3. Fill PPP init structure with required configuration parameters 4. Copy structure fields into PPP (DAC in this case) registers using LL_PPP_Init() function (like in Standard Peripherals Library or in HAL library)

1 2 3 4

slide-21
SLIDE 21

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration tasks

21 The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event on channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case). 1. Before PPP configuration it is necessary to connect the clock to the PPP peripheral. To do this we can use there dedicated macro: __HAL_RCC_PPP_CLK_ENABLE() 2. Initialize proper PPP init structure(s) with default values using LL_PPP_StructInit(). In case of ADC we have 4 different structures:

a. LL_ADC_CommonInitTypeDef – configuration of common parameters for all ADCs (like input clock source) and multimode configuration b. LL_ADC_InitTypeDef – configuration of the particular ADC basic parameters c. LL_ADC_REG_InitTypeDef – configuration of the regular conversions d. LL_ADC_INJ_InitTypeDef – configuration of the injected conversions – NOT USED in the exercise

3. Fill proper PPP init structure(s) with desired configuration parameters 4. Copy structure fields into PPP (ADC in this case) registers using LL_PPP_Init() function (like in Standard Peripherals Library

  • r in HAL library)
slide-22
SLIDE 22

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration tasks

22

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event

  • n channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case).

1. At the beginning we should select system clock as clock source for ADC using LL_RCC_SetADCClockSource() function 2. Before PPP configuration it is necessary to connect the clock to the ADC1 peripheral. To do this we can use there dedicated macro: __HAL_RCC_ADC_CLK_ENABLE() 3. Initialize LL_ADC_CommonInitTypeDef structure (defining common settings for all ADCs and multimode configuration) with default values using LL_ADC_CommonStructInit(). 4. Fill LL_ADC_CommonInitTypeDef structure with desired configuration parameters (clock source for ADC) 5. Copy structure fields into ADC registers using LL_ADC_CommonInit() function

/* ADC LL configuration */ __HAL_RCC_ADC1_CLK_ENABLE();//enable clock LL_ADC_CommonStructInit(&ADC_ComInitStruct); ADC_ComInitStruct.CommonClock = LL_ADC_CLOCK_SYNC_PCLK_DIV2; LL_ADC_CommonInit(ADC1,&ADC_ComInitStruct);

slide-23
SLIDE 23

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration tasks

23

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event

  • n channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case).

1. At the beginning we should select system clock as clock source for ADC using LL_RCC_SetADCClockSource() function 2. Before PPP configuration it is necessary to connect the clock to the ADC1 peripheral. To do this we can use there dedicated macro: __HAL_RCC_ADC_CLK_ENABLE() 3. Initialize LL_ADC_CommonInitTypeDef structure (defining common settings for all ADCs and multimode configuration) with default values using LL_ADC_CommonStructInit(). 4. Fill LL_ADC_CommonInitTypeDef structure with desired configuration parameters (clock source for ADC) 5. Copy structure fields into ADC registers using LL_ADC_CommonInit() function

/* ADC LL configuration */ LL_RCC_SetADCClockSource(LL_RCC_ADC_CLKSOURCE_SYSCLK); __HAL_RCC_ADC_CLK_ENABLE();//enable clock LL_ADC_CommonStructInit(&ADC_ComInitStruct); ADC_ComInitStruct.CommonClock = LL_ADC_CLOCK_SYNC_PCLK_DIV2; LL_ADC_CommonInit(ADC1,&ADC_ComInitStruct);

1 2 3 4 5

slide-24
SLIDE 24

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration tasks

24

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event on channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case). 1. Initialize LL_ADC_InitTypeDef structure (defining general settings for particular ADC) with default values using LL_ADC_StructInit(). 2. Fill LL_ADC_InitTypeDef structure with desired configuration parameters (clock source for ADC) 3. Copy structure fields into ADC registers using LL_ADC_Init() function

