Spectrum/FCC Update 01/20/2016 Criss Niemann 470 MHz More Changes Coming 470-476 14 476-482 15 482-488 16 488-494 Must be completed by 2022 Middle Class Tax Relief and Job Creation Act of 2012 TV stations that
SLIDE 2
SLIDE 3
More Changes Coming
Radio Astronomy
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69
470-476 476-482 482-488 488-494 494-500 500-506 506-512 512-518 518-524 524-530 530-536 536-542 542-548 548-554 554-560 560-566 566-572 572-578 578-584 584-590 590-596 596-602 602-608 608-614 614-620 620-626 626-632 632-638 638-644 644-650 650-656 656-662 662-668 668-674 674-680 680-686 686-692 692-698 698-704 704-710 710-716 716-722 722-728 728-734 734-740 740-746 746-752 752-758 758-764 764-770 770-776 776-782 782-788 788-794 794-800 800-806
Analog TV Analog TV
New Services
DTV DTV
S A F E T Y S A F E T Y
698 MHz 806 MHz 470 MHz
???
- FCC plans to auction more TV band to carriers
- TV stations that participate share auction $
- Middle Class Tax Relief and Job Creation Act of 2012
- Must be completed by 2022
SLIDE 4
Incentive Auction Process
Reverse Auction TV stations entertain bids to change/share channel OR go dark for $ Forward Auction Carriers bid $ on vacated spectrum Repacking Stations are moved to new channels
How much spectrum? Which spectrum? When?
SLIDE 5
Auction Timeline
May 15, 2014 – R&O Approved March 29, 2016 – Auction Begins Q3(ish), 2016 – Channel Reassignment Notice Issued 2019(ish) – End of 39 Month Transition for “Repacking”
SLIDE 6
Possible Auction Outcomes
600 MHz Band
MHz
SLIDE 7
White Space Devices
- Broadband “Wi-Fi”
– Rural internet access
- 2 Types
– Fixed & Portable
- WSD can operate in current open UFH
spectrum
- WSD are unlicensed devices
SLIDE 8
Review - Wireless Mic License Eligibility
- Broadcasters
- Educational TV
- Cable networks
- TV & Film Production
Any number of wireless mics
- Theaters
- Houses of Worship
- Convention Centers NEW RULES AS OF 2014
- Theme parks
- Educational Centers
- Government Locations
Venues and Sound Companies (50+ channels)
SLIDE 9
Part-74 Licensee advantages
- Ability to register against WSD interference
- Ability to transmit up to 250mW
- Co-channel operation allowed, if indoor
received signal strength is < -85 dBm
- Opportunity to operate in newly available
spectrum
SLIDE 10
WM Operation in Post-Auction 600 MHz Band ”Duplex Gap” and “Guard Bands”
Duplex Gap Duplex Gap Guard Band Guard Bands Guard Band 6 MHz Unlicensed + Licensed WM (Shared with WSDs) 4 MHz Licensed WM (no WSDs)
Unlicensed and Licensed WM (shared with WSDs) (WSDs Must Leave a 3 MHz gap on either side of TV 37 – see next slide)
SLIDE 11
TV37 Guard Bands (if needed)
- - a potential exclusive WM spectrum opportunity
Duplex Gap Guard Band Guard Bands
Lower 3 MHz Guard Band Channel 37 Upper 3 MHz Guard Band Bottom 1 MHz Segment Lower 2 MHz Segment WSD, Medical Telemetry and Radio Astronomy only - no microphones Upper 2 MHz Segment Top 1 MHz Segment No WSD No WSD No WSD No WSD No Microphones Microphones Microphones No Microphones
SLIDE 12
New Homes for Licensed Wireless Microphones
– 941–960 MHz – Coordinated with SBE
- Expands eligibility to all part 74 users licensees
- Expands former Shure X band (944-952 MHz)
– 1.4 GHz (1435-1525 MHz)
- Managed by AFTRCC aviation testing authority
- Special permission required
– 3.5 GHz – Coordinated with SBE – 7 GHz – Coordinated with SBE
- Two 25MHz bands
SLIDE 13
Additional News
- Petitions filed in December regarding the new rules
– See comments in Active Dockets on FCC website (Search
- n ECFS) 14-165 and 14-166
– Commission expected to make final determination on petitions prior to Auction
- Wireless Microphone Industry aligned in comments
SLIDE 14
Additional Info
- Deadline for broadcasters to indicate
participation was January 12
– Info not public
- Opening bid prices are public
– Example - WCBS (NY) $900M
SLIDE 15
Milestones
- March 29 Auction Begins
- Q3(ish) FCC issues Channel Reassignment
- Immediately following Channel Reassignment,
39 month Repack/Transition
– Wireless mics legal to operate, but – If new spectrum owner “commences operations” (begins testing), wireless mics must stop operating – Users should check databases weekly to see if/where new services are operating
- Wireless mics must stop operating in all of
the auctioned spectrum after 39 mo. repack
SLIDE 16
Spectrum Database
- https://keybridgeglobal.com
- www.spectrumbridge.com
- www.telcordia.com
SLIDE 17
Moving forward
- Investigate license eligibility
- Choose wireless mics with:
– Widest tuning range – Best spectral efficiency
- Consider other frequency bands
- No need to discard 600 MHz equipment
SLIDE 18
Moving forward
- Shure has been proactive in discontinuing
affected product bands
- Shure remains committed to providing
accurate and timely information in support of
- ur customers and our products and is actively
