BASIC ELECTRICITY PRESENTED BY: JOHN A NEMETH, PE, CFI PURPOSE Develop a working understanding of basic electric: Terms Concepts COMPARING ELECTRICTY TO HYDRAULICS VALVE PUMP TURBINE PUMP TANK WATER PRESSURE PRESSURE WATER FLOW

slide-1
SLIDE 1

BASIC ELECTRICITY

PRESENTED BY:

JOHN A NEMETH, PE, CFI

slide-2
SLIDE 2

PURPOSE

Develop a working understanding of basic electric:

  • Terms
  • Concepts
slide-3
SLIDE 3

COMPARING ELECTRICTY TO HYDRAULICS

slide-4
SLIDE 4

PUMP

TURBINE

VALVE

slide-5
SLIDE 5

PUMP TANK

slide-6
SLIDE 6

WATER PRESSURE PRESSURE

slide-7
SLIDE 7

WATER FLOW FLOW

slide-8
SLIDE 8

ELECTRICAL PRESSURE

PRESSURE

slide-9
SLIDE 9

ELECTRON FLOW FLOW

6.242 X 10

18

ELECTRONS / SECOND

slide-10
SLIDE 10

ELEMENTS OF HYDRAULIC & ELECTRICAL SYSTEMS

HYDRAULIC ELECTRICAL

CONSTANT-PRESSURE PUMP

BATTERY

slide-11
SLIDE 11

ELEMENTS OF HYDRAULIC & ELECTRICAL SYSTEMS

HYDRAULIC ELECTRICAL

WIRE / CONDUCTOR PIPE

slide-12
SLIDE 12

ELEMENTS OF HYDRAULIC & ELECTRICAL SYSTEMS

HYDRAULIC ELECTRICAL

DC MOTOR WATER TURBINE

slide-13
SLIDE 13

ELEMENTS OF HYDRAULIC & ELECTRICAL SYSTEMS

HYDRAULIC ELECTRICAL

DC VOLT METER

DIFFERENTIAL PRESSURE METER

slide-14
SLIDE 14

ELEMENTS OF HYDRAULIC & ELECTRICAL SYSTEMS

HYDRAULIC ELECTRICAL

DC AMMETER FLOW METER

slide-15
SLIDE 15

ELEMENTS OF HYDRAULIC & ELECTRICAL SYSTEMS

HYDRAULIC ELECTRICAL

SWITCH SHUTOFF VALVE

slide-16
SLIDE 16

COMPARING HYDRAULIC PRESSURE TO VOLTAGE

PUMP

PRESSURE GAUGES

slide-17
SLIDE 17

COMPARING HYDRAULIC PRESSURE TO VOLTAGE

BATTERY

VOLT METER

slide-18
SLIDE 18

COMPARING WATER FLOW TO CURRENT

FLOW METER

slide-19
SLIDE 19

DC AMMETER

COMPARING WATER FLOW TO CURRENT

slide-20
SLIDE 20

COMPARING WATER PIPES TO CONDUCTORS

WATER PIPE ELECTRICAL CONDUCTOR

slide-21
SLIDE 21

COMPARING CLOSED HYDRAULIC SYSTEMS TO ELECTRICAL CIRCUITS

slide-22
SLIDE 22

COMPARING CLOSED HYDRAULIC SYSTEMS TO ELECTRICAL CIRCUITS

slide-23
SLIDE 23

COMPARING CLOSED HYDRAULIC SYSTEMS TO ELECTRICAL CIRCUITS

ELECTRICAL SCHEMATIC

slide-24
SLIDE 24

COMPARING HYDRAULIC FRICTION TO ELECTRICAL RESISTANCE

WATER PIPE ELECTRICAL CONDUCTOR

slide-25
SLIDE 25

COMPARING HYDRAULIC FRICTION TO ELECTRICAL RESISTANCE

HEAT HEAT HEAT HEAT

Electrical resistance results in voltage drops but also generates heat

slide-26
SLIDE 26

COMPARING PIPE SIZE TO WIRE GAUGE

SMALL PIPE LARGE PIPE

slide-27
SLIDE 27

COMPARING PIPE SIZE TO WIRE GAUGE

SMALL GAUGE LARGE GAUGE

slide-28
SLIDE 28

COMPARING PIPE SIZE TO WIRE GAUGE

slide-29
SLIDE 29

AMPACITY OF CONDUCTORS

The ampacity of a conductor is: the amount of current a conductor can carry continuously without exceeding its temperature rating

slide-30
SLIDE 30

The ampacity values of a conductor depend on:

  • heating of the conductor by the current
  • ambient temperature
  • temperature rating of its insulation
  • the amount of heat dissipated

AMPACITY OF CONDUCTORS

slide-31
SLIDE 31
  • Aluminum conductors generate more heat that

copper conductors

  • Ampacity of aluminum conductor is less than a

copper conductor

AMPACITY OF CONDUCTORS

slide-32
SLIDE 32

CONDUCTIVITY OF CONDUCTORS

Some conductor materials conduct current with less resistance than do other materials

  • Copper conducts better than aluminum
  • Aluminum conducts better than steel
slide-33
SLIDE 33

CONDUCTIVITY OF CONDUCTORS

slide-34
SLIDE 34

OHM’S LAW

slide-35
SLIDE 35

OHM’S LAW

Ohm’s Law states: the voltage in a circuit is equal to the current multiplied by the resistance, or E = I x R

slide-36
SLIDE 36

OHM’S LAW IN A SIMPLE CIRCUIT

E = I x R Voltage (E) is measured in volts Current (I) is measure in amperes Resistance (R) is measured in ohms

slide-37
SLIDE 37

OHM’S LAW IN A SIMPLE CIRCUIT

Rearranging the terms, we can solve for current if voltage and resistance are known: current = voltage/resistance resistance = voltage/current

slide-38
SLIDE 38

ELECTRICAL POWER

  • The rate at which energy is used is call power
  • The amount of power is expressed in watts (W)

A 100 watt lightbulb produces more light and heat than a 60 watt lightbulb

slide-39
SLIDE 39

OHM’S LAW WHEEL

slide-40
SLIDE 40

OHM’S LAW WHEEL

slide-41
SLIDE 41

APPLYING OHM’S LAW

slide-42
SLIDE 42

APPLYING OHM’S LAW

TOTAL CURRENT CALCULATION

slide-43
SLIDE 43

BASIC ELECTRICITY: SUMMARY

  • Pressure in a water pipe is analogous to

voltage in an energized electrical conductor

  • Flow in a water pipe is analogous to

current in an energized electrical conductor

  • A restriction of flow in a water pipe is

analogous to resistance in an energized electrical conductor