LL_ADC_StructInit(&ADC_InitStruct); ADC_InitStruct.Resolution = LL_ADC_RESOLUTION_12B ; ADC_InitStruct.DataAlignment = LL_ADC_DATA_ALIGN_RIGHT; ADC_InitStruct.LowPowerMode = LL_ADC_LP_MODE_NONE; LL_ADC_Init(ADC1,&ADC_InitStruct);

slide-25
SLIDE 25

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration tasks

25

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event on channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case). 1. Initialize LL_ADC_InitTypeDef structure (defining general settings for particular ADC) with default values using LL_ADC_StructInit(). 2. Fill LL_ADC_InitTypeDef structure with desired configuration parameters (clock source for ADC) 3. Copy structure fields into ADC registers using LL_ADC_Init() function

LL_ADC_StructInit(&ADC_InitStruct); ADC_InitStruct.Resolution = LL_ADC_RESOLUTION_12B ; ADC_InitStruct.DataAlignment = LL_ADC_DATA_ALIGN_RIGHT; ADC_InitStruct.LowPowerMode = LL_ADC_LP_MODE_NONE; LL_ADC_Init(ADC1,&ADC_InitStruct);

1 2 3

slide-26
SLIDE 26

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration tasks

26

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event on channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case). 1. Initialize LL_ADC_REG_InitTypeDef structure (defining regular conversion parameters) with default values using LL_ADC_REG_StructInit(). 2. Fill LL_ADC_REG_InitTypeDef structure with desired configuration parameters (clock source for ADC) 3. Copy structure fields into ADC registers using LL_ADC_REG_Init() function

LL_ADC_REG_StructInit(&ADC_RegInitStruct); ADC_RegInitStruct.TriggerSource = LL_ADC_REG_TRIG_EXT_TIM2_CH2; ADC_RegInitStruct.SequencerDiscont = LL_ADC_REG_SEQ_DISCONT_DISABLE; ADC_RegInitStruct.ContinuousMode = LL_ADC_REG_CONV_SINGLE; ADC_RegInitStruct.DMATransfer = LL_ADC_REG_DMA_TRANSFER_UNLIMITED; ADC_RegInitStruct.Overrun = LL_ADC_REG_OVR_DATA_PRESERVED; LL_ADC_REG_Init(ADC1,&ADC_RegInitStruct);

slide-27
SLIDE 27

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration tasks

27

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event on channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case). 1. Initialize LL_ADC_REG_InitTypeDef structure (defining regular conversion parameters) with default values using LL_ADC_REG_StructInit(). 2. Fill LL_ADC_REG_InitTypeDef structure with desired configuration parameters (clock source for ADC) 3. Copy structure fields into ADC registers using LL_ADC_REG_Init() function

LL_ADC_REG_StructInit(&ADC_RegInitStruct); ADC_RegInitStruct.TriggerSource = LL_ADC_REG_TRIG_EXT_TIM2_CH2; ADC_RegInitStruct.SequencerDiscont = LL_ADC_REG_SEQ_DISCONT_DISABLE; ADC_RegInitStruct.SequencerLength = LL_ADC_REG_SEQ_SCAN_DISABLE; ADC_RegInitStruct.ContinuousMode = LL_ADC_REG_CONV_SINGLE; ADC_RegInitStruct.DMATransfer = LL_ADC_REG_DMA_TRANSFER_UNLIMITED; ADC_RegInitStruct.Overrun = LL_ADC_REG_OVR_DATA_PRESERVED; LL_ADC_REG_Init(ADC1,&ADC_RegInitStruct);

1 2 3

slide-28
SLIDE 28

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration 3/3

LL_ADC_SetChannelSamplingTime(ADC1, LL_ADC_CHANNEL_6 , LL_ADC_SAMPLINGTIME_12CYCLES_5); LL_ADC_SetChannelSingleDiff(ADC1, LL_ADC_CHANNEL_6, LL_ADC_SINGLE_ENDED ); 28

