SLIDE 1
SPRUCE GROVE COMMITTEE OF THE WHOLE February 20, 2018 ZERO LOT - - PowerPoint PPT Presentation
SPRUCE GROVE COMMITTEE OF THE WHOLE February 20, 2018 ZERO LOT - - PowerPoint PPT Presentation
SPRUCE GROVE COMMITTEE OF THE WHOLE February 20, 2018 ZERO LOT LINE DEVELOPMENT COMMITTEE OF THE WHOLE PRESENTATION February 20, 2018 Zero Lot Line Development in the Region Municipality ZLL Permitted Edmonton YES Strathcona County YES
SLIDE 2
SLIDE 3
Zero Lot Line Development in the Region
Municipality ZLL Permitted Edmonton
YES
Strathcona County (Sherwood Park)
YES
Leduc
YES
- Ft. Saskatchewan
IN PROGRESS
Beaumont
YES
Spruce Grove
No (Pilot Project Only)
- St. Albert
No
Stony Plain
No
SLIDE 4
GREENBURY GPL District vs. R1 District
GPL (ZLL) 7.6m (24.9ft)
6.1m (20.0ft) 1.5m (4.9ft) (x1)
$89,640 GPL (Standard) 8.5m (27.9ft)
6.1m (20.0ft) 1.2m (4.0ft) (x2)
$100,440 R1 (Standard) 9.0m (29.5ft)
6.1m (20.0ft) 1.2m (4.0ft) (x2)
$106,200 GPL (ZLL) vs R1 (Standard) 8.5m (27.9ft) vs 9.0m (29.5ft)
6.1m (20.0ft) 1.5m (4.9ft) (x1) vs 1.2m (4.0ft) (x2)
$16,560 difference in lot price
- based on 1.4m (4.6ft) difference in lot width
DISTRICT: LOT WIDTH:
HOUSE WIDTH: SIDE YARD:
LOT PRICE*:
*Lot Price based on avg. cost of $3,600/fft
GPL Lots R1 Lots
SLIDE 5
GREENBURY GPL District vs. R1 District
Lot Type House Width
- Min. Lot Width
Lot Cost* GPL – ‘ZLL’ Single Detached Lot
20’ (6.1m) 24.9’ (7.6m) $89,640
GPL – Standard Single Detached Lot
20’ (6.1m) 27.9’ (8.5m) $100,440
R1 – Standard Single Detached Lot
20’ (6.1m) 29.5’ (9.0m) 106,200
*Based on avg. cost of $3,600/fft
Difference in lot price in Greenbury vs all other developments = $16,560 (based on 1.4m (4.6ft) difference in lot width)
SLIDE 6
‘ZLL’ Lot Requirements
SLIDE 7
‘ZLL’ Housing Examples
SLIDE 8
‘ZLL’ Housing Examples
SLIDE 9
‘ZLL’ Housing Examples
SLIDE 10
‘ZLL’ Housing – Fire Safety Requirements Increased Fire Protection:
- Non-vented soffits
- Exterior gypsum board instead of
particle board
- Fire rated gypsum board on inside
- f exterior walls
- No unprotected openings
(windows or doors) along sidewalls
SLIDE 11
Developer Commitments
1. General Aesthetic: Commit to ensuring that housing will be developed with a high degree of architectural consideration. 2. Continuous Monitoring & Review: Commit to addressing design and building issues and concerns, if any arise. 3. Parking: Support the City’s desire to limit front attached zero lot line housing to one side of the street, along with the application of parking restrictions along that side. On-street parking will be permitted on blocks with lane access zero lot line product. 4. Encroachments: For single detached dwellings, ensure that utility meters are located on the same side of the houses, within their own property. For semi-detached units, cross lot easements will be utilized to locate the utility meters for both units in a banked location on one side of the pair of units. 5. Lot Depth: Increase the minimum lot depth from 30m to 33.5m to allow for more building and yard space in each lot. 6. Footing encroachment and foundation construction: Endeavor to sell groupings
- f
continuous lots to builders to incentivize builders to track build as much as possible. 7. Increased Education: Provide resources and educational material to prospective homeowners in an effort to reduce potential conflicts resulting from misunderstandings related to side yard easements and homeowner rights.
SLIDE 12
Summary
Zero Lot Line Housing is already being established as a more affordable single family housing option throughout the region and
- ffers several advantages, including:
- Achieving density targets set out by the EMRB Growth Plan by
establishing higher density single-family housing;
- More efficient use of developable land which, in turn, helps
reduce sprawl and increase affordability;
- More
efficient use
- f
infrastructure, reducing long term maintenance costs; and
- Allows a municipality to remain competitive for home builders in
the regional market.
SLIDE 13
