SST Sensing Limited

DESIGN • MANUFACTURE • CUSTOMISE • CONFIGURE

Solid State Sensors For Liquids & Gases

SST Sensing Limited

• Established in 2002 and now with 73 employees.
• 22% of revenue reinvested into customer led Research & Development.
• 480,000 sensors manufactured in 2018 with 98.5% on time deliveries.
• 15,000 sq-ft UK factory with expansion plans.
• ISO9001 quality management system.
• In-house test and calibration facilities approved by aerospace customers and traceable to

national standards.

• Export to Europe, China, the Americas, Middle and Far East countries.
• Customer focussed prototyping and manufacturing.

Design • Manufacture • Customise • Configure

SST Sensing Limited, Coatbridge, ML5 4NS, Scotland

Technical Capabilities

• In-house manufacturing production lines per instrument and sensor
• Every sensor tested prior to shipment not a sample from a batch
• Best practise customer service with clear response times
• In-house support and knowledgebase on sensors’ use in multiple applications
• Cutting edge patented non-depleting technologies
• Market awareness to remain competitive and leading from the front
• Daily multiple courier shipments
• Rapid customisation of sensors to fit customers specification

Design • Manufacture • Customise • Configure

SST Sensing Limited, Coatbridge, ML5 4NS, Scotland

Optical Liquid Level Switches

• Detect almost any liquid: oil or water based
• Fast & reliable detection with a very small amount of liquid
• Intelligent switching behaviour to work in different environments
• Low cost optical technology
• Designed to replace competitor sockets
• Ability to rapid prototype with customisation for electronics, switching

behaviour, environmental sealing and terminating cables/connectors

• Wide variety of power-supply, mechanical format and output options

Detects the presence and absence of liquid by loss of infra red signal refracted into liquid

How do Liquid Level Switches Work?

Designed to fit into small spaces (only the tip has to be in contact) No moving parts to fail - solid state Electronics suited to directly drive and switch equipment

In Liquid: Infra-red light is refracted out of the cone leaving less energy to reach the detector In Air: Infra-red light is reflected back to the detector

The amount of received light is measured to determine if the sensor is in air or liquid

Optical Liquid Level Switches

Applications – Leak Detection & Level Detection

• Automated refilling and maintaining level
• Low/High liquid level control processes and alerts
• Run dry event prevention
• Leak detection where reliability and speed are critical
• Loss of valuable fluids
• Directly drive automated shutdown events
• Popular coolant/hydraulic oil applications
• Tank level monitoring
• Gear boxes and lubricant maintenance
• Medical, food & beverage and chemical handling
• Compressors and Pumps
• Bilges, sumps, catch pans and drip trays
• Medical, process control and domestic products
• Oil & coolant levels in off-road vehicles and static

equipment

• Automated batch control, filling/refilling machines
• Industrial Wash Machines
• 3D printers
• Hydroponic, water bath and aquarium applications

Measuring Task Measuring Point

• Protecting Global Telecommunications
• We detect water getting into communications cabinets before it

damages the high value equipment inside.

• Protection from system downtime
• Located in hard to reach places

Product confidence for user – Alert to issue at early stage

Optical Liquid Level Switches

Leak Detection

• Loss of valuable fluids
• Peristaltic Pumps
• prevent loss of valuable fluid
• medical, food, chemical handling
• Prevent run dry events
• Compressors, Pumps, etc.
• automatic shutdown before damage occurs
• low level indicator, sight-glass
• replacement for coolant/hydraulic fluid levels
• Other leak detection
• compact design; ideal for small spaces
• under flooring; bilges, sumps, catch pans and drip trays
• highly sensitive and reliable sensor

Product confidence for user – Alert to issue at early stage

Tubing failure in a Peristatic pump

Optical Liquid Level Switches

Leak Detection

• Automated refilling, low/high liquid level processes
• Medical, process control and domestic products
• Food & beverage applications
• Fluid levels in off-road vehicles, aircraft and static equipment
• Tank Level Monitoring
• Automated batch control, filling/refilling machines
• Industrial Wash Machines
• 3D printers: resin and metal types

Directly drive an output such as a relay – saving time and cost on design

Optical Liquid Level Switches

Level Indication

Gas monitoring and control systems ensure a clean, healthy environment; from domestic houses and apartments to factories and other industrial facilities