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event on channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case). 1. Configure trigger edge to rising using LL_ADC_REG_SetTriggerEdge() function 2. Configure the sequencer to: a. setting the order of the channels to be converted (in our case single channel 6) b. select sampling time for each channel There is a single function to set both parameters: LL_ADC_SetChannelSamplingTime() 3. After the reset ADC is in deep power down mode. It is necessary to disable this mode using LL_ADC_DisableDeepPowerDown() function 4. Further we need to enable ADC internal voltage regulator using LL_ADC_EnableInternalRegulator() function and wait for it stabilization (implement your own delay() function)

slide-29
SLIDE 29

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC configuration 3/3

LL_ADC_REG_SetTriggerEdge(ADC1,LL_ADC_REG_TRIG_EXT_RISING); LL_ADC_REG_SetSequencerRanks(ADC1,LL_ADC_REG_RANK_1,LL_ADC_CHANNEL_6); LL_ADC_SetChannelSamplingTime(ADC1, LL_ADC_CHANNEL_6 , LL_ADC_SAMPLINGTIME_12CYCLES_5); LL_ADC_DisableDeepPowerDown(ADC1); LL_ADC_EnableInternalRegulator(ADC1); //wait 20us for internal regulator stabilization 29

b a 1 2

The task is to configure ADC1, Channel 6 to work in regular continue mode with DMA support, triggered by Timer2 Output Compare event on channel2, with sampling time 12.5 ADC clk cycles. ADC should be clocked by PCLK/2 synchronous clock (40MHz in our case). 1. Configure trigger edge to rising using LL_ADC_REG_SetTriggerEdge() function 2. Configure the sequencer to: a. setting the order of the channels to be converted (in our case single channel 6) b. select sampling time for each channel There is a single function to set both parameters: LL_ADC_SetChannelSamplingTime() 3. After the reset ADC is in deep power down mode. It is necessary to disable this mode using LL_ADC_DisableDeepPowerDown() function 4. Further we need to enable ADC internal voltage regulator using LL_ADC_EnableInternalRegulator() function and wait for it stabilization (implement your own delay() function)

3 4

slide-30
SLIDE 30

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - DAC_DMA configuration

30 The task is to configure Channel 3 in DMA1 to work with DAC using LL_DMA_InitTypeDef structure and LL_DMA_Init() function in the following way:

  • Continuously read data from internal buffer (dacbuf[DACBUFSIZE]) in halfwords, with pointer incrementation
  • Continuously write data (in halfwords, without pointer incrementation) to DAC1 data register for channel1 (12bits, right

alignment)*.

  • After the configuration we should enable the Channel3 in DMA1 using LL_DMA_EnableChannel() function

*) Hint: To get the proper address we can use function LL_DAC_DMA_GetRegAddr()

slide-31
SLIDE 31

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - DAC_DMA configuration

31

The task is to configure Channel 3 in DMA1 to work with DAC using LL_DMA_InitTypeDef structure and LL_DMA_Init() function in the following way:

  • Continuously read data from internal buffer (dacbuf[DACBUFSIZE]) in halfwords, with pointer incrementation
  • Continuously write data (in halfwords, without pointer incrementation) to DAC1 data register for channel1 (12bits, right alignment)*.
  • After the configuration we should enable the Channel3 in DMA1 using LL_DMA_EnableChannel() function

/* DAC DMA LL configuration */ __HAL_RCC_DMA1_CLK_ENABLE(); //enable clock LL_DMA_StructInit(&DMA_DAC_InitStruct); DMA_DAC_InitStruct.PeriphOrM2MSrcAddress = LL_DAC_DMA_GetRegAddr(DAC1,LL_DAC_CHANNEL_1,LL_DAC_DMA_REG_DATA_12BITS_RIGHT_ALIGNED); DMA_DAC_InitStruct.MemoryOrM2MDstAddress = (uint32_t)dacbuf; DMA_DAC_InitStruct.Direction = LL_DMA_DIRECTION_MEMORY_TO_PERIPH; DMA_DAC_InitStruct.Mode = LL_DMA_MODE_CIRCULAR; DMA_DAC_InitStruct.PeriphOrM2MSrcIncMode = LL_DMA_PERIPH_NOINCREMENT; DMA_DAC_InitStruct.MemoryOrM2MDstIncMode = LL_DMA_MEMORY_INCREMENT; DMA_DAC_InitStruct.PeriphOrM2MSrcDataSize = LL_DMA_PDATAALIGN_HALFWORD; DMA_DAC_InitStruct.MemoryOrM2MDstDataSize = LL_DMA_MDATAALIGN_HALFWORD; DMA_DAC_InitStruct.NbData = DACBUFSIZE; DMA_DAC_InitStruct.PeriphRequest = LL_DMA_REQUEST_6; DMA_DAC_InitStruct.Priority = LL_DMA_PRIORITY_LOW; LL_DMA_Init(DMA1, LL_DMA_CHANNEL_3, &DMA_DAC_InitStruct); LL_DMA_EnableChannel(DMA1, LL_DMA_CHANNEL_3);

