SPP HYDROTECH Industrial Service Soluons for the Power Industry We restore cooling tower fan blades and hubs. With a special ceramic coating which has a ceramic contend of more than 80% we
SLIDE 2
SLIDE 3
We Maintain Condenser and Heat Exchanger The anti vibration laths comes as as flat (approximately 2 – 4 mm thick) evacuated hose. Once the vacuum inside the hose is broken, the lath inflates automatically. The installation of the pre-fabricated lath is not a particular complicated
- peration and can be executed
during a short shut down. Condenser tube vibration, particular after re-tubing is not uncommon. We have the perfect solution: Anti vibration by installing laths. SPP HYDROTECH Co., Ltd.
SLIDE 4
We Maintain Condenser and Heat Exchanger
Water Air SPP HYDROTECH
For the removal of soft deposits in condenser tubes, cleaning projectiles are propelled by a mixture of air and water through the tubes. SPP HYDROTECH Co., Ltd.
SLIDE 5
We Maintain Condenser and Heat Exchanger
Condenser tube brush cleaning with air powered cleaning machines can removes a wide range of contamination – including scaling. SPP HYDROTECH Co., Ltd.
SLIDE 6
We Maintain Condenser and Heat Exchanger
As result we achieve perfectly clean tubes. SPP HYDROTECH Co., Ltd.
SLIDE 7
We Maintain Condenser and Heat Exchanger
With our technology we can even clean on-site sensitive equipment such as generator cooler. SPP HYDROTECH Co., Ltd. Our tube cleaning technology is fast, reliable and environmentally friendly. It can not damage tubes and has a proven track record.
SLIDE 8
We Maintain Condenser and Heat Exchanger
If tubes leakages are suspected, with our vacuum leak tester we can pinpoint the damaged tube within minutes. SPP HYDROTECH Co., Ltd.
SLIDE 9
We Maintain Condenser and Heat Exchanger
With our high resolution video scope we inspect tubes at a maximum length of 15 meter and minimum diameter of 14 mm. SPP HYDROTECH Co., Ltd.
SLIDE 10
We Maintain Condenser and Heat Exchanger
In order to determine possible tube wall losses, eddy current is the essential tool. With our technology we can perform eddy current testing on non magnetic and magnetic tubes – eliminating the need for IRIS. Probe for non magnetic tubes Probe for magnetic tubes SPP HYDROTECH Co., Ltd.
SLIDE 11
We Maintain Condenser and Heat Exchanger
As part of the eddy current documentation, tube sheet maps and plugging plans are provided. Important for the maintenance team: Not only the X and Y direction is shown, but also the Z direction. SPP HYDROTECH Co., Ltd.
SLIDE 12
We Clean Sensitive Equipment with CO2 Pellets
CO2 pellets blasting is a perfect solution for: ü Gas turbine blade cleaning ü Cleaning of gear boxes and motors ü Cleaning insulators ü Cleaning of bus bars ü General cleaning
0 ¡ 2 ¡ 4 ¡ 6 ¡ 8 ¡ 10 ¡ 12 ¡ 14 ¡ 16 ¡ 18 ¡ 20 ¡ dm3 ¡Sand ¡ dm3 ¡ Water ¡ dm3 ¡CO2 ¡ dm3
Necessary Deposit of Cleaning Material for the Cleaning of 1 m2 Area, Contaminated with Dirt
No secondary waste Blast equipment Pellets at -78.5°C SPP HYDROTECH Co., Ltd.
SLIDE 13
We Clean Sensitive Equipment with CO2 Pellets
SPP HYDROTECH Co., Ltd.
SLIDE 14
With our German Technology Partner we Deliver, Install and Maintain On-Load Condenser Tube Cleaning Systems
SPP HYDROTECH Co., Ltd.
SLIDE 15
We Deliver, Install and Maintain Automatic Debris Filter
Debris filter for condenser, tubular heat exchanger and plate heat exchanger with a minimum perforation of 300 µm SPP HYDROTECH Co., Ltd.
SLIDE 16
SPP HYDROTECH Co., Ltd. Particularly designed for small heat exchangers and plate heat exchangers, this fully automatic debris filter separates particles as small as 300 micron.
