SLIDE 1
@DanielPenning www.embeff.com
std::map<Code,Performance> myMCU{?}
The mapping between Code & Performance
std::map<Code,Performance> myMCU{?} @DanielPenning The - - PowerPoint PPT Presentation
std::map<Code,Performance> myMCU{?} @DanielPenning The - - PowerPoint PPT Presentation
std::map<Code,Performance> myMCU{?} @DanielPenning The mapping between Code & Performance www.embeff.com World Map (1459) World Map (1525) People admitted they dont know. @DanielPenning The mapping between Code &
SLIDE 2
SLIDE 3
World Map (1525)
SLIDE 4
@DanielPenning www.embeff.com
People admitted they don’t know.
The mapping between Code & Performance
SLIDE 5
@DanielPenning www.embeff.com
The Beginning of Modern Science
- 1. Admit ignorance
- 2. Observations
§ Measure and gather data. § Connect data into comprehensive theories.
The mapping between Code & Performance
SLIDE 6
SLIDE 7
@DanielPenning www.embeff.com
Embedded & Ignorance
Code
Target Architecture Target Speed Compiler Compiler Settings Target Cache Possibly a highly complex and interdependent mapping! The mapping between Code & Performance
?
Performance
SLIDE 8
SLIDE 9
@DanielPenning www.embeff.com
Consequences
Prejudices prevail Mistrust against libraries Low code quality Performance suffers
The mapping between Code & Performance
SLIDE 10
@DanielPenning www.embeff.com
Let’s admit our ignorance.
The mapping between Code & Performance
SLIDE 11
@DanielPenning www.embeff.com
Observations in Embedded
Profiling
§ Top Down Process. § Great to identify bottlenecks. § Bad to create specific understanding.
Build knowledge bottom up
§ Start with small code blocks. § Observe performance. § Create heuristics.
The mapping between Code & Performance
SLIDE 12
@DanielPenning www.embeff.com
Code Performance for armv7m
Architecture widely used (Cortex-M3/M4) Provides Data Watchpoint and Trace Unit
CMSIS Register Description DWT_CYCCNT Cycle Count Register DWT_CPICNT CPI Count Register DWT_EXCCNT Exception Overhead Count Register DWT_SLEEPCNT Sleep Count Register DWT_LSUCNT LSU Count Register DWT_FOLDCNT Folded-instruction Count Register
The mapping between Code & Performance
SLIDE 13
@DanielPenning www.embeff.com
Measure Cycles
- penocd
(PC)
JTAG
The mapping between Code & Performance STM32F4
DWT
BKPT //< Read CYCCNT CodeUnderTest(<Parameter>) BKPT //< Read CYCCNT
SLIDE 14
@DanielPenning www.embeff.com
Let’s make observations.
The mapping between Code & Performance
SLIDE 15
@DanielPenning www.embeff.com
Example 1: Basic Optimization
The mapping between Code & Performance int square(int x) { return x*x; }
square(int): push {r7} sub sp, sp, #12 add r7, sp, #0 str r0, [r7, #4] ldr r3, [r7, #4] ldr r2, [r7, #4] mul r3, r2, r3 mov r0, r3 adds r7, r7, #12 mov sp, r7 ldr r7, [sp], #4 bx lr square(int): mul r0, r0, r0 bx lr 5 10 15 20 25 30
Minimal (-Og) No (-O0) Cycles
SLIDE 16
@DanielPenning www.embeff.com
Heuristic #1 The difference between minimal and no
- ptimization is huge.
The mapping between Code & Performance
SLIDE 17
@DanielPenning www.embeff.com
Example 2: Pipeline
The mapping between Code & Performance int DependentOps(int x) { int tmp = x/3; int tmp2 = x/7; return tmp+tmp2; }
DependentOps_O1(int): ldr r3, .L2 smull r2, r3, r3, r0 asrs r1, r0, #31 subs r3, r3, r1 ldr r2, .L2+4 smull ip, r2, r2, r0 add r0, r0, r2 rsb r0, r1, r0, asr #2 add r0, r0, r3 bx lr .L2: .word 1431655766 .word
- 1840700269
DependentOps_O2(int): ldr r3, .L3 ldr r1, .L3+4 smull r2, r3, r3, r0 add r3, r3, r0 asrs r2, r0, #31 smull r1, r0, r1, r0 rsb r3, r2, r3, asr #2 subs r0, r0, r2 add r0, r0, r3 bx lr .L3: .word -1840700269 .word 1431655766
10 11 12 13 14 15 16 17
- O1
- O2
Cycles
SLIDE 18
@DanielPenning www.embeff.com
Heuristic #2 In low-level assembly, the compiler is probably smarter than you.
The mapping between Code & Performance
SLIDE 19
@DanielPenning www.embeff.com
Example 3: FPU vs Soft-FPU
The mapping between Code & Performance int MultiplyWithPi(int input) { return input * 3.14159265359f; } MultiplyWithPi_FPU(int): vmov s15, r0 @ int vldr.32 s14, .L3 vcvt.f32.s32 s15, s15 vmul.f32 s15, s15, s14 vcvt.s32.f32 s15, s15 vmov r0, s15 @ int bx lr .L3: .word 1078530011 MultiplyWithPi_SoftFPU(int): push {r3, lr} bl __aeabi_i2f ldr r1, .L4 bl __aeabi_fmul bl __aeabi_f2iz pop {r3, pc} .L4: .word 1078530011
SLIDE 20
@DanielPenning www.embeff.com
Example 3: FPU vs Soft-FPU
The mapping between Code & Performance int MultiplyWithPi(int input) { return input * 3.14159265359f; }
10 30 50 70 90 110
- 9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9
Cycles Input Value FPU Soft-FPU
SLIDE 21
@DanielPenning www.embeff.com
Heuristic #3 Software-FPU ~ 6x slower and not deterministic.
The mapping between Code & Performance
SLIDE 22
@DanielPenning www.embeff.com
Example 4: CRC Computation
Cyclic Redundancy Check
§ Direct Computation § Lookup-Table § Hardware-Support
Online Benchmarking
§ Execute on real hardware. § Technical Preview Stage. § https://barebench.com
The mapping between Code & Performance
SLIDE 23
@DanielPenning www.embeff.com
barebench.com
- Demo -
The mapping between Code & Performance
SLIDE 24
@DanielPenning www.embeff.com
Heuristic #4 Performance may be dependent on clock speed.
The mapping between Code & Performance
SLIDE 25
@DanielPenning www.embeff.com
Heuristic #5 Caching is essential for high clock speeds.
The mapping between Code & Performance
SLIDE 26
@DanielPenning www.embeff.com
Conclusion
Admit lack of knowledge. Measure performance. Use measurements to form heuristics. Share heuristics. Use heuristics instead of prejudices. Let‘s make embedded systems better!
The mapping between Code & Performance