slide-32
SLIDE 32

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC_DMA configuration

32 The task is to configure Channel 1 in DMA1 to work with ADC using LL_DMA_InitTypeDef structure and LL_DMA_Init() function in the following way:

  • Continuously read data (in halfwords, without pointer incrementation) from ADC1 regular data register*.
  • Continuously write data to internal buffer (adcbuf[ADCBUFSIZE]) in halfwords, with pointer incrementation
  • After the configuration we should enable the Channel1 in DMA1 using LL_DMA_EnableChannel() function

*) Hint: To get the proper address we can use function LL_ADC_DMA_GetRegAddr()

slide-33
SLIDE 33

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project - ADC_DMA configuration

/* ADC DMA LL configuration */ LL_DMA_StructInit(&DMA_ADC_InitStruct); DMA_ADC_InitStruct.PeriphOrM2MSrcAddress = LL_ADC_DMA_GetRegAddr(ADC1,LL_ADC_DMA_REG_REGULAR_DATA); DMA_ADC_InitStruct.MemoryOrM2MDstAddress = (uint32_t)adcbuf; DMA_ADC_InitStruct.Direction = LL_DMA_DIRECTION_PERIPH_TO_MEMORY; DMA_ADC_InitStruct.Mode = LL_DMA_MODE_CIRCULAR; DMA_ADC_InitStruct.PeriphOrM2MSrcIncMode = LL_DMA_PERIPH_NOINCREMENT; DMA_ADC_InitStruct.MemoryOrM2MDstIncMode = LL_DMA_MEMORY_INCREMENT; DMA_ADC_InitStruct.PeriphOrM2MSrcDataSize = LL_DMA_PDATAALIGN_HALFWORD; DMA_ADC_InitStruct.MemoryOrM2MDstDataSize = LL_DMA_MDATAALIGN_HALFWORD; DMA_ADC_InitStruct.NbData = ADCBUFSIZE; DMA_ADC_InitStruct.PeriphRequest = LL_DMA_REQUEST_0; DMA_ADC_InitStruct.Priority = LL_DMA_PRIORITY_LOW; LL_DMA_Init(DMA1, LL_DMA_CHANNEL_1, &DMA_ADC_InitStruct); LL_DMA_EnableChannel(DMA1, LL_DMA_CHANNEL_1);

33 The task is to configure Channel 1 in DMA1 to work with ADC using LL_DMA_InitTypeDef structure and LL_DMA_Init() function in the following way:

  • Continuously read data (in halfwords, without pointer incrementation) from ADC1 regular data register*.
  • Continuously write data to internal buffer (adcbuf[ADCBUFSIZE]) in halfwords, with pointer incrementation
  • After the configuration we should enable the Channel1 in DMA1 using LL_DMA_EnableChannel() function
slide-34
SLIDE 34

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – TIM2 configuration

34

The task is to configure Timer2 (TIM2) to work in up-counting mode with the following parameters/options:

  • Its output compare channel 2 should be configured in toggle mode with output compare parameters: frequency 5Hz, duty cycle 50%.
  • There is no need to output Channel2 on the pin.
  • TRGO signal of Timer2 should be configured on update and it will trigger DAC conversions
  • Compare event on channel 2 will be used to trigger the ADC conversions.
  • Source clock for the timer is APB clock = 80MHz

LL_TIM_InitTypeDef value ClockDivision ? Prescaler ? CounterMode ? Autoreload ?