Zirconia O2 Sensors

• 0.1 – 100% range O2 sensors
• Wide range of application specific formats

with digital and analogue output options

• No reference gas required
• Proven, very stable technology
• Closed loop sensing principle allows a failsafe

‘heartbeat’ operation

• Suitable for aggressive, high temperature,

high pressure and high humidity environments

• Suited to aggressive, harsh environments and

gas streams

• Simple, single point calibration
• Long operating life due to non-depleting

sensor cell technology

We are different to other zirconia sensors on the market: The sensors operating principle uses two mechanisms of stabilised zirconia to measure the partial pressure of oxygen (ppO2) Their unique construction supply a time based output that allows for benefits over others Learn more on AN0043

Applications – Monitoring, Controlling and Prevention

Zirconia O2 Sensors

• Control O2 levels in an application
• Ensure O2 levels are low before starting processes
• Prevention of oxidisation
• Ensuring high O2 levels (up to 100%)
• Monitor ambient levels

Measuring Task Measuring Point

• Combustion process oxygen trim control for

boilers/furnaces

• CEMS and vehicle emissions testing equipment
• OBIGGS and OBOGS aerospace applications
• Oxygen analysers
• Controlled Atmosphere for storage of goods
• Oxygen generation equipment
• Composting and other agricultural anaerobic processes
• Incubators and chambers
• Steam ovens
• Heat Treatment, drying and nitriding processes
• Nitrogen streams and generators

• Civil aviation

Fuel tank inerting technology, dramatically reducing likelihood of fuel ignition; OBIGGS (On-Board Inert Gas Generating System)

• Military aviation

Life support system for military aircraft; OBOGS (On-Board Oxygen Generating System)

Zirconia O2 Sensors in Aerospace

Used to optimise efficiency and reduce emission of harmful gases. Designed in collaboration with Siemens to work with oil, gas, biogas, wood gasification and biomass boilers

Zirconia O2 Sensors in Combustion Control

GAP Gas Analysis Probe monitors excess air within flue stack gases up to 700degC. Relays, analog and Modbus outputs with pressure and temperature compensation make the GAP the perfect analyzer for combustion optimisation and burner/boiler trim applications.

• The GAP provides customers with industry standard analog and Modbus connectivity
• Barometric pressure and temperature sensor compensated readings from internal sensors
• Relay controls including a single alarm relay
• Easy to swap sensor module taking seconds to change with no special tools
• Calibrate in fresh air, or with calibration gas via an external calibration port
• Long life sensor
• Semi-extractive process with bright digital display.
• Ideal for combustion control of burners and boilers

Zirconia O2 Sensors – From Sensors to Systems

LuminOx O2 Sensors

Fluorescence based Optical Oxygen Sensor

• 0 – 25% range, low cost O2 sensor
• Diffusion and flow through housing formats
• Solid state sensor, NOT an electrochemical sensor –

Contains not liquid electrolytes

• Negligible cross sensitivity
• RoHS compliant - does not contain any hazardous

materials

• Longer operating life due to non-depleting principle
• Easy to interface to digital output, 3.3V USART output

No additional circuitry required

• Integrated pressure and temperature sensors
• Multiple output values: O2, ppO2, barometric pressure,

temperature and error status output

Coming soon: PPM range sensor and RS485 modbus / 4-20mA outputs

Applications – Monitoring, Controlling & Prevention

LuminOx O2 Sensors

• Control O2 levels in an application
• Ensure O2 levels are low
• Prevention of oxidisation
• Battery powered operation
• Secondary, redundancy sensor
• Rapid prototyping with popular development boards

(Raspberry Pi, Arduino, etc)

• Controlled atmosphere storage of goods
• Ambient air monitoring
• Portable/remote datalogging
• Incubators and chambers
• Laboratory & medical equipment
• Landfill gas
• 3D printers
• Beverage nitrogen generators
• Low level and air leak monitoring
• Monitoring for raised O2 levels in O2

generating equipment (XXXXXXXX)

Measuring Task Measuring Point

• This is just an overview of some of the products we design and manufacture.
• Our sensors are designed into medical, industrial, aerospace, automotive and consumer products.
• We design and manufacture to ISO9001 and EN standards with inhouse aerospace level testing.
• SST is an innovative design and production organisation with global reach.
• We want to partner with companies that have ethical values that match SST’s and quality standards of the highest calibre.
• SST is constantly developing new products in our roadmap to stay leading edge in the market.
• Solutions driven design with fast turnaround.