16-Bit Prescaler

ITR 1..4

Trigger/Clock Controller

Trigger Output (TRGO) Update

APB1 clk

Auto Reload REG

+/- 32-Bit Counter

CH1 CH2 CH3 CH4 Capture Compare Capture Compare Capture Compare Capture Compare CH1 CH2 CH3 CH4

Autoreload (Period) CompareValue Prescaler CounterMode ClockDivision

LL_TIM_Init()

LL_TIM_InitTypeDef LL_TIM_OC_InitTypeDef

LL_TIM_OC_Init()

80MHz 80MHz 5Hz 5Hz/50% 2kHz

TRGO (update) – trigger for DAC CC2 – trigger for ADC

OCMode

LL_TIM_OC_InitTypeDef value CompareValue ? OCMode ?

slide-35
SLIDE 35

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – TIM2 configuration

/* TIM2 LL configuration */ __HAL_RCC_TIM2_CLK_ENABLE(); //enable clock TIM2_InitStruct.Prescaler = 7999; TIM2_InitStruct.CounterMode = LL_TIM_COUNTERMODE_UP; TIM2_InitStruct.Autoreload = 999; TIM2_InitStruct.ClockDivision = LL_TIM_CLOCKDIVISION_DIV1; LL_TIM_Init(TIM2,&TIM2_InitStruct); 35

Configuration of the clock and counter block of the timer (LL_TIM_InitTypeDef structure) 1. Connect clock to Timer2 (TIM2) using macro __HAL_RCC_TIM2_CLK_ENABLE() 2. Initialize LL_TIM_InitTypeDef structure with default values using LL_TIM_StructInit() function. 3. Fill LL_TIM_InitTypeDef structure with desired configuration parameters (calculated clock prescalers, mode and autoreload value for TIM2 to reach target 5Hz, 50% dc on OC channel4) 4. Copy structure fields into TIM2 registers using LL_TIM_Init() function

slide-36
SLIDE 36

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – TIM2 configuration

/* TIM2 LL configuration */ __HAL_RCC_TIM2_CLK_ENABLE(); //enable clock LL_TIM_StructInit(&TIM2_InitStruct); TIM2_InitStruct.Prescaler = 39999; TIM2_InitStruct.CounterMode = LL_TIM_COUNTERMODE_UP; TIM2_InitStruct.Autoreload = 399; TIM2_InitStruct.ClockDivision = LL_TIM_CLOCKDIVISION_DIV1; LL_TIM_Init(TIM2,&TIM2_InitStruct); 36

Configuration of the clock and counter block of the timer (LL_TIM_InitTypeDef structure) 1. Connect clock to Timer2 (TIM2) using macro __HAL_RCC_TIM2_CLK_ENABLE() 2. Initialize LL_TIM_InitTypeDef structure with default values using LL_TIM_StructInit() function. 3. Fill LL_TIM_InitTypeDef structure with desired configuration parameters (calculated clock prescalers, mode and autoreload value for TIM2 to reach target 5Hz, 50% dc on OC channel4) 4. Copy structure fields into TIM2 registers using LL_TIM_Init() function

1 3 4 2

slide-37
SLIDE 37

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – TIM2 configuration

/* TIM2 output compare mode for channel 2 - LL configuration */ TIM2_OCInitStruct.OCMode = LL_TIM_OCMODE_TOGGLE; TIM2_OCInitStruct.OCState = LL_TIM_OCSTATE_ENABLE; TIM2_OCInitStruct.CompareValue = 500; TIM2_OCInitStruct.OCPolarity = LL_TIM_OCPOLARITY_HIGH; LL_TIM_OC_Init(TIM2,LL_TIM_CHANNEL_CH2,&TIM2_OCInitStruct); LL_TIM_SetTriggerOutput(TIM2, LL_TIM_TRGO_UPDATE); LL_TIM_CC_EnableChannel(TIM2, LL_TIM_CHANNEL_CH2); 37

Configuration of the output compare block for channel2 of the timer2 (LL_TIM_OCInitTypeDef structure) 1. Initialize LL_TIM_OCInitTypeDef structure with default values using LL_TIM_OCStructInit() function. 2. Fill LL_TIM_OCInitTypeDef structure with desired configuration parameters (calculated pulse, mode and autoreload value for TIM2 to reach target 5Hz, 50% dc on OC channel4) 3. Copy structure fields into TIM2 registers using LL_TIM_OC_Init() function 4. Configure trigger output (TRGO) to update using LL_TIM_SetTriggerOutput() function. 5. Enable TIM2 channel2 using LL_TIM_CC_EnableChannel() function.

slide-38
SLIDE 38

Replacing HAL functions with init LL

3 - LL_L4_DAC_ADC_Init project – TIM2 configuration

/* TIM2 output compare mode for channel 2 - LL configuration */ LL_TIM_OC_StructInit(&TIM2_OCInitStruct); TIM2_OCInitStruct.OCMode = LL_TIM_OCMODE_TOGGLE; TIM2_OCInitStruct.OCState = LL_TIM_OCSTATE_ENABLE; TIM2_OCInitStruct.CompareValue = 200; TIM2_OCInitStruct.OCPolarity = LL_TIM_OCPOLARITY_HIGH; LL_TIM_OC_Init(TIM2,LL_TIM_CHANNEL_CH2,&TIM2_OCInitStruct); LL_TIM_SetTriggerOutput(TIM2, LL_TIM_TRGO_UPDATE); LL_TIM_CC_EnableChannel(TIM2, LL_TIM_CHANNEL_CH2); 38

Configuration of the output compare block for channel2 of the timer2 (LL_TIM_OCInitTypeDef structure) 1. Initialize LL_TIM_OCInitTypeDef structure with default values using LL_TIM_OCStructInit() function. 2. Fill LL_TIM_OCInitTypeDef structure with desired configuration parameters (calculated pulse, mode and autoreload value for TIM2 to reach target 5Hz, 50% dc on OC channel4) 3. Copy structure fields into TIM2 registers using LL_TIM_OC_Init() function 4. Configure trigger output (TRGO) to update using LL_TIM_SetTriggerOutput() function. 5. Enable TIM2 channel2 using LL_TIM_CC_EnableChannel() function.

2 3 4 5 1

slide-39
SLIDE 39

Replacing HAL functions with init LL

4 - LL_L4_DAC_ADC_Init project – starting the peripherals

39 /* DAC activation */ LL_DAC_EnableDMAReq(DAC1, LL_DAC_CHANNEL_1); LL_DAC_EnableTrigger(DAC1, LL_DAC_CHANNEL_1); LL_DAC_Enable(DAC1, LL_DAC_CHANNEL_1); /* ADC activation */ LL_ADC_StartCalibration(ADC1, LL_ADC_SINGLE_ENDED); LL_ADC_Enable(ADC1); LL_ADC_REG_StartConversion(ADC1); /* TIM2 activation */ LL_TIM_EnableCounter(TIM2);

Start already configured peripherals:

1. Enable DMA for Channel1 of DAC1 using LL_DAC_EnableDMAReq() function 2. Enable trigger for Channel1 of DAC1 using LL_DAC_EnableTrigger() function 3. Enable Channel1 of DAC1 using LL_DAC_Enable() function 4. Start calibration of ADC1 (for single ended conversions) using function LL_ADC_StartCalibration(). 5. Add necessary 116 ADC clk delay after calibration start 6. Enable ADC1 using LL_ADC_Enable() function 7. Start regular conversion (ADC1 will start conversion after next HW trigger) using LL_ADC_REG_StartConversion() function 8. Activate timer2 using LL_TIM_EnableCounter() function

slide-40
SLIDE 40

Replacing HAL functions with init LL

4 - LL_L4_DAC_ADC_Init project – starting the peripherals

40 /* DAC activation */ LL_DAC_EnableDMAReq(DAC1, LL_DAC_CHANNEL_1); LL_DAC_EnableTrigger(DAC1, LL_DAC_CHANNEL_1); LL_DAC_Enable(DAC1, LL_DAC_CHANNEL_1); /* ADC activation */ LL_ADC_StartCalibration(ADC1, LL_ADC_SINGLE_ENDED); //necessary 116 ADC clk delay LL_ADC_Enable(ADC1); LL_ADC_REG_StartConversion(ADC1); /* TIM2 activation */ LL_TIM_EnableCounter(TIM2);

Start already configured peripherals:

1. Enable DMA for Channel1 of DAC1 using LL_DAC_EnableDMAReq() function 2. Enable trigger for Channel1 of DAC1 using LL_DAC_EnableTrigger() function 3. Enable Channel1 of DAC1 using LL_DAC_Enable() function 4. Start calibration of ADC1 (for single ended conversions) using function LL_ADC_StartCalibration(). 5. Add necessary 116 ADC clk delay after calibration start 6. Enable ADC1 using LL_ADC_Enable() function 7. Start regular conversion (ADC1 will start conversion after next HW trigger) using LL_ADC_REG_StartConversion() function 8. Activate timer2 using LL_TIM_EnableCounter() function

1 2 3 4 5 6 7 8

slide-41
SLIDE 41

Comparison for L4_DAC_ADC example

41

function name size [B] function name size [B] Reduction vs HAL function name size [B] Reduction vs LL structures Reduction vs HAL Startup & Initialization HAL_Init 1432 HAL_Init 1256 12% HAL_Init 1256 0%

12%

Clock configuration SystemClock_Config 5512 LL_SystemClock_Config 1552 72% LL_SystemClock_Config 1552 0%

72%

GPIO configuration MX_GPIO_Init 5552 GPIO_LL_configuration 1984 64% LL_GPIO_configuration 1680 15%

70%

ADC configuration MX_ADC1_Init 8400 ADC_LL_configuration 2480 70% LL_ADC_configuration 1896 24%

77%

DAC configuration MX_DAC1_Init 8896 DAC_LL_configuration 2672 70% LL_DAC_configuration 1960 27%

78%

ADC DMA configuration DMA_ADC_LL_configuration 2928 na LL_DMA_ADC_configuration 2080 29%

na

DAC DMA configuration DMA_DAC_LL_configuration 3120 65% LL_DMA_DAC_configuration 2288 27%

75%

TIM2 configuration MX_TIM2_Init 10776 TIM2_LL_configuration 4272 60% LL_TIM2_configuration 2400 44%

78%

ADC activation HAL_ADC_Start_DMA 11424 ADC_LL_activation 4344 62% ADC_LL_activation 2472 43%

78%

DAC activation HAL_DAC_Start_DMA 11816 DAC_LL_activation 4384 63% DAC_LL_activation 2512 43%

79%

TIM2 activation HAL_TIM_OC_Start 11936 TIM2_LL_activation 4400 63% TIM2_LL_activation 2528 43%

79%

ADC without calibration Unitary Low Layer Library (based on simple functions) HAL Init Low Layer Library (based on structures) Role MX_DMA_Init 8984

Complete application code size

slide-42
SLIDE 42

Further reading

42

More information can be found in the following documents:

  • UM1860 - Getting started with STM32CubeL4 for STM32L4 Series, available on the web:

http://www.st.com/resource/en/user_manual/dm00157440.pdf

  • UM1884 - Description of STM32L4 HAL and Low Layer drivers, available on the web:

http://www.st.com/resource/en/user_manual/dm00173145.pdf

  • Doxygen based html manual: STM32L486xx_User_Manual.chm, available within STM32L4xx

Cube library in the path:

\STM32Cube_FW_L4_V1.5.0\Drivers\STM32L4xx_HAL_Driver\

slide-43
SLIDE 43

Enjoy!

www.st.com/mcu

/STM32 @ST_World st.com/e2e
